Title: Paul Scherrer Institute


1
Paul Scherrer Institute
Stefan Ritt
The PSI DRS4 Integrated Circuit Chip
2
Agenda
  • Introduction to Switched Capacitor Array Chips
  • Comparison with FADCs
  • Overview of chips on the market
  • The DRS4 chip
  • Design principles
  • Special features
  • Some applications
  • New ideas for DRS5 chip to be designed in 2011
  • Increased bandwidth
  • Zero dead time

3
Introduction toSwitched Capacitor ArrayChips
4
Detectors in Particle Physics
  • Particles interact with matter and produce light

Signal
100s mV
10-100 ns
5
Flash ADC Technique
FADC
Q-sensitive Preamplifier
60 MHz12 bit
Shaper
PMT/APD Wire
Amplitude
TDC
Time
  • Shaper is used to optimize signals for slow 60
    MHz FADC
  • Shaping stage can only remove information from
    the signal
  • Shaping is unnecessary if FADC is fast enough
  • All operations (CFD, optimal filtering,
    integration) can be done digitally

6
Nyquist-Shannon Theorem
  • If a function x(t) contains no frequencies higher
    than F Hertz, it is completely determined by
    giving its ordinates at a series of points spaced
    1/(2F) seconds apart.

If a detector produces frequencies up to 500 MHz
(0.6 ns rise time), all information from that
detector is recorded if sampled at 1 GSPS with
good enough signal-to-noise ratio
7
How to measure best timing?
Simulation of MCP with realistic noise and
different discriminators
K. Byrum, H. Frisch, J.-F. Genat et al., IEEE
Trans.Nucl.Sci.57, 525 (2010)
8
Currently available fast ADCs
  • 8 bits 3 GS/s 1.9 W ? 24 Gbits/s
  • 10 bits 3 GS/s 3.6 W ? 30 Gbits/s
  • 12 bits 3.6 GS/s 3.9 W ? 43.2 Gbits/s
  • 14 bits 0.4 GS/s 2.5 W ? 5.6 Gbits/s

24x1.8 Gbits/s
  • Requires high-end FPGA
  • Complex board design
  • FPGA power

1.8 GHz!
9
ADC boards
  • PX1500-4 2 Channel3 GS/s8 bits
  • ADC12D1X00RB 1 Channel 1.8 GS/s 12 bits

1-10 k / channel
10
Switched Capacitor Array
0.2-2 ns
Inverter Domino ring chain
IN
Waveform stored
Out
FADC 33 MHz
Clock
Shift Register
Time stretcher GHz ? MHz
11
Switched Capacitor Array
  • Cons
  • No continuous acquisition
  • Limited sampling depth
  • Nonlinear timing
  • Pros
  • High speed (5 GHz) high resolution (11.5 bit)
  • High channel density (9 channels on 5x5 mm2)
  • Low power (10-40 mW / channel)
  • Low cost ( 10 / channel)

Dt
Dt
Dt
Dt
Dt
Goal Minimize Limitations
12
The DRS4 Chip
13
Design Options
  • CMOS process (typically 0.35 0.13 mm) ?
    sampling speed
  • Number of channels, sampling depth, differential
    input
  • PLL for frequency stabilization
  • Input buffer or passive input
  • Analog output or (Wilkinson) ADC
  • Internal trigger
  • Exact design of sampling cell

PLL
Trigger
ADC
14
DRS History
1995
DSC
Roger Schnyder, Christian Brönnimann, pb
Tiny signal
20 pF
0.2 pF
DRS1
2002
I
Temperature Dependence
kT
2004
DRS2
Roberto Dinapoli
DRS3
2007
2008
DRS4
PLL-regulated Sampling Speed
15
DRS4
  • Fabricated in 0.25 mm 1P5M MMC process(UMC), 5
    x 5 mm2, radiation hard
  • 81 ch. each 1024 bins,4 ch. 2048, , 1 ch. 8192
  • Passive differential inputs/outputs
  • Sampling speed 700 MHz 5 GHz
  • On-chip PLL stabilization
  • Readout speed 30 MHz, multiplexedor in parallel

16
12 bit resolution
lt8 bits effective resolution
11.5 bits effective resolution
17
Bandwidth
  • Bandwidth is determined by bond wire and
    internalbus resistance/capacitance
  • 850 MHz (QFP), 950 MHz (QFN), ??? (flip-chip)

