Title: Developing an AVR Microcontroller System


1
Developing an AVR Microcontroller System
2
Table of Content
  • Introducing Microcontrollers
  • About AVR
  • AVR Mega8 Architecture
  • AVR Programming Interface
  • Demo Hello World AVR Design.
  • Demo Hardware Design
  • Demo Programming

3
1. Introducing Microcontrollers
4
Introducing Microcontrollers
  • A microprocessor is a central processing unit
    (CPU) on a single chip.
  • When a microprocessor and associated support
    circuitry, peripheral I/O components and memory
    (program as well as data) were put together to
    form a small computer specifically for data
    acquisition and control applications, it was
    called a microcomputer.

5
Introducing Microcontrollers
  • When the components that make a microcomputer
    were put together on a single chip of silicon, it
    was called the microcontroller.

6
Microcontrollers
A microcontroller interfaces to external devices
with a minimum of external components
7
Relevance of Microcontrollers
  • A recent white paper by Sun Microsystems claims
    that by the end of the decade, an average home
    will contain between 50 to 100 microcontrollers
    controlling digital phones, microwave ovens,
    VCRs, televisions sets and television remotes,
    dishwashers, home security systems, PDAs etc.
  • An average car has about 15 processors the 1999
    Mercedes S-class car has 63 microprocessors,
    while the 1999 BMW has 65 processors!
  • Except perhaps the human body, microprocessors
    and microcontrollers have gotten into everything
    around us.

8
2. About AVR
9
AVR General Features
  • Enhanced RISC architecture with mostly
    fixed-length instruction, load-store memory
    access and 32 general-purpose registers.
  • A two-stage instruction pipeline that speeds up
    execution
  • Majority of instructions take one clock cycle
  • Up to 10-MHz clock operation

10
AVR General Features
  • Wide variety of on-chip peripherals, including
    digital I/O, ADC, EEPROM, Timer, UART, RTC timer,
    PWM etc
  • Internal program and data memory.
  • In-System programmable (ISP)
  • Available in 8-pin to 64-pin size to suit wide
    variety of applications

11
AVR General Features
  • Up to 12 times performance speedup over
    conventional CISC controllers.
  • Wide operating voltage from 2.7V to 6.0V
  • Simple architecture offers a small learning curve
    to the uninitiated.

12
AVR Growing Family
13
3. AVR Mega8 Architecture
14
AVR Mega8 Features
  • 8-Kbyte self-programming Flash Program Memory
  • 1-Kbyte SRAM
  • 512 Byte EEPROM
  • 6 or 8 Channel 10-bit A/D-converter.
  • Up to 16 MIPS throughput at 16 Mhz.
  • 2.7 - 5.5 Volt operation.

15
AVR Architecture
16
AVR A single chip solution
17
AVR A single chip solution
18
High-Level Integration
19
AVR Influenced by IAR Systems
20
Code Size and Execution Time
21
Real life Applications
22
Comparison of Code Size
23
4. AVR Programming Interface
24
Parallel Port in-System-Programmer
25
(No Transcript)
26
5. Demo Hello World AVR Design
27
Hello World AVR Design
  • The purpose of this demo is
  • to design a simple AVR system
  • Interface it to and LCD display
  • Program it to display Hello World

28
6. Demo Hardware Design
29
AT Mega 8 Pinout
30
LCD Interface
31
Interfacing LCD to AVR
LCD Interface AVR Port
RS PORTC.2
RW PORTC.3
E PORTC.4
DATA PORTD
32
7. DEMO Programming
33
Software Tools needed
  • AVR Studio
  • GCC
  • AVRLibs
  • PonyProg

34
From AVR Lib...
  • Include the following files in your project
  • lcd.c
  • global.h
  • timer.h
  • lcd.h

35
Main.c
  • Add a new c source file to your AVR Studio
    project.
  • Type in the main function as shown below

36
  • Main()
  • lcdInitHW()
  • lcdInit()
  • lcdGotoXY(0,4)
  • lcdPrintData(Hello Word!, 11)

37
Thanks
