Modern Multiplexing Schemes

1
Modern Multiplexing Schemes
2
Lesson Objectives
By the end of this lesson, you will be able to

• Describe the operation of QPSK multiplexing
• Describe the operation of QAM multiplexing
• Define adaptive modulation
• Describe the characteristics of DSSS
• Describe how DSSS multiplexing operates
• State the characteristics of CDMA

3
Conceptual Building Blocks

• Cycle One complete wave
• Bit Binary Digit. A single element of
  information, 0 or 1
• bps bits per second
• Baud a measure of the number of signals sent
• Information can be transmitted using 3
  characteristics of a wave amplitude, frequency,
  phase

Cycle
4
Basic Phase Shift Keying Concept
Possible phase shifts
¼
¾
1.0 00 ¼ 900 ½ 1800 ¾ 2700
4 possible states
½
5
Phase Shift Concept
0o Shift
90o Shift
270o Shift
180o Shift
6
Phase Shifts Applied
900
2700
1800
Each wave is shifted relative to the preceding
wave. The amount of shift communicates the
specific state/value
7
Phase Shift Keying

• Four possible phase shifts (compared to the
  previous wave)
• 00 shift No shift
• 900 shift
• 1800 shift
• 2700 shift
• Four shifts ? 4 different states ? 4 bit
  combinations
• 00
• 01
• 10
• 11

8
Quadrature Phase Shift Keying (QPSK)

• Convey information through phase changes
• One phase change per time period
• Each change can send 2 bits of information

9
QPSK Example
Possible Wave forms
Stream of Signals Transmitted
A
B
D
C
C
D
2700
2700
900
1800
00
Phase Shift
Information Sent
00
10
01
11
11
0010011111
10
QPSK Characteristics

• 2 bits per baud
• Robust, relatively simple can tolerate high
  noise levels
• Relatively slow rates, but good quality
• Satellite transmission applications
• Cable TV return paths
• V.22 standard
• 600 baud
• Uses 1200 Hz and 2400 Hz signals to transmit in
  both directions

1200 Hz
2400 Hz
Originating modem
Receiving modem
11
Amplitude Modulation
A2
A1
A1
A2
1
1
0
0
2 possible states
12
Quadrature Amplitude Modulation

• Builds upon the QPSK concept
• Combines Amplitude Modulation and Phase Shift
  Keying
• In our example - 2 possible states (AM) x 4
  possible states (PSK) 8 possible states
• 8 possible states ? 3 Bits
• Bit rate ? x Baud

13
QAM Example
Bit value Amp. Phase shift
000 1 None
001 2 None
010 1 1/4
011 2 1/4
100 1 1/2
101 2 1/2
110 1 3/4
111 2 3/4
14
QAM Expansion

• Number of amplitude levels and phase shifts is a
  direct function of line quality
• A Common version is 16 QAM 4 bits per baud
• Other versions 64 QAM, 256 QAM

• 12 phase angles
• 4 have 2 different amplitudes

15
QAM Characteristics

• Higher spectral efficiency than QPSK ? more bps
• More bps ? greater vulnerability to noise,
  interference
• 16 QAM more stable than 64 QAM, more stable than
  256 QAM
• Used in standard NTSC Television broadcasts
• 64 QAM, 256 QAM used in digital cable TV and
  cable modems
• Typical cable modem network rates 20 Mbps (16
  QAM) through 40 Mbps (256 QAM) downstream
• Upstream 320 kbps (QPSK) through 10 Mbps (16 QAM)

16
Comparison of Modulation Schemes
Increased states ? greater data rates AND
? greater vulnerability to errors
17
Adaptive Modulation
Greater Distance ? Greater BER ? Less bps
18
Frequency Division Multiplexing
Guardbands
Fq
76 kHz
68 kHz
64 kHz
60 kHz
56 kHz
72 kHz
Review

• Split the frequency band that can be transmitted
  over the media into narrow
• frequency sub-bands
• Assign a communications channel to each of these
  narrow sub-bands
• Modulate information signal with a carrier
  frequency
• All occupy different frequencies
• No interference between them due to guard bands
• Resulting signals are analog

19
Discrete Multitone (DMT)

• QAM relatively high bit rate using one carrier
  frequency
• Combine QAM and FDM to achieve even greater
  capacity and efficiency
• The result Discrete Multitone (DMT)
• Developed by Amati Communications in collusion
  with Stanford University, originally for use in
  transmitting video over copper

20
DMT Configuration
Voice
1
2
3
256

1.024 MHz
25 kHz
4 KHz
Frequency

• 256 frequency bands (channels), each 4.3125 kHz
  bandwidth (shown). Each channel is called a tone
• Each channel has different carrier frequency
• Each channel uses QAM for greater efficiency

21
Digital Subscriber Line

• DSL - Most common application of DMT
• Originally developed as a possible means to offer
  video over copper, to compete with CATV
• Found niche as a way to achieve high speed
  Internet connections over copper wire
• Combines three distinct transmissions
• Voice Transmission
• Downstream data transmission
• Upstream data transmission

