Title: CIS 1140 Network Fundamentals


1
CIS 1140 Network Fundamentals
  • Chapter 5 Topologies and Ethernet Standards

Collected and Compiled By JD Willard MCSE, MCSA,
Network, Microsoft IT Academy
Administrator Computer Information Systems
Instructor Albany Technical College
2
Attention Accessing Demos
  • This course presents many demos.
  • The Demos require that you be logged in to the
    Virtual Technical College web site when you click
    on them to run.
  • To access and log in to the Virtual Technical
    College web site
  • To access the site type www.vtc.com in the url
    window
  • Log in using the username CIS 1140 or
    ATCStudent1
  • Enter the password student
  • If you should click on the demo link and you get
    an Access Denied it is because you have not
    logged in to vtc.com or you need to log out and
    log back in.
  • Remember that passwords are case sensitive so
    enter it in all lower case letters.

3
Objectives
  • Describe the basic and hybrid LAN physical
    topologies, and their uses, advantages, and
    disadvantages
  • Describe the backbone structures that form the
    foundation for most LANs
  • Understand the transmission methods underlying
    Ethernet networks
  • Compare the different types of switching used in
    data transmission

4
Network Topologies
  • There are two types of network topologies
  • Physical topology is the physical layout of the
    network, including cable and device configuration
  • Logical topology refers to the method used to
    communicate between the devices
  • It is important to understand the physical
    topology before designing networks, because they
    can affect the logical topology chosen, how the
    building is cabled, and what kind of media is
    used
  • Physical topologies are classified according to
    three geometric shapes bus, ring and star

Types of Topologies Demo
5
Simple Physical Topologies
  • Physical topology physical layout of nodes on a
    network
  • May create hybrid topologies
  • Does not specify
  • Device types
  • Connectivity methods
  • Addressing schemes
  • Topology integral to type of network, cabling
    infrastructure, and transmission media used
  • Three fundamental shapes
  • Bus
  • Ring
  • Star

Physical Topologies Demo
6
Topologies pt. 1 Demo
Topologies pt. 2 Demo
7
Bus
  • Bus consists of a single cable that connects all
    the nodes of a network without intervening
    connectivity devices, and requires a terminator
    at each end
  • The single cable is called the bus and supports
    one channel, where each node shares total
    capacity
  • Bus advantages easy to install and add devices
    requires less cable less expensive
  • Bus disadvantages requires 50 ohm terminators at
    each end of the cable entire network shuts down
    if the cable breaks difficult to troubleshoot
    requires grounding loop
  • Terminators stop signals after reaching end of
    wire
  • Prevent signal bounce
  • Inexpensive, not very scalable
  • Difficult to troubleshoot, not fault-tolerant

The Bus Topology Demo
8
Basic Ethernet Bus
  • An Ethernet network where all machines are daisy
    chained using coaxial cable (Thin
    Ethernet/Thin-net or Thick Ethernet/Thick-net).
  • Machine 2 wants to send a message to machine 4.
  • First it 'listens' to make sure no one else is
    using the network.
  • If it is all clear it starts to transmit its data
    on to the network (represented by the yellow
    flashing screens).
  • Each packet of data contains the destination
    address, the senders address, and of course the
    data to be transmitted.
  • The signal moves down the cable and is received
    by every machine on the network but because it is
    only addressed to number 4, the other machines
    ignore it.
  • Machine 4 then sends a message back to number 2
    acknowledging receipt of the data (represented by
    the purple flashing screens).

