1Biblioteca Centrale P. Arduino CIS
AgripolisEdited by the Group for Training in
Library Resources
- Course
- Access to bibliographic resources
- for post graduate Schools of Agripolis
- (15 hours)
23 PART
- Bibliographic searches through Scifinder
(presented by Federico Fogo) - Bibliographic searches through free data banks as
PUB MED, AGRICOLA, AGRIS etc.
3Bibliographic searchBasic Principles
- To perform a bibliographic search correctly, you
have to keep in mind - The difference between a catalog and a
bibliography - Use of logic Boolean operators and jolly
characters - The logical sequence of the steps you have to
follow
4CATALOG/BIBLIOGRAPHY
- A CATALOG
- A catalog comprehends the works that are
possessed by one or more libraries and tells you
where you can find them
- A BIBLIOGRAPHY
- A bibliography comprehends the existing documents
with chosen characteristics (what has been
published on a subject or what has been published
of a chosen author) but does not say anything
about where you can find those documents
5THE TOOLS Logical operators (or Boolean
operators) (They are named after the British
mathematician George Boole who developed that
logical system in mid 18 hundred)
- They are named after the British mathematician
George Boole who developed that logical system in
mid 18 hundred - The logical operators allow to specify
- The relation between the words that you have to
search - What words must be in the pages you retrieve
- What words must not be in the pages you retrieve
- What words can be used as an alternative
6THE TOOLS - Logical operators (or Boolean
operators) AND, OR, NOT
AND You will retrieve documents that contain both
words. As a result, you limit your search
WORD 1 AND WORD 2
OR You will retrieve documents that contain word
1 or either word 2 or both. As a result, you
expand your search
WORD 1 OR WORD 2
NOT You will retrieve documents that contains
word 1 but not word 2. As a result, you refine
your search
WORD 1 NOT WORD 2
7IMPLICIT BOOLEAN OPERATORS
- Often using web engines you can notice that the
symbols and are used instead of AND, NOT - Before those symbols there must be a space, but
they must not be separated by a space from the
word that follows - forest(blank)Cansiglio Cansiglio AND forest
- Cansiglio(blank)diseases(blank)-firs Diseases
of Cansiglio forest, but of firs -
8THE TOOLS ? and
- ? (Question mark)
- It stands in place of whatever character and can
be reused as much as you want - Ex. Nar?elli will find Naraelli, Narbelli,
Narcelli
(star) It truncates the word both at the top and
at the end Ex. Bio will find biology,
biotechnology, biochemistry
9(No Transcript)
10BIBLIOGRAPHIC SEARCH
- To do a bibliographic search we can
- To look up journals with their indexes
- To search databanks
11Databank
- A databank is an an electronic archive where
information are organized in a particular
structure, in order to make it easier and more
useful to retrieve them through the search
interface - The basic unit of an electronic archive is the
record, divided in fields (title, author, date
etc.)
12BIBLIOGRAPHIC DATA BANKS
- Bibliographic data banks contain bibliographic
citations of books, journals and miscellaneous
works, almost always together with an abstract - They are usually multidisciplinary or specialized
on a determined subject - They usually employ a very powerful searching
strategy - They allow to save the results of the query
- They represent a very important tool to start a
scientific work and/or a thesis
13BIBLIOGRAPHIC DATA BANKS
- Padova University offers a large number of data
banks on different subjects (Trova risorse on
AIRE PORTAL) - Bibliographic data banks are searched to find
documents on a specific subject. The documents
can be localized through on line catalogs (OPAC,
AIRE/SFX, etc.)
