Ohio Fire Academy

1
Ohio Department of Commerce

• Ohio Fire Academy
• OHIO HazMat WMD Awareness
• For the First Responder
• Course Nos. 1746 1751 1753

2
OhioHazmat WMD Awareness For The First
Responder
3
Course Information

• Course 1746-2009-???
• Course Title WMD Awareness

4
Introduction

• Who am I?
• Who are you?

5
Agenda

• Introduction 30 minutes
• Responsibilities 60 minutes
• Understanding HM 30 minutes
• R ID 120 minutes
• The ERG 45 minutes

6
Agenda (cont.)

• Resources 5 minutes
• Terrorism 60 minutes
• Decontamination 10 minutes
• Protective Clothing 2 hrs

7
Introduction (cont.)

• Disclaimer
• Executive Annex
• Table of Contents

8
Introduction (cont.)

• Course Description and Objectives
• OSHA 29 CFR 1910.120(q)(6)(I)
• NFPA
• Office of Domestic Preparedness

9
Introduction (cont.)

• Terminology
• Hazardous Materials
• Terrorism
• Definitions

10
UNIT ONE

• Role and Responsibility of the First Responder

11
Federal laws and standards

• Superfund Amendments and Reauthorization Act
  (SARA).
• 29 CFR 1910.120 and EPA 40 CFR part 311

12
Five levels of training

• Awareness
• Operations
• Technician
• Specialist
• On Scene Incident Commander

13
First Responder Awareness

• Responders at the awareness level are individuals
  who are likely to witness or discover a hazardous
  substance release and who have been trained to
  initiate an emergency response sequence by
  notifying the proper authorities of the release.
  They would take no further action beyond
  notifying the authorities of the release.

14
First Responder Operation

• Responders at the operations level are
  individuals who respond to releases or potential
  releases of hazardous substances as part of the
  initial response to the site for the purpose of
  protecting nearby persons, property, or the
  environment from the effects of the release.
  They are trained to respond in a defensive
  fashion without actually trying to stop the
  release. Their function is to contain the
  release from a safe distance, keep it from
  spreading, and prevent exposures.

15
Hazardous Material Technician

• Individuals who respond to a release or potential
  releases for the purpose of stopping the release.
  They assume a more aggressive role than the
  first responder at the operations level in that
  they will approach the point of release in order
  to plug, patch or otherwise stop the release of a
  hazardous substance.

16
Hazardous Material Specialist

• Individuals who respond with and provide support
  to hazardous materials technicians. Their duties
  parallel those of the hazardous materials
  technician, however, those duties require a more
  directed or specific knowledge of the various
  substances they may be called upon to contain.

17
On Scene Incident Commander

• Individuals who will assume control of the
  incident scene beyond the first responder
  awareness level. Incident commanders shall have
  received training equal to the operations level.

18
What is my role as a First Responder at the
Awareness Level?
19
First Responders must be able to perform basic

• Recognition
• Identification
• Isolation/Protection
• Notification, and
• Initiation of the Incident Command System

20
Recognition

• The First Responder must be able to recognize a
  hazardous materials incident.
•  RESPONDERS SHOULD NOT RUSH IN! IF YOU ARE HURT
  OR KILLED YOU CAN NOT HELP ANYONE.

21
Be Aware of any of the Following

• Vapor clouds
• Smoke
• Injured Persons
• Environmental Damage
• Evidence of explosive devices
• Booby traps
• Surrounding populations
• Dispersion pathways
• Suspicious persons around the scene

22
Potential Ignition Sources

• Traffic and Emergency Vehicles
• Open Flames
• Flares
• Lightening, or Static Discharges
• Electrical Sources, Downed Power Lines
• Flashlights and Two-Way Radios
• Exothermic Chemical Reactions (Heat Producing)

23
Identification

• Six clues
• Occupancy / Location
• Container Shapes and Sizes
• Markings and Colorings
• Placards / Labels
• Shipping Papers / Material Safety Data Sheets
  /Facility Pre-Plans
• Senses / Employees / Witnesses

24
It is not the responsibility of the first
responder to disregard their own personal safety
for the identification of the hazard.
25
THE FIRST RESPONDER SHOULD PROTECT THEMSELVES
FIRST!