9
Bus (continued)
A terminated bus topology network
10
Ring
  • Ring is where each node is connected to the two
    nearest nodes, effectively forming a circle
  • Data is transmitted in one direction around the
    ring, and is typically done so using token
    passing
  • The ring is used by Token Ring and FDDI networks
  • Ring advantages no network collisions each node
    functions as a repeater less cable required
  • Ring disadvantages Single malfunctioning node
    can disable entire network not flexible or
    scalable modifications requires network shutdown

The Ring Topology Demo
11
Ring
12
Star
  • Star is where each node is connected through a
    central device, such as a hub
  • All nodes transmit data to the hub, which then
    retransmits the data to the destination node
  • Easily moved, isolated, or interconnected with
    other networks
  • Scalable - Supports max of 1024 addressable nodes
    on logical network

A typical star topology network
13
Star
  • Any single cable connects only two devices
    Cabling problems affect two nodes at most
  • More fault-tolerant
  • Star advantages a break in the cable does not
    shut down the network higher reliability easier
    troubleshooting no terminators required
  • Star disadvantages uses more cable than ring or
    bus networks hubs are more expensive than
    terminators hub failures take down entire LAN
    segments

The Star Topology Demo
14
Hybrid Physical Topologies
  • Pure bus, ring, star topologies
  • Rarely exist
  • Too restrictive
  • Hybrid topology
  • More likely
  • Complex combination of pure topologies
  • Several options

Hybrid Topologies Demo
15
Star-Wired Ring
  • The star-wired ring topology uses the physical
    layout of a star in conjunction with the
    tokenpassing data transmission method. Data are
    sent around the star in a circular pattern. This
    hybrid topology benefits from the fault tolerance
    of the star topology (data transmission does not
    depend on each workstation to act as a repeater)
    and the reliability of token passing. Modern
    Token Ring networks, as specified in IEEE 802.5,
    use this hybrid topology.

16
Star-Wired Ring
Token Ring MAUs can be connected together using
straight-through patch cables to connect the Ring
Out port of one MAU and the Ring In port of the
next MAU until the network of MAUs forms a
circle. Up to 255 stations can be connected to
the network when using Shielded Twisted Pair
cable and 72 when using Unshielded Twisted Pair
cable.
17
MAU Showing Internal Ring
A Token Ring hub (MAU) simply changes the
topology from a physical ring to a star wired
ring. The Token still circulates around the
network and is still controlled in the same
manner, however, using a hub or a switch greatly
improves reliability because the hub can
automatically bypass any ports that are
disconnected or have a cabling fault.
31
18
Star-Wired Bus
A star-wired bus topology network
19
Star-wired Bus
  • In a star-wired bus topology, groups of
    workstations are star-connected to hubs and then
    networked via a single bus. With this design, you
    can cover longer distances and easily
    interconnect or isolate different network
    segments. One drawback is that this option is
    more expensive than using either the star or,
    especially, the bus topology alone because it
    requires more cabling and potentially more
    connectivity devices. The star-wired bus topology
    commonly forms the basis for modern Ethernet and
    Fast Ethernet networks.

20
Advantages and Disadvantages of the different
network topologies
21
Backbone Networks
  • A network backbone is the cabling that connects
    the hubs, switches, and routers on a network.
    Backbones usually are capable of more throughput
    than the cabling that connects workstations to
    hubs. This added capacity is necessary because
    backbones carry more traffic than any other
    cabling in the network. For example, an
    increasing number of businesses are implementing
    fiber-optic backbone but continue to use CAT5
    wiring for the cabling from hubs to workstations.
  • Although even the simplest LAN (including a star
    or bus topology LAN) technically has a backbone,
    enterprise-wide back-bones are more complex and
    more difficult to plan.
  • The backbone is the most significant building
    block of these networks.

22
Serial Backbone
  • A serial backbone is the simplest kind of
    backbone network. It consists of two or more hubs
    connected to each other by a single cable. They
    are not suitable for large networks or long
    distances. Although the serial backbone topology
    could be used for enterprise-wide networks, it is
    rarely implemented for that purpose.
  • Daisy chain linked series of devices
  • Hubs and switches often connected in daisy chain
    to extend a network
  • Hubs, gateways, routers, switches, and bridges
    can form part of backbone
  • Benefit
  • Logical growth solution
  • Modular additions
  • Low-cost LAN infrastructure
  • expansion
  • Easily attach hubs
  • Serial connection of repeating devices
  • Essential for distance communication
  • Standards
  • Define number of hubs allowed
  • Exceed standards
  • Intermittent, unpredictable data transmission
    errors

