World famous Surface chemists

1
World famous Surface chemists
2
Professor Gabor A. Somorjai Department of
Chemistry, University of California, Berkeley
3

• Developing low-energy electron diffraction (LEED)
  for surface crystallography.
• Using LEED, high-resolution electron energy loss
  spectroscopy (HREELS), and sum frequency
  generation (SFG) to identify the bonding of
  hydrocarbons as being similar to that in
  organometallic clusters.
• the development of molecular surface science at
  high pressures, pioneered the use of monolayer
  sensitive techniques that could be used for
  molecular studies at the solid-gas and
  solid-liquid interface using high pressure-high
  temperature STM and SFG.

4
Editor-in-chief of Catalysis Letters and serves
on the editorial board of eight other journals
5
Professor Gerhard Ertl Director,
Fritz-Haber-Institut der Max-Planck-Gesellschaft,
Berlin
6

• Fundamental reactivity knowledge of catalytic
  mechanisms gained from the modern surface science
  approach.
• Correlate catalytic reactivity with the structure
  and composition of the heterogeneous catalytic
  surface as in ammonia synthesis.
• Further applied this knowledge base to the
  synthesis of specific microstructures on the
  surface to carry out specific reactions in high
  selectivity.

7

• Studies on carbon monoxide oxidation on specific
  Pt crystallographic planes revealed the dynamics
  of the oscillatory behavior of the chemisorbed
  surface species.
• The development of the instrumentation that makes
  these observations possible is regarded as a
  breakthrough in surface science and a key step in
  developing our understanding of the very rapid
  and dynamic changes that many heterogeneous
  catalyzed reactions experience.

8
(No Transcript)
9
Vacuum Technology

• How to construct a simplified Ultra-high Vacuum
  (UHV) system?

10
(No Transcript)
11
Why is ultra-high vacuum (UHV) necessary?

• Monolayer time
• the time it takes to contaminate a surface
  with a single layer of molecular adsorbates
• the monolayer time can be estimated as
• t 4.2 10-6 / P
• where t seconds, P Torr.

12
Want 1 hour to do an experiment?
1 atmosphere 1.0133
bar 1 atmosphere
760 torr 1 atmosphere
1.0133105 Pa 1 torr
1 mm Hg 1 micron Hg
1 milliTorr 1 millibar
100 Pa 1
torr 133.32 Pa
1 millibar
0.75 Torr
The pressure needed for for one hour to
monolayer time is equal to P lt 110-9 Torr
13
Base pressure?

• At least
• P lt 2 10-10 Torr

14
A common unit for gas dose

• Langmuir (L) is defined as,
• an exposure of gas at room temperature at a
  pressure of P 1 10-6 Torr for 1 second (L
  10-6 T?s)

If one monolayer is created for 1 L exposure, one
should get 1 monolayer in one hour at a pressure
of P 10-6 / 3600 3 10-10 Torr.
15
Vacuum theory and pumping laws
How the vacuum is created?
16
Production of vacuum

• to reduce gas density in given volume to below
  atmospheric pressure with pump
• enclosed vessel has continuous sources which
  launch gas into volume and present pump with
  continuous gas load
• vacuum achievable at steady state is result of
  dynamic balance between gas load and ability of
  pump to remove gas form volume

17
Vacuum Theory using Ideal Gas Properties

• Mean velocity of a gas molecules of mass M, at
  absolute temperature T, is given by

At T 0 oC He 1200 m/s Ar
380 m/s N2 453 m/s
H2O 564 m/s
18

• Mean free path, which is used to define the
  various regions of gas flow, is given by
• for air at R.T., ? (mm) 6.6/P, P in Pa
• Particle flux, or the number of particle striking
  a surface per unit area, or passing through an
  imaginary plane of unit area, is given by

19

• The pressure, according to ideal gas law, is
  given by
• P nkT
• For a fixed volume containing a mixture of
  different non-interacting gases,

20
The Three Regions of Gas Flow

• When ?/d ltlt 1, the flow is vicious, where the
  vicious force is independent o the pressure.
• When ?/d gtgt 1, it is in the free-molecular flow
  regime, where the vicious drag is linearly
  proportional to pressure.
• A third regions of gas-flow, Knudsen or
  transition flow, is often used to describe the
  region between these two limits.

