Navigation

1
Navigation
2
TWO SAD JOKES

• Who leaves the table after everyones eaten?
• A cannibal.
• Why is the banana the most popular fruit?
• Because it has appeal.

3
How do we know where were at?
X
You are here. Huh?
4
Before GPS. Celestial navigation

• The pattern of stars and planets seen from Earth
  are constant in space. The celestial sphere.
• It is useful to be able to precisely specify
  positions on the celestial sphere.So, a set of
  coordinates is used that is similar to latitude
  and longitude on the Earth.The system of
  latitude and longitude was first suggested by
  Hipparchus, a Greek astronomer in the 2nd C.
  B.C.

5
(No Transcript)
6

• The North Celestial Pole is the point on the
  celestial sphere directly above the Earth's North
  Pole.Similarly, the South Celestial Pole is
  directly above the Earth's South Pole.
• The star Polaris, in the constellation Ursa
  Minor, is located very close to the North
  Celestial Pole.Polaris is therefore also called
  the North Star.

7
More accurate Longitude Latitude

• Longitude
• Angular distance on the earth's surface, measured
  east or west from the prime meridian at
  Greenwich, England.
• Lines of longitude are blue (east) and red (west)
  in the drawing.

8
Latitude

• The distance north or south of the earth's
  equator. 0 degrees latitude is the equator, the
  "belt" that goes around the "waist" of the earth.
  90 degrees north is the North Pole and 90 degrees
  south is the South Pole.
• Lines of latitude are blue (north) and red
  (south) in the drawing.

9
Tools of the trade

• Sexton measures the angle between celestial
  bodies and the Earth to determine position.
• Compass Point to magnetic North, so you can
  follow a course by knowing our position in
  relation to North.
• Loran C radio transmissions from set positions
  on the surface of the Earth, that triangulate to
  give you a position.
• GPS is a worldwide radio-navigation system
  formed from a constellation of 24 satellites and
  their ground stations.

10
Sexton

• a device that measures the angle between two
  objects. It uses the position of stars to find
  its latitude, longitude.

11
Compass
12
Loran C

• LORAN-C was originally developed to provide
  radio-navigation service for U.S. coastal waters
  and was later expanded to include complete
  coverage of the continental U.S. as well as most
  of Alaska. Twenty-four U.S. LORAN-C stations work
  in partnership with Canadian and Russian stations
  to provide coverage in Canadian waters and in the
  Bering Sea. LORAN-C provides better than 0.25
  nautical mile absolute accuracy for suitably
  equipped users within the published areas.
• What is Loran-C?
• Loran-C is a low frequency/long wave electronic
  position fixing system using radio signals
  transmissions _at_ 100 KHz from 3 or more
  transmitters, linked in a chain. It gives a
  latitude and longitude readout position to
  marine, aero and land receivers.

13
(No Transcript)
14
The Global Positioning System (GPS)

• is a worldwide radio-navigation system formed
  from a constellation of 24 satellites and their
  ground stations.
• GPS uses these "man-made stars" as reference
  points to calculate positions accurate to a
  matter of meters. In fact, with advanced forms of
  GPS you can make measurements to better than a
  centimeter!
• In a sense it's like giving every square meter on
  the planet a unique address.
• GPS receivers have been miniaturized to just a
  few integrated circuits and so are becoming very
  economical. And that makes the technology
  accessible to virtually everyone.
• These days GPS is finding its way into cars,
  boats, planes, construction equipment, movie
  making gear, farm machinery, even laptop
  computers.

15
(No Transcript)
16
Coordinates given in Longitude, Latitude
East
West
Longitude 40 E
Latitude 65 N
North
South
17
(No Transcript)
18
Mapping activity

• http//olc.spsd.sk.ca/DE/k9mod/Mapskill/mod3fl5.sw
  f