23
Distributed Backbone
  • Consists of a number of hubs connected to a
    series of central hubs or routers in a hierarchy
  • Allows for simple expansion and limited capital
    outlay for growth
  • Layers of hubs can be added to existing layers
  • A more complicated distributed backbone connects
    multiple LANs or LAN segments using routers
  • Provides network administrators with the ability
    to segregate workgroups and therefore manage them
    more easily
  • Adapts well to an enterprise-wide network
    confined to a single building, where layers of
    hubs can be assigned according to the floor or
    department
  • You must consider the maximum allowable distance
    between nodes and the server dictated by the
    network media
  • Central point of failure is the hub at the
    uppermost layer
  • Implementing can be relatively simple, quick, and
    inexpensive

A distributed backbone connecting multiple LANs
24
Collapsed Backbone
  • Uses a router or switch as the single central
    connection point for multiple sub-networks
  • A single router or switch is the highest layer of
    the backbone.
  • The dangers of using this arrangement relate to
    the fact that a failure in the central router or
    switch can bring down the entire network
  • In addition, because routers cannot move traffic
    as quickly as hubs, using a router may slow data
    transmission.
  • A substantial advantages is that this arrangement
    allows you to interconnect different types of
    sub-networks.
  • You can also centrally manage maintenance and
    troubleshooting chores.

25
Parallel Backbone
  • The most robust enterprise-wide topology.
  • This variation of the collapsed backbone
    arrangement consists of more than one connection
    from the central router or switch to each network
    segment.
  • Each hub is connected to the router or switch by
    more than one cable.
  • The advantage of using a parallel backbone is
    that its redundant (duplicate) links ensure
    network connectivity to any area of the
    enterprise.
  • Parallel backbones are more expensive than other
    enterprise-wide topologies because they require
    much more cabling than the others. However, they
    make up for the additional cost by offering
    increased performance.
  • As a network administrator, you might choose to
    implement parallel links to only some of the most
    critical devices on your network. By selectively
    implementing the parallel structure, you can
    lower connectivity costs and leave available
    additional ports on the connectivity devices.

Most Reliable and Most Expensive to Set UP
26
Logical Topologies
  • Logical topology how data is transmitted between
    nodes
  • May not match physical topology
  • Bus logical topology signals travel from one
    network device to all other devices on network
  • Required by bus, star, star-wired physical
    topologies
  • Ring logical topology signals follow circular
    path between sender and receiver
  • Required by ring, star-wired ring topologies

Logical Topologies Demo
27
Switching Circuit Switching
  • Switching component of networks logical
    topology that determines how connections are
    created between nodes
  • Circuit switching connection established between
    two network nodes before transmission
  • Bandwidth dedicated to connection
  • Remains available until communication terminated
  • While connected, all data follows same path
    initially selected by switch
  • Monopolizes bandwidth while connected
  • Resource wasted
  • Uses
  • Live audio, videoconferencing
  • Home modem connecting to ISP

28
Message Switching
  • Establishes connection between two devices,
    transfers information, then breaks connection
  • Information then stored and forwarded from second
    device to third device on path
  • Store and forward routine continues until
    message reaches destination
  • All information follows same physical path
  • Requires that each device in datas path have
    sufficient memory and processing power to accept
    and store information

29
Packet Switching
  • Breaks data into packets before transmission
  • Packets can travel any network path
  • Contain destination address and sequencing
    information
  • Can attempt to find fastest circuit available
  • When packets reach destination node, they are
    reassembled
  • Based on control information
  • Not optimal for live audio or video transmission
  • Advantages
  • No wasted bandwidth
  • Devices do not process information
  • Examples
  • Ethernet networks
  • Internet

30
MPLS (Multiprotocol Label Switching)
  • IETF
  • Introduced in 1999
  • Multiple layer 3 protocols
  • Travel over any one of several connection-oriented
    layer 2 protocols
  • Supports IP
  • Common use
  • Layer 2 WAN protocols
  • Advantages
  • Use packet-switched technologies over
    traditionally circuit switched networks
  • Create end-to-end paths
  • Act like circuit-switched connections
  • Addresses traditional packet switching
    limitations
  • Better QoS (quality of service)

