Getting More from HART CommunicationsRon
HelsonHART Communication FoundationAustin, TX
2
HART? Communication Protocol

• The Worldwide Standard for
• Smart Instrument Communication
• HART? is a registered trademark of the HART
  Communication Foundation

3
Things You Probably Know About HART

• Most smart instruments use
  HART Communication
• HART smart field devices are
  used interchangeably with
  traditional analog only
  units
• Hand Held Communicators are often used to
  perform device set-up, calibration, commissioning
  and periodic maintenance functions
• PC-based instrument management tools can
  remotely communicate with HART devices to
  manage calibration and other instrument
  parameters from central locations (instrument
  shop or control room)
• HART Savings for Installation Maintenance

4
Things You May Not Know About HART

• All HART smart devices generate considerable data
  of value to process operations 24/7
• HART provides access to all device
  data while the 4-20mA analog signal
  is being used for
  control
• Information about the status (health)
  of the field device and quality
  of the 4-20mA
  signal is transmitted with every message
• The Primary Variable is transmitted as a 4-20mA
  signal and also as digital value
• Many devices have other process variables
  (measured or calculated) in addition to the
  Primary Variable
• Using HART Data More Asset VALUE

5
Getting More from Your HART Assets

• HART devices can provide much more VALUE!
• In most installations, communication with HART
  devices is occasional or infrequent at best
• Communication is typically through hand held
  communicators for initial commissioning and
  periodic maintenance
• This part-time communication provides real
  savings, but uses only a small portion of the
  capability available in HART devices
• Continuous communication allows YOU to get the
  full value from YOUR HART assets
• Continuous Communication More VALUE

6
What You should know About HART Device Data

• 35-40 data items Standard in every HART device
• Device Status Diagnostic Alerts
• Process Variables Units
• Loop Current Range
• Basic Configuration Parameters
• Upper Lower Range Values
• Loop Test
• Force Loop Current to specific value
• Manufacturer Device Tag
• Standard commands for easy access

Lets look at the Easy-to-Use Data Items
7
HART Device Data

• Data in HART devices is Valuable to more than
  just the Instrument Dept
• Data includes
• Process Variables
• Device Status Alerts
• Device Information
• Basic Calibration Information
• All Data is easily available to Your Plant
  Systems!

8
Digital Process Variable Data

• Many HART devices are multi-variable and support
  more than one process measurement or calculated
  value
• Many Pressure Temperature devices
• Most Flow, Level Analytical devices
• All Valve Positioners / Controllers
• All Process Variable data includes
• IEEE Floating Point Value
• Standard Engineering Units Code
• Process Data Status
• Primary Variable is continuously transmitted on
  the 4-20mA loop
• HART gives You access to All Process Variables in
  the device

9
Typical HART Process Variable Data
10
Status Diagnostics

• HART smart field devices continuously self-assess
  and monitor their performance
• Device status information returned with every
  message
• Includes quality of 4-20mA signal and process
  variable data
• Using HART data increases control system
  integrity
• Get early warning of device problems
• Automatically track and detect changes
  in Range or Engineering Units
• Validate PV and Loop Current values at control
  system against those read from the device
• Now lets look at how to Use this Data

11
Getting HART in Plant Systems

• Most control system suppliers offer some type of
  HART interface solution today
• Capability varies
• Several have HART-capable I/O
• Others working to improve
• Third party interfaces
• Multiplexers - Provides path for HART data to OPC
  Servers and PC-based configuration and diagnostic
  applications
• Gateways to plant networks - TCP/IP Ethernet,
  Modbus, Profibus, etc
• Loop Monitors - convert HART device data into
  4-20mA signals, contact closures or fault alarms

MMI Engineering Maintenance
Controller
HART DA T A
I/O
12
Getting HART on Plant Networks

• OPC Server provides easy
  access to HART device
  data
  anywhere on plant network
• Allows several applications to
  access data in a HART device
  at the
  same time
• Provides popular MMI and
  Trending packages with access
  to data in
  HART devices
• Connect to one or thousands
  of devices using common
  HART I/O systems
  interfaces

HART SERVER TOOL
HART Device Data on Your Desktop Process
Variables, Range Values, Device Status
13
Using HART in Control Systems

• Continuously Monitor
  Device Status Diagnostics
• Device Malfunction
• Loop Current Fixed
• Device Needs Maintenance
• Validate data between
  Device System
• Read Loop Current, PV and Range
  values from device
• Validate with system values
• Track changes in Upper/Lower Range values (20mA
  4mA points)
• Use capability of Multi-Variable devices
• Access 2nd, 3rd 4th Process Variables for
  operator display, trending, or control
  functions
• Get value from additional measurements,
  calculated values (totalizers),
  actual valve position, etc.

