Compiler Construction Parsing Part I

1
Compiler ConstructionParsing Part I

• ?4? Parsing

2
What We Did Last Time

• The cycle in lexical analysis
• RE ? NFA
• NFA ? DFA
• DFA ? Minimal DFA
• DFA ? RE
• Engineering issues in building scanners

3
Todays Goals

• Parsing Part I
• Context-free grammars
• Sentence derivations
• Grammar ambiguity
• Left recursion problem with top-down parsing and
  how to fix it
• Predictive top-down parsing
• LL(1) condition
• Recursive descent parsing

4
Compilers
5
The Front End

• Parser
• Checks the stream of words and their parts of
  speech(produced by the scanner) for grammatical
  correctness
• Determines if the input is syntactically well
  formed
• Guides checking at deeper levels than syntax
• Builds an IR representation of the code
  Think of this as the mathematics of diagramming
  sentences

6
The Study of Parsing (syntax analysis)

• The process of discovering a derivation for some
  sentence
• Need a mathematical model of syntax a grammar G
• Need an algorithm for testing membership in L(G)
• Need to keep in mind that our goal is building
  parsers, not studying the mathematics of
  arbitrary languages
• Roadmap
• Context-free grammars and derivations
• Top-down parsing
• Hand-coded recursive descent parsers
• LL(1) parsersLL(1) parsed top-down, left to
  right scan, leftmost derivation, 1 symbol
  lookahead
• Bottom-up parsing
• Operator precedence parsing
• LR(1) parsersLR(1) parsed bottom-up, left to
  right scan, reverse rightmost derivation, 1
  symbol lookahead

7
Syntax analysis

• Every PL has rules for syntactic structure.
• The rules are normally specified by a CFG
  (Context-Free Grammar) or BNF (Backus-Naur Form)
• Usually, we can automatically construct an
  efficient parser from a CFG or BNF.
• Grammars also allow SYNTAX-DIRECTED TRANSLATION.

8
Specifying Syntax with a Grammar

• Context-free syntax is specified with a
  context-free grammar
• SheepNoise ? SheepNoise baa
• baa
• This CFG defines the set of noises sheep normally
  make
• It is written in a variant of BackusNaur form
• Formally, a grammar is a four tuple, G
  (S,N,T,P)
• S is the start symbol (set
  of strings in L(G))
• N is a set of non-terminal symbols
  (syntactic variables)
• T is a set of terminal symbols
  (words)
• P is a set of productions or rewrite rules (P
  N ?(N ?T))

9
The Big Picture
Chomsky Hierarchy of Language Grammars (1956)
10
Deriving Syntax

• We can use the SheepNoise grammar to create
  sentences
• use the productions as rewriting rules

While it is cute, this example quickly runs out
of intellectual steam ...
11
A More Useful Grammar
To explore the uses of CFGs, we need a more
complex grammar

• Such a sequence of rewrites is called a
  derivation
• Process of discovering a derivation is called
  parsing

We denote this derivation Expr ? id num id
12
Derivations

• At each step, we choose a non-terminal to replace
• Different choices can lead to different
  derivations
• Two derivations are of interest
• Leftmost derivation replace leftmost NT at each
  step
• Rightmost derivation replace rightmost NT at
  each step
• These are the two systematic derivations
• (We dont care about randomly-ordered
  derivations!)
• The example on the preceding slide was a leftmost
  derivation
• Of course, there is also a rightmost derivation
• Interestingly, it turns out to be different

13
The Two Derivations for x 2 y
Leftmost derivation
Rightmost derivation

• In both cases, Expr ? id num id
• The two derivations produce different parse
  trees
• Actually, each of two different derivations
  produces both parse trees as the grammar itself
  is ambiguous
• The parse trees imply different evaluation
  orders!

14
Derivations and Parse Trees
Leftmost derivation
This evaluates as x ( 2 y )
15
Derivations and Parse Trees
Rightmost derivation
This evaluates as ( x 2 ) y
16
Ambiguity

• Definitions
• If a grammar has more than one leftmost
  derivation for a single sentential form, the
  grammar is ambiguous
• If a grammar has more than one rightmost
  derivation for a single sentential form, the
  grammar is ambiguous
• The leftmost and rightmost derivations for a
  sentential form may differ, even in an
  unambiguous grammar
• Examples
• Associativity and precedence
• Dangling else

17
Ambiguous Grammars

• This grammar allows multiple leftmost derivations
  for x - 2 y
• Hard to automate derivation if gt 1 choice
• The grammar is ambiguous

