Project Management

1
Project Management

• Project Organization
• Jiwei Ma

2
Content

• Introduction
• Organization theory
• Basic organization types
• Project organization and project
• Project team building

3
Introduction

• Project organization is the foundation of project
  management
• Project objective is decisive to project
  organization
• Project organization is designed mainly to carry
  out project controlling

4
Project Objective and Project Organization
Methods Tools
People
Organization
5
Organization Model
Environment
Social structure
Physical Structure
ORG
Culture
Technology
6
Organization Theory

• Organization theory studies,
• The structural components of a system
• Organization structure
• Task breakdown and responsibility definition
• Management functionalities arrangement
• The mechanism and procedure of a system
• The mechanism of material flow
• The mechanism of information flow

7
Development of Organization Theory

• Adam Smith
• efficiency on division of labor ? social
  structure of organization
• Karl Marx
• Relationships between the organization and
  individuals, fundamental antagonism between labor
  and the interests of capital
• Emile Durkheim
• increasing specialization, hierarchy,
  interdependence of work tasks
• formal and informal aspects of organization ?
  tension between economic and human aspects

8
Development of Organization Theory

• Max Weber
• bureaucracy is objective and impersonal ?
  benefits of rationality (formal authority)
• types of social action formal rationality,
  substantive rationality, affectional, traditional
• three types of legitimate Herrschaft rational,
  traditional, charismatic
• Fredrick Winslow Taylor
• Scientific Management method to discover the
  most efficient working techniques for manual
  forms of labor
• close supervision of highly specified physical
  work
• managerial control

9
Development of Organization Theory

• Henry Fayol
• universal principles for the rational
  administration of organizational activities
• principles span-of-control, exceptions,
  departmentation, unity-of-command, hierarchy
• esprit de corps unity of sentiment and harmony
  contribute to the functioning of an organization
• functions of manager planning, organizing,
  command, coordination, control

10
Classical Organization Theory

• The classical organization theory is focused on
  the mechanism of power, authority, and control
• Three types of organizations
• Charismatic authority
• Based on the sacred or outstanding characteristic
  of the individual
• Traditional authority
• Essentially a respect for custom
• Rational legal authority
• Based on code or set of rules
• The last one was regarded as the predominant form
  of organization

11
Classical Organization Theory

• Bureaucracy is the most efficient form of
  organization
• A legal code shall be established for all members
  to obey
• The code form a system of abstract rules, and
  administration looks after the interest of the
  organization within the limit of this system
• The person exercising authority also obeys this
  impersonal order
• Only through being a member does the member obey
  the law
• Obedience is due not to the person who holds the
  authority but to the impersonal order which has
  granted him this position

12
Classical Organization Theory

• The theory is based on the assumption of formal
  and total rationality
• Isolated from the environment
• The primary concern of the theory is
• the behaving mechanism to avoid corruption,
  unfairness, and nepotism within the organization
• instead of the slow, rigid and inefficient
  bureaucracy

13
Organization Theory - Modified

• The modified organization theory has less
  idealistic assumption and established
  organization control principles with more
  practical realism
• Principles
• Division of work - Repetition of the same
  function brings speed and accuracy. Thus work
  should be divided according to skill and
  technical expertise
• Authority and responsibility - Authority is
  linked to responsibility, and together require
  increasing judgment and morality at senior levels

14
Organization Theory - Modified

• Principles
• Discipline essential for the smooth running of
  an organization
• Unity of command an employee should receive
  orders from one superior only
• Unity of direction One and one plan for a group
  having the same objective
• Remuneration of personnel
• Assure fairness
• Encourage keenness by rewarding well-directed
  effort
• Avoid over-payment beyond reasonable limits

15
Organization Theory - Modified

• Principles
• Equity employees must be treated equally and
  fairly
• Stability of tenure of personnel a period of
  stability will help employees to delivery their
  best
• Esprit de corps dividing ones own team is a
  grave sin against the business
• Provide a key to modern organization and possible
  approach to current organizational solutions
• Unable to explain many modern practices
  contradictory to the principles due to the limits

16
Organization Structure

• Hierarchical organization
• Functional organization
• Project organization
• Matrix organization

17
Hierarchical Organization
A
18
Example Army
Division
19
Functional Organization
A
20
Example Typical Functional Organization in
Manufacturing Industry
21
Example Modified Functional Organization
President
22
Functional Organization

• Advantages
• Emphasis of specialization and opportunities for
  employees to obtain professional training and
  advances
• Promotion opportunity for professionals
• Professionals can work for different project at
  same time
• Functional department can be the basis of
  technical continuity and sustainability
• Stability of tenure of professionals

