Radionuclide synovectomy

1
Radionuclide Synovectomy (RS)
Herbert Marder
Jacqueline Hochman PGY4 Feb 22, 2005
2
Outline

• History
• Indications for use
• Alternative procedures
• Principles of the procedure
• Complications
• Special considerations in the hemophilic patient
• Evidence based application

3
Images of Radiation
4
Radionuclide Synovectomy (RS)

• Radioactive
• Radioisotope
• Radiocolloid

• Synovectomy
• Synoviorthesis

Local form of radiotherapy to control resistant
synovitis recurrent hemarthrosis
5
A brief history on radionuclide synovectomy

6
RS

• First used by Fellinger et al. in 1952
• Die lokale Behandlung der rheumatischen
  Erkrankungen. (Wien Z Inn Med. 1952)
• Translation
• The local treatment of rheumatic illnesses

7
History of radionuclide synovectomy

• 1971 Ahlberg et al. Radioactive Gold
  inhaemophilia
• Hypothesis radiation causes fibrosis of the
  synovium with diminuation of the extensive
  vasculature and might prevent the progression to
  arthropathy.
• 1991 Yttrium-90
• 1984, 1996 198Au, Rhenium-186, 90Y
• 1994 32P chromic phosphate
• 1997 RS is invaluable in hemophilic patients
  with inhibitors

8
. 2005

• RS is the procedure of choice for haemophilic
  patients requiring synovectomy
• Role in refractory synovitis 2nd to other
  inflammatory conditions
• Particularly medical condition makes surgery
  dangerous or impossible

9
Reflecting Radiation by Ellen Jantzen
10
Indications for RS

• Rheumatoid Arthritis
• Seronegative spondyloarthropathy
• Chronic pyrophosphate arthropathy
• Pigmented villonodular synovitis
• Hemarthrosis or synovitis in the hemophiliac

11
Contraindications

• pregnancy
• breastfeeding
• ruptured bakers cyst
• local skin infection
• massive hemarthrosis

12
What are the alternatives?
13
Radionuclide vs Surgical Synovectomy

• Surgical
• Surgical anaesthetic complications
• Incomplete removal of synovium
• Prolonged joint immobilization
• Loss ROM, fibrosis, scarring

• Radionuclide
• Less costly
• No general anaesthesia
• Day-procedure
• Minimally invasive
• Less risk of bleeding
• No age restriction (absolute)
• Can use in poor surgical candidates

14
Chemical synovectomy

• Agents thiotepa, osmic acid
• Limited success in controlling synovitis
• May cause massive hemorrhaging in hemophiliacs

15
Principles of the Procedure
16
RS Goals of the procedure

• Deliver targeted radiation to synovium
• Homogenous distribution of radioisotope
• Phagocytosis by synovial cells leuks
• Minimize radiation to surrounding tissue
• Minimize leakage

17
Mechanism of Action of RS

• Radioactive particles phagocytosed by superficial
  synovial cells
• Radiation causes
• coagulation necrosis
• sloughing of cells
• regression of synovium
• ? inflammatory infiltrate
• sclerosis

18
Mechanism of Action of RS
(A) ß-Emitting colloidal particles (yellow stars)
phagocytized by inflamed hypertrophic synovial
lining with proliferating synoviocytes (pink).
Top cartilage layer remains unaffected. (B)
Subsequent cell damage and sclerosis of synovial
membrane.
19
Clinical Outcome of RS

• Reduction in
• pain
• swelling
• stiffness
• Improvement in
• ROM
• QUALITY OF LIFE

20
Theoretical Complications of RS

• Leakage
• Chromosomal defects
• Malignancy
• Bleeding
• Inflammatory reaction

21
Minimize complications by

• Using larger particle, stable radiocolloid
• Prior to procedure, reduce inflammation
• Joint lavage or steroid injection days earlier
• Prophylactic factor infusion
• NSAIDS, PT, limited splinting
• Fluoroscopic guidance
• Flush the needle track with saline or steroids on
  withdrawal
• Joint immobilization post Rx

22
SELF-PORTRAIT When I look in the mirror I can
foresee my own radiation death. ARTIST NATASHA
From the Chernobyl childrens project.
23
Radioisotope Selection Factors

• Half-life
• Beta-emitting preferable
• Mean tissue penetrance
• Particle size
• Irreversible binding between particle
  radionuclide
• Particle biodegradability

24
Radionuclide Options

• Gold (Au-198)
• Yttrium (Y-90)
• Chromic phosphate (P-32)
• Rhenium (Re-186)
• Erbium (Er-169)

Only P-32 has FDA approval for intra-cavitary
use in US
25
Comparison of isotope properties
26
Why use P32 for RS?