14ACCESS TO UNIVERSITY OF PADOVA DATA BANKSHOW
TO CONFIGURE AUTH-PROXY
- Access to University of Padova data banks is
allowed only from computers connected to the
University web - To connect to the University web from your home
or from another University students have to
carefully follow the instructions that can be
found at - http//www.cab.unipd.it/node/127
15Bibliographic searches through Scifinder
- Scifinder
- (dott. Federico Fogo)
16Bibliographic searches through free data banks
- PubMed,
- Treesearch,
- AGRICOLA,
- AGRIS/CARIS
- (Dott.ssa Micaela De Col)
17PubMed Bibliographic Search
- PubMed is a resource that is developed and kept
up by the National Center for Biotechnology
Information (NCBI), at the U.S. National Library
of Medicine (NLM), located at the National
Institutes of Health (NIH). - It is available for free on the Internet at
http//pubmed.gov. - Links to full-text articles, information about
library holdings, and other NLM databases are
available
18PubMed Bibliographic Search
- PubMed Content
- PubMed comprehends over 20 million citations of
biomedical literature from MEDLINE, life science
journals, and online books. - MEDLINE NLMs database comprehends millions of
references from articles published in biomedical
and related journals which have been fully
indexed - In-process citations that have not yet been
analyzed and indexed by MEDLINE - Publisher supplied citations that may not receive
full indexing by MEDLINE because they are not
biomedical in nature -
19MEDLINE
- Is the NLM premier bibliographic database that
contains references to journal articles in life
sciences with a focus on biomedicine - Includes the fields of medicine, nursing,
dentistry, veterinary medicine, the health care
system, and preclinical sciences
20MEDLINE
- Time coverage generally 1946 to the present,
with some older documents. - Source currently, citations from approximately
5.516 worldwide journals in 39 languages - for citations added from 2005-2009 about 45 are
for cited articles published in the U.S., about
91 are published in English and about 83 have
English abstracts written by the authors of the
articles.
21How do I search PubMed?
- Search
- by subject
- by author
- by journal
- Other search
- You can get
- lists of bibliographic citations from articles
- Link to the full-text (if present) or to related
articles
22MEDLINE structure
- Articles are indexed using a powerful thesaurus,
called Medical Subject Headings (MeSH). The MeSH
Database provides the option to identify
appropriate MeSH terms for searches. - Records are subdivided in FIELDS
- (Author, title, ect)
23 MeSH (Medical subject headings)
- MeSH is the National Library of Medicine's
controlled vocabulary thesaurus. It consists of
sets of terms naming descriptors in a
hierarchical structure that permits searching at
various levels of specificity. - The Medical Subject Headings Section staff
continually revise and update the MeSH vocabulary - The MeSH database can be searched by MeSH term,
MeSH Entry Term, Subheading, Publication Type,
Supplementary Concept, or MeSH Scope Note.
24Esempio
- Animal Diseases C22
- Abortion, VeterinaryC22.021
- Actinobacillosis C22.039
- Aleutian Mink Disease C22.062
- Anal Gland Neoplasms C22.073
- Anaplasmosis C22.085
- Bird Diseases C22.131
- Borna Disease C22.152
- Cat Diseases C22.180
- Cattle Diseases C22.196
- Disease Models, Animal C22.232
25Mesh Browser
http//www.nlm.nih.gov/mesh/MBrowser.html
26Before you start a few tools
- Combine search terms with connector words
(Boolean operators) AND, OR or NOT using
upper case letters. - To search for all terms that begin with a word,
enter the word followed by an asterisk (), the
wildcard character.For instance, risk will show
risk, risks, risk-taking The term infection
will not show infection control because there is
a blank after the term infection - Searching for a phrase
- () PubMed processes searches in a left-to-right
sequence. Use parentheses to nest concepts that
should be processed as a unit and then
incorporated into the overall search. -
- search by a specific field es. Albertini
mAU, Liver diseasesMH
27Boolean operators AND, OR, NOT
- Enter Boolean operators in uppercase characters
to combine or exclude search terms - Boolean operators must be used when combining
tagged search terms as follows search term tag
BOOLEAN OPERATOR search term tag. - PubMed processes searches in a left-to-right
sequence. Use parentheses to nest concepts that
should be processed as a unit and then
incorporated into the overall search. - In a tag with more than one Boolean operator AND
will be processed before OR - A search with "influenza AND vaccine OR
vaccination will show articles that contains
both terms "influenza and "vaccine and will
show all the articles on "vaccination To obtain
different results write "influenza AND
(vaccine OR vaccination)"
28MEDLINE search fields
- You may also search a specific field, and bypass
the automatic term mapping, by adding the
appropriate tag to a search term - The search tag must be enclosed in square
brackets. - term tag
- Es. merkel au liver cirrhosis ti cancer
jour - Case and spacing do not matter (e.g., crabs mh
Crabsmh). - automatic term mapping
- Untagged terms that are entered in the search box
are matched (in this order) against a MeSH
(Medical Subject Headings) translation table, a
Journals translation table, the Full Author
translation table, Author index, the Full
Investigator (Collaborator) translation table and
an Investigator (Collaborator) index.