• Isolation / Protection
• Isolate the area by prohibiting access
• Move un-injured un-contaminated people outside
  of the release area
• Isolate anyone contaminated

26
Isolation / Protection (cont.)

• Stop at a safe distance and use binoculars or
  such vision-enhancing device to assess the scene
  for placards or other clues.THE STOPPING POINT
  MAY BE DIFFERENT FOR EACH INCIDENT

27
RESPONDERS MUST NOT EXCEED THEIR LEVEL OF
TRAINING AND PROTECTION.
28
HAZARDOUS MATERIAL FIRST RESPONDERS TRAINED TO
THE AWARENESS LEVEL SHOULD NEVER PASS INTO THE
CONTAMINATED AREA OF THE RELEASE FOR ANY REASON
OUTSIDE OF DUTY TO SAVE LIVES.
29
Notification

• Fire Departments
• Police Departments
• Sheriffs Offices
• Highway Patrol
• Emergency Medical Services (EMS)
• Hazardous Material Response Teams
• FBI (WMD Related Incidents)
• Environmental Protection Agency
• Public Health Departments
• Public Utilities Commission
• Environmental Clean-up Companies

30
What they need to know

• The chemical name, placard and/or U.N. number
  with a description of the incident.
• Weather conditions and wind direction
• Status of the hazardous material container
• (stable, leaking, burning, etc.,)
• The location impacted
• (residential, commercial, industrial, etc.,)
• Victim s injuries

31
Incident Command

• The role of the Incident Commander (IC) will be
  assumed by the appropriate authority, as
  designated by state or local law. In many cases,
  the IC will be the most senior public safety
  officer (most likely the fire department chief or
  deputy chief however, in many circumstances it
  may be a local sheriff or senior local or state
  police official). As such, it is the
  responsibility of the IC to establish the
  Incident Command System (ICS) and to ensure that
  notifications of the above mentioned responders
  have been made or are in the process of being
  made. As the referenced agencies arrive, the IC
  will evolve into a Unified Command, as necessary.

32
The Incident Commander

• The Ohio Revised Code 3737.80 specifies
• In any emergency situation relating to the
  prevention of an imminent release of a hazardous
  material, to the cleanup or disposal of a
  hazardous material that has been released, or to
  the related mitigation of the effects of a
  release of a hazardous material, the chief of the
  fire department in whose jurisdiction the
  emergency situation is occurring or his designee
  is responsible for primary coordination of the
  on-scene activities of all agencies of the state,
  the United States government, and political
  subdivisions that are responding to the emergency
  situation until the chief relinquishes that
  responsibility to a representative of one of the
  responding public agencies and so notifies that
  representative.

33
Incident Command System
34
Incident Commander Title used under the
emergency response training section of OSHA 29
CFR, Part 1910.120.
35
Safety Officer Tasked with the responsibility
to maintain the health and safety issues of site
operations. He shall have the authority to
Suspend, Alter, or Terminate any operations that
are determined to be unsafe or immediately
dangerous to life or health (IDLH)
36
PIO Their purpose is to make contact with the
media and the general public. They will release
information regarding site activities.
37
Liaison Serves as the contact between the
Incident Commander and other governmental and/or
private organizational personnel.
38
Finance/Administration The Financial Officer
provides the necessary financial guidance and
contractual support that may be necessary during
a large incident.
39
Logistics Oversees the delivery of the
manpower, supplies and/or the equipment to
effectively control the incident site.
40
(No Transcript)
41
Planning Develops an emergency action plan and
monitors the success of the established plan.
42
(No Transcript)
43
Operations Directs the activities of the team
leaders within the site and coordinates these
activities with the I.C.
44
(No Transcript)
45
Unified Command

• New Federal Guidelines
• National Incident Management System (NIMS)

46
Response Procedures

• Standard Operating Procedures
• Emergency Response Plans

47
ICS Summary

• The first fifteen minutes on the scene of a
  hazardous materials incident will set the stage
  for the remaining response. If the initial
  response is safe and appropriate and the first
  responder fulfills their duty to recognize,
  identify, isolate, protect, notify and establish
  command then the subsequent responders can build
  upon this foundation and safely mitigate the
  hazard.