31
802.3 Ethernet
Ethernet Demo
  • Ethernet is a LAN standard that specifies an
    implementation of the physical layer and the MAC
    sub-layer of the data link layer.
  • An Ethernet network is a broadcast system this
    means that when a station transmits data, every
    other station receives the data. The frames
    contain a destination address in the frame header
    and only the station with that address will pick
    up the frame and pass it on to upper-layer
    protocols to be processed.
  • The access method Carrier Sense Multiple
    Access/Collision Detection (CSMA/CD).

Ethernet/Fast Ethernet/Gigabit Ethernet Demo
32
CSMA/CD (Carrier Sense Multiple Access with
Collision Detection)
  • Network access method
  • Controls how nodes access communications channel
  • Necessary to share finite bandwidth
  • Carrier sense
  • Ethernet NICs listen, wait until free channel
    detected
  • Multiple access
  • Ethernet nodes simultaneously monitor traffic,
    access media

CSMA/CD Access Method demo
33
CSMA/CD (contd.)
  • Collision
  • Two nodes simultaneously
  • Check channel, determine it is free, begin
    transmission
  • Collision detection
  • Manner nodes respond to collision
  • Requires collision detection routine
  • Enacted if node detects collision
  • Jamming
  • NIC issues
  • 32-bit sequence
  • Indicates
  • previous
  • message faulty

34
CSMA/CD (contd.)
  • Heavily trafficked network segments
  • Collisions common
  • Segment growth
  • Performance suffers
  • Critical mass number dependencies
  • Data type and volume regularly transmitted
  • Collisions corrupt data, truncate data frames
  • Network must compensate for them
  • Collision domain
  • Portion of network where collisions occur
  • Ethernet network design
  • Repeaters repeat collisions
  • Result in larger collision domain
  • Switches and routers
  • Separate collision domains

35
CSMA/CD (contd.)
  • Collision domains differ from broadcast domains
  • Ethernet cabling distance limitations
  • Effected by collision domains
  • Data propagation delay
  • Time for data to travel
  • From one segment point to another point
  • Too long
  • Cannot identify collisions accurately
  • 100 Mbps networks
  • Three segment maximum connected with two hubs
  • 10 Mbps buses
  • Five segment maximum connected with four hubs

36
Collision Domain
  • On an Ethernet network, an individual segment is
    known as a collision domain, or a portion of a
    network in which collisions will occur if two
    nodes transmit data at the same time.
  • The more nodes transmitting data on a network,
    the more collisions will take place and you may
    see performance suffer as a result of collisions.
  • Collisions are likely to occur at the Physical
    Layer (on the channel or wire).
  • Repeaters and Hubs are Physical Layer devices and
    therefore share the Ethernet channel.
  • Portions of the network connected by repeaters or
    hubs must share the bandwidth of the single
    Ethernet channel.
  • Repeaters/Hubs simply regenerate any signal they
    receive, they repeat collisions just as they
    repeat data.
  • Networks can be separated into multiple
    collisions domains by using switches.

Collision Domains Demo
37
10BASE-T
  • The 10 represents its maximum throughput of
    10Mbps, the Base indicates that it uses
    baseband transmission, and the T stands for
    twisted pair, the medium it uses.
  • On a 10BaseT network, one pair of wires in the
    UTP cable is used for transmission, while a
    second pair of wires is used for reception. By
    using two pairs of wires, 10BaseT networks use
    full-duplex transmission.
  • A 10BaseT network requires CAT3 or higher UTP.
  • Fault tolerance capacity for component or system
    to continue functioning despite damage or partial
    malfunction
  • Physical star configuration
  • Maximum cable length is 100 meters
  • Nodes connected via concentrator
  • Maximum of 1024 Nodes per logical segment
  • Passive Topology connect to Active Hubs
  • No external terminators
  • 10Base-T Advantages 1) the star wiring topology
    supports easier maintenance and troubleshooting,
    2) twisted pair wiring is inexpensive and widely
    used, and 3) optionally supports full-duplex
    operation.