29Seach field descriptions and Tag
30Searching for a phraseUSING DOUBLE QUOTES ..
- In searching for a phrase enclose the phrase in
double quotes - For example myocardial infarction Will show
all the articles where this phrase appears as I
wrote it, without any other terms - Without .. Pubmed applies an AND operator
between concepts - When you enter your search terms as a phrase
PubMed will not perform automatic term mapping
that includes the MeSH term and any specific
terms indented under that term in the MeSH
hierarchy. - If you use a hyphen or quotes and the phrase is
not found, the hyphen or quotes are ignored and
the phrase is processed using automatic term
mapping.
31Link
- PubMed is available free on the Internet at
- http//www.ncbi.nlm.nih.gov/pubmed
-
32Esempi
- Search for records in Javma Journal that contain
the term cancer in text - Records that contain liver in general, but not
studies on humans - 3. Records on neoplasia in cats and dogs
indifferently -
33Simple search Text word
- Includes all words and numbers in the title,
abstract, other abstract, etc. - When?
- To use when? Is useful if
- There are no Mesh descriptors to pick up a
subject - If the available descriptor is not specific
enough - Searchin for in process articles, i.e. articles
that have not been indexed yet with MESH
descriptor terms.
34Simple search Text word
- Remember to type in the SEARCH box the synonims
of the term you are looking for - To search for all terms that begin with a word,
enter the word followed by an asterisk (), the
wildcard character. - Pro you can use colloquial words and phrases
- Connot all the words used in natural language
are key words
35Simple search Text word
- .
- Enter the terms or more terms (or key concepts)
in the search box whitout tags - Automatic suggestions will display as you type
your search terms. - Click Search.
36Simple search Text word
- You can use "AND", "OR" and "NOT".
- Automatic mapping untagged terms that are
entered in the search box are matched (in this
order) against a - MeSH (Medical Subject Headings) translation
table, - a Journals translation table,
- the Full Author translation table, Author index,
the Full Investigator (Collaborator) translation
table and an Investigator (Collaborator) index. - When a match is found for a term or phrase in a
translation table the mapping process is complete
and does not continue on to the next translation
table. - PubMed PubMed ignores stopwords in searches.
37Simple search Text word
- PubMed displays a list of results in Summary
format in batches of 20 citations.
38Searching by journal title
- Enter in the search box one of the following
- full journal title (e.g., molecular biology of
the cell) - using the search field JOUR or TA - title abbreviation (e.g., mol biol cell) - using
the search field JOUR or TA - ISSN number, a standardized international code
(e.g., 1059-1524) using the search field IS - If you do not use a search field tag the program
could mistake the term for a key word (ex
Science) - Click Search
- REMEMBER
- To find full journal names, use the NLM Catalog,
or mouse over the citation journal abbreviation.
