DNA / RNA

1
DNA / RNA

• Chapter 08

2
DNA

• Deoxyribonucleic acid (DNA) is a nucleic acid
  that contains the blueprint for making the
  proteins the cell needs.
• DNA contains genes.
• Genes are specific messages instructing the cell
  on how to construct a protein.

3
DNA

• DNA is the chemical used to pass genetic
  information on to the next generation of
  organisms.
• DNA controls the synthesis of proteins, which
  helps determine the characteristics of the
  organism and regulate the cells metabolism.

4
DNA

• DNA contains the genetic instructions used in the
  development of all known living organisms and
  some viruses.
• DNA molecules are used for long term storage of
  information.
• DNA carries the instructions necessary to create
  RNA and proteins therefore, it is often compared
  to a blueprint.

5
DNA Structure

• DNA is a nucleic acid.
• Nucleic acids are large polymers of nucleotides.

6
DNA Structure

• DNA consists of two long polymers of simple units
  known as nucleotides.
• These two strands run in opposite directions to
  each other and are therefore known as
  anti-parallel.
• The strands have backbones made of sugars with
  phosphate groups attached.

7
DNA Structure

• Attached to each sugar is one of four types of
  molecules called bases.
• Information is encoded in the sequence of these
  four bases along the backbone.
• The information is read using the genetic code.

8
DNA Structure

• The genetic code specifies the sequence of amino
  acids within proteins.
• The code is read by copying stretches of DNA into
  RNA (A process known as transcription).

9
DNA Structure

• A nucleotide consists of a sugar molecule, a
  phosphate group, and a nitrogenous base.
• There are four different nitrogenous bases in DNA

10
DNA Structure

• Adenine (A), guanine (G), cytosine (C), and
  thymine (T).
• The DNA nucleotides can combine into a long
  linear DNA molecule that can pair with another
  linear DNA molecule.

11
DNA Structure

• The two paired strands of DNA form a double helix
  with sugars and phosphates on the outside and the
  nitrogenous bases on the inside.
• The nucleotides form hydrogen bonds with one
  another, which helps to stabilize the helical
  structure.

12
DNA Structure

• Adenine pairs with Thymine (A-T).
• Guanine pairs with Cytosine (G-C).

13
(No Transcript)
14
Nitrogenous Bases

• The nucleotide bases are nitrogenous bases that
  are involved in pairing in DNA and RNA. This is
  known as base pairing.
• In genetics they are simply called bases.
• Adenine, Guanine, Cytosine, and Thymine are DNA
  bases.
• Adenine, Guanine, Cytosine, and Uracil are RNA
  bases.

15
Adenine
16
Guanine
17
Thymine
18
Cytosine
19
Uracil
20
Chromosomes

• Within cells, DNA is organized into structures
  called chromosomes.

21
Chromosomes

• The chromosomes are duplicated before the cell
  divides, a process known as DNA replication.
• Within the chromosomes, chromatin proteins such
  as histones compact and organize DNA. The
  chromatins help determine which parts of the DNA
  are transcribed.

22
Eukaryotes Vs. Prokaryotes

• Eukaryotic organisms (animals, plants, fungi, and
  protists) store their DNA inside the cell
  nucleus.
• Prokaryotic organisms (bacteria and archae) have
  no nucleus therefore, the DNA is found in the
  cytoplasm.

23
DNA Replication

• When a cell grows and divides, two new cells
  result.
• DNA replication is the process by which a cell
  makes another copy of its DNA.
• Base pairing rules and many enzymes make
  replication possible.

24
DNA Replication

• DNA replication is the process of copying a
  double-stranded DNA molecule to form two
  double-stranded molecules.

25
DNA Replication

• Each DNA strand holds the same genetic
  information therefore, both strands can serve as
  a template for the reproduction of the
  complementary strand.
• The template strand is conserved in its entirety
  and the new strand is assembled from nucleotides.
  This is known as semiconservative replication.

26
DNA Replication

• The resulting double-stranded DNA molecules are
  identical.
• DNA replication must happen before cell division
  can occur.