18
Two Leftmost Derivations for x 2 y

• The Difference
• Different productions chosen on the second step

New choice
Original choice

• Both derivations succeed in producing x - 2 y

19
Derivations and Precedence/Association

• These two derivations point out a problem with
  the grammarIt has no notion of precedence, or
  implied order of evaluation
• To add precedence
• Create a non-terminal for each level of
  precedence
• Isolate the corresponding part of the grammar
• Force the parser to recognize high precedence
  subexpressions first
• For algebraic expressions
• Multiplication and division, first (level one)
• Subtraction and addition, next (level two)
• To add association
• On same precedence
• Left-associative The next-level (higher)
  nonterminal places at the last of a production

20
Derivations and Precedence
Adding the standard algebraic precedence produces
21
Derivations and Precedence
This produces x ( 2 y ), along with an
appropriate parse tree. Both the leftmost and
rightmost derivations give the same
expression, because the grammar directly encodes
the desired precedence.
22
Ambiguous Grammars by dangling else

• Classic example the if-then-else problem
• Stmt ? if Expr then Stmt
• if Expr then Stmt else Stmt
• other stmts
• This ambiguity is entirely grammatical in nature

23
Ambiguity
This sentential form has two derivations
if Expr1 then if Expr2 then Stmt1 else Stmt2
production 1, then production 2
production 2, then production 1
24
Ambiguity

• Removing the ambiguity
• Must rewrite the grammar to avoid generating the
  problem
• Match each else to innermost unmatched if
  (common sense rule)

Intuition a NoElse always has no else on its
last cascaded else if statement
With this grammar, the example has only one
derivation
25
Ambiguity
if Expr1 then if Expr2 then Stmt1 else Stmt2
This binds the else controlling S2 to the inner if
26
Deeper Ambiguity

• Ambiguity usually refers to confusion in the CFG
• Overloading can create deeper ambiguity
• a f(17)
• In many Algol-like languages, f could be either a
  function or a subscripted variable
• Disambiguating this one requires context
• Need values of declarations
• Really an issue of type, not context-free syntax
• Requires an extra-grammatical solution (not in
  CFG)
• Must handle these with a different mechanism
• Step outside grammar rather than use a more
  complex grammar

27
Ambiguity - The Final Word

• Ambiguity arises from two distinct sources
• Confusion in the context-free syntax
  (if-then-else)
• Confusion that requires context to resolve
  (overloading)
• Resolving ambiguity
• To remove context-free ambiguity, rewrite the
  grammar
• To handle context-sensitive ambiguity takes
  cooperation
• Knowledge of declarations, types,
• Accept a superset of L(G) check it by other
  means
• This is a language design problem
• Sometimes, the compiler writer accepts an
  ambiguous grammar
• Parsing techniques that do the right thing
• i.e., always select the same derivation

28
Parsing Techniques

• Top-down parsers (LL(1), recursive descent)
• Start at the root of the parse tree and grow
  toward leaves
• Pick a production try to match the input
• Bad pick ? may need to backtrack
• Some grammars are backtrack-free (predictive
  parsing)
• Bottom-up parsers (LR(1), operator precedence)
• Start at the leaves and grow toward root
• As input is consumed, encode possibilities in an
  internal state
• Start in a state valid for legal first tokens
• Bottom-up parsers handle a large class of
  grammars

29
Top-down Parsing

• A top-down parser starts with the root of the
  parse tree The root node is labeled with the
  goal symbol of thegrammar
• Top-down parsing algorithm
• Construct the root node of the parse tree
• Repeat until the fringe of the parse tree matches
  the input string
• At a node labeled A, select a production with A
  on its lhs and, for each symbol on its rhs,
  construct the appropriate child
• When a terminal symbol is added to the fringe and
  it doesnt match the fringe, backtrack
• Find the next node to be expanded
  (label ? NT)
• The key is picking the right production in step 1
• That choice should be guided by the input string

30
The Expression Grammar
Version with precedence derived last lecture
And the input x 2 y
31
Example
Lets try x 2 y
Leftmost derivation, choose productions in an
order that exposes problems
32
Example
Lets try x 2 y
This worked well, except that doesnt match
The parser must backtrack to here
33
Example
Continuing with x 2 y
34
Example
Trying to match the 2 in x 2 y

• Where are we?
• 2 matches 2
• We have more input, but no NTs left to expand
• The expansion terminated too soon
• ? Need to backtrack

35
Example
Trying again with 2 in x 2 y
This time, we matched consumed all the input ?
Success!
36
Another Possible Parse
Other choices for expansion are possible