39Searching by author
- The format to search for this field is last name
followed by a space and up to the first two
initials followed by a space and a suffix
abbreviation, if applicable, all without periods
or a comma after the last name (e.g., fauci as or
o'brien jc jr). Initials and suffixes may be
omitted when searching. - use the search field AU Es. Smith JB AU
- PubMed automatically truncates on an author's
name to account for varying initials, e.g.,
o'brien j au will retrieve o'brien ja, o'brien
jb, o'brien jc jr, as well as o'brien j. To turn
off this automatic truncation, enclose the
author's name in double quotes and tag with au
in brackets, e.g., "o'brien j" au to retrieve
just o'brien j. - If only the author's last name is entered, tag
the name with the author search field au, to
find the name in the author field only . -
40Searching by author
First authir or co-author
41Searching by author
- If only the author's last name is entered, tag
the name with the author search field au, to
find the name in the author field only . - Without tagging the search field au PubMed will
search that name in all fields(abstract, text,
title etc.) not only in the field author
42Searching by author - ADVANCED SEARCH
- Use the Advanced search Search Builder to search
for terms in a specific search field - To search by author, select Author from the All
Fields menu, enter an authors name, and then
click the Add to Search Box button to add the
name to the search box. - The author search box includes an autocomplete
feature.
43Combining more authors with Boolean operator AND
44Combining more authors with Boolean operator OR
45Search by journal Advanced search
To search by journal, select Journal from the All
Fields menu, enter a journal name, and then click
the Add to Search Box button to add the name to
the search box. The journal search box includes
an autocomplete feature..
46Search by journal Advanced search
47Limits
- You can limit your search by dates, type of
article, languages, species, sex, subsets, ages,
text options, and specific search fields.
- Specific search fields tags
- Choose a specific search field tag to limit all
terms in the search box to that field. -
48Limits
- Publication Types
- restricts your search based on the type of
material the article represents, such as - Clinical Trial
- Editorial
- Letter
- etc-.
- Languages
- The languages limit restricts your search to
articles written in a particular language. - Languages displays a list of the most frequently
used languages. - .
49Limits
- Ages
- The age limits restrict your search to a
specific age group for a human study - Humans or animals
- The species limit restricts your search to a
human or animal study - Gender
- Sex restricts your search to a specific sex for
a human study (Male/Female)
50Limits
- Subsets
- Journal Groups More Subsets
- The Journal/Citation subsets restrict retrieval
to specialized journals or articles on
specialized topics in other journals. - Topics
- The topics subsets restrict
- retrieval to specific subjects including
- AIDS
- Bioethics
- Cancer
- Complementary Medicine
- Dietary Supplements
- Etc.
51Understanding Your Search Results Display
settings
- Search results initially display in a summary
format in the order they were entered in PubMed
as last in, first out. You can change the display
format. - A default of 20 citations is displayed per page.
If there are more than 20 citations, they will be
displayed on subsequent pages. - To display the abstract for a journal article,
click the title link for each citation. Some
citations do not have abstracts and include the
note No abstract available..
52Understanding Your Search Results Display
settings
Search results initially display in a summary
format in the order they were entered in PubMed
as last in, first out. You can change the
display format. To change the display format only
for selected citations, click the check box to
the left of each citation before selecting a
display format.
Menu a tendina
53Understanding Your Search Results Display
formats
- PubMed Citation Display Formats
-
- Summary default (Authors, Title, Journal source,
etc.) -
54Understanding Your Search Results Display
formats
- Abstract include abstract, but the Abstract
(text) format does not include MeSH data. -
55Understanding Your Search Results Display
formats
- MEDLINE Two-character tagged field format (for
the complete record. Use this format to export
citations into reference management programs.
56Search details
- PubMed may modify or add additional search terms
to your search to optimize retrieval.
- Click Advanced search Details or see the Search
details portlet to view your search as it was
translated using automatic term mapping and
search rules. - The Query Translation box shows the search
strategy used to run the search. - Translations details how each term was translated
using PubMed's search rules and syntax. - User Query shows the search terms as you entered
them in the search box and any syntax errors with
the query.
57Display settings
From Display Settings, select the number of
items per page to display. You can change the
number of citations displayed on a single page
from 5 to 200 items.
58Sort by
- Sort options include
- Recently Added (Citations in PubMed are displayed
in reverse date added order last in, first out.
