Osteichthyes

1
Osteichthyes
2
Osteichthyes

• Means fish with bony skeletons
• There are over 20,000 species of bony fish

3
Where Do Most Fish Live?

• Most fish live in the epipelagic zone

4
Photic Zones in the Ocean
5
Why do fish move?

• To increase their chances of survival
• To help them reproduce
• To find food and shelter
• To get oxygen
• To migrate
• To avoid predators
• Fish want to use as little energy as possible to
  get what they need

6
What Slows Fish Down?

• Frictional drag the rubbing of the surface of a
  fishs body against the water slows it down.
• Ideal shape to reduce drag is a sphere

7
What Slows Fish Down? 2nd Type of Drag

• Form Drag is caused by cross-sectional area
  pushing through viscous (THICK) water
• To reduce form drag the fish should be like a
  long cylinder

8
What Slows a Fish down?Type of drag 3

• Turbulance caused by movement of the natural
  currents in the water.
• The best shape to reduce this drag is like a
  torpedo, 4.5 times the objects diameter.

9
Barracuda
10
Types of Fins

1. Tail Fin (CAUDAL FIN)
2. Paired Fins (PECTORAL and PELVIC FINS)
3. Medial Fins (DORSA and ANAL FINS)

11
External Anatomy of a Fish
12
External Anatomy
13
PRESSURE AND DEPTH

• The weight of air pressing on an average adult
  person is about 8 tons. If this pressure were to
  be suddenly removed from us our blood would boil
  and we would die in seconds.

14
How a Fish Swims

• A fish swims by contracting the muscles on one
  side of its body like a wave along one side of
  its body going from head to foot.

15
How a Fish Swims
16
Caudal Fins

• Caudal fins have different shapes

1.   Homocercal --gt Top and bottom halves the
same size a.       Rounded (Low A.R.) b.
Truncate (Intermediate A.R.) c.       Forked
(Intermediate A.R.) d.      Lunate (High A.R.)
2.      Heterocercal --gt Top half different
size than bottom half
17
Types of Caudal Fins
18
Types of Caudal Fins

• Heterocercal often found on sharks

19
Types of Caudal Fins

• Some shapes help the fish swim fast like the
  lunate shape while others make the fish swim slow
  but turn well

20
Paired Fins

• Help the fish turn and stop

21
Medial FinsDorsal and Anal Fins

• Help prevent the fish from spinning and keep it
  stable in the water

22
Measuring Fin Efficiency

• Aspect Ratio (fin height)2 / fin area Higher
  aspect ratio faster fish

23
Caudal FinsPush the fish forward
24
Aspect Ratio and Fin Types
25
Movement, Streamlining, and Speed

• The speed limit of a fish is determined by the
  viscosity or thickness of the water
• Streamlining of the fastest swimming fish (ex.
  Tuna) reduces turbulence
• Eyes are flattened against the head and male sex
  organs are usually internal
• Barracudas can reach speeds of 40 km/hr
• Yellowfin Tuna can reach speeds of 45 km/hr
• Larger Tuna can reach 110 km/hr

26
Cruising Speed

• Cruising speed for fish is about
• 1 or 2 body lengths per second (BL/sec.)

27
Measuring Length
28
Kinds of Muscle in Fast Swimming Fish

• 75 of the total body mass of fast swimming fish
  like tuna is muscle
• There is a greater percentage of red muscle than
  white muscle
• Red muscle contains myoglobin, a pigment that
  attracts oxygen.
• The power output of red muscle is 6 times that of
  white muscle

29
Salmon
30
Salmon Red Muscle
31
Yellowfin Tuna
32
(No Transcript)
33
Barracuda
34
Flounder
35
Flounder Muscle
36
Water Viscosity

• Water viscosity is the thickness of water caused
  by the sticky cohesion of water molecules to each
  other and the adhesion of water molecules to
  other objects causing friction.
• Cold water creates 2x as much friction as warm
  water.
• An organism in warm water must be smaller than a
  same shaped organism in cold water to prevent
  sinking due to viscosity

37
Water Viscosity
38
Fish Senses

• Sight some fish can see color and can see in
  very dim light
• Hearing fish can hear
• Smell fish have nostrils used for smelling
• Touch fish can feel objects against their skin
• Lateral line- A system of canals on the sides of
  fishes that helps fish detect changes in
  pressure, vibrations and currents

39
Fish Eyes
40
Fish Hearing
41
Fish Smell
42
Lateral Line
43
Lateral Line
44
Lateral Line
45
Lateral Line
46
Lateral Line

• Fish hear via their lateral lines, a line of
  pressure sensors running along each side of the
  fish that pick up pressure waves ( sound) in
  water. When someone pounds on an aquarium, that
  creates waves of pressure in the water that, to
  the fish, would be analogous to cupping your
  hands and pounding on your ears--NEVER POUND ON A
  FISH TANK!