23
Functional Organization

• Disadvantages
• Instead of customers, functional activities
  become the focus of departments
• Its difficult to find a fully responsible person
  for a problem or fault
• Slow and hindered reaction to customers
  requirement due to multi-layer and multi-branch
  management structure
• Negligence of the needs of project and
  individuals working on project
• Difficult for cross-department coordination due
  to communication and information exchange
  barriers, which is critical to the complex project

24
Example Project Organization
General Manager
25
Example Project Organization
Ajax Express Company President
26
Project Organization

• Advantages
• Project manager is fully responsible for the
  project and directly report to senior management
  level
• Members of project team report to project manager
• Separation of project from functional department
  makes communication simple and easy
• Unity of direction enables project teams to
  concentrate on project objective
• Centralization of management expedites the
  decision making process and enable an fast
  reaction
• Unity of command

27
Project Organization

• Disadvantages
• Duplication of resource input when there are more
  than one project
• Waste of critical resources due to project
  managers preparatory inventory
• Inconsistency in companys regulatory management
• Difficulty for communication and information
  exchange
• Lack of stability of tenure and continuity of
  professional career for employees

28
Matrix Organization
A
29
Example Matrix Organization
General Manager
Marketing
Production
Accounting
HR
30
Example Matrix Organization
Ajax Express Company President
31
Multi-level Matrix Organization
A
32
Matrix Organization

• Advantages
• Most of works center around project
• Different projects can share the expertise of
  various functional departments
• Project team member has a strong connection to
  project, while still maintains a sense of
  belonging
• Fast reaction to both internal and external
  requirement
• Part of project team members are from
  administrative department, it helps to maintain
  the consistency in regulatory management
• Easy to maintain the balance of resource input
  among different project

33
Matrix Organization

• Disadvantages
• Lack of the unity of command
• Project manager will concentrate on project
  objective, instead of companys objective
• Its difficult to allocate resources and easy to
  invoke dispute between project managers
• High demand on the coordination between project
  manager and functional department manager

34
Comparison of Various Organization Structures
Functional Matrix Matrix Matrix Project
Functional Light-weight Balanced Heavy-weight Project
Project managers power Few or none Limited middle Strong Fully authorized
Percentage of full time members None 0 25 15 60 50 95 85 100
Project manager position Part-time Part-time Full-time Full-time Full-time
Title for project manager Project Coordinator Project Coordinator Project Manager Project Manager Project Manager
Project administrative personnel Part-time Part-time Part-time Full-time Full-time
35
Project Organization Case

• An office building is fully invested by public
  fund and will be used by a governmental
  institute.
• This institute does not have construction
  specialist or a team to manage the project, so
  its decided to hire a consulting company to
  manage the project under an owners
  representative.
• The owners representative, reporting to the
  director of this governmental institute, will be
  fully responsible for all of the project issues.
• Any decision regarding major functionality and
  project implementation of this office building
  will be made by top management level of this
  institute, and than carried out by the owners
  representative.
• It is also required by law to hire a certified
  consulting company to deal with project
  procurement, and a site supervising company to
  monitor the construction procedure.

36
Project Organization Case

• A state owned company decided to expand its
  production capacity by building a new facility.
• This company has a maintenance team with
  mechanical, electrical, and production equipment
  engineers.
• The top management level assigned an owners
  representative to be responsible for all the
  project issues, who will directly report to the
  president of the company.
• A decision-making committee has been established
  to monitor the project and support the president
  regarding critical decision making procedure.
• The company decided to hire a consulting company
  to provide project management consulting service
  to the owners representative and owners project
  engineers.
• It is also required by law to hire a certified
  consulting company to deal with project
  procurement, and a site supervising company to
  monitor the construction procedure.

37
Project Organization Case

• A foreign invested joint-venture is going to
  build an industrial facility in China.
• This company has a maintenance team with
  mechanical, electrical, and production equipment
  engineers.
• The company has set up a project engineering
  department to deal with project engineering
  issues.
• The director of the project engineering
  department will be reporting to the chief
  operating officer of the company.
• Other functional departments of the company such
  as purchasing, accounting, etc. will also be
  involved in certain project issues.
• A consulting team has been hired as a part of the
  project engineering department to deal with
  project management issues as well as certain
  technical issues during design and construction
  procedure.
• A site supervising company has also been hired to
  monitor the construction procedure.

