Dynamic Properties of Fire Sprinklers

1
Dynamic Properties of Fire Sprinklers
2
Master Thesis Defense

• For
• Jim Dillingham
• May 2002

3
Introduction

• Project Description
• Construction of a Small Timber Building Model
• Longitudinal and Transverse Test Axis when on the
  3ft x 3ft Shake Table
• Four Designs were Tested , 3 CPVC, and 1 Steel

• Purpose of Research
• Large Consequences to Fire Sprinkler Failures

4
Model Construction
The model being built to fit on the 3x3 shake
table
5
2 of the 6 Hold-Downs to Attach Model to the
Shake Table
6
Model Drawings
7
(No Transcript)
8
Building Test Properties
9
More Photos
10
(No Transcript)
11
(No Transcript)
12
Sprinkler System Designs

• Types of sprinkler systems considered
• CPVC
• Steel
• Recording Locations
• Drops

13
CPVC Design 1
14
CPVC Design 2 And 3
15
Steel Design
16
Results
Frequency Test Range 10 25 Hz Fundamental
Frequencies Observed both Experimental and
Analytical
17
CPVC Test Results
Test with the largest amplification recorded
(58x).
18
(No Transcript)
19
Steel Test Results
Test with the largest amplification recorded
(35x).
20
(No Transcript)
21
SAP2000 Results
22
CPVC Design 1
Longitudinal Mode 2 36.5 Hz
Longitudinal Mode 1 15.1 Hz
23
CPVC Design 1
Transverse Mode 1 15 Hz
Transverse Mode 2 35.2 Hz
Transverse Mode 3 36.7 Hz
24
CPVC Design 2
Longitudinal Mode 1 15.1Hz
Longitudinal Mode 2 16.8 Hz
25
CPVC Design 2
Longitudinal Mode 3 36.5 Hz
Longitudinal Mode 4 39 Hz
26
CPVC Design 2
Transverse Mode 1 5.6 Hz
Transverse Mode 2 15.1 Hz
27
CPVC Design 2
Transverse Mode 3 20.5 Hz
Transverse Mode 4 36.5 Hz
28
CPVC Design 3
Longitudinal Mode 3 38.9 Hz
Longitudinal Mode 2 36.5 Hz
Longitudinal Mode 1 15.1 Hz
29
CPVC Design 3
Transverse Mode 3 36.5 Hz
Transverse Mode 2 19.8 Hz
Transverse Mode 1 15 Hz
30
Steel Design
Longitudinal Mode 2 45.2 Hz
Longitudinal Mode 1 14.2 Hz
31
Steel Design
Transverse Mode 2 28.9 Hz
Transverse Mode 1 13.1 Hz
32
Test Video
33
(No Transcript)
34
(No Transcript)
35
Conclusions

• No Failures Occurred
• High levels of Accelerations were Recorded.
• CPVC is extremely Flexible
• Modulus of Elasticity 420,000 psi
• Accelerations in the Sprinkler System
• were Amplified over the Base Input

36

• Securely Fixed Sprinkler Systems
• Respond to
• Buildings Fundamental Frequencies
• NFPA-13 1999
• Current Design Code
• Protects Systems from Dynamic Failures

37
Potential For Future Research

• Larger more complicated sprinkler systems can be
  tested to witness shaking effects in different
  sized components.
• A model with multiple floors could test how
  flexible couplings react to inter-story drift.
• In a room-size model multiple interior objects
  can be studied to observe the interaction to a
  dynamic sprinkler system. Potential items are
  gypsum board, dropped ceiling grids, mechanical
  equipment, etc.

38
THE END
