Title: Atomic Absorption Spectroscopy


1
Atomic Absorption Spectroscopy
Prof Mark A. Buntine School of Chemistry
Dr Vicky Barnett University Senior College
2
Atomic Absorption Spectroscopy
  • This material has been developed as a part of
    the Australian School Innovation in Science,
    Technology and Mathematics Project funded by the
    Australian Government Department of Education,
    Science and Training as a part of the Boosting
    Innovation in Science, Technology and Mathematics
    Teaching (BISTMT) Programme.

3
Professor Mark A. Buntine Badger Room
232 mark.buntine_at_adelaide.edu.au
4
Atomic Absorption Spectroscopy
  • AAS is commonly used for metal analysis
  • A solution of a metal compound is sprayed into a
    flame and vaporises
  • The metal atoms absorb light of a specific
    frequency, and the amount of light absorbed is a
    direct measure of the number of atoms of the
    metal in the solution

5
Atomic Absorption SpectroscopyAn Aussie
Invention
  • Developed by Alan Walsh (below) of the CSIRO in
    early 1950s.

6
Electromagnetic Radiation
Sinusoidally oscillating electric (E) and
magnetic (M) fields.
Electric magnetic fields are orthogonal to each
other.
Electronic spectroscopy concerns interaction of
the electric field (E) with matter.
7
The Electromagnetic Spectrum
  • Names of the regions are historical.
  • There is no abrupt or fundamental change in going
    from one region to the next.
  • Visible light represents only a very small
    fraction of the electromagnetic spectrum.

8
The Visible Spectrum
  • l lt 400 nm, UV
  • 400 nm lt l lt 700 nm, VIS
  • l gt 700 nm, IR


9
The Electromagnetic Spectrum
  • Remember that we are dealing with light.
  • It is convenient to think of light as particles
    (photons).
  • Relationship between energy and frequency is


10
Energy Frequency
  • Note that energy and frequency are directly
    proportional.
  • Consequence higher frequency radiation is more
    energetic.

E.g. X-ray radiation (? 1018 Hz) 4.0 x 106
kJ/mol IR radiation (? 1013 Hz) 39.9
kJ/mol (h 6.626 x 10-34 J.s)
11
Energy Wavelength
  • Given that frequency and wavelength are related
    ?c/?
  • Energy and wavelength are inversely proportional
  • Consequence longer wavelength radiation is less
    energetic

eg. ?-ray radiation (? 10-11 m) 1.2 x 107
kJ/mol Orange light (? 600 nm) 199.4 kJ/mol
(h 6.626 x 10-34 J.s c 2.998 x
108 m/s)
12
Absorption of Light
  • When a molecule absorbs a photon, the energy of
    the molecule increases.
  • Microwave radiation stimulates rotations
  • Infrared radiation stimulates vibrations
  • UV/VIS radiation stimulates electronic
    transitions
  • X-rays break chemical bonds and ionize molecules

13
Absorption of Light
  • When light is absorbed by a sample, the radiant
    power P (energy per unit time per unit area) of
    the beam of light decreases.
  • The energy absorbed may stimulate rotation,
    vibration or electronic transition depending on
    the wavelength of the incident light.

14
Atomic Absorption Spectroscopy
  • Uses absorption of light to measure the
    concentration of gas-phase atoms.
  • Since samples are usually liquids or solids, the
    analyte atoms must be vapourised in a flame (or
    graphite furnace).

15
Absorption and Emission
Excited States
Ground State
Multiple Transitions
Absorption
Emission
16
Absorption and Emission
Excited States
Ground State
17
Atomic Absorption
  • When atoms absorb light, the incoming energy
    excites an electron to a higher energy level.
  • Electronic transitions are usually observed in
    the visible or ultraviolet regions of the
    electromagnetic spectrum.

18
Atomic Absorption Spectrum
  • An absorption spectrum is the absorption of
    light as a function of wavelength.
  • The spectrum of an atom depends on its energy
    level structure.
  • Absorption spectra are useful for identifying
    species.

19
Atomic Absorption/Emission/Fluorescence
Spectroscopy
20
Atomic Absorption Spectroscopy
  • The analyte concentration is determined from the
    amount of absorption.