21
Molecular Transport and Pumping Laws

• Three parameters P, S, Q
• P pressure Torr
• S volumetric flow liter/sec
• Q throughput Torrliters/sec
• QTorrliters/sec PTorrSliter/sec

22

• Complete pumping equation is
• Q SP VdP/dt
• No pumping (S 0), just a closed chamber with a
  constant gas load from outgassing and/or leaks.
• P (Q/V)t
• Negligible outgassing or other leaking sources, Q
  0, corresponding to Q ltlt SP,
• P Poe-(S/V)t

23
Pumping law in the High and Ultra-high vacuum
regions

• The ultimate pressure is the behavior of the gas
  load over time.
• In the HV and UHV region, the pressure decrease
  with time (no leaks!),
• P(t2) P(t1)(t1/t2)
• The final base pressure is related to some
  ultimate values of Q and S,
• Po Qo/So

24
Sources of Gases in Vacuum Systems

• Leaks through vacuum vessel.
• Virtual leaks from trapped gas volumes.
• Vaporization of volatile material.
• Surface outgassing from adsorbed gases on walls
  of vessel.

25

• Volume outgassing from diffusion of dissolved
  gases in bulk material of vessel.
• Permeation through porous material or seals of
  vessel.
• Backstreaming of volatile fluids from pump.

26
Idealized initial pumpdown of a 100 L system,
size 505040 cm, with a roughing pump and UHV
pump.
27
The UHV region can only be achieved by bakeout.
28
Measurement of pressure

• Mechanical phenomena gauges measure actual force
  exerted by gas (e.g. manometer).
• Transport phenomena measuring gaseous drag on
  moving body (e.g. spinning rotor gauge) or
  thermal conductivity of gas (e.g. thermocouple
  gauge).
• Ionization phenomena gauges ionize gas and
  measure total ion current (e.g. ion gauge).
• Partial pressure residual gas analyzersmass
  spectrometers.

29
Vacuum gauges must calibrated by

• Comparison with absolute standard calibrated from
  its own physical properties.
• Attachment to calibrated vacuum system.
• Comparison with calibrated reference gauge.

30
Vacuum gauges used in vacuum systems
31
Thermocouple gauge
For roughing vacuum (molecular flow regime)
measurements
32
Ionization gauges

• Thermionic/hot cathode ionization gauges.
• Energetic beam of electrons (constant I-) used to
  ionize gas molecules and produce ion current.
• I p KI -, K ion gauge sensitivity
• Upper pressure limit (10-3 Torr) secondary ion
  ionization excitation, filament burn out.
• Lower pressure limit (10-10 Torr) secondary
  electron current from X-ray emission.

33
Diagram of an ion gauge for measuring UHV
34
Residual gas analyzers

• More compact mass spectrometers with higher
  sensitivity.
• Gaseous ions formed in ion source box by electron
  bombardment, extracted with suitable fields,
  separated in analyzer and then collected and
  measured.
• Magnetic sector analyzer masses separated by
  static magnetic and electric fields.
• Quadrupole mass analyzer masses separated in
  oscillating quadrupolar electric field.

35
The RGA 100 Residual Gas Analyzer
36
Quadrupole Mass Filter Components
37
Principles of Filter Operation
38
Residual Gas Analysis
39
Vacuum pumps and their characteristics

• Gas transfer pumps
• (a) Positive displacement pumps that transfer
  repeated volumes of gas from inlet to outlet by
  compression ( e.g. rotary pump).
• (b) Kinetic pumps that continuously transfer gas
  from inlet to outlet by imparting momentum to gas
  molecules (e.g. Diffusion pump, turbomolecular
  pump).

40

• Entrapment/capture pumps,
• retain molecules by sorption or condensation
  on internal surfaces (e.g. sorption pump,
  sublimation pump, sputter ion pump, cryogenic
  pump).