27
DNA Replication

• Helicases are enzymes that bind to the DNA and
  separate the two strands of DNA.
• DNA polymerase incorporates DNA nucleotides into
  the new DNA strand. The nucleotides enter
  according to the base pairing rules.

28
DNA Replication

• In prokaryotic cells, this replication process
  starts at only one place along the DNA molecule
  (origin of replication).
• In eukaryotic cells, the replication starts at
  the same time along several different places of
  the DNA molecule.

29
DNA Replication

• Two new identical, double-stranded DNA molecules
  are formed.
• The new strands of DNA form on each side of the
  old DNA strands.

30
DNA Replication

• The exposed nitrogenous bases of the original DNA
  serve as the pattern on which the new DNA is
  formed.
• Two double helices are formed with identical
  nucleotide sequences.
• A portion of the DNA polymerase molecule edits
  the newly created DNA molecule and makes
  corrections if needed.

31
DNA Replication
32
Repair of Genetic Information

• If an error or damage occurs to the DNA helix on
  one strand, the pairing arrangement of
  nitrogenous bases on the other undamaged strand
  can be read.
• This information is used to repair the damaged
  strand.

33
DNA Code

• DNA stores information.
• The order of the nitrogenous bases is the genetic
  information that codes for proteins.
• The nucleotides are read in sets of three.
• Each sequence of three nucleotides is a codeword
  for a single amino acid.
• The information to code one protein can be
  thousands of nucleotides long.

34
RNA Structure And Function

• Ribonucleic Acid (RNA) is important in protein
  production.
• RNAs nucleotides contain a ribose sugar whereas
  DNAs nucleotides contain a deoxyribose sugar.
• Ribose has an OH group and deoxyribose has an H
  group on the second carbon atom.

35
RNA Structure And Function

• RNA contains the nitrogenous bases Uracil (U),
  guanine (G), cytosine (C), and adenine (A).
• DNA is found in the cells nucleus, while RNA is
  made in the nucleus and then moves out into the
  cytoplasm of the cell.

36
RNA Structure And Function

• DNA directs protein synthesis by using RNA.
• RNA is made by enzymes that read the protein
  coding information in DNA.
• RNA nucleotides pair with DNA nucleotides.
• RNA contains Uracil instead of Thymine so adenine
  in DNA pairs with Uracil in RNA.

37
Nucleic Acid Base Pairing Rules
DNA pairs with DNA DNA pairs with RNA RNA pairs with RNA
A pairs with T A pairs with U A pairs with U
T pairs with A T pairs with A U pairs with A
G pairs with C G pairs with C G pairs with C
C pairs with G C pairs with G C pairs with G
38
Transcription

• Transcription is the process of using DNA as a
  template to synthesize RNA.
• The RNA polymerase enzyme reads the sequence of
  DNA nucleotides and follows the base pairing
  rules between DNA and RNA to build the new RNA
  molecule.

39
Transcription

• The two strands of the double stranded DNA
  molecule are separated to expose the nitrogenous
  bases.
• The DNAs nitrogenous bases are read and paired
  with the RNA nucleotides.
• Only one strand of the DNA molecule is read (the
  coding strand). The other strand is referred to
  as the non-coding strand.

40
Transcription

• Promoter sequences are specific sequences of DNA
  nucleotides that RNA polymerase uses to find a
  protein-coding region of DNA and to find out
  which strand of DNA is the coding strand.

41
Transcription

• Termination sequences are DNA nucleotide
  sequences that indicate when RNA polymerase
  should finish making an RNA molecule.

42
3 Types of RNA

• Messenger RNA (mRNA) carries the blueprint for
  making the necessary protein.
• Transfer RNA (tRNA) reads mRNA and brings in
  the necessary amino acids.
• Ribosomal RNA (rRNA) reads the mRNA and brings
  in the necessary amino acids.

43
Translation

• Translation is the process of using information
  in RNA to direct protein synthesis.
• mRNA is read in sets of three nucleotides called
  codons.

44
Translation

• A codon is a set of three nucleotides that codes
  for a specific amino acid.
• The ribosome is made up of proteins and ribosomal
  RNA (rRNA).
• The ribsome holds the mRNA in place and reads
  its codons.

