Mechanical Properties of Dental Materials

1
Mechanical Properties of Dental Materials
2
Occlusal forces

• Average occlusal forces for fully dentate
  patients
• 150 Newton in the anterior region to 500N in
  posterior region
• Maximum occlusal forces different reports in the
  literature up to 3500N.
• The occlusal forces for edentulous patients 15
  of dentate patients.

3

• Bulk Properties

4
Stress

• Force per unit area a force exerted on one
  body
• that presses on, pulls on, pushes against,
  or tends to invest,
• compress another body the deformation
  caused in a body by such a force
• an internal force that resists an
  externally applied load or
• force. It is normally defined in terms of
  mechanical stress, which
• is the force divided by the perpendicular
  cross sectional area over
• which the force is applied.
•
  GPT
  2005, J Prosthetic Dentistry
• Stress Internal resistance to applied external
  force.
• Stress Force/Area

5
Types of stresses

• Axial
• Compressive
• Tensile

6
Types of stresses

• Non Axial
• Shear
• Torsion
• Bending

7
Strain

• Strain change in length per unit length when
  stress is applied the change in length/original
  length
• GPT 2005, J Prosthetic Dentistry
• Strain(e) Deformation/Original length

8
Stress-Strain curve
9
Resilience the resistance of a material to
permanent deformation A Proportional limit
Elastic limit
10
A Proportional limit

• The greatest stress that a material will sustain
  without a deviation from the proportionality of
  stress to strain, below which no permanent
  deformation happens.

11
Elastic limit

• The maximum stress that a material will withstand
  without permanent deformation.

12
(No Transcript)
13
BYield strength(YS)

• The stress at which a material exhibits a
  specified limiting deviation from proportionality
  of stress to strain
• YS indicates a degree of permanent
  deformation (usually 0.2)
• YS indicates a functional failure!!!

14
Elastic modulus

• Is a measure of elasticity of the material how
  stiff the material is in the elastic range
• Elastic modulus Stress/Strain
• The slope of the curve

15
Poissons ratio

• Ratio of lateral to axial strain within the
  elastic range

16
Ductility and malleability

• Ductility The ability of a material to be
  plastically deformed.
• Malleability The ability of a material to be
  hammered or rolled into thin sheets without
  fractureing.

17
Plastic deformation
18
C Ultimate strength

• Tensile or Compressive.
• The Ultimate strength The maximum that a
  material can withstand before failure (tension or
  compressive).
• it does give an indication of the needed
  thickness (cross section) of the restorations
  before failure.

19
D fracture strength

• The stress at which the material fractures.

20
Toughness

• The resistance of a material to fracture
• So what does yellow area under curve represent?

21
Fracture toughness

• The amount of energy required for fracture.

22

• Bond strength
• the bond strength between two dental
  materials.
• Either tensile or shear
• Fatigue bond strength?

23
Bending and torsion

• Endodontic files and reamers

24
Transverse strength

• Modulus of rupture or flexural strength
• 3- point bending test

25
Fatigue strength

• Fatigue Progressive fracture under repeated
  loading
• The importance of endurance limit?

26
Fluid behaviour and Viscosity

• Viscosity the resistance of a fluid to flow
• Viscosity Shear stress/shear strain rate.

27
Viscous fluids
The importance of thixotropic impression materials
28
Creep and stress relaxation

• Creep is the increase in strain in a material
  under constant pressure.
• Creep test is used for study of new amalgam
  materials

29
Surface mechanical properties
30
Indentation hardness

• Brinell hardness test. Ball,(steel or T carbide),
• Knoop hardness Microindentation, pyramid shape.
• Vickers 136 degrees diamond pyramid.
• Rockwellmetal cone.
• Shore A hardness for rubber

31
Stress analysis

• Lab based studies.
• Photoelasticity
• Finite Element Analysis.

32
Wear

• Loss of material due to contact between two
  surfaces

33
Surface phenomena

• Atoms or molecules at surface different to bulk
• Stainless steel Vs steel

34
Colloidal systems

• Two or more phases with one highly dispersed on
  the other.
• Types
• Sols and Gels
• Emulsions

35
Gels

• Entangled framework of solid colloidal praticles
  in which liquid is tapped in the intestices in
  which liquid is trapped

36
Emulsions

• A uniform dispersion of minute droplets of one
  liquid into another with the aid of emulsifier.

37
(No Transcript)
38
Surface tension and wetting
High contact angle less wetting
Low contact angle better wetting
39
Adhesion

• The bonding of dissimilar materials by either
• Chemical bonding (True) OR
• Mechanical bonding (retention).

40
Optical properties

• Basic coloursRed, Green and Blue.
• Why only three??

Munsell colour system
Hue Chroma Value
41
(No Transcript)
42
Hue

• Basic colour

43
Chroma

• Colourfulness OR saturation

44
Value

• lightness

45
Metamerism

• When two colour samples match when viewed under
  one light source but not another.
• Any significance in dentistry?

46
Flouresence

• The emission of luminous energy by a material
  when a beam of light is shown on it.
• What impact does this have in anterior
  restorations.

47
Thermal properties

• Heat of fusion melting or freezing heat.
• Coefficient of thermal expansion of paramount
  importance in clinical dentistry, why???
• Glass transition temperature??? For non metallic
  structures glasses and polymers