BASE Terminology Demo
38
10BASET 5-4-3 Rule
5-4-3 rule of networking between two
communicating nodes, network cannot contain more
than five network segments connected by four
repeating devices, and no more than three of the
segments may be populated
39
100BaseT Ethernet
  • 100Base-T (Fast Ethernet)
  • IEEE 802.3u standard
  • Similarities with 10Base-T
  • Baseband transmission, star topology, RJ-45
    connectors
  • Requires CAT5 or higher UTP
  • Supports three network segments maximum
  • Connected with two repeating devices
  • 100 meter segment length limit between nodes
  • Maximum of 1024 Nodes per logical segment
  • 100Base-TX
  • 100-Mbps throughput over twisted pair
  • Full-duplex transmission doubles effective
    bandwidth

40
1000BaseT Gigabit Ethernet
  • 1000BASE-T or 802.3ab is a standard for Gigabit
    Ethernet over copper wiring. It requires, at a
    minimum, Cat 5e ("Category 5 enhanced") cable.
    Category 6 cable may also be used. The 1000BASE-T
    standard was approved by the IEEE 802.3 in 1999.
  • In a departure from both 10BASE-T and 100BASE-TX,
    1000BASE-T uses all four cable pairs to achieve
    full duplex transmission. The aggregate data rate
    of 1000 Mb/s is achieved by transmission at a
    data rate of 250 Mb/s over each wire pair.
  • Each network segment can have a maximum distance
    of 100 meters. This usually consists of 90 m
    horizontal (inside the building), 9 m at the
    patch panel, and 1 m from the port to the
    computer or node.
  • 1000BaseT buses can practically support a maximum
    of two network segments connected with one hub
    and 1024 nodes per logical segment.

41
10GBaseT Ethernet
  • 10GBase-T
  • IEEE 802.3an
  • 10GBASE-T cable infrastructure can also be used
    for 1000BASE-T allowing a gradual upgrade from
    1000BASE-T
  • Pushing limits of twisted pair
  • Requires Cat 6 or Cat 7 cabling
  • Maximum segment length 100 meters
  • Benefit
  • Very fast data transmission, lower cost than
    fiber-optic
  • Use
  • Connect network devices
  • Connect servers, workstations to LAN

42
100Base-FX Ethernet
  • 100Base-FX supports a 100 Mb/s transmission rate
    over two multimode fiber optic cables. One cable
    is used to transmit data, and the other is used
    to receive data.
  • It allows maximum segment lengths of 412 meters
    for half-duplex links, and 2000 meters or more
    for full-duplex links.
  • The 100Base-FX standard allows several types of
    fiber optic connectors to be used. Duplex "SC"
    connectors are recommended, but "ST" and FDDI
    "MIC" connectors are also permitted.
  • In full-duplex mode, 100Base-FL segment lengths
    can be increased from 412 meters to 2000 meters.
    Even longer distances can be supported with the
    more expensive single mode fiber (SMF).
  • The 100BaseFX standard uses a star topology, with
    its repeaters connected through a bus with a
    maximum of two repeaters allowed to connect three
    segments.

2000
2000 Full duplex
2000
Full duplex
6000
43
1000Base-LX Ethernet
  • 1000Base-LX operates with a 1300nm laser over
    single and multi-mode fiber
  • The "L" in 1000Base-LX stands for "long" as it
    uses long wavelength lasers to transmit data over
    fiber optic cable.
  • Long wavelength lasers are more expensive than
    short wavelength, but have the advantage of being
    able to drive longer distances.
  • Maximum segment lengths range from 550 meters
    using multimode fiber to 5000 meters using single
    mode.
  • One repeater may be used to connect two segments.
  • Excellent choice for long backbones