• Pure ?-emitter
• Large particle size gt500m?
• Long t1/2 ? no local inflammatory reaction
• Travels short distance, penetrance 3mm
• Predominately absorbed by synovium
• Moderately high energy -gt rapid uptake

27
Other variables affectingradiation delivery

• Joint size
• Amount of synovial fluid
• Synovial thickness

28
Radioactive Art by Lulu radiation can be your
friend
29
How is it done?
30
Technique

• Aseptic technique, fluoro for elbows ankles
• 21 guage needle/3-way stopcock
• Infiltrate site of injection with 1 lidocaine
• Confirm position of needle fluoro/contrast,
  aspirate jt
• Inject small amount depo-medrol to confirm free
  flow
• Inject 0.5-1ml 32P, flush w/ depo-medrol
• 37mBq for large joints, 18.5 for small, 50 less
  in kids
• Slowly withdraw while injecting steroid
• Local pressure, 2-3 passive ROM

31
Management Post-procedure

• for bilateral procedures - admit
• 1hr post injection imaging for loculation
• OT splint x 48-72hrs, crutches for unilateral
• Crutches x 2weeks
• Special considerations in the hemophiliac patient
• Prophylaxis
• factor VIII
• FEIBA - factor eight inhibitor bypass
• factor VII

32
Leakage Detection

• Immobilize x 1hr
• Scan local joint, adjacent l.node w/
  scintillation camera using bremsstrahlung energy
  window or
• Geiger Muller Counter sequential point counting
  over treated jts, LN, RE system
• ? radiation difficult to detect

33
Chernobyl baby
34
Who will benefit?What is the evidence?
35
3 dancers by Picasso
36
Meta-analysis of 2190 Treated Joints

• Literature search 1971-1999
• Break down of 1º disease in 2190 joints
• 1880 rheumatoid arthritis (RA)
• 121 osteoarthritis (OA)
• 37 seronegative arthritis (SA)
• 15 vonWillebrands disease (VWD)
• 116 haemophilia
• ? Pigmented villonodular synovitis (PVS)

Kresnik et al. Nuc med comm 2002.
37
Steinbrocker Classification
38
Results mean improvement rate

• RA 66.7 15.4
• OA 56 11
• Steinbrocker I 72.8 12.3
• Steinbrocker II 64 17.3
• Steinbrocker III IV 52.4 23.6
• Haemophilia, VWD 914.3
• PVS 77.325.3

Overall response rate in 1 year 72.517
Kresnik et al. Nuc med comm 2002.
39
Imaging Before After RS
Kresnik et al. Nuc med comm 2002.
40
Groups for RS
Kresnik et al. Nuc med comm 2002.
41
Conclusions from Meta-Analysis

• Better results in
• RA gt OA
• In those with milder radiological changes
• Steibrocker I II vs III IV
• Reasonable to repeat in initial responders
• Consider surgery for deformed/unstable jts

Kresnik et al. Nuc med comm 2002.
42
Anonymous Artist
43
Multicenter study in inflammatory conditions
(2004)

• To evaluate the effectiveness of RS in RA (group
  A) vs other disorders (group B) using a
  questionnaire
• N691 pts, 803 procedures
• Ameliorations in joint pain, swelling/effusion,
  or ROM
• 80 of group A, effect lasted longer in this
  group
• 56 of group B, larger joints responded better in
  this grp only
• Quality of life improvement
• 78 group A
• 59 group B

Although slightly more efficient in RA, RS is an
effective treatment option in OA other
disorders with concomitant synovitis.
44
The hemophiliac patient

• Recurrent joint
• bleeding synovitis

45
Background

• Mod-severe hemophiliacs develop 1st bleed as
  young as 2-5 years old
• Followed by hemarthrosis-synovitis-hemarthrosis
  cycle
• Fe deposition ? synovitis? hypertrophy
• Rich vascularization ? rebleed ? Target joint
• Target joint
• Reduced range of motion
• Muscle atrophy
• Cumulative joint deformity

46
Hemarthrosis-synovitis-hemarthrosis Cycle
47
Special considerations in hemophilia

• Advantages of radionuclide synovectomy vs surgery
• Minimal factor requirement
• Several joints at once
• Factor replacement concurrent with or prior to
  procedure to 50 N level
• Tx 8-12hrs later to reduce chance of bleed
• Admit/immobilize LE injections, all inhibitor pts
• 80 success rate

48
Treatment Algorithm for Hemophiliac
49
Radiation anonymous artist
50
Radionuclide Synovectomy for Hemophilic
Arthropathy A Comprehensive Review of Safety
Efficacy.

• Dunn et al. Comprehensive review of safety
  efficacy.
• Thrombosis and Haemostasis 2002.