• This doesnt terminate
  (obviously)
• Wrong choice of expansion leads to
  non-termination
• Non-termination is a bad property for a parser
  to have
• Parser must make the right choice

37
Left Recursion

• Top-down parsers cannot handle left-recursive
  grammars
• Formally,
• A grammar is left recursive if ? A ? NT such that
• ? a derivation A ? Aa, for some string a ? (NT ?
  T )
• Our expression grammar is left recursive
• This can lead to non-termination in a top-down
  parser
• For a top-down parser, any recursion must be
  right recursion
• We would like to convert the left recursion to
  right recursion
• Non-termination is a bad property in any part of
  a compiler

38
Eliminating Left Recursion

• To remove left recursion, we can transform the
  grammar
• Consider a grammar fragment of the form
• Fee ? Fee a
• ß
• where neither a nor ß start with Fee
• We can rewrite this as
• Fee ? ß Fie
• Fie ? a Fie
• e
• where Fie is a new non-terminal
• This accepts the same language, but uses only
  right recursion

39
Eliminating Left Recursion
The expression grammar contains two cases of left
recursion
Term ? Term Factor Term / Factor
Factor
Expr ? Expr Term Expr Term
Term
Applying the transformation yields
Expr ? Term Expr' Expr' Term Expr'
Term Expr' e
Term ? Factor Term' Term' Factor Term'
/ Factor Term' e
These fragments use only right recursion They
retain the original left associativity
40
Eliminating Left Recursion
Substituting them back into the grammar yields

• This grammar is correct, if somewhat
  non-intuitive.
• It is left associative, as was the original
• A top-down parser will terminate using it.
• A top-down parser may need to backtrack with
  it.

41
Eliminating Left Recursion

• The transformation eliminates immediate left
  recursion
• What about more general, indirect left recursion
  ?
• The general algorithm
• arrange the NTs into some order A1, A2, , An
• for i ? 1 to n
• for s ? 1 to i 1
• replace each production Ai ? As? with
  Ai? d1? d2?dk?,
• where As? d1d2dk are all the
  current productions for As
• eliminate any immediate left recursion on
  Ai using the direct transformation
• This assumes that the initial grammar has no
  cycles (Ai ? Ai ), and no epsilon productions

And back
42
Eliminating Left Recursion

• How does this algorithm work?
• Impose arbitrary order on the non-terminals
• Outer loop cycles through NT in order
• Inner loop ensures that a production expanding Ai
  has no non-terminal As in its rhs, for s lt i
• Last step in outer loop converts any direct
  recursion on Ai to right recursion using the
  transformation showed earlier
• New non-terminals are added at the end of the
  order have no left recursion
• At the start of the ith outer loop iteration
• For all k lt i, no production that expands Ak
  contains a non-terminal
• As in its rhs, for s lt k

43
Example

• Order of symbols G, E, T

• 1. Ai G

4. Ai T G ?E E ? T E' E' ? T E' E' ? e T ?
id T' T' ?E' T T' T' ? e

• 3. Ai T, As E
• G ?E
• E ? T E'
• E' ? T E'
• E' ? e
• T ? T E' T
• T ? id

2. Ai E G ?E E ? T E' E' ? T E' E' ? e T ? E
T T ? id
G ?E E ? E T E ? T T ? E T T ? id
Go to Algorithm
44
Roadmap (Where are We?)

• We set out to study parsing
• Specifying syntax
• Context-free grammars
• Ambiguity
• Top-down parsers
• Algorithm its problem with left recursion
• Left-recursion removal
• Predictive top-down parsing
• The LL(1) condition
• Simple recursive descent parsers

45
Picking the Right Production

• If it picks the wrong production, a top-down
  parser may backtrack
• Alternative is to look ahead in input use
  context to pick correctly
• How much lookahead is needed?
• In general, an arbitrarily large amount
• Use the Cocke-Younger, Kasami algorithm or
  Earleys algorithm
• Fortunately,
• Large subclasses of CFGs can be parsed with
  limited lookahead
• Most programming language constructs fall in
  those subclasses
• Among the interesting subclasses are LL(1) and
  LR(1) grammars

46
Predictive Parsing

• Basic idea
• Given A ? a ß, the parser should be able to
  choose between a ß
• FIRST sets
• For some rhs a?G, define FIRST(a) as the set of
  tokens that appear as the first symbol in some
  string that derives from a
• That is, x ? FIRST(a) iff a ? x ?, for some ?
• We will defer the problem of how to compute FIRST
  sets until we look at the LR(1) table
  construction algorithm

47
Predictive Parsing

• Basic idea
• Given A ? a ß, the parser should be able to
  choose between a ß
• FIRST sets
• For some rhs a?G, define FIRST(a) as the set of
  tokens that appear
• as the first symbol in some string that derives
  from a
• That is, x ? FIRST(a) iff a ? x ?, for some ?
• The LL(1) Property
• If A ? a and A ? ß both appear in the grammar, we
  would like
• FIRST(a) n FIRST(ß) Ø
• This would allow the parser to make a correct
  choice with a lookahead of exactly one symbol !

