CARDIO PULMONARY BYPASS

1
CARDIO PULMONARY BYPASS

• MODERATORDR.POONAM MALHOTHRA
• PRESENTORSDR.SENTHIL
• DR.PRABHU

www.anaesthesia.co.in anaesthesia.co.in_at_gmail.co
m
2
Cardiopulmonary Bypass
provide a non beating bloodless heart with
flow temporarily diverted to an extra-corporeal
circuit that functionally replaces heart and lung
boldest and most decisive feats of mans
mind
3
DEVELOPMENT OF HEART LUNG MACHINE
GIBBON ERA
1930 October 3 Gibbon watches over a patient
die of pulmonary embolism Birth of the idea Work
at Thomas Jefferson Hospital, Philadelphia 1939
use of heparin 1939 CPB in cats and dogs W W -
II interruption
4
1945 GIBBON RESUMES WORK
5
BULL FINCH LAB MGH
6
JOHN GIBBON JR
Coupling extra corporeal circulation, oxygenation
and cardiac surgery 1952 first ASD closure
died autopsy PDA 1953 May 6 2nd patient
Cecelia Bavelok ,16/f ASD closure
7
JOHN GIBBON
8
CPB EQUIPMENT
9

• FUNCTION OF CPB
• Oxygenation and elimination ofco2
• Circulation of blood
• Systemic cooling and re-warming
• Diversion of blood from the heart

10
CPB CIRCUIT
11
CPB CIRCIUT
12
CPB CIRCUIT
Venous canula reservoir pump heat
exchanger oxygenator arterial filter aortic canula
Vent cardiotomy suction gas
blender saftey devices monitoring devices
13
OXYGENATORS
Vertical screen Gibbon Rotating disc
Kay Cross Stationary film
Kirklin Bubble De
Wall Lillehei Membrane
Kolff, Neville
14
(No Transcript)
15
BUBBLE OXYGENATOR
Blood drains into chamber Oxygen diffuses through
diffusion plate -produce bubbles Small bubbles
enhance O2 exchange Large bubbles enhance CO2
removal Easy to prime Inexpensive RISKS Air
embolism gt 2 hours protein denaturation platelet
, complement activation Defoaming
16
MEMBRANE OXYGENATOR

• Imitates natural lung
• Gas exchange across thin membrane
• 2 Types
• Microporous
• Nonporous

17
Membrane oxygenator
MICROPOROUS Polypropelene Small pores impervious
to blood 2 Types 1. Hollow Fiber 2. Parallel
Plate/ Pleated Sheet
18
Membrane oxygenator
Non Porous Methyl Silicone Rubber Increased
priming volume ECMO
19
Membrane Oxygenator
PCO2 controlled by gas flow PO2
controlled by fio2 Safer Less particulate and
gaseous emboli Less reactive
20
BLOOD PUMPS
Ideal Pump Flow Rate 7 Lts/ Min Pressure 500 Mm
Hg Non Damaging No Turbulence Disposable Exact
Calibration Manually Operable
21
BLOOD PUMPS

• 4 Types
• Roller Pump
• Centrifugal Pump
• Pulsatile Pump
• Non Occlusive Roller Pump

22
ROLLER PUMP
23
Roller pump
Since 1956 Positive Displacement Pump Most
commonly used length of tubing inside curved
raceway Predictable pump flow Preload/ Afterload
independent Simple Can be used as vent
24
Roller pump

• PROBLEMS
• Mal occlusion
• Tubing Fracture
• Runaway pump
• Spallation
• Air Pumping
• Cavitation

25
CENTRIFUGAL PUMPS
Since 1976 Rotates and generates a
vortex Magnetically coupled another magnet in
pump head Non Occlusive Pre After load Dependent
26
CENTRIFUGAL PUMPS
Less blood trauma Do not over pressurize
disrupt No tubing wear No spallation No
cavitation Decreased risk of air embolism
27
CENTRIFUGAL PUMPS
DIS ADVANTAGES Lacks versatility in placement No
vent / suction Adds to complexity Adds to
cost Non Pulsatile Retrograde flow
28
VENOUS CANULATION and DRAINAGE
CANULA chosen by Size and AGE WEIGHT 1 STAGE 10
- 46 F 2 STAGE 36- 51 F Flow 1/3 SVC 2/3
IVC CANULATION Bicaval
Cavo atrial Single Atrial Peripheral

29
(No Transcript)
30
VENOUS DRAINAGE
Gravity Siphon Assisted Vacuum Assisted ( VAVD)
Regulated vacuum to closed hard shell
reservoir Kinetic Assisted ( KAVD) centrifugal
pump in venous line Roller pump between
canula and reservoir
31
Advantages of AVD

• Improved venous return
• Lowering the priming volume.
• Alternative venous cannulation sites
• Almost impossible to have an air-lock in the
  venous line.

32
VAVD
33
ARTERIAL CANULAE
Narrowest part of circuit High flow jet Pressure
gradient gt 100 mm hemolysis Choose smallest
canula that will provide calculated flow rate
with a gradient lt 100 mm Hg COANDA EFFECT Jet
stream adheres to boundary lower pressure on
opposite wall carotid hypoperfusion
34
ARTERIAL CANULATION

• Femoral Canulation
• Redo Surgery
• Aortic Surgery
• Minimal Access Surgery
• Severe Atherosclerosis of Asc Aorta

35
TUBING

• Transparent
• Resilient
• Flexible
• Non-kinking
• Hardness

• Toughness
• Inertness
• Smooth
• Non-wettable
• Heat Tolerance
• Blood compatibility

36
TUBING
Size of tube Art- 3/8 th inch, Venous-1/2 inch,
Suction-1/4th inch Latex
Rubber Hemolysis PVC Stiffens Silicone
Rubber Spallation

37
Heparin Bonded Circuits
Increase hemocompatibility Reduced complement
activation Decreased heparin requirement Lower
blood loss Less transfusion requirement
38
TCM
39
Warm and cool patient temp range 4 - 42
c Nonsterile water in manifolds of tubing Water
circulates in opposite direction to that of
blood Heat exchangers _at_
venous reservoir, cardioplegia
delivery

•



40
Venous Reservoir
Hard shell
Hard shell open to atmosphere risk of air
embolism VAVD possible
41
Venous Reservoir
Soft shell collapses on itself decreased risk of
air embolism VAVD not possible
42
VENOUS RESERVOIR WITH INTEGRATED OXYGENATOR AND
HEAT EXCHANGER
43
FILTERS
Screen Filters Woven polyester or nylon Defined
pore size Filter by interception Harder to deair
44
FILTERS
Depth Filters Packed fibre/foam No defined pore
size Filter by impaction and absorption Concern
hemolysis,thrombocytopenia
45
MONITORING
Inline blood gas monitoring HCT Line
pressure Arterial flow meter Temperature
monitoring Expired gas monitoring
46
(No Transcript)
47
