Evolution of Teamwork in Multiagent Systems

1
Evolution of Teamwork in Multiagent Systems

• Research Preparation Examination
• by Jacob Schrum

2
Why Multiple Agents?

• Many applications
• Physical World
• Robotics
• Autonomous automobiles
• Military applications
• Network Systems
• Artificial World
• Games
• Graphics
• Entertainment
• Artificial Life

3
Why Multiagent Perspective?

• Decentralized control
• Failure recovery
• Individual agents simpler
  than whole
• Some environments dont
  support central control
• Human interaction
• Humans are also agents
• Agents interacting with
  humans are in MAS

4
Teamwork in Multiagent Systems

• Problem divided amongst many agents
• Teamwork often required for success
• Communication sometimes an issue
• How to learn teamwork open question

5
Direct Approach Careful Design

• Hand code everything
• Benefits
• Understand end product
• Drawbacks
• Not general
• Difficult
• Programmer time
• Common in
• Robotics
• Video games
• Most deployed systems
• What if no one knows how to program it?

6
Learn it Reinforcement Learning

• Environment is Markov Decision Process
• Learn optimal policy
• Depends on value function (TD methods)
• Proven convergence in tabular case
• Function approximation needed for bigger problems
• Problems with Partially Observable MDPs
• Successes in
• Pred/Prey Scenarios (Tan 1993)
• Soccer keep away
  (Kalyanakrishnan, Stone 2009)
• Robocup soccer (many)

7
Breed it Evolution

• Based on evolution via natural selection
• Benefits
• Less restrictive policy representation
• Demonstrated success in POMDP domains
• Drawbacks
• Computationally intensive
• Time intensive
• Focus of talk

8
Evolution Basics

1. Initialize population P
2. Evaluate all p in P (assign fitness)
3. Derive P by selecting/modifying members of P
   based on their fitness scores
4. Repeat from step 2 with P as P until done

• P is usually similar to P, but slightly better
• Many variations
• Genetic Algorithms, Evolution Strategies, etc.

9
Evolution in Multiagent Systems

• Team Composition
• Homogeneous
• Heterogeneous
• Heterogeneous from Subpopulations
• Entire population
• Type of Selection
• Individual
• Team
• Self-Selection
• Multiple Objectives

Pick one member from each subpopulation to make a
team
10
1.A. Homogeneous Teams

• Team members share same policy
• Members know what to expect from team members
• One individual evaluated per trial
• Evaluations reliable because of consistent team
  composition

11
1.B. Heterogeneous Teams

• Team composed of several policies
• Uncertainty as to who teammates will be
• Multiple individuals evaluated per trial
• Evaluation differs depending on choice of team
  members

12
1.C. Subpopulations

• Each slot filled by representative from specific
  subpopulation
• Subpopulations specialize
• Individuals know what to expect of members in
  each slot
• Team composition is still heterogeneous

13
1.D. Entire Population

• The entire population is seen as a cooperating
  team
• Team level selection not possible
• Population may divide into competing
  subpopulations
• Mating restrictions
• Genetic/Tag-based recognition

14
2.A. Individual Selection

• Individuals selected based on own fitness
• Commonly used with heterogeneous teams
• Can result in selfish behaviors
• Altruism relevant
• sacrificing own fitness to raise fitness of
  another
• Reciprocity relevant
• helping another to get help in return

15
2.B. Team Selection

• Individuals selected based on team fitness
• Common fitness, sum, average, etc.
• Commonly used with homogeneous teams
• Enables slackers in heterogeneous teams
• Altruism and reciprocity have no meaning
• No credit assignment problems between members

16
2.C. Self-Selection

• Individuals choose when and with whom to mate
• Common in Artificial Life simulations
• AL studies emergence of biological phenomena
• Usually involves a spatial component
• Extinction is possible
• Auto restart
• Spawn new members

17
3. Multiple Objectives

• Assume individual has fitness scores
• F (f1,,fN) in objectives 1 through N
• Which values of F are best?
• Traditional approach
• fitness(F) f1w1 fNwN for weights
  w1,,wN
• Pareto-based approach
• Partition population into non-dominated Pareto
  fronts
• Assign fitness based on Pareto-front

18
Pareto Front Example

• Each point represents
  an individuals scores
• Point dominates other points
  in its box
• 3 Pareto fronts of
  non-dominated points

19
Case Studies

• Review State of the Art
• For each study
• Classify type of selection
• Classify team composition
• Identify unanswered questions
• Future research directions

20
AntFarm

• Evolve foraging behavior
• Pheromones to communicate
• Individual selection
• Entire population as a team
• No cooperative foraging!
• Likely cause individual selection
• Individual selection offers less incentive for
  teamwork
• Teamwork especially difficult when there is only
  one team

AntFarm Towards Simulated Evolution. Collins,
Jefferson. 1991
21
Evolving Communication

• Exploration task
• Pheromones to communicate
• Team selection
• Homogeneous teams vs. static bots
• Pairs of objectives, Pareto-based
• Different behaviors in different runs
• Compromise strategy
• Blocking strategy
• Teamwork possible with homogeneous teams
• Need to move beyond grid-worlds
• Move beyond two objectives

Emergence of Communication in Competitive
Multi-Agent Systems A Pareto Multi-Objective
Approach. McPartland, Nolfi, Abbass. 2005
22
SwarmEvolveTags

• Birds visit food stations
• Energy can be shared
• Sharing based on tags
• Self-selection

• Entire population as team
• Competing subpopulations emerged
• Cooperation in entire population without team
  selection
• Altruism via aiding similar individuals
• Teamwork as a result of subpopulation homogeneity

