Multiple Regression

1
Multiple Regression

• Dummy Variables
• Multicollinearity
• Interaction Effects
• Heteroscedasticity

2
Lecture Objectives

• You should be able to
• Convert categorical variables into dummies.
• Identify and eliminate Multicollinearity.
• Use interaction terms and interpret their
  coefficients.
• Identify heteroscedasticity.

3
I. Using Categorical DataDummy Variables
Y X1 X2
Accidents
per 10000 Car
Obs Drivers Age Color
1 89 17 Red
2 70 17 Black
3 75 17 Blue
4 85 18 Red
5 74 18 Black
6 76 18 Blue
7 90 19 Red
8 78 19 Black
9 70 19 Blue
10 80 20 Red
Consider insurance company data on accidents and
their relationship to age of driver and the color
of car driven. See spreadsheet for complete
data.
4
Coding a Categorical Variable
Original Coding Original Coding     Alternate Coding Alternate Coding
Y X1 X2   Y X1 X2
Accidents   Accidents
per 10000 Car   per 10000 Car
Drivers Age Color   Drivers Age Color
89 17 1   89 17 3
70 17 2   70 17 1
75 17 3   75 17 2
85 18 1   85 18 3
74 18 2   74 18 1
76 18 3   76 18 2
90 19 1   90 19 3
78 19 2   78 19 1
70 19 3   70 19 2
80 20 1   80 20 3
This is the incorrect way. Output from the two
ways of coding give inconsistent results.
5
Original CodingPartial Output and Forecasts
SUMMARYOUTPUT
Regression Statistics Regression Statistics
Multiple R 0.817505768
R Square 0.668315681
Adjusted R Square 0.640675321
Standard Error 7.224556247
Observations 27
RESIDUAL OUTPUT
Observation Predicted Accidents Residuals
1 88.3556 0.6444
2 83.3556 -13.3556
3 78.3556 -3.3556
4 84.9611 0.0389
5 79.9611 -5.9611
6 74.9611 1.0389
7 81.5667 8.4333
8 76.5667 1.4333
9 71.5667 -1.5667
10 78.1722 1.8278
  Coefficients
Intercept 151.0611
Age -3.3944
Color -5.0000
6
Modified CodingPartial Output and Forecasts
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.872347406
R Square 0.760989997
Adjusted R Square 0.741072497
Standard Error 6.132770959
Observations 27
RESIDUAL OUTPUT
Observation Predicted Accidents Residuals
1 90.0222 -1.0222
2 76.6889 -6.6889
3 83.3556 -8.3556
4 86.6278 -1.6278
5 73.2944 0.7056
6 79.9611 -3.9611
7 83.2333 6.7667
8 69.9000 8.1000
9 76.5667 -6.5667
10 79.8389 0.1611
  Coefficients
Intercept 127.7278
Age -3.3944
Color 6.6667
7
Coding with Dummies
Original Dummies Original Dummies       Alternately Coded Dummies Alternately Coded Dummies Alternately Coded Dummies
Y X1 X2 X3   Y X1 X2 X3
Accidents   Accidents
per 10000   per 10000
Drivers Age D1 Red D2 Black   Drivers Age D1 Black D2 Blue
89 17 1 0   89 17 0 0
70 17 0 1   70 17 1 0
75 17 0 0   75 17 0 1
85 18 1 0   85 18 0 0
74 18 0 1   74 18 1 0
76 18 0 0   76 18 0 1
90 19 1 0   90 19 0 0
78 19 0 1   78 19 1 0
70 19 0 0   70 19 0 1
80 20 1 0   80 20 0 0
This is the correct way. Output from either way
of coding gives the same forecasts.
8
Original Dummy Coding
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.882407076
R Square 0.778642248
Adjusted R Square 0.749769497
Standard Error 6.028895798
Observations 27
RESIDUAL OUTPUT

Observation Predicted Accidents Residuals
1 91.1333 -2.1333
2 77.8000 -7.8000
3 81.1333 -6.1333
4 87.7389 -2.7389
5 74.4056 -0.4056
6 77.7389 -1.7389
7 84.3444 5.6556
8 71.0111 6.9889
9 74.3444 -4.3444
10 80.9500 -0.9500
  Coefficients
Intercept 138.8389
Age -3.3944
D1 Red 10.0000
D2 Black -3.3333
9
Modified Dummy Coding
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.882407076
R Square 0.778642248
Adjusted R Square 0.749769497
Standard Error 6.028895798
Observations 27
RESIDUAL OUTPUT
Observation Predicted Accidents Residuals
1 91.1333 -2.1333
2 77.8000 -7.8000
3 81.1333 -6.1333
4 87.7389 -2.7389
5 74.4056 -0.4056
6 77.7389 -1.7389
7 84.3444 5.6556
8 71.0111 6.9889
9 74.3444 -4.3444
10 80.9500 -0.9500
  Coefficients
Intercept 148.8389
Age -3.3944
D1 Black -13.3333
D2 Blue -10.0000
10
II. Multicollinearity

