Java Advanced Imaging II

1
Lecture11

• Java Advanced Imaging II

2
JAI Applications

• We will look at how JAI is used for the following
  application areas.
• Network Imaging
• Dealing with large images - Tiling

3
Java security

• The policy files define security policies. There
  is by default a single system-wide policy file,
  and a single user policy file.
• The system policy file is by default located at
• java.home/lib/security/java.policy (Linux)
• java.home\lib\security\java.policy (Windows)
• Here, java.home is a system property specifying
  the directory into which the Java 2 SDK was
  installed.
• The user policy file is by default located at
• user.home/.java.policy (Linux)
• user.home\.java.policy (Windows)
• Here, user.home is a system property specifying
  the users home directory.

4
Policy Files

• When the Policy is initialized, the system policy
  is loaded in first, and then the user policy is
  added to it. If neither policy is present, a
  built-in policy is used.
• The policy file locations are specified as the
  values of properties whose names are of the form
• policy.url.n
• Here, n is a number. You specify each such
  property value in a line of the following form
• policy.url.nURL
• Here, URL is a URL specification. For example,
  the default system and user policy files are
  defined in the security properties file as
• policy.url.1filejava.home/lib/security/java.p
  olicy
• policy.url.2fileuser.home/.java.policy

5
Additional Policy files

• java -Djava.security.manager
• -Djava.security.policypURL SomeApp
• Here, pURL is a URL specifying the location of a
  policy file, then the specified policy file will
  be loaded in addition to all the policy files
  that are specified in the security properties
  file.
• (The -Djava.security.manager argument ensures
  that the default security manager is installed,
  and thus the application is subject to policy
  checks.
• If you want to pass a policy file to the
  appletviewer, again use a -Djava.security.policy
  argument as follows
• appletviewer -J-Djava.security.policypURL
  myApplet
• Please note The -Djava.security.policy policy
  file value will be ignored (for both java and
  appletviewer commands) if the policy.allowSystemP
  roperty property in the security properties file
  is set to false. The default is true.

6
Remote Method Invocation

• Remote Method Invocation allows programming at a
  higher level abstraction in the client-server
  paradigm.
• RMI architecture consists of clients and servers
  linked through a registry, called the RMI
  registry. RMI registry maintains active
  references to remote objects.
• With RMI, methods in remote objects are invoked
  as if they were in a local object. Such a method
  has two parts to it
• one on the client side (local side) and
• the other on the server side (remote side).
• The client side methods are called stubs and the
  server side methods are called skeletons
  (skeletons are only required for Java1.1).
• A stub acts as a proxy to the remote method and
  has no application logic in it.
• The skeleton is the stubs counterpart on the
  server side. To invoke a method a client calls
  the stub, which passes the request to the
  skeleton over the network.
• The methods may require parameter objects which
  must be serializable in order for them to be
  passed on to the remote side.

7
Steps for building and Running an RMI
Client/Server application

• Enter and compile the source (both client side
  and server side and interfaces). E.g.
• AshokaImageClient.java It simply loads an
  display an image from the server.
• AshokaImageLoader.java An interface which
  defines all the interface methods between client
  and the server.
• AshokaImageServer.java The server source
  program which implement the AshokaImageLoader
  interface.
• Generate Stubs and Skeletons.
• Run RMI compiler
• rmic AshokaImageServer
• Install Files on the Client and Server machines.
• AshokaImageClient.class, AshokaImageServer_Stub.cl
  ass, and AshokaImageLoader.class must be on the
  client machine.
• AshokaImageServer.class, AshokaImageServer_Stub.cl
  ass, AshokaImageServer_Skeleton.class, and
  AshokaImageLoader.class must be on the server.
• Start the RMI Registry on the server machine.
• start rmiregistry
• Start the server.
• java AshokaImageServer
• Start the client.
• java AshokaImageClient

8
Client-Server Example

• Let write a simple application which loads an
  image from the server. We first need an interface
  file, say AshokaImageLoader.java, which contain
  the following
• import javax.media.jai.RenderedOp
• public interface AshokaImageLoader extends
  java.rmi.Remote
• public RenderedOp loadImage(String filename)
• throws java.rmi.RemoteException
• The client talk to the server through the above
  interface.
• We are using JAI for the server program since JAI
  RenderedOp class is serializable
• Object communication require such objects to be
  serializable
• Note that Core Java BufferedImage is not
  serializable!
• But client program do not need to use JAI since
  RenderedOp can be casted to RenderedImage which
  is defined in Core Java.