2 nH
Bond wire
Parasitic 10 pF
finalbus width
QFP package
850 MHz (-3dB)
Simulation
Measurement
Ueli Hartmann
18
Bump Bonding
  • Reduce input inductance by using
  • bump bonding instead of wire bonding

200 mm
75 mm
19
How to minimize dead time ?
  • Fast analog readout 30 ns / sample
  • Parallel readout
  • Region-of-interestreadout
  • Simultaneouswrite / read

AD9222 12 bit 8 channels
20
ROI readout mode
normal trigger stop after latency
delayed trigger stop
Trigger
stop
Delay
33 MHz
e.g. 100 samples _at_ 33 MHz ? 3 us dead time ?
300,000 events / sec.
readout shift register
Patent pending!
21
Daisy-chaining of channels
Domino Wave
Domino Wave
clock
clock
enable input
enable input
Channel 0
1
Channel 0
0
enable input
enable input
Channel 1
0
Channel 1
1
Channel 2
1
Channel 2
0
Channel 3
0
Channel 3
1
Channel 4
Channel 4
0
1
Channel 5
Channel 5
1
0
Channel 6
Channel 6
0
1
Channel 7
Channel 7
1
0
DRS4 can be partitioned in 8x1024, 4x2048,
2x4096, 1x8192 cellsChip daisy-chaining possible
to reach virtually unlimited sampling depth
22
Simultaneous Write/Read
FPGA
Channel 0
0
Channel 1
0
8-foldanalog multi-eventbuffer
Channel 2
0
Channel 3
0
Channel 4
0
Channel 5
0
Channel 6
0
Channel 7
0
Expected crosstalk few mV
23
DRS4 around the world
Shipped (-Jan 2011) 2200 Chips 120 Evaluation
Boards
24
MEG Experiment
  • MEG experiment _at_ PSI searches for m?eg decay
  • After 10 years of chip design, DAQ setup,
    firmware programming, MEG runs with 3000 channels
    as designed
  • 40 ps timing resolutions between all channels,
    running at 1.6 GS/s
  • Double buffer readout mode increases life time
    to 99.7 at 10 Hz event rate (3 MB/event)
  • Took 400 TB in 2010

25
DRS4 _at_ MEG
LMK03000
4 x DRS4
32 channels
3000 Channels
26
On-line waveform display
S848 PMTs
virtual oscilloscope
template fit
click
pedestal histo
27
Crosstalk elimination

Crosstalk removal by subtracting empty channel
subtract
Hit
Hit
28
Template Fit
pb Experiment 500 MHz sampling
  • Determine standard PMT pulse by averaging over
    many events ? Template
  • Find hit in waveform
  • Shift (TDC) and scale (ADC)template to hit
  • Minimize c2
  • Compare fit with waveform
  • Repeat if above threshold
  • Store ADC TDC values

29
Trigger and DAQ on same board
  • SCA can only sample a limited (1024-bin window)
    ? many application require a wider window,
    trigger capability would require continuous
    digitization
  • Using a multiplexer in DRS4, input signals can
    simultaneously digitized at 120 MHz and sampled
    in the DRS
  • FPGA can make local trigger(or global one) and
    stop DRSupon a trigger
  • DRS readout (5 GSPS)though same 8-channel FADCs

global trigger bus
trigger
FPGA
DRS
FADC12 bit 65 MHz
analog front end
LVDS
SRAM
30
Slow waveform and Fast window
Window only limited by RAM
Continuous Waveform 120 MSPS (8 ns bins)
31
Sine Curve Fit Method
i
yji i-th sample of
measurement j aj fj aj oj sine wave
parameters bi phase error ?
fixed jitter
  • Iterative global fit
  • Determine rough sine wave parameters for each
    measurement by fit
  • Determine bi using all measurements where sample
    i is near zero crossing
  • Make several iterations

j
S. Lehner, B. Keil, PSI
32
Fixed Pattern Jitter Results
  • TDi typically 50 ps RMS _at_ 5 GHz
  • TIi goes up to 600 ps
  • Jitter is mostly constant over time, ? measured
    and corrected
  • Residual random jitter 3-4 ps RMS
  • Achievable resolution exceeds best CFD HPTDC