• We wish to forecast the height of a person based
  on the length of his/her feet. Consider data as
  shown

Height Right Left
77.31 11.59 11.54
67.58 9.57 9.63
70.40 8.97 8.98
64.84 9.39 9.46
77.03 12.05 12.03
79.66 11.39 11.41
72.37 10.55 10.61
73.18 10.31 10.33
77.60 11.81 11.81
71.40 9.92 9.88
11
Regression with Right Foot
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.903100477
R Square 0.815590472
Adjusted R Square 0.813800088
Standard Error 2.005327453
Observations 105
As right foot length increases by an inch, height
increases on average by 3.99 inches.
  Coefficients
Intercept 31.5457001
Right 3.9936768
12
Regression with Left Foot
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.900285778
R Square 0.810514482
Adjusted R Square 0.808674817
Standard Error 2.032739063
Observations 105
As left foot length increases by an inch, height
increases on average by 3.99 inches.
  Coefficients
Intercept 31.52588005
Left 3.99585252
13
Regression with Both
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.904210562
R Square 0.817596741
Adjusted R Square 0.814020206
Standard Error 2.004141795
Observations 105
As right foot length increases by an inch, height
increases on average by 8.52 inches (assuming
left foot is constant!) while lengthening of the
left foot makes a person shorter by 4.55 inches!!
  Coefficients
Intercept 31.76029318
Right 8.528657878
Left -4.555977176
14
The Reason? Multicollinearity.
  Height Right Left
Height (y) 1.0000
Right (X1) 0.9031 1.0000
Left (X2) 0.9003 0.9990 1.0000
While both feet (Xs) are correlated with height
(y), they are also highly correlated with each
other (0.999). In other words, the second foot
adds no extra information to the prediction of y.
One of the two Xs is sufficient.
15
III. Interaction Effects
Scores on test of reflexes Scores on test of reflexes Scores on test of reflexes
Y X1 X2
Obs Score Age Gender
1 80 25 0
2 82 28 0
3 75 32 0
4 70 33 0
5 65 35 0
6 60 43 0
7 67 46 0
8 70 55 0
9 60 56 0
10 55 67 0
11 90 24 1
Do reflexes slow down with age? Are there gender
differences? A portion of the data is shown
here.
16
Scatterplots with Age, Gender
Does age seem related? How about Gender?
17
Correlation, Regression
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.898113
R Square 0.806608
Adjusted R Square 0.783856
Standard Error 6.547818
Observations 20
Correlations  Score Age
Score 1
Age -0.8981 1
Gender -0.1311 0.1406
  Coefficients Standard Error t Stat P-value
Intercept 103.8807 4.735902 21.93473 6.58346E-14
Age -0.84478 0.101411 -8.33024 2.09518E-07
Gender -0.13641 2.957645 -0.04612 0.963752398
Age is related, gender is not.
18
Interaction Term
Y X1 X2 X1X2
Obs Score Age Gender Age Gender
1 80 25 0 0
2 82 28 0 0
3 75 32 0 0
4 70 33 0 0
5 65 35 0 0
6 60 43 0 0
7 67 46 0 0
..
11 90 24 1 24
12 87 28 1 28
A 2-way interaction term is the product of the
two variables.
19
Regression with Interaction
SUMMARY OUTPUT
Regression Statistics Regression Statistics
Multiple R 0.943570838
R Square 0.890325927
Adjusted R Square 0.869762038
Standard Error 5.082689038
Observations 20
How do we interpret the coefficient for the
interaction term?
  Coefficients Standard Error t Stat P-value
Intercept 90.10731707 5.389545 16.71891 1.49E-11
Age -0.516840883 0.122483 -4.21968 0.000651
Gender 24.27622946 7.353093 3.301499 0.004505
AgeGender -0.558724118 0.159875 -3.49476 0.002997
20
Meaning of Interaction

• X1 and X2 are said to interact with each other
  if the impact of X1 on y changes as the value of
  X2 changes.
• In this example, the impact of age (X1) on
  reflexes (y) is different for males and females
  (changing values of X2). Hence age and gender are
  said to interact.
• Explain how this is different from
  multicollinearity.

21
IV. Heteroscedasticity
Consider the water levels in Lake Lanier. There
is a trend that can be used to forecast. However,
the variability around the trendline is not
consistent. The increase in variation makes the
prediction margin of error unreliable.
22
Example 2 Income and Spending
As income grows, the ability to spend on luxury
goods grows with it, and so does the variation in
how much is actually spent. Once again, forecasts
become less reliable due to changing variation
(heteroscedasticity).
23
Solution

• When heteroscedasticity is identified, data may
  need to be transformed (change to a log scale,
  for instance) to reduce its impact. The type of
  transformation needed depends on the data.