9
Server Code

• import java.rmi. import java.rmi.server.
• import javax.media.jai.
• public class AshokaImageServer extends
  UnicastRemoteObject
• implements AshokaImageLoader
• public AshokaImageServer() throws
  java.rmi.RemoteException
• public synchronized RenderedOp loadImage(String
  filename)
• throws java.rmi.RemoteException
• try
• return JAI.create("fileload",filename)
• catch (Exception e) return null
• public static void main(String args)
• try
• AshokaImageServer jserver new
  AshokaImageServer()
• Naming.rebind(AshokaImageServer",jserver)
• catch (Exception e) System.out.println("SRun
  "e)

10
Creating Stubs and Skeletons

• After compiling the above server program you can
  run rmic (The RMI compiler) to create stubs and
  skeletons as follows
• rmic AshokaImageServer

11
Client Program

• // import core java packages only!
• public class AshokaImageClient extends JFrame
• protected AshokaImageLoader loader null
• private RenderedImage rimage
• public AshokaImageClient()
• setTitle("Remote Image Viewer")
• activate()
• try
• rimage (RenderedImage) loader.loadIm
  age("lena_256.jpg")
• catch (Exception e) System.out.println(e)

• // Work with the rimage
• // Continued Next Slide

12
Client Program

• public void activate()
• System.setSecurityManager(new RMISecurityMa
  nager())
• try
• loader (AshokaImageLoader)
• Naming.lookup("AshokaImageServer")
• catch (Exception e)
• System.out.println(e)

13
Network Imaging

• Any of Java extensions can be used with RMI.
• But JAI provides direct facilities for remote
  imaging.
• E.g. A rendered chain can be done in a remote JAI
  image server.

14
Remote JAI Image Server

• First we need the remote JAI image server
  running. For that we run the following shell
  script in Linux platform
• !/bin/sh
• CLASSPATH
• rmiregistry
• JAI/usr/java/java/jre/lib/ext
• CLASSPATHJAI/jai_core.jarJAI/jai_codec.jarJA
  I/mlibwrapper_jai.jar
• java -Djava.rmi.server.codebase"fileJAI/jai_cor
  e.jar\
• fileJAI/jai_codec.jar fileJAI/mlibwrapper_jai
  .jar"\
• -Djava.rmi.server.useCodebaseOnlyfalse\
• -Djava.security.policyfilePWD/policy\
• com.sun.media.jai.rmi.JAIRMIImageServer

15
Load the image in the Remote Server

• RemoteJAI rc new RemoteJAI("jairmi",
  "JAIRMIRemoteServer1.1")
• ParameterBlock pb1 new ParameterBlock()
• pb1.add(fileName)
• pb1.add(null)
• pb1.add(Boolean.FALSE)
• RemoteRenderedOp remoteImage rc.create("fil
  eload",pb1,null)

16
Convolution in the remote server

• ParameterBlock pb2 new ParameterBlock()
• pb2.addSource(remoteImage)
• float oneBys2 1/2.0f
• float kernelData oneBys2, -oneBys2,
  - oneBys2, oneBys2
• KernelJAI haarKernel new KernelJAI(2,2,0,0
  ,kernelData)
• pb2.add(haarKernel)
• RemoteRenderedOp convolvedImage
  rc.create("Convolve",pb2,null)
• Note that RemoteRenderedOp is a subclass of
  RenderedOp

17
Tiled Imaging

• Note that RenderedOp, OpImage, RemoteImage,
  TiledImage classes are all subclasses of
  PlanarImage which implements the RenderedImage
  interface.
• We have seen that the RenderedImage works in
  terms of tiles.
• Converting Image class object to a PlanarImage
  object
• Image img
• // Read and load img
• PlanarImage pimg JAI.create(awtimage,img)
• Tiling is useful to optimize speed and memory.
• If the tiles are too small, say compared to
  viewport, there will be too many tile
  computations, possibly degrading the performance.
• Too large a tile requires a large amount of
  memory.

