Introduction to asynchronous circuit design: specification and synthesis

1
Introduction toasynchronous circuit design
specification and synthesis

• Part IV
• Synthesis from HDL
• Other synthesis paradigms

2
Outline

• Synthesis from standard HDL (Verilog) L. Lavagno
  et al Async00
• Subset for asynchronous specification
• Data-path/control partitioning
• Circuit architecture. Control generation
• Synthesis from asynchronous HDL (CSP, Tangram)
• CSP for control generation A. Martin et al,
  Caltech
• Tangram for silicon compilation K. van Berkel et
  al, Philips
• Control synthesis using FSMs K. Yun, S. Nowick
• Burst-mode machines
• Comparison with STGs
• Disclaimer this is NOT a comprehensive review

3
Motivation

• Language-based design key enabler to synchronous
  logic success
• Use HDL as single language for
• specification
• logic simulation and debugging
• synthesis
• post-layout simulation
• HDL must support multiple levels of abstraction

4
Control-data partitioning

• Splitting of asynchronous control and synchronous
  data path
• Automated insertion of bundling delays

CONTROL UNIT
DATA PATH
request
delay
acknowledge
5
Design flow
HDL specification
Synthesizable HDL (data)
Control/data splitting
STG (control)
Synthesis (Synopsys)
Logic delays
Synthesis (petrify)
Timing analysis (Synopsys)
HDL implementation
Logic implementation
Delay insertion
6
Asynchronous Verilog subset by example
always begin wait(start) R SMP 3 RES
SMP 4 R if(RES7 1) RES 0 else
begin if(RES6 1) RES 1 end done
1 wait(!start) done 0 end
SMP
R
R E S
RES
C.U.
done
start

• begin-end for sequencing, fork-join for
  concurrency, if-else for input choice
• Only structured mix of sequencing, concurrency
  and choice can be specified

7
Controller design flow
HDL
Syntax-directed translation
Petri Net
Transformations
Reductions
Trace Expressions
Synthesis
Circuit
8
Trace expressions example

• ( a ( b c) ) (d e)

9
Reduction Example
a
d?a ( b f )

f
b
e
c


c


h
g h?e
d
g
10
Transformation concurrency reduction
a

• Concurrency in TE
• b and f have a common
• parallel father

f
b
c
d
11
Transformation concurrency reduction
a

• f and b are ordered

f
b

c
d
12
Synthesis

• Place-based encoding ( based on a David-cell
  approach)
• Transformations to improve area and performance
• Structural methods to derive a circuit Pastor
  et al. Transactions on CAD, Nov98

13
Place-based encoding
p2
p1
p2
p1
1100
p3
t1
ER(t1) 111-
t1
p3
0010
p4
t2
ER(t2) --11
t2
p3-
p4
0001
p4-
14
Synthesis example VME bus
ldtack
p2
p1-
LDS
p8-
p11-
p3
lds
D
p1
LDTACK
LDTACK-
DSr
p2-
p7-
p4
p10-
dsr
dtack
D
DTACK-
LDS-
ldtack-
p8
p3-
Place encoding
p11
p5
DTACK
D-
p9-
p6-
dsr-
lds-
dtack-
p4-
DSr-
p9
p6
p10
p7
D-
p5-
15
VME bus spec after transforms
ldtack
p2
ldtack
p1-
p8-
p11-
lds
d
p3
lds
D
dtack
p1
dsr
p2-
p7-
dsr-
p9
p9-
ldtack-
p4
p10-
dsr
dtack
ldtack-
p8
lds-
dtack-
Reductions Transforms
p3-
p11
p5
d-
p9-
p6-
dsr-
lds-
dtack-
p4-
p9
p6
p10
p7
D-
p5-
16
Deriving Next state function
Next-state function of signal y ?
17
Deriving Next State function
Next-state function of signal y ?
y x z
18
Conclusion