22
DSL Concepts

• Dedicate one 4 KHz channel to voice (telephone)
• Dedicate remaining channels to high speed data
• Test each channel to determine its ability to
  handle data at an acceptable error rate
• As data is transmitted, allocate it to the
  appropriate channels based upon error rates
• Channels are monitored constantly
• Allocation of data to channels is dynamically
  adjusted, based upon errors

23
Impact of Media on DSL

• DSL designed to operate on twisted copper media
• Affected by Attenuation Distortion
• Attenuation is different for each frequency
• Attenuation increases as frequency increases
• Load coils are a fix for attenuation distortion
• Equalizes loss to approximately 3.5 KHz
• Beyond 4 KHZ, loss is extreme

24
DSL Typical Data Allocation
Attenuation increases as Frequency increases
Amplitude
Frequency
Attenuation ? Errors Decrease bpc as errors
increase
Bits per channel
Frequency
25
DSL Deployment Today

• Copper loops gt 18,000 are loaded to compensate
  for attenuation distortion
• DSL only available in loops up to 18,000
• Data transmission capability decreases as
  distance increases
• Most common form of DSL is ADSL
• Data capability ranges from 600 kbps 7 Mbps
  downstream 128 kbps 1 Mbps upstream, depending
  upon cost and distance

26
ADSL System
Voice Network
Voice Switch
DSLAM
Filter
Data Switch
DSL Modem
Data Network
DSLAM DSL Access Multiplexer
27
Direct Sequence Spread Spectrum

• Converts a signal to a much wider bandwidth or
  data rate for transmission
• Specific spreading codes are used for each signal
  stream
• Codes pseudo random , pseudo noise
• Random 0s, and 1s appear to have no discernible
  pattern
• Pseudo there is a pattern that actually repeats
• Benefits
• Transmission is spread over broad bandwidth, so
  power is less at any frequency
• Immune to various kinds of noise
• Very difficult to intercept, decode, or jam

28
DSSS Codes
Voice Signal
1 1 -1 -1 -1 1 1
1 -1 1 1 -1 1 -1
-1-1 1 -1 1 1 -1
Code Sequence
Voice Bit Stream 64 kbps Chipping Rate 1.25
million chips per second
29
DSSS Process - 1
Establish a pseudo random code

1 Chip
Remember that over time this repeats
30
DSSS Process - 2
Create a signal stream of information
31
DSSS Process - 3
Multiply the signal stream by the pseudo random
code Using the exclusive or function (XOR)
Signal chip are the same Result is high
Signal chip are different Result is low
32
DSSS Process 3 Continued
Signal
PN Code
Spread signal

• Frequency is higher than original voice signal
• Resulting sequence looks like noise
• Power (amplitude) in resultant signal is spread,
  so it
• appears to be less reduces interference
  from other DSSS
• All of original information is still contained in
  it

33
DSSS Decoding - 1
Spread spectrum signal is received. Multiply it
by the same PN code, using the XOR process
Received signal
PN code
Original information
34
DSSS Decoding - 2
How are unwanted signals handled?
Received signal
PN code
Decoded noise
Signal Format
35
DSSS Multiple Stations

• Each station requires a different PN code
• Shifting a standard PN code creates a different
  code

Signal
PN Code
Spread signal
New PN Code
Decoded signal with new code noise
36
Code Division Multiple Access (CDMA)

• Utilizes DSSS
• Originated in World War II as a code that would
  be difficult to intercept
• Actress Hedy Lamarr and George Antheil held
  original patent to original CDMA concept

• Commercial CDMA was invented by Irwin Jacobs who
  went on to
• found Qualcomm in 1985.
• 1989 Telecommunications Industry Assn agreed upon
  CDMA standard
• CDMA service began in 1996

37
CDMA Operation
TRANSMITTING

• Voice signal generated by talking
• Signal is digitized through a PCM scheme
• Digitized signal multiplied by the PN code
• Resultant spread spectrum signal transmitted
  using QAM and/or QPSK techniques
• RECEIVING
• QAM, QPSK signal received and demodulated into
  spread spectrum
• Multiplied by PN code accepted as signal or
  rejected as noise
• Accepted signal converted to analog voice signal

38
CDMA Systems

• Superior capacity 10 20 greater than other
  conventional cellular systems
• Power a critical consideration base stations
  control power for all cellular phones
• Low power levels keep system capacity high, and
  save batteries
• Vulnerable to channel pollution too many
  signals from base stations appear at subscribers
  phone, none are dominant
• Channel specific frequency
• Channel bandwidth 1.25 MHz
• 2 11 carrier frequencies/cell.
• 12 40 voice calls/channel

39
What Weve Covered

• Describe the operation of QPSK multiplexing
• Describe the operation of QAM multiplexing
• Define adaptive modulation
• Describe the characteristics of DSSS
• Describe how DSSS multiplexing operates
• State the characteristics of CDMA
