Exam Revision

1
Exam Revision
100 Questions
2

1. What is the correct name for this tool?

Diagonal Cutters
End Cutters
Engineers Pliers
Long Handled Pliers
Blacksmiths Tongs
3
2. Which of the following images shows a Tee
Hinge?
4
DowelJoint
Rebate Joint
Mortise and Tenon joint
Cross halving Joint
Bridle Joint
Dovetail Joint
Through Housing Joint
3.What is the correct name for the joint shown on
the left
5
5. What do the Vernier callipers shown below read?
3.4mm
3.6mm
5.6mm
10.2mm
6

• 6. On the diagram above indicate the dial that
  makes the blade move in and out.
• (The blade adjustment nut )

7
Try Plane
6. What is the correct name for this
plane?
Shoulder Plane
Smoothing Plane
Compass Plane
Rebate plane
Bull Nose Plane
Block Plane
Jack Plane
8
7. What is the correct name for a square
notch cut along the side of a board?
Rebate
Tongue
Chamfer
Groove
9
8. What is the most suitable adhesive for gluing
Plastic Laminate to a Kitchen Worktop
PVA
Epoxy Resin
Impact Adhesive
Cascamite
Tensol Cement
10
9. .Where on the graph would you find the 50th
percentile?
11
10. What is the most suitable adhesive to glue
together this chest of drawers?
PVA
Epoxy Resin
Impact Adhesive
Cascamite
Tensol Cement
12
11. What is the most suitable adhesive to
glue together acrylic?
PVA
Epoxy Resin
Impact Adhesive
Cascamite
Tensol Cement
13
12. What is the correct name for the wood tool
shown below?
Parting tool
Scraper
Gouge
Skew Chisel
14
13. On the Lathe above, where is the Chuck?
15
14. Why is aluminium the most suitable material
for casting in the school workshop?
Because it has a low melting point
Because it melts quickly
Because it is Non Ferrous
Because it is lightweight
16
15. On the diagram to The left where is the
Countersink
17
Oven
Fluidising Tank
Vacuum Former
Strip Heater
16.What is the correct name for the machine shown
above
18
17) On the diagram above indicate the Drag
19
18. What is the correct name for the type of
tool shown below?
Parting tool
Knife Tool
Roughing tool
20
Blind Rivets
Pop Rivets
Countersunk rivets
Snap Head Rivets
19.What is the correct name for the rivets shown
above?
21
20.Where on the graph would you find the 95th
percentile?
22
21. What is the correct name for thistool?
Cope
Rapping Iron
Rammer
Striking Off Rod
Sprue Pin
Draw Pin
Vent Spike
Gate Cutter
23
22. What is the missing size from the
cutting list below
End
Click on the correct answer from the choices below
80 90 100 110 120 130 140 150 160 170
24
23. On the Lathe above, where is theToolpost?
25
24. Where is the Compound Slide?
26
25. Which of the images above shows a Countersunk
Wood Screw?
27
26. What is the correct name for the tool shown
below
Rivet Bar
Rivet Set Snap
Rivet Punch
Riveter
28
27. What is a hand countersink used for?
Centre Punching Holes
Removing Burrs
Drilling Holes
29
28) On the diagram above indicate the Cope
30
29. Which of the following images shows a Butt
Hinge?
31
Slow the lathe down
Speed the lathe up
30. State one safety precaution you would take
when turning large diameter work on the wood
lathe?
32
31. On the image above which tool is a Die
33
32. What is the correct name for the wood tool
shown below?
Parting tool
Scraper
Gouge
Skew Chisel
34
33. Which drawing shows a Blind Hole
35
34. On the image above which tool is the Plug Tap
36
35. Which metal is most suited to casting in the
school workshop?
Steel
Copper
Brass
Aluminium
37
36. What is the correct name for this tool?
Tinsnips
Pliers
End Cutters
Shears
38
DowelJoint
Rebate Joint
Mortise and Tenon joint
Cross halving Joint
Bridle Joint
Dovetail Joint
Through Housing Joint
37. What is the correct name for the joint shown
on the left
39
38. Which of the following tools would be used to
cut 6mm Dia steel bar?
A Coping Saw
A Piercing saw