18
Reformatting PlanarImage

• public static RenderedOp reformatImage(PlanarImage
  img, Dimension tileDim)
• ImageLayout tileLayout new ImageLayout(img)
• tileLayout.setTileWidth(tileDim.width)
• tileLayout.setTileHeight(tileDim.height)
• HashMap map new HashMap()
• map.put(JAI.KEY_IMAGE_LAYOUT, tileLayout)
• map.put(JAI.KEY_INTERPOLATION,
• Interpolation.getInstance(Interpolation.INTERP_B
  ICUBIC))
• RenderingHints tileHints new
  RenderingHints(map)
• ParameterBlock pb new ParameterBlock()
• pb.addSource(img)
• return JAI.create("format", pb, tileHints)

19
Rendering Hints in JAI

• The rendering-hints concept was introduced in
  Java2D.
• The java.awt.RenderingHints class represents
  rendering hints.
• In the representation each rendering hint is a
  key-value pair.
• When a particular method, say a rendering related
  method of Graphics2D, require multiple rendering
  hints they are passed to these methods as the Map
  object of a key-value pair.
• The rendering hints key is of type
  RenderingHints.Key, and the value is an object.
• JAI doesnt use the Java2D rendering hints for
  rendering a node. Instead it uses its own
  rendering hints, the keys for which are defined
  in the JAI class. A JAI rendering hint key is of
  type JAI.RenderingKey, which is a inner class of
  JAI.
• E.g. Check the previous slide about reformatting
  a planarImage

20
Viewing a tile of a large image

• PlanarImage img
• // Load the img
• // Say we want to display a tile indexed by
  (ti,tj)
• Raster tile img.getTile(ti,tj)
• DataBuffer databuf tile.getDataBuffer()
• SampleModel sm img.getSampleModel()
• WritableRaster wr tile.createWritableRaster(sm,
  databuf, new Point(0,0))
• ColorModel cm img.getColorModel()
• BufferedImage bi (cm,wr, cm.isAlphaPremul
  tiplied(),null)
• // Display bi at the right location of the
  viewport

21
Writing to pixels

• The PlanarImage is read-only.
• To write to pixels you need to use TiledImage
  class which extends and implements
  WritableRenderedImage interface which handles
  writing of pixel data to tiles.
• To write pixels, you need to obtain a
  WritableRaster object for the desired rectangular
  region.
• You cannot write to this instance of
  WritableRaster immediately because unlike
  BufferedImage, TiledImage does not have all its
  data resident in the memory. You need to get all
  the tiles that cover the rectangular region.

22
Writing to a pixel (x,y)

• TiledImage image
• // Work with image
• Int xIndex image.XtoTileX(x)
• Int yIndex image.YtoTileY(y)
• WritableRaster tr image.getWritableTile(xInd
  ex,yIndex)
• if (tr ! null) tr.setPixel(x,y,pixelValue)
• image.releaseWritableTile(xIndex,yIndex)
• //

23
TiledImage from a PlanarImage

• public static TiledImage createTiledImage(PlanarIm
  age img)
• SampleModel sm img.getSampleModel()
• ColorModel cm img.getColorModel()
• TiledImage ti new TiledImage(
• img.getMinX(), img.getMinY(),
• img.getWidth(),img.getheight(),
• img.getTileGridXOffset(),
• img.getTileGridYOffset(),
• sm, cm)
• ti.setData(img.copyData())
• return ti
• Check the JAI specification for other TiledImage
  constructors.

24
TileCache interface

• TileCache provides a mechanism by which an
  OpImage may cache its computed tiles.
• There may be multiple TileCaches used in an
  application up to the point of having a different
  TileCache for each OpImage.
• The default tile cache
• TileCache tilecache JAI.getDefaultInstance().get
  TileCache()
• The default cache size is 64MB. You can change
  this
• Tilecache.setMemoryCapacity(20482048L)
• A new tile cache objects can be obtained
• TileCache newtilecache JAI.getTileCache()
• The TileCache used for a particular OpImage is
  derived from the RenderingHints assigned to the
  associated imaging chain node.
• The rendering hints key associated with tile
  cache is JAI.KEY_TILE_CACHE
• Please read the TileCache interface specification
  given in JAI specification.