47
Functions of the Lateral Line

• Detect changes in pressure and vibrations and
  currents
• Detect prey
• Swim together in a school
• Detect predators on the side or behind them
• Pick up vibrations from the swimming together of
  other animals

48
(No Transcript)
49
BUOYANCY
50
BUOYANCY

• Ways animals and plants avoid sinking
• By adjusting body density to the same density as
  that of the water around them (neutral buoyancy).

• Having flattened or bristly shapes that increase
  surface area and reduce sinking.

51
Maintaining Buoyancy

• To maintain buoyancy the fish will either
• Adjust the density of its body by using a SWIM
  BLADDER
• They will adjust the density of the components of
  their insides (they will consume lighter weight
  ions and leave the heavier ones in the
  surrounding water)

52
SWIM BLADDERS

• A swim bladder is a balloon-like structure that
  is
• inflated to make the fish rise higher in the
  water
• or deflated to make the fish sink lower

53
(No Transcript)
54
SWIM BLADDER
55
SWIM BLADDER

• CLOSED

• OPEN

56
No Swim Bladder

• Some fish like Tuna do not have a swim bladder
  and must swim fast to prevent sinking
• Some fish like catfish do not have a swim bladder
  and spend their life on the bottom

57
Respiration

• Fish use gills to absorb oxygen from the
  surrounding water

58
Comparison of Gas in Ocean Water and the
Atmosphere

• Undissolved

Gas Chemical Symbol Percentage in
Air Percentage in Sea Water Nitrogen N 2
78.08 62.6 Oxygen O 2
20.95 34.3 Carbon Dioxide CO 2
0.033 1.4 Dissolved Oxygen
59
Dissolved Gases

• Gas Ocean Atmosphere
• Oxygen 5-10ml/L 200ml/L
• Dissolved gases vary in water with temperature
  and salinity.
• Cold fresh water can hold more dissolved gas than
  warm saltwater.

60
Parts of a Gill

• Gill Arch - stiff structure that supports the
  gill filaments and the gill rakers
• Gill Rakers prevent food from clogging up the
  gill filaments
• Gill Filaments fingerlike projections where
  oxygen is absorbed and carbon dioxide is removed

61
Parts of a Gill
62

• Fish Breathing

63
How Fish Breathe
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
Counter-Current System

• Gas is exchanged in gills because water and blood
  move along side each other in opposite directions

68
PRESSURE AND DEPTH

• A column of water only 10 m deep exerts a
  pressure of 1 ATM. Every 10 m of water exerts
  another ATM of pressure. Organisms living at 100m
  or 500m are subjected to 10 ATM or 50 ATM (plus 1
  ATM of air pressure above the sea).

69
PRESSURE AND DEPTH
70
Fish and Body Temperature

• Types of temperature systems
• Endothermic (homeothermic) maintain a constant
  internal body temperature (ex. Humans 98.60F)
• Ectothermic or Poikilothermic - have a
  temperature similar to their surroundings (ex. If
  the water is 560F F then the fish will have a
  body temperature around 560F)

71
Fish Reproduction

• Most fish have internal sex organs that we cannot
  see.
• fish gonads (sex organs) produce gametes (sex
  cells) only at certain times.
• These times must be the same for both males and
  females and must be timed to the most favorable
  conditions.

72
Fish Reproduction

• Fish may only reproduce when there
• 1. Is enough of the right kind of food
• 2.There are enough hours of light each day
• 3. The water is the right temperature

73
Fish Reproduction

• Includes
• Courtship a series of behaviors designed to
  attract mates
• Spawning a release of gametes into the water
• Copulation a direct transfer of sperm into a
  females body

74
Fish Reproduction

• Most fish reproduce by spawning.
• This is when the female swims and lays eggs on
  plants or sand in the water
• The male fish swims behind her depositing sperm
  into the water where some of it may land on and
  fertilize the eggs

75
Sunfish Spawning
76
Fish Reproduction

• Other Fish give birth to live young like humans
  (ex. Guppy giving birth)

77
Fish Reproduction

• Some fishes are hermaphrodites. They have both
  male and female gonads
• Hermaphrodism is more common among the deep-water
  fishes. (Gourami)

78
Deep Sea Fish

• Deep Sea Fangtooth

79
Fish Reproduction

• Reproduction in fishes involves many adaptations
  that help individuals get together and select
  mates.

80
Fish Courtship

• Mandarin Fish Dancing to attract a female

81
Fish Reproduction

• Sex Reversal
• Males may change to females or females to males
  (ex. Clownfish)

82
Sex Reversal

• Among some species of anemone fishes a single
  large female who mates only with a single large
  dominant male inhabits each sea anemone. All
  others are small non-breeding males. If the
  female disappears her mate changes into a female
  and the largest of the non-breeding males becomes
  the new dominant male. The new female can start
  spawning as soon as 26 days after her sex change.