A Panel Saw
A Jnr Hacksaw
40
39. What is the most suitable adhesive to glue
together this garden bench?
PVA
Epoxy Resin
Impact Adhesive
Cascamite
Tensol Cement
41
40. What is another name for Mole Grips?
Self Grip Pliers
Engineers Pliers
Long nose Pliers
Stillson
Plumbers Wrench
42
Aesthetic
Gardengnome
Ergonome
Ergonomics
41.What is the correct name for the scaled wooden
figure often used by designers ?
43
42. Which of the following planes would be used
to plane a long uneven edge?
A Smoothing Plane
A Jack Plane
A Block Plane
A Try Plane
44
43. What is the missing size from the cutting
list below
Base
Click on the correct answer from the choices below
5 10 15 20 30 40 70 80 90 120
45
44. Where is the Forked Centre ?
46
45. What major advantage does a Stillson
Wrench have over an Adjustable Spanner?
It is cheaper to buy
It is easier to use
It can grip round objects like pipe
It has been drop forged
47
46. What is the correct name for this tool?
Tin Snips
Heavy Duty Snips
Jewellers Snips
Diagonal Cutters
48
47. Which tool is designed to cut rivets?
Engineers Pliers
Long Nose Pliers
Diagonal Cutters
End Cutters
49
48. Which of the above pictures shows the pattern
with the correct taper?
50
49. What does Ergonomics mean?
The study of the dimensions of the human body
The Study of the human body in its working
environment
The study of sensory values,
51
50. Where on the graph would you find the 5th
percentile?
52
51. What is the correct name for the drill bits
shown on the left
Forstner bits
Flat Bits
Masonry Bits
Twist Drills
Centre drills
53
Oven
Fluidising Tank
Vacuum Former
Strip Heater
52. What is the correct name for the machine
shown above
54
Oven
Fluidising Tank
Vacuum Former
Strip Heater
53. Which machine was used to make the chocolate
box inserts shown on the left?
55
Anodising
Painting
Plastic dip coating
Galvanizing
54.What is the correct name for the process of
coating Mild steel in molten Zinc
56
DowelJoint
Rebate Joint
Mortise and Tenon joint
Cross halving Joint
Bridle Joint
Dovetail Joint
Through Housing Joint
55. What is the correct name for the joint shown
on the left
57
56. What does Anthropometrics mean?
The study of the dimensions of the human body
The Study of the human body in its working
environment
The study of sensory values,
58
57. What is the missing size from the cutting
list below
Side
Click on the correct answer from the choices below
130 140 240 260 280 300 320 340 370 390
59
58. Where is the Revolving Centre?
60
Bridle Joint
Dowel Joint
Rebate Joint
Dovetail Joint
Mortise and Tenon joint
Through Housing Joint
59. What is the correct name for the joint shown
above
61
Oven
Fluidising Tank
Vacuum Former
Strip Heater
60.What is the correct name for the machine shown
above
62
61.Which of the images above shows a Round Head
Wood Screw?
63
Bridle Joint
Dowel Joint
Rebate Joint
Dovetail Joint
Mortise and Tenon joint
Through Housing Joint
62.What is the correct name for the joint shown
above
64
Connectors
Bolts
Connecting Blocks
Knock down fittings
63. What is the generic name for these fixings?
65
64. Where is the Headstock?
66
65. What is the correct name for the wood tool
shown below?
Parting tool
Scraper
Gouge
Skew Chisel
67
Pop Rivets
Countersunk rivets
Snap Head Rivets
66. What is the correct name for the rivets shown
above?
68
67. Which tool is designed for working in tight
areas and cutting fine wire?
Engineers Pliers
Long Nose Pliers
Diagonal Cutters
End Cutters
69
68. Which of the following images shows a
PianoHinge?
70
69. Which of the following metals is Ferrous
(Contains Iron)
Aluminium
Copper
Brass
Stainless Steel
71
70. Which of the following metals is an Alloy
Aluminium
Copper
Lead
Brass
72
71. Which of the following woodscrews will
Rust if exposed to the rain