• Initial prototype of automated flow without state
  explosion for ASIC design
• From HDLs (control / data splitting)
• Existing tools for data-path synthesis
• Direct synthesis guarantees implementation(HDL ?
  Petri net, Petri-net-based encoding)
• Synthesis of large controllers by efficient spec
  models (Free-choice Petri nets trace
  expressions)
• Exploration of the design space (optimization) by
  property-preserving transformations
• Logic synthesis by structural methods
• Quality of design often acceptable
• Timing post-optimization can be applied

19
Synthesis from asynchronous HDL

• CSP based languages
• CSP communicating sequential processes T.
  Hoare
• Two synthesis techniques
• based on program transformations Caltech
• based on direct compilation Philips
• Tools are more mature than for asynchronous
  synthesis from standard HDL
• Complete shift in design methodology is required

20
Using CSP for control generation

• After li goes high do full handshake at the
  right, then complete handshake at the left and
  iterate.

ro
li
Q element
ri
lo
STG
li
ro
ri
ro-
ri-
lo
li-
lo-
liroriro-not rilonot lilo-
CSP

• sequencing operator
• ro ro goes high ro- ro goes low
• li wait until li is high not li wait
  until li is low

21
Using CSP for control generation
liroriro-not rilonot lilo-
CSP
weak
ri
Production rules li -gt ro ri -gt ro- not ri
-gt lo not li -gt lo-
ro
li

• Conflict ro and ro- are not mutually exclusive
  (since ri and li are not)
• Eliminate conflict by state signal insertion (
  CSC)

22
Conflict elimination
lirorixxro-not rilonot
lix-not xlo-
CSP
Production rules not x and li -gt ro x or not
li -gt ro- x and not ri -gt lo not x or ri -gt
lo- ri -gt x not li -gt x-
ro
li
x
FF
not x
lo
ri
23
Conclusions

• Generating circuits from CSP control program is
  similar to STG synthesis
• One can be reduced to the other
• Particular technique may vary. Direct CSP program
  transformations can be (and were) used instead of
  methods based on state space generation
• See reference list for more details

24
Buffer example in Tangram
(a?byte b!byte) begin x0 var byte
forever do a?x0 b!x0 od end
a
b
Buffer
passive port
Each circle mapped to a netlist
active port

Q element
a
b
Data path
25
Summary

• Tangram program is partitioned into data path and
  control
• Data path is implemented as dual or single rail
• Control is mapped to composition of standard
  elements ( etc)
• Each standard element is mapped to a circuit
• Post-optimization is done
• Composing islands of control elements and
  re-synthesis with STG can give more aggressive
  optimization
• Philips made a few chips using Tangram, including
  a product 8051 micro-controller in low-power
  pager Muna (25 wks battery life from one AAA
  battery)
• Similar approach used in Balsa(Manchester Univ.,
  public domain)

26
Burst mode FSM

• Close to synchronous FSMs with binary encoded I/O
• Work in bursts
• Input transitions fire
• Output transitions fire
• State signals change
• Mostly limited to fundamental mode next input
  burst cannot arrive before stabilization at the
  outputs

s1
b-/x-
ab/y
a-/xy-
s2
s4
c-/y
c/y-
s3
27
Extended Burst mode

• Directed dont cares (b) some concurrency is
  allowed for input transitions that do not
  influence an output burst
• Conditional guards ltbgt if b1 then

s1
b-/x-
ab/y
ltbgta-/xy-
s2
s4
c-/y
ltbgtc/y-
s3
28
Synthesis of XBM

• Next state and output functions free of
  functional and logic hazards
• Sequential feedbacks should not introduce new
  hazards
• State assignment
• one state of the BM spec to one layer of Karnaugh
  map
• compatible layers are merged
• layers are compatible if merging does not
  introduce CSC violations or hazards
• Layers are encoded using race free encoding

29
XBM and STG
x-
a
b
s1
b-/x-
ab/y
y
ltbgta-/xy-
s2
s4
c-/y
ltbgtc/y-
a-
c
s3
eps
y-
c-
y-
x
y
b-
30
Summary

• Specification XBM is subclass of STGs
• Synthesis techniques are extensions of
  synchronous state assignment and logic
  minimization
• Timing
• environment is limited to fundamental mode
  (difficult for pipelined and highly concurrent
  systems)
• internals are delay insensitive
• See reference list for details
