Ocean Sediments

1
Ocean Sediments
2
Importance of Sediments

• Economic Value
• Oil, fossil fuels
• Salt Phosphorus deposits
• Determine shape structure of Ocean bottom
• Strongly affect distribution of Benthic Organisms
• Chronological record of Earths history
• Tectonic history
• Climate history
• Evolutionary history

3
Sediment Thickness
4
(No Transcript)
5
Topographic profiles
6
Law of Superposition

• Younger sediments over Old sediments
• YOUNG
• ----------------------
• OLD

7
Sediment Classification

• By Grain Size
• By Origin

8
Sediment Classification

• Grain Size
• Clay lt4 µm
• Silt 4-62 µm
• Sand 62-2000 µm
• Gravel gt2000 µm

9
Table 3.1
10
Basic Sediment Transport(READ CC4)
11
Sediment Sorting

• Well-sorted sediments are those of similar size
  class
• Beach well sorted (far from source)
• Glacier not sorted (close to source)

12
Sediment Angularity

• Sediment weathering during transport induces loss
  in angularity
• Angular grains (close to source)
• Rounded grains (far from source)

13
Sediment Classification

• Origin
• Lithogenous or Terrigenous (75)
• Biogenous (20)
• Hydrogenous
• Cosmogenous

14
Lithogenous Sediments

• Fragments of rocks broken, weathered and eroded
  form lithogenous sediments

15
http//images.google.com
Frost Wedging
16
Wind Rain erosion
www.naturalphotos.com
17
Lithogenous Sediments

• Transport of sediments by
• Rivers
• Glaciers
• Waves
• Wind
• Landslides
• Humans

18
www.southalabama.edu
http//earthobservatory.nasa.gov
19
Sediment Discharge by Rivers

• Ganges 1700 million Tm/year
• Amazon 900 million Tm/year
• Mississippi 260 million Tm/year
• (Figure 6-2)

20
(No Transcript)
21

• http//www.pbs.org/harriman/images/

22

• http//www.pbs.org/harriman/images/

23
(No Transcript)
24
walrus.wr.usgs.gov/elnino/coastal/ images/
25
http//earthobservatory.nasa.gov
26
Aerial dust transport

• Winter

• Summer

27
St Helens
28

• http//geohazards.cr.usgs.gov/

• http//web.umr.edu/rogersda

29

• http//www.hihwnms.nos.noaa.gov/graphics/

30
Biogenous Sediments

• Composed of planktonic organism remains
• Calcareous skeletons (CaCO3)
• Siliceous skeletons (SiO2)
• Accumulation rate controlled by
• Primary productivity
• Rate of dissolution
• (Importance of fecal pellets)

31
Figure 3.21a
Diatoms (siliceous high latitudes) Coccololithosp
heres (calcareous mid latitides)
32
Figure 3.21b
Radiolarians (siliceous low latitudes)
33
Foraminifera (calcareous all latitides)
34
Pteropods (calcareous all latitudes)

• http//www.mbari.org/expeditions/

35
Dissolution Biogenous Particles

• Silica
• Ocean is UNDERSATURATED with silica
• Dissolution highest in surface waters
• Low Pressure
• High Temperature
• Accumulation in sediments occurs in
• Areas of very high productivity
• Poles and upwelling zones (diatoms)
• Tropics (Radiolarians)

36
Dissolution Biogenous Particles

• Carbonates
• Foraminifera (Calcite) less soluble
• Pteropods (Aragonite) More soluble
• Dissolution is highest in Deep Waters
• High pressure
• Low temperatures
• Low pH (high C02)
• Carbonate Compensation Depth (CCD)

37
Carbonate Compensation Depth

• CCD varies with Latitude
• CCD varies between Oceans
• North Pacific 1000m
• South Pacific 2500m
• Atlantic 4000m

38
Carbonate Compensation Depth

• New Deep Waters have low CO2 conc.
• Old Deep Waters have high CO2 conc.
• Animal respiration
• Decomposer activities
• Pacific Deep Waters are older than Atlantic Deep
  Waters

39
Global Thermohaline Circulation
40
Carbonate Compensation Depth Greenhouse Effect?

• CO2 atmosphere, seawater sediments are
  interrelated!
• Will increase in atmospheric CO2 cause increase
  in dissolved seawater CO2?
• Consequences of a shallow CCD?
• Release into atmosphere of dissolved carbonate
  sediments?

41
Hydrogenous Sediments

• Lower concentrations than Lithogenous and
  Biogenous sediments
• Ocean water usually is UNDERSATURATED, but..
• Hydrothermal Vent Minerals (metal rich sedim.)
• Manganese Nodules (areas of low sedimentation)
• Carbonate banks - CaCO3 precipitates at
• High Temperature
• Low Pressure
• High pH (low CO2)
• Caused by high productivity - photosynthesis

42
(No Transcript)
43
Bahamian Bank
44
Carbonate Sediments
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
Figure 3.23
49
(No Transcript)
50
Chicxulub crater
51
(No Transcript)
52
End