48
UNIT ONE TEST
49
UNIT TWO

• Understanding Hazardous Materials

50
Potential OutcomesTRACEM

• Thermal (Fire and/or Explosion)
• Radiological
• Chemical exposure
• Asphyxiation (Oxygen Deficiency)
• Etiological (Biological Hazards)
• Mechanical

51
Thermal (Fire and/or Explosion)

• Heat from a fire or the heat released by a
  chemical reaction
• Extreme cold, such as liquefied gas or cryogenic
  liquids

52
Radiological
Alpha - Most damaging, but least
penetrating Hazard Internal Shielding Paper,
dead layer of skin, travels 1 to 2 cm in air
Beta - Small particle low penetration Hazard -
Primarily external, but also internal Shielding -
Plastic, safety glasses, travels several feet in
air
-
?-
53
Gamma / X - Highly penetratingHazard - External
- most external dose due to gammaShielding -
Lead, steel, concrete, thick layers of water
Radiological (cont.)
?

• Neutron - Highly penetrating
• Hazard - External - most external dose due to
  gamma
• Shielding plastic, water

N
54
Characteristics of Radiation
Example of the penetrating power of the various
types of ionizing radiation
55
Asphyxiation

• Oxygen Deficiency
• Chemical Reaction  THE RELEASE OF CERTAIN
  PRODUCTS (I.E. NITROGEN) CAN DEPLETE THE OXYGEN
  LEVEL BELOW SURVIVAL LIMITS.

56
Chemical

• Toxic or poisonous effects
• Destructive effects from the exposure of the
  chemical on human tissue

57
Etiological

• Bacteria
• Viruses

Bacillus anthracis
58
Mechanical

• Debris
• Excessive percussion (Noise)

59
Routes of exposure

• Inhalation
• Ingestion
• Absorption
• Injection

60
Inhalation

• Nose
• Throat
• Trachea
• Lungs

61
Ingestion

• Mouth
• Throat
• Esophagus
• Stomach
• Intestines

62
Absorption

• Eyes
• Skin

63
Injection

• Needles
• Projectiles
• Shards
• Nails

64
Exposure to Hazards

• Acute
• Chronic
• Both types of exposures can have acute
  (immediate) and/or chronic (long term) effects.

65
Terrorist Events

• Intentional release
• Secondary devices
• Inflict mass casualties

66
Terrorist Chemical Agents

• Choking Agents
• Blood Agents
• Blister Agents
• Nerve Agents

The symptoms of these exposures can range from a
runny nose to rapid death and are considered to
be available to terrorist groups worldwide.
67
Emergency Medical Care

• Treatment only after emergency decon
• Safety First

68
Emergency Decon

• If a rescue is attempted and is successful
• the victim and the rescuer should be flushed
• with copious amounts of water
• Strip their outer level of clothing
• await hazardous materials operations level
• responders to arrive
• THE RESCUER NOW BECOMES A VICTIM BECAUSE OF
  UNKNOWN HAZARD EXPOSURE!!!

69
UNIT TWO TEST
70
UNIT THREE

• The Ability to Recognize and Identify Hazardous
  Materials

71
Clues of hazardous materials

• Six Basic Clues of Hazardous Materials
• Occupancy and/or Location
• Container Shape and Size
• Markings and Colorings
• Placards and Label Descriptions
• Shipping Papers and MSDS
• Human Senses

72
Occupancy and/or Location

• Fixed site facility
• Transportation sources

73
Fixed Site Facilities can include

• Farms
• Residential Areas
• Power Plants
• Medical Facilities
• School Labs and Research Facilities
• Manufacturing Plants
• Chemical Plants
• Clandestine Drug Labs

74
Farms

• Pesticides
• Herbicides
• Anhydrous Ammonia

75
Residential Areas

• Pool Chemicals
• Household Cleaning Chemicals

76
Power Plants

• Nuclear Fuel
• Radioactive Waste from Reactors

77
Medical facilities

• Radioactive Medicines
• Resonance Imaging Equipment

78
School labs and Research Facilities

• Chemical Research
• Biological Research
• Nuclear Research

79

• Manufacturing Plants
• Chemical Production Plants
• Storage Facilities
• Disposal Facilities