Evolution of cooperation without reciprocity.
Riolo, Cohen, Axelrod. 2001
Tags and the Evolution of Cooperation in
Complex Environments. Spector, Klein, Perry. 2004
23
Legion-I

• Roman legions defend countryside and cities
• Team level selection
• Homogeneous teams
• Multi-modal behavior
• Defend city
• Pursue barbarians
• Homogeneous team members must fill all roles
• Could not learn more complicated/strategic tasks
• Example building roads to speed up travel

Neuroevolution for Adaptive Teams. Bryant,
Miikkulainen. 2003
24
Role-Based Cooperation

• Toroidal predator/prey grid world
• Individual selection
• Team fitness shared by team members
• Multi-Agent ESP subpopulation based
• Simple non-communicating method
  outperforms communicating method
• Teamwork without homogeneity
• Communication not always needed
• May only apply to simple domains
• Still need to scale up complexity
• Get away from grid worlds

Coevolution of Role-Based Cooperation in
Multi-Agent Systems. Yong, Miikkulainen. 2007
25
NERO

• Machine Learning game
• Human interaction via fitness function
• Individual selection
• Entire population is team
• Multiple objectives
• User defines weights dynamically
• Maintenance of fitness function
• Old behaviors can be forgotten
  when learning new ones
• Need to learn multiple tasks simultaneously

Evolving Neural Network Agents in the NERO
Videogame. Stanley, Bryant, Miikkulainen. 2005
26
Pareto Multi-objective NPCs

• Evolved monsters vs. bot with stick
• Individual selection
• Large heterogeneous teams of 15
• Third of entire population
• Multiple objectives, Pareto-based
• Credit assignment trick
• Learns multiple objectives simultaneously
• Different runs can lead to very different results
• Different areas of trade-off surface
• Population becomes mostly homogeneous

Constructing Complex NPC Behavior via
Multi-Objective Neuroevolution. Schrum,
Miikkulainen. 2008
27
Dead End Game

• Human prey vs. predators
• Offline evolution vs. bot
• Team level selection
• Homogeneous teams
• Online evolution vs. human
• Individual selection
• Small heterogeneous team
• Different configurations appropriate at different
  levels
• Sometimes the domain leaves no choice

Interactive Opponents Generate Interesting
Games. Yannakakis, Hallam. 2004
28
Cooperating Robots

• Retrieve tokens
• Simulation ? Robots
• Compared selection levels
• Individual vs. Team
• Compared team compositions
• Homogeneous vs. heterogeneous
• Homogeneous better with teamwork and altruism
• Homogeneous best with team selection
• Heterogeneous best with individual selection
• Did not consider subpopulations
• Tasks only involved foraging (no other objectives)

Genetic Team Composition and Level of Selection
in the Evolution of Cooperation. Waibel,
Keller, Floreano. 2008
29
Summary of Issues

• More complexity
• Move beyond grid worlds
• Need multiple contradictory objectives
• Act in continuous, real-time world
• Best evolutionary configuration
• More comparisons between team compositions
• Especially subpopulation-based method
• Task/configuration pairings?
• Credit assignment issues
• Multi-modal behavior
• What to do and when

30
Experiment

• Four monsters vs. bot with stick
• Smaller team makes task harder
• Compare homogeneous, heterogeneous and
  subpopulation
• Homogeneous uses team selection
• Others use individual selection
• Multiple objectives
• Group damage
• Individual injury
• Individual time alive

31
Heterogeneous Results

• Many generations (600)
• Not that long in real time
• Mostly selfish
• Good teamwork can arise though (Baiting)
• Teamwork depends on population being homogeneous

Teamwork
Selfish
32
Homogeneous Results

• Fewer Generations (100-200)
• Actually longer in real time
• Always some form a teamwork
• Baiting
• Timed Assault

Time Assault
Baiting
33
Subpopulations Results

• Many Generations (400)
• Each generation takes a lot of real time
• Easy for slacker subpopulation to persist
• Limited teamwork
• Only some members participate

Cooperating Pair
34
Discussion

• Can subpopulation method do better?
• Better credit assignment
• Team level selection (how?)
• Speed up homogeneous and subpopulations
• Heterogeneous discourage selfishness

35
Future Research Questions

• Credit assignment issues
• Cooperating individuals cannot be identified
• Objectives define best evolutionary
  configuration?
• Complex domains/real problems
• Many objectives
• Continuous, real-time
• Potential challenge domains
• Robocup Soccer
• Unreal Tournament

36
Conclusion

• Teamwork in Multiagent Systems important area
• Evolution has been successful
• Better understand why
• Team configuration
• Level of selection
• Presence/absence of credit assignment problems
• Apply to harder domains
• Real-time
• Continuous/noisy
• Multiple contradictory objectives

37
Questions?

• schrum2_at_cs.utexas.edu

38
Auxiliary Slides
39
Cooperation Without Reciprocity

• Abstract study of the evolution of cooperation
• Donor/recipient model
• 3 random pairings with option of donating fitness
  c so that recipient can gain fitness b
• Choice to donate based on similarity of tags
• Individual selection with entire population as
  team
• Subpopulations emerged based on tags
• Donation rate changes cyclically, but generally
  stays high (73) for c lt b
• Need to apply in actual domain requiring teamwork

Evolution of cooperation without reciprocity.
Riolo, Cohen, Axelrod. 2001
40
Cooperation Without Reciprocity Results
41
Team Composition in MAS

• Taxonomy proposed by Stone

Heterogeneous Communicating Agents Heterogeneous Non-communicating Agents
Homogeneous Communicating Agents Homogeneous Non-communicating Agents

• Definition of communication is broad
• Message passing, blackboard, information sharing,
  etc.

Multiagent Systems A Survey from a Machine
Learning Perspective. Stone. 2000
