Astronomical Units

1
Astronomical Units Light Years

• Project

2
Distance in Space
An ellipse is an oval-shaped path.
An astronomical unit (AU) is the average distance
between Earth and the sun it is about 150
million kilometers.
Light-year The distance that light travels in one
year, about 9.5 trillion kilometers or 63,240 AU
3
The speed of light is the fastest speed that
could EVER be achieved. The speed of light is
300,000 km per SECOND!! (Thats 186,000 miles per
second) Light takes 2 seconds to reach the
Earth from the moon - it takes it 8 minutes to
reach the Earth from the Sun
4
If you were in a spaceship that travelled at the
speed of light and you started a journey from the
Sun it would take about 3 minutes to reach
Mercury, 5 minutes to reach Venus, 8 minutes to
reach the Earth, 51/2 hours to reach Pluto, 4
years to reach the next star, 5000 years to
reach the edge of the galaxy, 50,000 years to
reach the next galaxy, 500,000 years to reach
the next Cluster!!
5
Real rockets dont travel at the speed of light,
they travel MUCH slower. The Apollo missions
took 4 days to reach the moon - at the speed of
light it would have taken 2 seconds!! These
rockets were travelling roughly 200,000 times
slower than light. At this speed it would take
125 YEARS to get to Pluto!
6
The Astronomical Unit, au
Earth
The Earths orbit around the sun is not circular
it is elliptical
Sun
7
The Astronomical Unit, au
Earth
The average radius of the orbit is defined as
one astronomical unit, au
Sun
8
The Astronomical Unit, au
Earth
1 au 1.49 x 1011m
about 150 million kilometers
Sun
9
A model of our Solar System

• You will make a scale model with proportional
  astronomical units with respect to the sun
• Make Earth 5 mm in diameter and the rest of the
  planets to scale with respect to the Earth
• Use the internet and/or you Prentice Hall book to
  determine the colors and appearance of each planet

10
Table 1 Planet Distances
Planets Distance from the edge of the Sun in AU
Mercury .39
Venus .72
Earth 1.0
Mars 1.5
Asteroid Belt 2.5-2.8
Jupiter 5.2
Saturn 9.2
Uranus 19.2
Neptune 30.0
Pluto 39.4
1 AU 10 cm
3.9 cm
0.39 AU 3.9 cm
Measure from the outer edge of the sun to the
leading edge of the planet
11
Table  2 Planet Diameters
Planets Diameter (mm)
Mercury 2.0
Venus 4.75
Earth 5.0
Mars 2.65
Jupiter 56.0
Saturn 47.0
Uranus 20.0
Neptune 19.0
Pluto 1.0
0.2 cm
2.0 mm 0.2 cm
12
10 millimeters
?
1 centimeter
13
7.2 centimeters
3.9 centimeters
Venus
Mercury