80
Clandestine Drug/WMD Labs

• Heavy Chemical Odors
• Sulfur
• Anhydrous Ammonia
• Lye
• Red Phosphorus
• Fortified Appearance to Location
• Occupants come outside to smoke
• Unusual Traffic at all hours
• Abnormal amounts of common products

81
DO NOT TOUCH ANYTHING!.
82
Transportation Sources

• Rail
• Air
• Marine
• Pipeline
• Highway

83
Rail

• Active or Abandoned
• List of telephone numbers for immediate contact

84
Air

• Usually smaller packages
• Formidable terrorist target
• Crop dusters

85
Marine

• Large quantities

86
Pipeline

• Natural Gas
• Crude Oil
• Gasoline
• Diesel
• Heating Oil

87
Highway

• Responders are more likely to have a hazardous
  incident related to highway transportation than
  with any other mode..

88
Container Shape and Size

• Individual containers
• Bulk transport containers
• Found in the NAERG
• Bulk storage containers

89
Tanks and Containers
90
DOT/MC 306Non-pressure Tank
91
DOT/MC 307Low Pressure Chemical Tank
92
MC-312Corrosive Liquid Tank
93
MC-331High Pressure Tank
94
MC-338Cryogenic Liquid Tank
95
Compressed Gas/Tube Trailer
96
Dry Bulk Cargo Tanker
97
Inter-Modal Containers
98
RAILROAD CARS
99
Railroad Tank CarsPressure
100
Railroad Tank CarsNon-pressure
101
Railroad Tank CarsOther
102
Railroad Tanks CarsOthers (cont.)
103
Storage Containers
104
Storage Containers (cont.)
105
Storage Containers (cont.)
106
Drums
107
Markings and Colorings

• National Fire Protection Association (NFPA) 704
  System
• Hazardous Materials Information System (HMIS)

108
National Fire Protection Association (NFPA) 704
System
109
Hazardous Materials Information System (HMIS)
110
Placards and Labels
UN Hazard Classification System
111
United NationsHAZARD CLASSES
112
UN Hazard Classes

• Nine Classes

113
Class 1 Explosives

• 1.1 Mass Explosives Dynamite
• 1.2 Projection Hazards Flares
• 1.3 Mass Fire Hazards Display Fireworks
• 1.4 Minor Hazards Ammunition
• 1.5 Very Insensitive Blasting Agents
• 1.6 Extremely Insensitive Explosive Devices

114
Class 2 Compressed Gasses

• 2.1 Flammable Gases
• Propane
• 2.2 Non-Flammable Gases
• Helium
• 2.3 Poisonous/Toxic Gases
• Fluorine, Compressed

115
Class 3 Flammable Liquids

• Flammable Liquids
• Gasoline

116
Class 4 Flammable Solids

• 4.1 Flammable Solids
• Magnesium
• 4.2 Spontaneously Combustible
• White Phosphorus
• 4.3 Spontaneously Combustible When Wet
• Sodium

117
Class 5 Oxidizers/Organic Peroxides

• 5.1 Oxidizers
• Ammonium Nitrate
• 5.2 Organic Peroxides
• Methyl Ethyl Ketone Peroxide

118
Class 6 Toxic Materials and Infectious Substances

• 6.1 Poison (Toxic Material)
• Potassium Cyanide
• 6.2 Infectious Substances
• Anthrax Virus

119
Class 7 Radioactive materials

• Radioactive
• Uranium

120
Class 8 Corrosives

• Corrosives
• Battery Fluid

121
Class 9 Miscellaneous

• Miscellaneous Hazardous Materials
• Polychlorinated Biphenyls (PCB)
• ORM-D (Other Regulated Material-Domestic)
• Food Flavorings, Medicines

122
Associated Placard Colors
123
Dangerous Placard

• First Responders will have no idea what hazardous
  materials are being transported when the
  DANGEROUS placard is being used.

124
Shipping Papers and MSDSs

• Must be available in all modes of transportation
  or any business or industry.

