Title: Equation of continuity and Bernoulli


1
Equation of continuity and Bernoullis
Principle(Ch. 10)
  • Owen von KugelgenHead-Royce School

2
Moving Fluids
  • Continuity Principle A1v1 A2v2
  • Bernoullis Principle P1 Dgh1 (1/2)Dv12 P2
    Dgh2 (1/2)Dv22 (really just conservation of
    energy!)

3
Continuity Principle A1v1 A2v2
A1
A2
v2
v1
When the diameter of a pipe decreases, the speed
of the water increases (imagine a garden hose)
4
Continuity Principle A1v1 A2v2
A1
A2
?x2
?x1
Vol1/t Vol2/t A1 ?x1 / t A2 ?x2 / t A1v1
A2v2
5
Can we apply energy concepts to fluids?
  • PE mghPE/Vol Dgh
  • Pressure F/AP (Fd)/Vol W/VolP
    Energy/Vol
  • KE (1/2)mv2 KE/Vol (1/2)Dv2

6
BernoullisPrinciple
7
Bernoullis Principle
P2
h
P1
P2 P1 Dgh?Pressure ?PE/V Dg?h
8
Bernoullis Principle
v2
P1
P2
v1
P1 Dgh1 (1/2)Dv12 P2 Dgh2 (1/2)Dv22
P1 P2 (1/2)Dv22 - (1/2)Dv12 P1 P2
(1/2)Dv22 - v12 Due to the continuity
principle v2 gt v1 so P1 gt P2
9
Bernoullis Principle
Conceptual meaning Higher fluid speed produces
lower pressure This helps wings lift balls
curve atomizers and carburetors Do their job
10
(No Transcript)
11
(No Transcript)
12
Wing lift
The air across the top of a conventional airfoil
experiences constricted flow lines and
increased air speed relative to the wing. This
causes a decrease in pressure on the top
according to the Bernoulli equation and provides
a lift force
13
Curve Ball
