Introduction to Automated Design Optimization

1
ME 475
Introduction to Automated Design Optimization
2
Analysis versus Design
ME 475

• Analysis
• Given system properties and loading
  conditions
• Find responses of the system
• Design
• Given loading conditions and targets for
  response
• Find system properties that satisfy those
  targets

3
Design Complexity
ME 475
Design Complexity
Design Time and Cost
4
Typical Design Process
ME 475
Initial Design Concept
HEEDS
Time Money Intellectual Capital
Yes
Final Design
5
A General Optimization Solution
ME 475
Automotive Civil
Infrastructure Biomedical
Aerospace
6
Automated Design Optimization
ME 475
Basic Procedure
7
Automated Design Optimization
ME 475
Identify Objective(s) Constraints Design
Variables Analysis Methods Note These
definitions affect subsequent steps
8
Automated Design Optimization
ME 475
9
Automated Design Optimization
ME 475
10
Automated Design Optimization
ME 475
New Design (HEEDS)
Extract Results from Output File
Converged?
No
Yes
Optimized Design(s)
11
CAE Portals
ME 475
When
What
Where
12
Tangible Benefits
ME 475
Crash rails 100 increase in energy
absorbed 20 reduction in mass Composite
wing 80 increase in buckling load 15
increase in stiffness Bumper 20 reduction in
mass with equivalent performance Coronary
stent 50 reduction in strain Percentages
relative to best designs found by experienced
engineers
13
Return on Investment
ME 475

• Reduced Design Costs
• Time, labor, prototypes, tooling
• Reinvest savings in future innovation projects
• Reduced Warranty Costs
• Higher quality designs
• Greater customer satisfaction
• Increased Competitive Advantage
• Innovative designs
• Faster to market
• Savings on material, manufacturing, mass, etc.

14
Topology Optimization
ME 475

• Suggests material placement or layout based on
  load path efficiency
• Maximizes stiffness
• Conceptual design tool
• Uses Abaqus Standard FEA solver

15
When to Use Topology Optimization
ME 475

• Early in the design cycle to find shape concepts
• To suggest regions for mass reduction

16
Design of Experiments
ME 475

• Determine how variables affect the response of a
  particular design
• Design sensitivities
• Build models relating the response to the
  variables
• Surrogate models, response surface models

17
When to Use Design of Experiments
ME 475

• Following optimization
• To identify parameters that cause greatest
  variation in your design

18
Parameter Optimization
ME 475
Minimize (or maximize) F(x1,x2,,xn)
such that Gi(x1,x2,,xn) lt 0,
i1,2,,p Hj(x1,x2,,xn) 0, j1,2,,q
where (x1,x2,,xn) are the n design
variables F(x1,x2,,xn) is the objective
(performance) function Gi(x1,x2,,xn) are the
p inequality constraints Hj(x1,x2,,xn) are
the q equality constraints
19
Parameter Optimization
ME 475
Objective Search the performance design
landscape to find the highest peak or lowest
valley within the feasible range

• Typically dont know the nature of surface
  before search begins
• Search algorithm choice depends on type of design
  landscape
• Local searches may yield only incremental
  improvement
• Number of parameters may be large

20
Selecting an Optimization Method
ME 475

• Design Space depends on
• Number, type and range of variables and
  responses
• Objectives and constraints

21
SHERPA Search Algorithm
ME 475

• Hybrid
• Blend of methods used simultaneously, not
  sequentially
• Aspects of evolutionary methods, simulated
  annealing, response surface methods, gradient
  methods, and more
• Takes advantage of best attributes of each
  approach
• Global and local search performed together

• Adaptive
• Each method adapts itself to the design space
• Master controller determines the contribution of
  each method to the search process
• Efficiently learns about design space and
  effectively searches even very complicated spaces

• Both single and multi-objective capabilities

22
SHERPA Benchmark Example
ME 475
Find the cross-sectional shape of a cantilevered
I-beam with a tip load (4 design vars)
Design variables H, h1, b1, b2 Objective
Minimize mass Constraints Stress, Deflection
23
SHERPA Benchmark Example
ME 475
Find the cross-sectional shape of a cantilevered
I-beam with a tip load (4 design vars)
Effectiveness and Efficiency of Search (Goal
1)
24
Advantages of SHERPA
ME 475

• Efficient
• Requires fewer evaluations than other methods for
  many problems
• Rapid set up no tuning parameters
• Solution the first time more often, instead of
  iterating to identify the best method or the best
  tuning parameters
• Robust
• Better solutions more often than other methods
  for broad classes of problems
• Global and local optimization at the same time
• Easy to Use
• Only one parameter number of allowable
  evaluations
• Need not be an expert in optimization theory

25
Nonlinear Optimization Problems
ME 475

• Usually involve nonlinear or transient analysis
• Gradients not accurate, not available, or
  expensive
• Multi-modal and or noisy design landscape
• Moderate to large CPU time per evaluation
• In other words, most engineering problems

