Title: Module 1: WANs and Routers


1
Module 1WANs and Routers
  • CCNA 2 - Version 3.0

2
Introduction to WANs
  • Major Characteristics of WANs
  • WANs connect devices that are separated by wide
    geographical areas
  • WANs use the services of carriers such as the
    Regional Bell Operating Companies (RBOCs), Sprint
    MCI
  • WANs use serial connections of various types to
    access bandwidth over large geographic areas
  • WANs operate at the Physical and Data-Link Layer
    of the OSI Model

3
Functions of an Internetwork
  • Consistent end-to-end addressing
  • Best path selection (thanks to routing tables)
  • Dynamic or static routing
  • Switching

4
WAN Devices
  • Need (some of) the following to construct a WAN
  • Routers - offer many services, including
    internetworking and WAN interface ports.
  • Switches - provide connectivity for voice, data,
    and video communication.
  • Modems - include channel service units/digital
    service units (CSU/DSUs) that interface T1/E1
    services, and Terminal Adapters/Network
    Termination 1 (TA/NT1s) that interface Integrated
    Services Digital Network (ISDN) services.
  • Communication servers - concentrate dial-in and
    dial-out user communication.

5
WAN Symbols
6
The WAN Physical Layer
  • WAN physical layer - describes the interface
    between the data terminal equipment (DTE) and the
    data circuit-terminating equipment (DCE)
  • Usually
  • DCE the service provider
  • DTE the attached device (customer side)

7
WAN Physical LayerStandards and Protocols
  • EIA/TIA-232
  • EIA/TIA-449
  • V.24
  • V.35
  • X.21
  • G.703
  • EIA-530
  • ISDN
  • T1, T3, E1, and E3
  • xDSL
  • SONET (OC-3, OC-12, OC-48, OC-192)

8
WAN Data Link LayerStandards and Protocols
  • High-level data link control (HDLC)
  • Frame Relay
  • Point-to-Point Protocol (PPP)
  • Synchronous Data Link Control (SDLC)
  • Serial Line Internet Protocol (SLIP)
  • X.25
  • ATM
  • LAPB
  • LAPD
  • LAPF

9
What is a Router?
  • Routers
  • are a special type of computer
  • have some of the same basic components as a
    standard desktop PC
  • CPU, input/output interfaces, system bus
  • connect and allow communication between two
    networks
  • determine the best path for data to travel
    through the connected networks
  • Uses routing tables to best path selection

10
The Role of a Router in LANs and WANs
  • Routers have both LAN and WAN interfaces
  • WAN technologies are frequently used to connect
    routers
  • Routers are the backbone devices of large
    intranets and of the Internet
  • Routers operate at Layer 3 of the OSI model,
    making decisions based on network addresses.
  • The two main functions of a router are
  • best path selection
  • switching frames to the proper interface

11
Main Internal Router Components
  • random access memory (RAM)
  • nonvolatile random-access memory (NVRAM)
  • flash memory
  • read-only memory (ROM)
  • interfaces

12
Main Internal Router Components
13
RAM(also called Dynamic RAM or DRAM)
  • Stores routing tables
  • Holds fast-switching cache
  • Stores running configuration (active
    configuration) files
  • Holds ARP cache
  • Performs packet buffering (shared RAM)
  • Maintains packet-hold queues
  • Provides temporary memory for the configuration
    file of the router while the router is powered on
  • Loses content when router is powered down or
    restarted

14
NVRAM (Non-volatile RAM)
  • Stores startup configuration file (also called
    backup configuration file)
  • Retains contents when router is powered down or
    restarted
  • Stores a copy of routers config file

15
FLASH MEMORY
  • Stores Cisco image (IOS) software images
  • Allows software to be updated without removing
    and replacing chips on the processor
  • Retains content when router is powered down or
    restarted
  • Can store multiple versions of IOS software (in a
    2600 series router, it can be upgraded with
    single in-line memory modules)
  • Is a type of electronically erasable,
    programmable ROM (EEPROM)

16
ROM (Read-Only Memory)
  • Maintains instructions for power-on self test
    (POST) diagnostics
  • Stores bootstrap program and basic operating
    system software
  • Requires replacing pluggable chips on the
    motherboard for software upgrades

17
Router Interfaces
  • Interfaces have the following characteristics and
    functions
  • Connect the router to the network for frame entry
    and exit
  • Can be on the motherboard or on a separate module
  • Connects the router to LANs and WANs
  • 3 types of router interfaces
  • LAN interfaces (usually connect to an Ethernet
    LAN)
  • WAN interfaces (provide connections through a
    service provider to a distant site or to the
    Internet)
  • Console/AUX ports (asynchronous ports that
    provide for router management NOT network
    connections)

18
External Router Components
19
Router internal components
  • CPU The Central Processing Unit (CPU) executes
    instructions in the operating system.
  • RAM Random-access memory (RAM) is used for
    routing table information, fast switching cache,
    running configuration, and packet queues.
  • Flash Flash memory is used for storage of a
    full Cisco IOS software image.
  • NVRAM Nonvolatile random-access memory (NVRAM)
    is used to store the startup configuration.
  • Buses Most routers contain a system bus and a
    CPU bus.
  • ROM Read-only memory (ROM) is used for
    permanently storing startup diagnostic code (ROM
    Monitor).
  • Interfaces The interfaces are the router
    connections to the outside. The three types of
    interfaces are local-area network (LANs),
    wide-area network (WANs), and Console/AUX.
  • Power Supply The power supply provides the
    necessary power to operate the internal
    components.
  • Configuration files contain instructions that a
    router uses to control the flow of traffic
    through its interfaces

20
Management port connections
  • The console port and the auxiliary (AUX) port are
    management ports used for troubleshooting,
    monitoring and initial configuring.
  • Mgmt ports do NO routing
  • Console port connection PC to router
  • asynchronous serial ports
  • non network connections

21
The Console Port
  • Used for
  • initial configuration of the router
  • monitoring
  • disaster and password recovery procedures
  • The console port displays router startup,
    debugging, and error messages by default
  • A rollover cable, terminal emulation software and
    a RJ-45 to DB-9 adapter are needed to establish a
    terminal session between PC and router

22
  • The console port is also preferred over the
    auxiliary port for troubleshooting.
  • Because
  • displays router startup, debugging, and error
    messages by default
  • No networking services to be started
  • can be used for disaster and password recovery
    procedures

23
Connecting a PC to a Router
  • Configure terminal emulation software on the PC
    for
  • The appropriate COM port
  • 9600 baud
  • 8 data bits
  • No parity
  • 1 stop bit
  • No flow control

24
Connecting LAN Interfaces
  • In most LAN environments, the router is connected
    to the LAN using an Ethernet or Fast Ethernet
    interface
  • A straight-through cable is used to make this
    connection
  • A 10/100BaseTX router interface requires Category
    5 or better, unshielded twisted-pair (UTP)
    regardless of the router type
  • The correct interface must be used
  • If the wrong interface is connected, damage can
    result to the router or other networking devices
  • Many different types of connections use the same
    style of connector
  • Ethernet, ISDN BRI, Console, AUX, integrated
    CSU/DSU, and Token Ring interfaces use the same
    eight-pin connector, RJ-45, RJ-48, or RJ-49.

25
Connecting WAN Interfaces
  • WAN services are usually leased from service
    providers
  • WAN connections may take any number of
    formsAmong these WAN connection types are
  • leased line
  • circuit-switched
  • packet-switched

26
  • If you wanted to physically connect a router to
    all hosts on a LAN what is needed?

27
Module 1WANs and Routers
THE END
  • CCNA 2 - Version 3.0