45
3 Phases of Translation

• Initiation
• Elongation
• Termination

46
Initiation

• The small ribosomal subunit binds to the mRNA and
  moves along until it reaches an AUG codon to
  signal the beginning of translation.
• Transfer RNA (tRNA) carries amino acids to the
  mRNA complex.

47
Initiation

• The anticodon portion of the tRNA interacts with
  the mRNA to match the correct amino acid to the
  codon in the mRNA nucleotide sequence.
• The tRNA that binds to the AUG codon that signals
  the beginning of translation carries the amino
  acid methionine therefore, every protein begins
  with this amino acid.

48
Elongation

• The ribosome functions as an assembly line.
• New amino acids are carried by tRNA to the
  corresponding mRNA segment.
• The anticodon on tRNA matches with the codon on
  mRNA.
• The amino acid is then attached to the end of the
  chain and the protein becomes elongated.

49
Termination

• The ribosome will continue to add new amino acids
  until a stop signal is reached on the mRNA
  molecule.
• The stop codon can be either UAA, UAG, or UGA.

50
Termination

• When these codons are encountered, a release
  factor enters the ribosome. The ribosomal
  subunits release mRNA.
• The mRNA can then either be reused or broken down
  to stop protein production.

51
Translation
52
Nearly Universal Genetic Code

• The code for making protein from DNA is the same
  for nearly all cells.
• Bacteria, protists, plants, fungi, and animals
  all use DNA to store their genetic information.
• They all transcribe information in DNA to RNA.
• They all translate the RNA to synthesize protein
  using a ribosome.

53
Nearly Universal Genetic Code

• Almost all use the same three nucleotide codons
  to code for the same amino acid.
• In eukaryotic cells, transcription always occurs
  in the nucleu, and translation always occurs in
  the cytoplasm.

54
Nearly Universal Genetic Code

• These similarities make it possible to use
  bacteria to synthesize human proteins (i.e.
  insulin).
• Some viruses use RNA to store their genetic
  information (retroviruses). HIV is an example of
  this. Retroviruses use RNA to make DNA, which is
  then used to make proteins.

55
Gene Expression

• Gene expression occurs when a cell transcribes
  and translates a gene.
• Cells control which genes are used to make
  proteins.
• The different cell types in the human body are
  due to which proteins the cell is producing.

56
Controlling Protein Quantity

• An enzymes activity can be regulated by
  controlling how much of that enzyme is made.
• The cell controls how much mRNA is available for
  translation, which in turn determines the
  quantity of the protein produced.

57
Controlling Protein Quantity

• Enhancer and silencer sequences affect the
  ability of RNA polymerase to transcribe a
  specific protein.
• Enhancer sequences increase protein synthesis by
  increasing transcription.
• Silencer sequences decrease protein production by
  decreasing transcription.

58
RNA Degradation

• Cells regulate gene expression by limiting the
  length of time that mRNA is available for
  translation.
• Enzymes in the cell break down mRNA.

59
Mutations

• A mutation is any change in the DNA sequence of
  an organism.
• Errors during DNA replication can cause mutation.
• External factors can cause mutation

60
Mutations

• Radiation, carcinogens, drugs, viruses.
• Not all mutations cause a change in the organism.
• If the mutation occurs away from the
  protein-coding sequence of the DNA, it is
  unlikely to be harmful to the organism.

61
Silent Mutation

• A silent mutation is a change that does not
  change the amino acids used to build a protein.

62
Nonsense Mutation

• A nonsense mutation causes a ribosome to stop
  protein synthesis by introducing a stop codon too
  early.
• This prevents the formation of functional
  proteins.

63
Missense Mutation

• A missense mutation causes the wrong amino acid
  to be used in making a protein.
• This will change the shape of the protein and
  affect its active sites.
• This can cause an abnormally functioning protein.

64
Insertions And Deletions

• Some mutations involve larger spans of DNA than a
  change in a single nucleotide.
• An insertion mutation adds one or more
  nucleotides to the normals DNA sequence.

65
Insertions And Deletions

• This can add amino acids to the protein and
  change its function.
• A deletion mutation removes one or more
  nucleotides.
• This can delete amino acids from the protein and
  change its function.
