Symphony: Distributed Hashing in a Small World

1
Symphony Distributed Hashing in a Small World

• Gurmeet Singh Manku
• Mayank Bawa
• Prabhakar Raghavan

Presented by Satpreet Singh
2
Motivation

• GOAL To maintain a large DHT over a WAN
• DESIRED CHARACTERISTICS
• Scalability (work for a range of network sizes)
• Stability (handle churn)
• Performance (provide low-latency lookups low
  maintenance costs with churn)
• Flexibility (provide design knobs, preferably
  run-time)
• Simplicity (easy to understand, code, deploy)
• SOLUTION Symphony (fuses ideas from Chord
  Klienbergs Small World greedy routing
  algorithm/result)

3
Features/Advantages of Symphony

• Low state maintenance (conseq. of low degree)
• Fewer pings/keep-alives, less (ambient) control
  traffic
• Distributed locking and coordination overhead
  over smaller sets of nodes
• Smaller bootstrapping time when a node joins
• Smaller recovery time when a node leaves
• 2. Smooth out-degree vs latency tradeoff
• Only protocol that offers this tuning knob
  even at run time!
• Out-degree not fixed at runtime, or as
  function of network size.
• 3. Flexibility and support for heterogeneity
• Different nodes can have different number of
  links
• 4. Fault tolerance
• Only short links are bolstered. No backups for
  long links

4
Architecture Overview

• Establish keyspace as 0, 1) (wrap around a
  ring like in Chord)
• Every node manages subrange from own-id. to
  next-clockwise-nodes-id. ( equi-sized)
• Objects hash to m-bit hash-key K, managed by
  node that manages real number containing K/2m
• 2 Short-links one with each immediate neighbor

5
Architecture Overview

• k ( 1) Long Links (uni-/bi-direct.)
• draws a rand. number (x) from a Probability
  Distribution Function
• contacts manager of (x) using a Routing Protocol
• Establishes a link (if incoming links at manager
  2k, if not resample PDF)
• PDF is a type of harmonic distribution (so,
  Symphony)
• Pn(x) 1/(x ln n) in x ? 1/n, 1
• 0 otherwise
• PDF estimates n using an Estimation Protocol

6
Network Size Estimation Protocol

• Goal to estimate n - the current total number
  of nodes in the DHT
• So if,
• - S is any set of s distinct nodes,
• Xs is the sum of segment-lengths managed by them,
• Estimated n s/Xs
• All s nodes update their estimate,
• Experimentally s 3 found good enough,
• So simply use node and its two immediate
  neighbors
• Fact Impact of increasing s on avg. latency is
  insignificant

x Length of arc 1/x Estimate of n
(Idea from Viceroy)
7
Routing Protocol(s)
Klienbergs Small World result A message can be
routed to any node by greedy routing in O(log2n)
hops, in a construction where each node has one
link to each of its 4 directional neighbors and
a single long-distance link to a node chosen from
a suitable PDF. To lookup hash key x ? 0,1),
contact the manager of x Unidirectional
Routing Protocol Node forwards a lookup for x
along (short or long) link that minimizes the
clockwise distance to x Bidirectional Routing
Protocol Node forwards a lookup for x along
(short or long) link that minimizes the absolute
distance to x In both cases, expected path
length in an n-node network with k O(1) links
is O(1/k log2n) hops. Bidirectional
1-Lookahead reduce latency by 40 and 30 each
8
Join/Leave Protocols

• JOIN
• The new node chooses its id x from 0, 1)
  uniformly at random
• Using the routing protocol it identifies the
  current manager of x
• It then runs the estimation protocol using s 3
• X then uses Pnx to establish its long distance
  links
• Cost k links O(1/k log2n) msgs. O(log2n)
  messages
• LEAVE
• All out- and in- links to xs long distance
  neighbors are snapped
• Other nodes whose outgoing links to x are just
  broken, reinstate those links with other nodes
• The immediate neighbors of x establish
  short-links between themselves
• Successor of x initiates estimation protocol
  over s 3 neighbors
• Cost O(log2n) messages

9
Re-linking Protocols etc

• RE-LINKING
• nx xs current estimate of n
• nxlink xs estimate when long distance links
  were last established
• When nx and nxlink differ ? stale estimate
• Re-link only when nx / nxlink is not in the
  range 0.5, 2
• Re-linking gains are marginal, cost high
  O(log2n) messages
• LOOKAHEAD
• Node can maintain list of neighbors neighbors
• Improves choice of neighbor for routing queries
• No extra messages piggyback on keep-alives of
  TCP link
• Cost O(k2) space. Number of long-links remains
  unchanged
• FAULT TOLERANCE
• Deletion of short links more detrimental as
  leads to node isolation
• Make f copies of nodes content in f next
  clockwise nodes

10
Experimental Data

• SETUP
• Large DHT 25 to 215 nodes simulated in network
• Four kinds of test networks
• Static, Expanding, Expanding-Relink Dynamic


Estimate Protocol Performance estimate improves
for log(n) neighbors, but impact on avg. latency
is minimal (later)
11
Experimental Data
Routing Protocol Performance Increasing links
beyond 2 has marginal benefits. Bidirectional
routing is good (30 reduction in latency)
12
Experimental Data

• Lookahead Performance
• 1-Lookahead reduces avg. latency by 40 for
  small value of k.
• Also, it does not entail an increase in the no.
  of long-links per node.
• Neighbor-lists are exchanged periodically
  piggy-backed on normal routing traffic or
  keep-alives

13
Experimental Data

• Fault-tolerance motivation
• Left On deleting a random set of links (short
  long), successful lookups drops quite quickly
  deletion of short links causes node isolation
  quickly
• Right Impact of removing only long links not
  as severe (and only avg. latency goes up)
• Thus, only fortify short links. Make f copies of
  content in clockwise direction.

14
Comparisons Conclusions

• Conclusions
• For large DHTs, (25 to 215 nodes) Symphony
  outperforms others
• Avg. TCP links 10 Latency is about 8 hops
• Lower costs of Join/Leave compared to Chord etc.
• Number of neighbors not fixed at outset No
  backup links

15
Wrapping up

• Symphony...
• is a simple protocol for managing large DHTs
• supports a dynamic network of hosts with
  relatively short lifetimes
• scales well
• has low lookup latency
• has low maintenance cost
• requires few neighbors per node
• supports heterogenity in nodes (run-time knobs)
• provides flexibility in design

Questions ?