125
Shipping Papers

• Rail
• Way Bill
• Consist
• Highway
• Bill of Lading
• Freight Bill
• Manifest
• Air
• Air Bill

126
Shipping Papers

• Rail
• Way Bill
• Consist
• Highway
• Bill of Lading
• Freight Bill
• Manifest
• Air
• Air Bill

127
MSDSs

• MSDS
• Ammonia
• Sulfuric Acid

128
Human Senses

• Never deliberately use your own sense of taste
  or smell to identify a hazardous material
  however dont forget that a victim or witness may
  have already used these senses and may be of
  great benefit if asked what the product smelled
  like and how they are feeling.

129
UNIT THREE QUIZ
130

131
Unit Four

• The Emergency Response Guidebook

132
Unit Four Quiz

• Student Manual Page 71
• Answer the questions with information obtained by
  utilizing the following clip and your ERG

133
(No Transcript)
134
The ERG Performance Evaluation

• Appendix C

135
(No Transcript)
136
Unit Five

• Recognition of Additional Resources

137
Unit Six

• Recognizing Terrorist Activities

138
Terrorism Clues

• Occupancy
• Type of event
• Timing of the incident
• On-scene warning signs

139
Occupancy

• Government Buildings
• Schools
• Religious Buildings
• Public Assembly Points
• Mass Transit Systems
• Places with High Economic Impact

140
Occupancy (cont.)

• Military Installations
• Financial Institutions
• Entertainment Facilities
• Hospitals
• Utilities
• Places of Historical or Symbolic Significance

141

• Type of Event
• Political Rallies
• Timing of the Incident
• Holidays, Birthdays
• Celebrations
• Recent Known Threats

142
On scene warning signs

• Suspicious persons leaving the area
• Suspicious vehicles in the area
• Signs and symptoms of WMD agents
• Secondary devices discovered

143
Target Analysis

• Ethnic, separatist
• Extreme Issue
• Foreign Terrorist
• Right or Left wing extremeist

144
Sources for WMD agents

• Home production
• Laboratory production
• Industrial facilities
• Military
• Medical/university research facilities

145
Indicators of WMD Attack

• Primary Indicators
• Symptoms of victims
• Mass casualties
• Casualty pattern
• Dissemination device
• Warning given or credit taken

146
Indicators of WMD Attack (cont.)

• Secondary Indicators
• Dead animals or birds
• Statements of the victims
• Things out of place

147
Recognition of WMD / Hazmat Incident

• Chemical
• Biological
• Nuclear
• Radiological
• Explosive
• Incendiary

148
Chemical

• Recognition
• The six clues
• Victim signs and symptoms
• Threats Risks
• Usually a liquid when containerized
• May boil at low temperatures and become gases
• Normally disseminated as gasses or aerosols
• Most are influenced by weather conditions

149
Chemical (cont.)

• Basic Protection Measures
• SCBA only
• PPE
• Decontamination

150
Biological

• Recognition
• Large influx of calls
• Similar signs and symptoms

151
Biological (cont.)

• Threats Risks
• Do not penetrate unbroken skin
• Non-volatile
• Are more toxic than chemicals by weight
• Are undetectable by human senses
• Have limited field detection
• Disseminated as aerosols
• Effects range from skin disorder to death
• All are obtained from nature
• Are relatively easy to produce
• Have a delayed effect

152
Biological (cont.)

• Basic Protection
• SCBA
• APR with HEPA filter
• Protective clothing
• Good sanitation
• Decontamination

153
Radiological/Nuclear

• Recognition
• Dirty Bombs
• Small explosions that create dusts
• Threats Risks
• Alpha particles
• Beta particles
• Gamma Radiation

154
Nuclear (cont.)

• Risks
• The total amount of radiation received
• The dose rate
• The specific type of radiation
• Health risks
• Exposure
• Ingestion
• External contamination
• Internal contamination

155
Nuclear (cont.)

• Basic Protection
• Time
• Distance
• Shielding
• SCBA
• APR
• PPE
• Decon

156
Explosive

• Recognition
• Vehicles
• Pipe bombs
• Satchel devices
• IEDs

157
Explosives(cont.)

• Threats Risks
• Blast Pressure (Positive Negative)
• Fragmentation
• Thermal

158
Explosive (cont.)

• Basic Protection Measures
• Watch out for
• Abandoned containers
• Incidents preceded by a written or verbal threat
• Trip wires / booby traps
• Suspicious mailings
• Strong chemical odors
• Devices containing unknown items
• Multiple explosions