51
Comprehensive Review

• Study group hematologists, nuclear medicine
  specialists, orthopedic surgeons with expertise
  in RS
• Aim
• Develop standardized protocol
• Define research questions
• Literature review

52
Experience with 32P Synovectomy
Outcome Joint bleeding Pain
ROM Radiographic AE Miscellaneous
Ref Dose No. Joint Age f/u pts
No. Yrs
Dunn et al. Thrombosis Haemostasis 2002
53
Impact on Bleeding Rates

• Rivard and colleagues (1985) studied 14 pts, 22
  joints
• mean pre-RS bleeding rate 12.9 bleeds / yr
• Mean 1yr after RS 4.8/y
• Mean last f/u 2.5 bleeds / yr.
• 8 joints required repeat P-32 injections
• excluding these joints pre-RS rate 9.9 bleeds/yr
  2.2 bleeds/yr in f/u
• Rivard (1994) studied 29 pts, 38 joints, f/u up
  to 15yrs
• similar trends in ? bleeding rates,
• Pre - 12.1/y ?1yr post - 5.1/yr-gt last f/u -
  6.1/y
• Siegel and Luck (1999) studied 125 procedures
• 50 decline in rate of joint bleeding, 2-10yrs
  after procedure in 81
• No bleeding in 54 of joints
• Younger pts lt 18y had a greater reduction in
  bleeding than gt 40y pts
• Studies w/ P32 were similarly positve to gold

Dunn et al. Thrombosis Haemostasis 2002
54
Impact on Pain

• 4 groups provided specific data on pain
• Rivard et al. (1994) on P32 RS
• Surveyed 40pts, from 1-15yrs post-P32 RS
• 73 reported less pain
• 27 reported no change in pain
• Overall, studies post-gold, yttrium, P32
• Showed majority had marked reduction in pain

Dunn et al. Thrombosis Haemostasis 2002
55
Influence of P32 RS on ROM
Rivard GE. Recent advances in hemophilia care
1990.
56
Impact of 32P RS on radiographs

• 6 groups reported on x-ray data
• Rivard et al.1994,(Pettersson scores)
• N23 jts, f/u 1-14yrs (mean 8.7)
• 2 joints improved by 1 point
• 3 joints unchanged
• 19 joints deteriorated by 1-7 points
• All jts scored ?2, worsened by 1-7 points

Dunn et al. Thrombosis Haemostasis 2002
57
Potential Complications of P32 RS

• Small amount of leakage
• Chromosomal defects are rare
• Appear to resolve over time
• No published reports of malignancy
• Post-injection bleeds (Rivard et al. 1994)
• in 11/31 joints, all had high-titer inhibitors
• 20/31 were not pre-treated with factor
• Inflammatory reactions ameliorated by steroid
  injections
• Local skin soft-tissue radiation damage is rare

Dunn et al. Thrombosis Haemostasis 2002
58
What does the future have in store?

• New radionuclides
• 188Re-microspheres,
• 153Sm-particulate hydroxyapatite
• Complex computer models w/ MRI to determine
  dosimetry more precisely

59
Summary (I)

• RS is effective in reducing recurrent
  hemarthrosis
• In most reports, 80 of treated joints
• had gt 50 reduction in bleeding rate
• effect often sustained, may improve over time
• Many pts experience less pain
• Most (at least initially) maintain or improve ROM
• May slow radiographic progression in mild disease
• Most joints have radiographic progression

Dunn et al. Thrombosis Haemostasis 2002
60
Summary(II)

• Effective and safe alternative to surgical
  synovectomy
• In inflammatory arthropathies causing resistant
  synovitis despite standard Rx
• In hemophiliacs for haemostasis and prevention of
  target joints

61
(No Transcript)
62
References

• Dunn AL et al. Radionuclide synovectomy for
  hemophilic arthropathy A comprehensive review of
  safety and efficacy and recommendation for a
  standardized treatment protocal. Thromb Haemost
  200287383-93.
• Fischer M Modder D. Radionuclide therapy of
  inflammatory joint diseases. Nuclear Medicine
  Communications. 200223829-831.
• Kresnik et al. Clinical outcome of
  radiosynoviorthesis a meta-analysis including
  2190 treated joints. Nuclear Medicine
  Communications 200223683-688.
• Prahalad S Passo M. Long-term outcome among
  patients with Juvenile Rheumatoid Arthritis.
  Frontiers in Bioscience 1998313-22.
• Rau H et al. Nuklearmedizin-nuclear medicine
  200443 (2)57-62.
• Schneider et al. Radiosynovectomy in
  rheumatologu, orthopedics, and hemophilia. The J
  of Nuc Med 200546(N1suppl)48S-54S.

63
Radionuclide Synovectomy
Jacqueline Hochman PGY4 Feb 22, 2005
