Single View Metrology Class 3

1
Single View MetrologyClass 3
2
3D photography course schedule(tentative)
Lecture Exercise
Sept 26 Introduction -
Oct. 3 Geometry Camera model Camera calibration
Oct. 10 Single View Metrology Measuring in images
Oct. 17 Feature Tracking/matching (Friedrich Fraundorfer) Correspondence computation
Oct. 24 Epipolar Geometry F-matrix computation
Oct. 31 Shape-from-Silhouettes (Li Guan) Visual-hull computation
Nov. 7 Stereo matching Project proposals
Nov. 14 Structured light and active range sensing Papers
Nov. 21 Structure from motion Papers
Nov. 28 Multi-view geometry and self-calibration Papers
Dec. 5 Shape-from-X Papers
Dec. 12 3D modeling and registration Papers
Dec. 19 Appearance modeling and image-based rendering Final project presentations
3
Single View Metrology
4
Measuring in a plane

• Need to compute H as well as uncertainty

5
Direct Linear Transformation(DLT)
6
Direct Linear Transformation(DLT)

• Equations are linear in h

• Only 2 out of 3 are linearly independent
• (indeed, 2 eq/pt)

(only drop third row if wi?0)

• Holds for any homogeneous representation, e.g.
  (xi,yi,1)

7
Direct Linear Transformation(DLT)

• Solving for H

size A is 8x9 or 12x9, but rank 8
Trivial solution is h09T is not interesting
1-D null-space yields solution of interest pick
for example the one with
8
Direct Linear Transformation(DLT)

• Over-determined solution

No exact solution because of inexact
measurement i.e. noise

• Find approximate solution
• Additional constraint needed to avoid 0, e.g.
• not possible, so minimize

9
DLT algorithm

• Objective
• Given n4 2D to 2D point correspondences
  xi?xi, determine the 2D homography matrix H
  such that xiHxi
• Algorithm
• For each correspondence xi ?xi compute Ai.
  Usually only two first rows needed.
• Assemble n 2x9 matrices Ai into a single 2nx9
  matrix A
• Obtain SVD of A. Solution for h is last column of
  V
• Determine H from h

10
Importance of normalization
102
102
102
102
104
104
102
1
1
orders of magnitude difference!
Monte Carlo simulation for identity computation
based on 5 points (not normalized ? normalized)
11
Normalized DLT algorithm

• Objective
• Given n4 2D to 2D point correspondences
  xi?xi, determine the 2D homography matrix H
  such that xiHxi
• Algorithm
• Normalize points
• Apply DLT algorithm to
• Denormalize solution

12
Geometric distance
d(.,.) Euclidean distance (in image)
e.g. calibration pattern
13
Reprojection error
14
Statistical cost function and Maximum Likelihood
Estimation

• Optimal cost function related to noise model
• Assume zero-mean isotropic Gaussian noise (assume
  outliers removed)

Error in one image
15
Statistical cost function and Maximum Likelihood
Estimation

• Optimal cost function related to noise model
• Assume zero-mean isotropic Gaussian noise (assume
  outliers removed)

Error in both images
16
Gold Standard algorithm

• Objective
• Given n4 2D to 2D point correspondences
  xi?xi, determine the Maximum Likelyhood
  Estimation of H
• (this also implies computing optimal xiHxi)
• Algorithm
• Initialization compute an initial estimate using
  normalized DLT or RANSAC
• Geometric minimization of reprojection error
• ? Minimize using Levenberg-Marquardt over 9
  entries of h
• or Gold Standard error
• ? compute initial estimate for optimal xi
• ? minimize cost
  over H,x1,x2,,xn
• ? if many points, use sparse method

17
Uncertainty error in one image

1. Estimate the transformation from the data
2. Compute Jacobian , evaluated at
3. The covariance matrix of the estimated is
   given by

18
Uncertainty error in both images
separate in homography and point parameters
19
Using covariance matrix in point transfer
Error in one image
20
Example
s1 pixel S0.5cm
(Criminisi97)
21
Example
s1 pixel S0.5cm
(Criminisi97)
22
Example
(Criminisi97)
23
Monte Carlo estimation of covariance

• To be used when previous assumptions do not hold
  (e.g. non-flat within variance) or to complicate
  to compute.
• Simple and general, but expensive
• Generate samples according to assumed noise
  distribution, carry out computations, observe
  distribution of result

24
Single view measurements3D scene
25
Background Projective geometry of 1D
3DOF (2x2-1)
The cross ratio
Invariant under projective transformations
26
Vanishing points

• Under perspective projection points at infinity
  can have a finite image
• The projection of 3D parallel lines intersect at
  vanishing points in the image

27
Basic geometry
28
Basic geometry

• Allows to relate height of point to height of
  camera

29
Homology mapping between parallel planes

• Allows to transfer point from one plane to another

30
Single view measurements
31
Single view measurements
32
Forensic applications
190.64.1 cm

• 190.62.9 cm

A. Criminisi, I. Reid, and A. Zisserman.
Computing 3D euclidean distance from a single
view. Technical Report OUEL 2158/98, Dept. Eng.
Science, University of Oxford, 1998.
33
Example
courtesy of Antonio Criminisi
34
La Flagellazione di Cristo (1460) Galleria
Nazionale delle Marche by Piero della Francesca
(1416-1492)
http//www.robots.ox.ac.uk/vgg/projects/SingleVie
w/
35
More interesting stuff

• Criminisi demo http//www.robots.ox.ac.uk/vgg/pre
  sentations/spie98/criminis/index.html
• work by Derek Hoiem on learning single view 3D
  structure and apps http//www.cs.cmu.edu/dhoiem
  /
• similar work by Ashutosh Saxena on learning
  single view depth http//ai.stanford.edu/asaxena/
  learningdepth/

36
Next class

• Feature tracking and matching