The Recently Added date is the date that a record
was initially added to PubMed) - Publication Date(most recent citations first )
- First Author (sort A to Z )
- Last Author (sort A to Z )
- Journal(sort A to Z )
- Title (sort A to Z)
59Send to
- Use Send to for
- Saving citations in a File
- Saving citations temporarily in your Clipboard
- Saving citations permanently in My NCBI
Collections - E-mailing citations
- Ordering journal articles
- Printing search results
601. AGRIS/CARIS (FAO)
- AGRIS (International Information System for the
Agricultural Sciences and Technology) is a global
public domain Database with 2655372 structured
bibliographical records on agricultural science
and technology - The AGRIS initiative was set up by the FAO in the
70s and created a worldwide cooperation for
sharing access to agricultural science and
technology information. Based on available
technologies, AGRIS was initially collecting
bibliographic references for a central database.
However, since the advent of the Internet in the
late 90s AGRIS has become the brand name for a
network of centres, - The Database is maintained by FAO and its content
is provided by more than 150 participating
institutions from 65 countries
611. AGRIS/CARIS (FAO)
- The AGRIS open archives and bibliographical
databases cover the many aspects of agriculture,
including forestry, animal husbandry, aquatic
sciences and fisheries, and human nutrition,
extension literature from over 100 participating
countries. Material includes unique grey
literature such as unpublished scientific and
technical reports, theses, conference papers,
government publications, and more. - 82.11 of records are citations from scientific
journals. The bibliographic references contain
either links to the full text of the publication
or additional information retrieved from related
Internet resources.
621. AGRIS/CARIS (FAO)
632. AGRICOLA
- AGRICOLA (AGRICultural OnLine Access) serves as
the catalog and index to the collections of the
National Agricultural Library, as well as a
primary public source for world-wide access to
agricultural information. - The database covers materials in all formats and
periods, including printed works from as far back
as the 15th century.
642. AGRICOLA
- The records describe publications and resources
encompassing all aspects of agriculture and
allied disciplines, including animal and
veterinary sciences, entomology, plant sciences,
forestry, aquaculture and fisheries, farming and
farming systems, agricultural economics,
extension and education, food and human
nutrition, and earth and environmental sciences. - Although the NAL Catalog (AGRICOLA) does not
contain the text of the materials it cites,
thousands of its records are linked to full-text
documents online, with new links added daily.
652. AGRICOLA
- The NAL Catalog (AGRICOLA) is organized into two
bibliographic data sets - The NAL Online Public Access Catalog contains
citations to books, audiovisuals, serials, and
other materials, most of which are in the
Library's collection. (The Catalog does contain
some records for items not held at NAL.) - The Article Citation Database includes citations,
many with abstracts, to journal articles, book
chapters, reports, and reprints, selected
primarily from the materials found in the NAL
Catalog.
662. AGRICOLA
http//agricola.nal.usda.gov/
673. TREESEARCH
- Treesearch is an online system for locating and
delivering publications by Research and
Development scientists in the US Forest Service. - Publications in the collection include research
monographs published by the agency as well as
papers written by our scientists but published by
other organizations in their journals, conference
proceedings, or books. - Research results behind these publications have
been peer reviewed to ensure the best quality
science. - Treesearch make available all new books,
chapters, and articles beginning January 2004,
and to add older publications as rapidly as
possible. At the start of 2004 the collection
contained over 7,000 publications, making it the
largest freely available collection of online
forestry research in the world.
683. TREESEARCH
- Treesearch lets you search listings by author,
keyword, originating Station or date . Keyword
searches examine both the title and abstract. - Once you have selected a publication, you can
view and print the entire publication online.
That's because all publications listed in
Treesearch have their full text available online,
usually in Adobe's Portable Document Format
(PDF).
693. TREESEARCH
http//www.treesearch.fs.fed.us
70THANK FOR YOUR ATTENTION AND GOOD WORK!!!!!!!
- If you have any requests, suggestions or you need
further information please contact - micaela.decol_at_unipd.it
- biblio.agripolis_at_unipd.it