33
Time-of-Flight PET
  • Conventional electronicsCFD TDC 500 ps RMS
  • TOF needs
  • 100-200 ps
  • gt1 MHz rate

C. Levin, Stanford University
34
ToF-PET Project
  • Started fall 2010 after NSS/MIC in Knoxville
    (Siemens PET RD home)
  • New project started to replace current PET
    electronics with DRS4 (5)
  • PCB ready summer 2011, firmware by Univ. Tübingen
  • Simulations show that SCA technique can achieve
    100 ps easily

FPGA
Ping-Pong Scheme
Channel 0
1
Channel 0
ROI
Channel 1
0
Channel 1
Channel 2
0
20 samples (10 ns _at_ 2 GS/s) 30 ns / sample
600 ns 40 ns overhead 640 ns ? 1 MHz rate
Channel 3
0
Channel 4
0
Channel 5
0
Channel 6
0
Channel 7
0
35
DRS5 Chip Ideas
36
Plans for DRS5
  • Increase analog bandwidth 5 GHz
  • Smaller input capacitance
  • Increase sampling speed 10 GS/s
  • Switch to 110 nm technology
  • Deeper sampling depth
  • 8 x 4096 / chip
  • Minimize readout time (dead time free) for
    muSR ToF-PET
  • (minor) reduction in analogreadout speed (30 ns
    ? 20 ns)
  • Implement FIFO technology

J. Milnes, J. Howoth, Photek
mSR
MHz event rate
CTA
37
Next Generation SCA
Short sampling depth
Deep sampling depth
  • Low parasitic input capacitance? High bandwidth
  • Large area? low resistance bus, lowresistance
    analog switches? high bandwidth
  • Digitize long waveforms
  • Accommodate long trigger delay
  • Faster sampling speed for a given trigger latency

How to combine best of both worlds?
38
Cascaded Switched Capacitor Arrays
shift register
input
  • 32 fast sampling cells (10 GSPS/110nm CMOS)
  • 100 ps sample time, 3.1 ns hold time
  • Hold time long enough to transfer voltage to
    secondary sampling stage with moderately fast
    buffer (300 MHz)
  • Shift register gets clocked by inverter chain
    from fast sampling stage

. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
fast sampling stage
secondary sampling stage
39
How noise affects timing
voltage noise band of signal
voltage noise Du
signal height U
timing jitter arising from voltage noise
timing uncertainty Dt
rise time tr
timing jitter is much smaller for
faster rise-time
number of samples on slope
40
TDC vs. Waveform Digitizing
Constant Fraction Discriminator
Q-sensitive Preamplifier
Shaper
PMT/APD Wire
TDC
  • CFD and TDC on same board ? crosstalk
  • CFD depends on noise on single point,while
    waveform digitizing can average over several
    points
  • Inverter chain is same both in TDCs and SCAs
  • Can we replace TDCs by SCAs?? yes if the readout
    rate is sufficient

41
Typical Waveform
42
Dead-time free acquisition
  • Self-trigger writing of short 32-bin segments
  • Simultaneous reading ofsegments
  • Quasi dead time-free
  • Data driven readout
  • Ext. ADC runs continuously
  • ASIC tells FPGA when there is new data
  • Coarse timing from300 MHz counter
  • Fine timing by waveformdigitizing and analysis
    in FPGA
  • 20 20 ns 0.4 ms readout time? 2 MHz
    sustained event rate
  • Attractive replacement for CFDTDC

DRS5
43
Plug Play Firmware
  • Emphasis shift from dedicated hardware to
    firmware
  • Pre-designed modules for CFD, TDC, peak sensing
    ADC,
  • Modules can be configured by user and downloaded

CFD
TDC
FIFO
ADC Readout
SCALER
Interface
FIFO
FIFO
ADC
FIFO
Data bus
Parameter bus
44
Conclusions
  • DRS4 chip successfully used in many areas, true
    potential of SCA technology is just now
    discovered
  • Planned DRS5 chip will increase BW and decrease
    readout dead time
  • SCA technology should be able to replace most
    traditional electronics in particle detection

45
Thanks to
  • Roland Horisberger Original Idea
  • Roberto Dinapoli Analog Design of DRS34
  • Ueli Hartmann DRS4 Evaluation Boards
  • PSI chip design core team
Write a Comment
User Comments (0)
About PowerShow.com