21
Atomic Absorption Spectroscopy
  • The analyte concentration is determined from the
    amount of absorption.

22
Atomic Absorption Spectroscopy
  • Emission lamp produces light frequencies unique
    to the element under investigation
  • When focussed through the flame these frequencies
    are readily absorbed by the test element
  • The excited atoms are unstable- energy is
    emitted in all directions hence the intensity
    of the focussed beam that hits the detector plate
    is diminished
  • The degree of absorbance indicates the amount of
    element present

23
Atomic Absorption Spectroscopy
  • It is possible to measure the concentration of an
    absorbing species in a sample by applying the
    Beer-Lambert Law

e extinction coefficient
24
Atomic Absorption Spectroscopy
  • But what if e is unknown?
  • Concentration measurements can be made from a
    working curve after calibrating the instrument
    with standards of known concentration.

25
AAS - Calibration Curve
  • The instrument is calibrated before use by
    testing the absorbance with solutions of known
    concentration.
  • Consider that you wanted to test the sodium
    content of bottled water.
  • The following data was collected using solutions
    of sodium chloride of known concentration

Concentration (ppm) 2 4 6 8
Absorbance 0.18 0.38 0.52 0.76
26
Calibration Curve for Sodium
A b s o r b a n c e
1.0
0.8
0.6
0.4
0.2
2
4
6
8
Concentration (ppm)
27
Use of Calibration curve to determine sodium
concentration sample absorbance 0.65
A b s o r b a n c e
1.0
0.8
0.6
0.4
?Concentration Na 7.3ppm
0.2
2
4
6
8
Concentration (ppm)
28
Atomic Absorption Spectroscopy
  • Instrumentation Light Sources
    Atomisation Detection Methods

29
Light Sources
  • Hollow-Cathode Lamps (most common).
  • Lasers (more specialised).
  • Hollow-cathode lamps can be used to detect one or
    several atomic species simultaneously. Lasers,
    while more sensitive, have the disadvantage that
    they can detect only one element at a time.

30
Hollow-Cathode Lamps
  • Hollow-cathode lamps are a type of discharge lamp
    that produce narrow emission from atomic
    species.
  • They get their name from the cup-shaped cathode,
    which is made from the element(s) of interest.

31
Hollow-Cathode Lamps
  • The electric discharge ionises rare gas(Ne or Ar
    usually) atoms, which in turn, are accelerated
    into the cathode and sputter metal atoms into the
    gas phase.

32
Hollow-Cathode Lamps
33
Hollow-Cathode Lamps
  • The gas-phase metal atoms collide with other
    atoms (or electrons) and are excited to higher
    energy levels. The excited atoms decay by
    emitting light.
  • The emitted wavelengths are characteristic for
    each atom.

34
Hollow-Cathode Lamps
collision-induced excitation
M
spontaneous emission
M
35
Hollow-Cathode Spectrum
Harris Fig. 21-3 Steel hollow-cathode
36
Atomisation
  • Atomic Absorption Spectroscopy (AAS) requires
    that the analyte atoms be in the gas phase.
  • Vapourisation is usually performed by
  • Flames
  • Furnaces
  • Plasmas

37
Flame Atomisation
  • Flame AAS can only analyse solutions.
  • A slot-type burner is used to increase the
    absorption path length (recall Beer-Lambert Law).
  • Solutions are aspirated with the gas flow into a
    nebulising/mixing chamber to form small droplets
    prior to entering the flame.

38
Flame Atomisation
Harris Fig 21-4(a)
39
Flame Atomisation
  • Degree of atomisation is temperature dependent.
  • Vary flame temperature by fuel/oxidant mixture.

40
Furnaces
  • Improved sensitivity over flame sources.
  • (Hence) less sample is required.
  • Generally, the same temp range as flames.
  • More difficult to use, but with operator skill at
    the atomisation step, more precise measurements
    can be obtained.

41
Furnaces
42
Furnaces
43
Inductively Coupled Plasmas
  • Enables much higher temperatures to be achieved.
    Uses Argon gas to generate the plasma.
  • Temps 6,000-10,000 K.
  • Used for emission expts rather than absorption
    expts due to the higher sensitivity and elevated
    temperatures.
  • Atoms are generated in excited states and
    spontaneously emit light.

44
Inductively Coupled Plasmas
  • Steps Involved
  • RF induction coil wrapped around a gas jacket.
  • Spark ionises the Ar gas.
  • RF field traps accelerates the free electrons,
    which collide with other atoms and initiate a
    chain reaction of ionisation.

45
Detection
  • Photomultiplier Tube (PMT).pp 472-473 (Ch. 20)
    Harris

46
Photomultiplier Tubes
  • Useful in low intensity applications.
  • Few photons strike the photocathode.
  • Electrons emitted and amplified by dynode chain.
  • Many electrons strike the anode.