26
Example Hydroformed Lower Rail
ME 475
27
Shape Design Variables
ME 475
67 design variables 66 control points and one
gage thickness
z
y
rigid wall
lumped mass
x
arrows indicate directions of offset
crush zone
cross-section
28
Optimization Statement
ME 475

• Identify the rail shape and thickness
• Maximize energy absorbed in crush zone
• Subject to constraints on
• Peak force
• Mass
• Manufacturability

29
Optimized Design
ME 475
30
Validation
ME 475
31
Lower Rail Benefits
ME 475

• Compared to 6 month manual search
• Peak force reduction by 30
• Energy absorption increased by 100
• Weight reduction by 20
• Overall crash response resulted in equivalent of
  FIVE STAR rating

32
Future Gen Passenger Compartment
ME 475
Side Impact Roof Crush Mass
improvement in safety cage 30 kg (about 23)
33
Sensor Magnetic Flux Linearity
ME 475
Displacement
N
S
6.0 mm
S
N
Magnetic Circuit
34
Sensor Magnetic Flux Linearity
ME 475

• Compared to previous best design found
• Linearity of response 7 times better
• Volume reduced by 50
• Setup solution time was 4 days, instead of 2-3
  weeks

35
Front Suspension
ME 475
Picture taken from MSC/ADAMS Manual
36
Problem Statement
ME 475
Determine the optimum location of the front
suspension hard points to produce the desired
bump steer and camber gain.
37
Results
ME 475
38
Piston Design for a Diesel Engine
ME 475

• Piston pin location is optimized to reduce piston
  slap in a diesel engine at 1100, 1500, 2000, and
  2700 RPM

• Design Variables
• Piston Pin X location
• Piston Pin Y location
• Design Objectives
• Minimize maximum piston impact with the wall
• Minimize total piston impact with the wall
  throughout the engine cycle.

39
Piston Design for a Diesel Engine
ME 475

• 110 designs were evaluated for each engine speed
  (440 runs of CASE)
• Total computational time was approximately 0.5
  days using a 2.4 GHz processor.
• Optimized pin offset was essentially identical to
  what was found experimentally on the dynamometer.

40

Soft Tissue Membrane Inflation
ME 475
A biaxial stress state suitable for interrogating
nonlinear anisotropic properties of membranous
soft tissue can be realized using membrane
inflation Orthotropic nonlinear elasticity four
material parameters
Drexler et al., J. Biomech. 40 (2007), 812-819
Courtesy of Jeffrey Bischoff, Zimmer Inc.
41
Optimization Progression
ME 475
R2 1.6 1.8
2.0
0 50
100 150
Iteration
42
Polymer Property Calibration
ME 475
Rate Sensitive Polymer Neo-Hookean material
model with a four-term Prony series Five
undetermined coefficients (design variables)
43
Stent Shape Optimization
ME 475
LOADCASE 1 Expand the stent in the radial
direction by 8.23226 mm.
LOADCASE 2 Crimp the annealed stent by 2.0 mm.
ANNEAL
44
Stent Subsystem Design Model
ME 475
45
Stent Baseline and Final Designs
ME 475

• BASELINE DESIGN
• (Provided)

FINAL DESIGN (Found by HEEDS)
Max. Strain 0.99
Max. Strain 3.3
46
Example Frame Torsional Stiffness
ME 475
Goal Maximize torsional stiffness with no
increase in mass
47
Loading and Optimization Statement
ME 475
Objective Minimize deflection of unsupported
corner Constraints mass lt baseline
model max von mises stress lt baseline
model first 3 modal frequencies gt baseline
model
48
Design Variables
ME 475
10 shape parameters 5 each for two cross
members 7 thickness variables 3 each for two
cross members 1 for the longitudinal rails
49
Design Results
ME 475

• Torsional stiffness increased by 12
• height of cross members increased
• cross member locations moved toward the ends
• connection plate thicknesses decreased
• cross member thicknesses increased
• thickness of the rails remained constant

Baseline Design
Optimized Design
50
Design of a Composite Wing
ME 475

• Design variables
• Number of plies
• Orientation of plies
• Skin, spars, tip
• Objectives, Constraints
• Minimize mass
• Buckling, stiffness, failure constraints
• Analysis Tool
• Abaqus

51
Failure Index
ME 475

• Baseline

HEEDS 30 reduction in failure index
52
Deflection
ME 475

• Baseline

HEEDS 15 reduction in deflection
53
Buckling
ME 475

• Baseline

HEEDS 80 increase in buckling load
54
Design of a Composite Wing
ME 475

• Buckling Load increased by 80
• Failure index decreased by 30
• Bending stiffness increased by 15
• Mass increased by 6

55
Rubber Bushing
ME 475
Parametric model 6 parameters
56
Rubber Bushing Target Response
ME 475
57
Rubber Bushing Final Design
ME 475
Final design
58
Rubber Bushing Response
ME 475