159
Incendiary

• Recognition
• Road flares
• Gasoline and motor oil
• Light bulbs
• Common electrical components
• Matches
• Household chemicals
• Fireworks
• Propane and butane cylinders
• Plastic pipes, bottles and cans

160
Incendiary (cont.)

• Threats Risks
• Basic types of incendiary devices
• Chemical
• Electronic
• Mechanical
• Delivery of incendiary devices
• Hand thrown
• Stationary
• Propelled

161
Incendiary (cont.)

• Basic Protection Measures
• PPE
• Observation of
• Secondary timed devices
• Multiple fire locations
• Signs of accelerants
• Flammable liquid containers
• Splatter patterns
• Fusing residue

162
RESPONDERS SHOULD ALWAYS BE OBSERVANT OF
SECONDARY DEVICES!!
163
Potential Outcomes for Terrorist CBRNE Event

• Thousands of casualties
• Residual contamination
• Overwhelmed emergency services
• Disrupted municipal functions
• Panic and confusion
• Loss of faith in the responders

164
Role of the First Responder Awareness at WMD /
Hazmat Incident

• Recognition and identification
• Protect themselves and others
• Notify authorities

165
Basic Isolation Procedures for WMD / Hazmat

• Isolate the area for protection and pending
  arrival of proper authorities.

166
Protection of WMD Crime Scene

• Remain extremely vigilant
• You may be called upon to testify
• Try to retain the evidentiary value of everything

167
Additional Contacts during WMD Incident

• Who are you going to call?
• FBI
• State Responders

168
UNIT SIX QUIZ
169
Unit Seven

• Decontamination

170
Can First Responders Do Decon!

• If it can be done safely!
• Contaminated live victims should receive
  immediate emergency decon.

Live Patients Cant Wait for Technical Decon to
Arrive!
171
Four Types of Decon

• Emergency Decon (Gross)
• Mass Decon (Gross)
• Technical Decon
• Hospital Decon

172
Decontamination

• Emergency Decontamination Procedure
• Wet
• Strip
• Flush
• Cover

173
Emergency Gross Decon

• Ambulatory Patients Should Receive Directed
  Self-Decon
• Use tepid, low pressure water
• Remove Clothing - 80 of contaminant is on
  clothing

Wet Strip Flush Cover
174
Emergency Gross Decon

• Avoid overspray splashing
• If corrosives, flush affected area for 15-20
  minutes
• Control Runoff, if possible. If not, then grassy
  area.

Wet Strip Flush Cover
175
Transport

• Always provide Gross Decon before Transport
• Minimize Secondary Respiratory Threat
• DO NOT cover doors and windows
• Open Windows, Vents and Exhaust to Exchange Air

BE SURE TO NOTIFY THE HOSPITAL IN ADVANCE!
176
Emergency vs. Mass Decon

• Mass Decon is Emergency Decon for More People!

177
Main Purposes of Mass Decontamination

• Protect response and medical personnel
• Remove chemical agent from Contaminated victims
• Limit spread of contamination

178
Time is Critical!

• That will cause the least harm
• Use the fastest approach
• And do the most good
• For the majority of the people!

179
Mass Casualty Decon General Principles

• Expect at least a 51 ratio of unaffected to
  affected casualties
• Decontaminate victims as soon as possible
• Disrobing (head to toe) is decontamination, more
  removal is better

180
Mass Casualty Decon General Principles

• Water flushing generally is the best mass decon
  method
• After a known exposure to a chemical agent,
  emergency responders should be decontaminated as
  soon as possible.