41
The different vacuum pumps
42
1. Roughing pumps (1 atmosphere to 1-10 micron)

• Rotary vane (oil) mechanical pumps
• low cost, durable, long life
• high pumping speed
• oil-backstreaming must be controlled
• Cryosorption pumps (sorption pumps)
• very clean
• inexpensive and simple
• limited capacity, frequent reconditioning

43
Rotary vane mechanical pumps
44
(No Transcript)
45
Sorption pumps
The sorption pump has no moving parts and
therefore no oils or other lubricants. (5 liters
of liquid nitrogen)
46
(No Transcript)
47
2. Diffusion pumps (high vacuum and UHV)

• Low cost per unit pumping speed, very high
  pumping speeds
• Very well understood
• Hard to destroy
• Continuous operating expense (LN2)
• Potential for serious vacuum accidents
• Open systemForbidden in certain applications

48
(No Transcript)
49
3. Turbomolecular pumps (high vacuum and UHV)

• Medium to high cost per unit pumping speed
• Very clean, pumps rare gases
• Requires periodic maintenance which can be
  expensive
• Difficult to reach very low UHV base pressures
• Open systemForbidden in certain applications

50
A typical turbomolecular pump
51
? High vacuum port ? Three-phase motor ?
Water-cooling ? Stator package ? Rotor ? Motor
shaft ? Ball bearing ? Lubrication duct ?
Fore-vacuum port
52
4. Titanium sublimation pumps (HV and UHV)

• Very inexpensive and simple
• Requires periodic maintenance, which is cheap
• Often misused, which limits their performance
• Selective in what it pumps (good for oxygen, N2,
  air, not for rare gases)

53
A typical titanium sublimation pump
54
(No Transcript)
55
5. Cryopumps

• Expensive per unit pumping speed
• Very high pumping speeds are possible
• Pumping hydrogen (pumps everything)
• Requires periodic recharging
• Vibration can be a serious problem

56
6. Ion pumps (also called sputter-ion pumps)

• Expensive per unit pumping speed
• Low pumping speed
• Generates hydrocarbons
• Has a memory effect
• Very low maintenance
• Moderately difficult to destroy
• Excellent base pressures

57

• Does not pump rare gases well
• Does not pump hydrogen
• Closed system very safe against vacuum accidents

A typical ion-pump
58
(No Transcript)
59
(No Transcript)
60
An ideal UHV work-station consists of several
types of pump used in different applications

• a cryo-sorption pump or trapped rotary pump for
  initial pumpdown from atmosphere
• a turbo-molecular pump to pump rare gases, assist
  in initial pump-down, and to pump load-locks
• an ultra-high vacuum pump. Depending on the
  application, this can be an ion-pump/Ti
  sublimation pump, or a diffusion pump.

61
The baking of an UHV system
62
Simplified vacuum system design

• Materials for ultra-high vacuum
• Construction materials for UHV
• Common vacuum problems

63
Materials for Ultra-high vacuum
64
Properties required

• (a) Low vapor pressure.
• (b) Bakeable to gt 200 oC without losing
  mechanical strength.
• (c) Impermeable to gases.

65
(d) Inert towards reaction with other materials
in system or vacuum process. (e) Inert towards
irradiation by electromagnetic or particle
beams. (f) Easy machining and fabrication into
suitable components.
66
Metals

• (a) Stainless steel
• Excellent all round material.
• Distortion during welding.
• (b) Aluminum and aluminum alloys
• Good corrosion resistance, easily machined and
  jointed.
• Poor strength at high temperatures, high
  distortion when welding .

67

• (c) Nickel alloys
• High strength at high temperatures, excellent
  corrosion resistance.
• High cost, machining problems.
• (d) Copper
• Easily machined, good corrosion resistance,
  especially oxygen free, high conductivity grade
  (OFHC) material.
• Difficult to braze in hydrogen atmosphere.

68

• (e) Brass
• Good corrosion resistance.
• Zinc evaporates out at temperatures above 100 oC.
• (f) Mild steel
• Not generally used as it is liable to rust.

69
Plastics

• (a) PTFE low outgassing rate, good electrical
  insulator, heat resistant, self lubricating.
• (b) Polycarbonate moderate outgassing rate and
  water absorption, good electrical insulator.

70

• (c) Nylon and acrylic high outgassing rate and
  water absorption rates, self lubricating.
• (d) PVC high outgassing rate and water
  absorption rates.
• (e) Polyethyene only suitable if well outgassed.
• (f) Nitrile rubber easily jointed, sealing
  rings.
• (g) Viton low outgassing, heat resistant,
  sealing rings.

71
Common vacuum problems

• Improper cleaning techniques
• Incompatible materials
• Leaks
• Virtual leaks