550m using MMF to 5000m using SMF
44
1000Base-SX Ethernet
  • 1000BASE-SX is a fiber optic gigabit Ethernet
    standard.
  • The "S" in 1000Base-SX stands for "short" as it
    uses short wavelength lasers to transmit data
    over fiber optic cable. The short wavelength
    lasers specified by the standard operate at 850
    nanometers. Less expensive than long wavelength
    lasers.
  • Only multi-mode optical fiber is supported.
  • Maximum segment lengths range from 275 meters
    (62.5 micron fibers) to 550 meters (50 micron
    fibers) depending on the diameter of the fiber
    used.
  • Only one repeater may be used between two
    segments.
  • Best suited for shorter network runs

275 to 550 meters
45
10Gigabit Ethernet (802.3ae)
  • The IEEE 802.3ae standard specifies 10Gigabit
    Ethernet, also referred to as 10GbE, over
    multimode and single-mode fiber optics.
  • 10GbE increases the maximum fiber optic cable
    lengths up to 40 kilometers.
  • All use SC or LC connectors.
  • Common characteristics
  • Star topology, allow one repeater, full-duplex
    mode
  • Differences
  • Signals light wavelength, maximum allowable
    segment length

46
10GBase-SR and 10GBase-SW
  • 10GBase-SR and 10GBase-SW
  • 10G 10 Gbps
  • Base baseband transmission
  • S short reach
  • Physical layer encoding
  • R works with LAN fiber connections
  • W works with SONET fiber connections
  • Multimode fiber 850 nanometer signal
    transmission
  • Maximum segment length
  • 300 meters using 50 micron fiber
  • 66 meters using 62.5 micron fiber

47
10GBase-LR and 10GBase-LW
  • 10GBase-LR and 10GBase-LW
  • 10G 10 Gbps
  • Base baseband transmission
  • L long reach
  • Single-mode fiber 1319 nanometer signal
    transmission
  • Maximum segment length
  • 10,000 meters
  • 10GBase-LR WAN or MAN
  • 10GBase-LW SONET WAN links

48
10GBase-ER and 10GBase-EW
  • 10GBase-ER and 10GBase-EW
  • E extended reach
  • Single-mode fiber
  • Transmit signals with 1550 nanometer wavelengths
  • Longest fiber-optic segment reach
  • 40,000 meters (25 miles)
  • 10GBase-EW
  • Encoding for SONET
  • Best suited for WAN use

49
Summary of Common Ethernet Standards
50
Ethernet Frames
  • Ethernet networks may use one (or a combination)
    of four kinds of data frames
  • Ethernet_802.2 (Raw)
  • Ethernet_802.3 (Novell proprietary)
  • Ethernet_II (DIX)
  • Ethernet_SNAP
  • Frame types differ in way they code and decode
    packets of data
  • Ethernet frame types have no relation to
    networks topology or cabling characteristics

51
Using and Configuring Frames
  • Cannot expect interoperability between frame
    types
  • Nodes Data Link layer services must be properly
    configured for types of frames it might receive
  • LAN administrators must ensure all devices use
    same, correct frame type
  • Most networks use Ethernet_II
  • Frame types typically specified through devices
    NIC configuration software
  • (AutoSense) Most NICs automatically sense frame
    types running on network and adjust

52
Frame Fields
  • Ethernet frame types share many common fields
  • Every frame contains
  • 7-byte preamble and 1-byte start-of-frame
    delimiter (SFD)
  • 14-byte header
  • Destination address
  • Source address
  • Additional field that varies in function and size
  • 4-byte FCS field
  • Data portion
  • 46 to 1500 bytes of information

Ethernet_II (DIX) frame
53
Summary
  • A physical topology is the basic physical layout
    of a network it does not specify devices,
    connectivity methods, or addresses on the network
  • A bus topology consists of a single cable
    connecting all nodes on a network without
    intervening connectivity devices
  • In a star topology, every node on the network is
    connected through a central device, such as a hub
  • LANs often employ a hybrid of more than one
    simple physical topology
  • Network backbones may follow serial, distributed,
    collapsed, or parallel topologies
  • Ethernet employs a network access method called
    CSMA/CD
  • Networks may use one (or a combination) of four
    kinds of Ethernet data frames

54
The End
Write a Comment
User Comments (0)
About PowerShow.com