Steel
Brass
Stainless Steel
73
72. Which of the following terms would not
be classed as Aesthetic?
Colour
Size
Proportion
Shape
Form
Weight
Line
74
73. What is the correct name for these tools?
Centre Punches
Nail Punches
Parallel Punches
Letter Punches
75
74. What is Brazing Rod made from?
Steel
Copper
Brass
Aluminium
76
75. Which of the following planes would be
used to level off the base of a through
housing joint.
77
76. Letter stamps can be used to stamp letters on
which of the following?
Perspex
Acrylic
Aluminium
High Speed Steel
78
Dowel Joint
Rebate Joint
Mortise and Tenon joint
Cross halving Joint
Bridle Joint
Dovetail Joint
77. What is the correct name for the joint shown
above
Through Housing Joint
79
Anodising
Painting
Plastic dip coating
Galvanizing
78. What is the correct name for the process used
to coat the handle of the trowel with plastic?
80
79. What are Toolmakers clamps used for?
The Toolmakers clamp can be used to hold small
pieces of work while it is being brazed
The Toolmakers clamp can be used to hold small
pieces of work while working on them
The Toolmakers clamp can be used to hold small
pieces of work while it is being welded
81
80. Which tool could be used to create
this dimpled pattern on the back of this
drawer handle?
Cross Pein Hammer
Repousse Hammer
Pillar Drill
Centre Punch
Parallel Punch
82
81. Which of the following tools would be used to
cut 0.5mm thick Copper Sheet?
A Coping Saw
Tin Snips
A Panel Saw
Engineers Pliers
83
82. Which metalwork technique is illustrated in
the pictures below
Facing
Tapering
Knurling
Drilling
84
83. What is the correct name for the process
shown below
Forging
Welding
Casting
Brazing
Turning
85
84. On the image above which tool is a Tap
86
85. What is the correct name for the process
shown below
Forging
Welding
Casting
Brazing
Turning
87
86. The Handle of this box will be turned on a
lathe. What length of a piece of wood is required?
Handle
Click on the correct answer from the choices below
130 140 240 260 290 300 390 440 470 490
88
87. What is the correct name for the process
shown below
Forging
Welding
Casting
Brazing
Turning
89
88. What is the correct name for the process
shown below
Forging
Welding
Casting
Brazing
Knurling
90
89. What is the correct name for the drill bit
shown on the left
Forstner bit
Flat Bit
Masonry Bit
Twist Drill
Centre drill
91
90. What is the correct name for the machine
shown on the left
Mig Welder
Spot Welder
Tig Welder
Arc Welder
92
91. On the diagram to The left where is the
pilot hole
93
92. Which of the following hardwoods is most
suited for the manufacture of a garden bench?
Mahogany
Teak
Birch
Rosewood
Balsa
94
93. Which of the following hardwoods is most
suited for the manufacture of chopping board?
Oak
Beech
Elm
Rosewood
Balsa
95
94. What is the correct name for the material
shown on the left?
Plywood
MDF
Hardboard
Blockboard
Pine
Chipboard
Veneered Chipboard
Mahogany
96
95. What is the correct name for the material
shown on the left?
Plywood
MDF
Hardboard
Blockboard
Pine
Chipboard
Veneered Chipboard
Mahogany
97
96. What is the correct name for the material
shown on the left?
Plywood
MDF
Hardboard
Blockboard
Pine
Chipboard
Veneered Chipboard
Mahogany
98
97) On the diagram above indicate the Runner
99
98. What is the correct name for the material
shown on the left?
Plywood
MDF
Hardboard
Blockboard
Pine
Chipboard
Veneered Chipboard
Mahogany
100
99. What is the main disadvantage to using
an adjustable spanner
It takes time to adjust the spanner to the
correct size.
The adjustable Spanner has a tendency to round
the corners of the nut or bolt.
Adjustable spanners are bigger than ordinary
spanners.
101
100. Where is the tailstock ?
102
Quiz Completed
Well Done
103
?
Wrong
Click here to try again