This is almost correct See the next slide
48
Predictive Parsing

• What about e-productions?
• ? They complicate the definition of LL(1)
• If A ? a and A ? ß and e ? FIRST(a), then we need
  to ensure that FIRST(ß) is disjoint from
  FOLLOW(a), too
• Define FIRST(a) as
• FIRST(a) ? FOLLOW(a), if e ? FIRST(a)
• FIRST(a), otherwise
• Then, a grammar is LL(1) iff A ? a and A ? ß
  implies
• FIRST(a) n FIRST(ß) Ø

FOLLOW(a) is the set of all words in the
grammar that can legally appear immediately after
an a
49
Predictive Parsing

• Given a grammar that has the LL(1) property
• Can write a simple routine to recognize each lhs
• Code is both simple fast
• Consider A ? ß1 ß2 ß3, with
• FIRST(ß1) n FIRST (ß2) n FIRST (ß3) Ø

50
Recursive Descent Parsing
Recall the expression grammar, after
transformation
This produces a parser with six mutually
recursive routines Goal Expr EPrime
Term TPrime Factor Each recognizes one NT or
T The term descent refers to the direction in
which the parse tree is built.
51
Fig. 4.10. Transition diagrams for grammar (4.11).
(Grammar 4.11 )
?
E E' T T' F ? ? ? ? ? TE' TE' ? FT' FT' ? (E) id
?
52
Fig. 4.11. Simplified transition diagrams.
53
Fig. 4.12. Simplified transition diagrams for
arithmetic expressions.
54
Recursive Descent Parsing
A couple of routines from the expression parser
55
Recursive Descent Parsing

• To build a parse tree
• Augment parsing routines to build nodes
• Pass nodes between routines using a stack
• Node for each symbol on rhs
• Action is to pop rhs nodes, make them children of
  lhs node, and push this subtree
• To build an abstract syntax tree
• Build fewer nodes
• Put them together in a different order

Expr( ) result ?true if (Term( ) false)
then return false else if (EPrime( )
false) then result ?false
else build an Expr node
pop EPrime node pop Term node
make EPrime Term children
of Expr push Expr node return
result
Success ? build a piece of the parse tree
56
Left Factoring

• What if my grammar does not have the LL(1)
  property?
• ? Sometimes, we can transform the grammar
• The Algorithm

?A ? NT, find the longest prefix a that
occurs in two or more right-hand
sides of A if a ? e then replace all of the A
productions, A ? aß1 aß2 aßn ?
, with A ? aZ ? Z ? ß1 ß2
ßn where Z is a new element of
NT Repeat until no common prefixes remain
57
Left Factoring
A graphical explanation for the same idea
A ? aß1 aß2 aß3
becomes
A ? a Z Z ? ß1 ß2 ßn
58
Left Factoring An Example
Consider the following fragment of the expression
grammar
Factor ? Identifier Identifier
ExprList Identifier ( ExprList )
FIRST(rhs1) Identifier FIRST(rhs2)
Identifier FIRST(rhs3) Identifier
After left factoring, it becomes
Factor ? Identifier Arguments Arguments ?
ExprList ( ExprList )
e
FIRST(rhs1) Identifier FIRST(rhs2)
FIRST(rhs3) ( FIRST(rhs4)
FOLLOW(Factor) ? It has the LL(1) property
This form has the same syntax, with the LL(1)
property
59
Left Factoring
60
Recursive Descent (Summary)

• Build FIRST (and FOLLOW) sets
• Massage grammar to have LL(1) condition
• Remove left recursion
• Left factor it
• Define a procedure for each non-terminal
• Implement a case for each right-hand side
• Call procedures as needed for non-terminals
• Add extra code, as needed
• Perform context-sensitive checking
• Build an IR to record the code
• Can we automate this process?

61
Summary

• Parsing Part I
• Introduction to parsinggrammar, derivation,
  ambiguity, left recursion
• Predictive top-down parsing
• LL(1) condition
• Recursive descent parsing

62
Next Class

• Table-driven LL(1) parsing
• Bottom-up parsing