38
Team Building

• Basic Concept
• Types of Team
• Rules of a Team
• Steps to Build a Team
• Team Effectiveness

39
Team Building

• Basic Concept
• A team is a group of people working towards a
  common goal
• Every team member has his/her own goals in a
  hierarchy system that conform to the common goal
• A team may be a formal organization or an
  informal workgroup
• Team building is the process of enabling that
  group of people to reach their goal

40
Types of Team in Size
41
Types of Team in Size
Type of Team Building Scale Key Factors
Individual 1 person Individual skills and perceptions
Small Team 2-12 people Relationships between people
Team Island 2 or more teams Relationships between teams
Organization 15 people The culture of the organization
42
Team Building

• Rules of a Team
• Purpose Members share the vision and the sense
  of the mission
• Priorities Members know what needs to done next,
  by whom, and by when
• Roles Every member know his own role
• Decisions Authority and decision making lines
  are clearly understood
• Conflict Conflict is dealt openly and is
  considered important issues
• Personal traits members feel their unique
  personalities are appreciated and well utilized.

43
Team Building

• Rules of a Team
• Norms Group norms for working together are well
  established and observed.
• Effectiveness Members find team meetings
  efficient and productive.
• Success Members share the clear view of the
  teams success and the sense of accomplishment.
• Training Opportunities for updating skills are
  provided and taken advantage of by team members.

44
Team Building

• Steps to Build a Team
• Forming
• Storming
• Norming
• Performing
• Adjourning

45
Steps to Build a Team

• Forming
• Personal relations are characterized by
  dependence
• Members have a desire for acceptance by the group
• Members behave to keep things simple and to avoid
  controversy
• Serious topics and feelings are avoided
• Discussion centers around orientation to tasks
  and one another
• To advance to next step, members have to risk
  discussions beyond non-threatening topics with
  possible conflict

46
Steps to Build a Team

• Storming
• Characterized by competition, conflict in
  personal relations and organization of
  tasks/functions
• Conflicts arise when members are organized for
  tasks and structured for function
• Individuals have to bend to suit the group
  organization
• There will be questions over leadership,
  structure, power, and authority
• To advance to the next step, members have to move
  from a testing and proving mentality to a
  problem-solving mentality

47
Steps to Build a Team

• Norming
• Characterized by cohesion and recognition
• Members are willing to change and mold their
  feelings, ideas, attitudes, and beliefs
• Leadership is shared and cliques dissolve with
  more and more sense of group belonging
• Data flow between group members increases and
  creativity is high
• Interactions between members are characterized by
  openness and sharing of information

48
Steps to Build a Team

• Performing
• Not reached by all groups
• Characterized by interdependence in personal
  relations and efficiency of problem solving
• Members can work independently, in subgroups, or
  as a total unit with equal performance
• Roles and authorities can dynamically adjust to
  the changing needs of the group and individuals
• Members are both highly task and people oriented
• Group morale is high and group loyalty is intense

49
Steps to Build a Team

• Adjourning
• Characterized by termination of task behavior and
  disengagement from relationships
• There will be a recognition for participation and
  achievement
• There might be a sense of fear due to the feeling
  of giving up control and inclusion in the group

50
Team Building

• Team Effectiveness
• Team goals are development through team
  interaction and by members willingness
• Participation of team members is high
• Feedback is asked openly and given freely with a
  desire to help
• Decision making is participated actively by all
  members
• Leadership is distributed and shared among team
  members

51
Team Building

• Team Effectiveness
• Problem solving becomes the focal point of team
  work
• Conflict is not suppressed, but openly dealt and
  managed among team members in order to improve
  team performance
• Team member resources (talents, skills,
  knowledge, and experiences) are fully identified,
  recognized, and utilized whenever appropriate.
• Risk taking and creativity are encouraged, while
  mistakes are treated as a source of learning
  rather than reasons for punishment

52
Team Building

• Team Leader
• To put forward exciting vision with team members
  and keep it in front of the team
• To help the team develop principles, including
  norms, success criteria, performance quality
  standards, and reward system
• To facilitate communication and information
  exchange within the team
• To tolerate failure
• To accept group decision even with personal
  disagreement when needed
• To act as interface and buffer between team and
  rest of the world

53
Team Building

• Team Member
• To take responsibility
• To be positive in determining team principles
• To have a positive attitude toward any changes
• To accomplish tasks with a strong feeling of
  control
• To make kind and constructive criticism
• Dont have to be a good friend, but need to be a
  good teammate

54
Thank You

• Jiwei Ma
• jiweima_at_hotmail.com