14
Adding HART to Control Systems

• Some control systems have direct interface and
  support the use of HART process diagnostic data
  through-out
• Third party products support use with non-HART
  systems
• Multiplexer - Parallel with system I/O
• Several manufacturers
• Some integrally packaged with FTA
• Data access may be limited if one HART channel
  serves multiple devices
• Gateways - HART to Modbus, HART to Profibus and
  more to come...
• Tri-Loop - Converts secondary process variables
  into 4-20mA signals
• SPA - Converts secondary variables and device
  status alerts into contact closures

MMI Engineering Maintenance
Controller
I/O
15
MultiVariable Interface for non-HART
Systems
FV-Differential Pressure TV-Static
Pressure SV-Temperature PV-Compensated Flow
4-20mA Signals

• Tri-Loop takes digital process variable values
  from HART and produces 4-20mA signal for each
  secondary variable

HART Burst Mode Command 3
One Wire from Field to Control Room Multiple
Analog Signals to Control System
HART MultiVariable Transmitter With process
variables for Compensated Flow, Differential
Pressure,Static Pressure, and Temperature
16
Critical Loop Interface for non-HART
Systems
SPA gets process variable and device status data
via HART and generates additional 4-20mA signal
and/or contact closures for High/Low Alarm or
Instrument Fault
4-20mA Proportional to PV
HART Multivariable Device
HART Instrument Fault Alarm
Second Variable (SV) High/Low Alarm
Third Variable (TV) High/Low Alarm
Fourth Variable (FV) High/Low Alarm
4-20mA Proportional to SV, TV, or FV
One Wire from Field to Control Room Multiple
Analog Signals and Alarm Contacts in the Control
System
17
HART Master (Host) Capabilities

• Master implementation rules are more flexible
  than field device rules
• Capabilities vary based on the application
• Example Field Calibrator does not provide
  same functionality
  as DCS
• Simple HART features not supported
  in all Masters
• HART Master Classifications

Class Description
0 Host does not meet the minimum requirements
of Conformance Class 1 1 The host can utilize
cyclical process data from any field device
2 The host can supply the user with basic
identification and configuration data from any
field device 3 The host can perform basic
configuration for any field device - Minimum
level for classification as Generic Host
4 The host provides basic commissioning and
calibration support for any device 5 The host
can access all data items and device specific
functions for any device
18
Other Things You Should Know

• HART is Safe, Secure, and Available
• Tested and Accepted global standard
• Supported by all major instrumentation
  manufacturers
• Saves Time and Money
• Install and commission devices in fraction of the
  time
• Enhanced communications and diagnostics reduce
  maintenance downtime
• Low or no additional cost by many suppliers
• Improves Plant Operation and Product Quality
• Additional process variables and performance
  indicators
• Continuous device status for early detection of
  warnings and errors
• Digital capability ensures easy integration with
  plant networks
• Protects Your Asset Investments
• Compatible with existing instrumentation systems,
  equipment and people
• Allows benefits to be achieved incrementally
• No need to replace entire system
• HART High VALUE No RISK

19
Summary

• You probably have HART devices in your plant
  today
• Now you know more about the valuable data they
  can provide
• Its easy to get the additional data and VALUE
  from Your HART devices - Risk Free!
• HART is the lowest cost solution for improving
  Plant Performance and supporting Asset Management
  initiatives

20
What to Do?

• Identify your HART devices
• Provide HART capability training for your staff
• Talk with your systems supplier about access to
  your HART data and providing you with tools to
  better use the capability in your HART devices
• Use your assets to their fullest
  You probably are using only a small part of
  HART-ability
• Find Out More!

21
Support for HART Technology

• Provides Worldwide Support for Application of the
  HART Protocol Technology
• Technology Owner and Standards Setting Body for
  the HART Protocol
• Independent Non-Profit Organization
• Funded by Membership and Training/Support
  service fees
• Any Company interested in Use of the HART
  Protocol should be a member

22
Foundation Services

• Manage and control the HART Protocol
  Specifications
• Enhance the HART Technology
  as necessary to support industry
  needs for Smart Instrumentation
• Provide Training Workshops,
  Newsletters, Web Site and other
  Services to Educate Industry on
  use of the HART Protocol
• Manage Library of all Registered Device
  Descriptions

23
The Bottom Line...

• Most Users and Suppliers do not use the full
  value of HART Communication
• Get More from HART Communications!
• The HCF is here to help YOU!