181
Decontamination for Contaminated First Responders

• Contaminated clothing and equipment must be
  bagged and tagged

182
Appendix A

• PERSONALPROTECTIVEEQUIPMENT

183
Personal Protective Equipment (PPE) is the
general term given to the protective clothing
that is worn during a response to an incident.
184
Levels of Protection

• LEVEL A
• Vapor tight suit
• SCBA or Supplied Air
• HIGHEST LEVEL OF PROTECTION

185
Levels of Protection

• LEVEL B
• Splash Suit
• SCBA or Supplied Air
• Next to highest level of protection

186
Levels of Protection

• LEVEL C
• Splash Suit
• Cartridge or canister APR
• Minimal level of protection

187
Levels of Protection

• LEVEL D
• Work uniforms
• Minimum protection

188
KNOWING THE SUITS LIMITATIONS IS IMPORTANT FOR
THE SAFETY OF THE RESPONDER
189
The State of Ohio Security Task Force (SOSTF)
has made available the First Responder Kit for
escape from a hazardous materials incident
190
PURPOSE

• Personal protective clothing protects
• From the rapid movement of a hazardous release
• From accidental contact with a contaminated
  victim
• The APR is donned for
• !! ESCAPE PURPOSES ONLY!!

191
CAUTION!

• IN NO WAY DOES THIS EQUIPMENT INCREASE THE ROLE
  AND RESPONSIBILITY OF THE FIRST RESPONDER LEVEL
  AS DEFINED!

192
Respiratory Protection Standards

• OSHA employers are required to develop and
  implement a written respiratory protection
  program
• (29 CFR 1910.134)

193
Personal Protective Equipment (PPE) Program

• Must consist of the following criteria
• Policy Procedures
• Selection criteria for PPE
• Maintenance Storage
• Decon Disposal
• Training Fitting

194
Personal Protective Equipment (PPE) Program

• Additionally
• Donning Doffing Procedures
• Inspection Procedures
• PPE Hazards Limitations
• Program Elevation

195
PPE Respiratory Protection Training

• When you are provided with the First Responder
  Kit for hazardous materials response, you will be
  fit-tested and given further training in the
  use of this equipment.

196
Appendix A

• PERSONALPROTECTIVEEQUIPMENT

197
Personal Protective Equipment (PPE) is the
general term given to the protective clothing
that is worn during a response to an incident.
198
Levels of Protection

• LEVEL A
• Vapor tight suit
• SCBA or Supplied Air
• HIGHEST LEVEL OF PROTECTION

199
Levels of Protection

• LEVEL B
• Splash Suit
• SCBA or Supplied Air
• Next to highest level of protection

200
Levels of Protection

• LEVEL C
• Splash Suit
• Cartridge or canister APR
• Minimal level of protection

201
Levels of Protection

• LEVEL D
• Work uniforms
• Minimum protection

202
KNOWING THE SUITS LIMITATIONS IS IMPORTANT FOR
THE SAFETY OF THE RESPONDER
203
The State of Ohio Security Task Force (SOSTF)
has made available the First Responder Kit for
escape from a hazardous materials incident
204
PURPOSE

• Personal protective clothing protects
• From the rapid movement of a hazardous release
• From accidental contact with a contaminated
  victim
• The APR is donned for
• !! ESCAPE PURPOSES ONLY!!

205
CAUTION!

• IN NO WAY DOES THIS EQUIPMENT INCREASE THE ROLE
  AND RESPONSIBILITY OF THE FIRST RESPONDER LEVEL
  AS DEFINED!

206
Respiratory Protection Standards

• OSHA employers are required to develop and
  implement a written respiratory protection
  program
• (29 CFR 1910.134)

207
Personal Protective Equipment (PPE) Program

• Must consist of the following criteria
• Policy Procedures
• Selection criteria for PPE
• Maintenance Storage
• Decon Disposal
• Training Fitting

208
Personal Protective Equipment (PPE) Program

• Additionally
• Donning Doffing Procedures
• Inspection Procedures
• PPE Hazards Limitations
• Program Elevation

209
PPE Respiratory Protection Training

• When you are provided with the First Responder
  Kit for hazardous materials response, you will be
  fit-tested and given further training in the
  use of this equipment.

210

• Ohio Fire Academy
• 8895 E. Main Street
• Reynoldsburg, OH 43068
• 1.888.726.7731
• TTY/TDD 1.800.750.0750
• www.com.ohio.gov/fire
• EVERYONE GOES HOME
