Keeping a Hawkeye on The Grid

1
Keeping a Hawkeyeon The Grid

• Nick LeRoy
• Computer Sciences Department
• University of Wisconsin-Madison
• nleroy_at_cs.wisc.edu
• http//www.cs.wisc.edu/condor/hawkeye

2
The Grid Idea

• Large scale distributed computing
• Solve massive computational problems

3
The Grid Reality

• Sites go down
• Updates need to by synchronized
• Firewalls get in the way
• Human errors occur
• Separate administrative domains cause
  inconsistencies

4
The Emperor's New Grid
Grid
5
Some Observations

• A lot of these problems can't be solved by
  technology alone
• Human errors
• Separate administrative domains
• Detecting problems is often quite difficult and
  time consuming

6
More Observations

• Can't fix problems before we're aware of them
• Impossible to prevent all classes of problems

7
So...

• Often more cost effective to detect work around
  problems
• Even when prevention is possible
• Detection is always required
• Automation is our friend

8
Watching the Grid

• We need a monitoring system
• That can automate detection
• That is flexible
• That is easy to deploy
• That can alert us of problems
• In a timely manner

9
Hawkeye

• Hawkeye is a monitoring tool
• Designed for grid and distributed applications
• Provides Automated detection
• Very Flexible
• Is Easy to deploy
• Provides Timely Alerts of problems

10
Watching the Grid
Grid
11
Hawkeye Uses

• Can be used for
• Monitoring system load, I/O, usage, etc.
• Watching for run-away processes
• Monitoring the health of your pool
• Watching the health of grid site
• ...

12
Some Details about Hawkeye

• Distributed monitoring system
• Uses a push data model
• Built on Condor technology
• Uses ClassAds match-making
• Every Condor has Hawkeye built-in
• Stable, production quality

13
Hawkeye UI

• Alert you when things go wrong
• When virtually any condition is found
• When various problems are found
• My checkpoint server's disk is full
• Joe has had a CVS lock for 20 minutes
• Help you visualize what's going on
• Plotting via RRDT

14
Why would I run Hawkeye?

• Make system administration easier
• Simplify pool maintenance
• Condor
• Other batch system
• Scalable solution

15
Hawkeye Architecture
16
Hawkeye Monitoring Agent
Hawkeye Job Manager
ClassAd
17
Hawkeye ClassAds

• Hawkeye uses Condor ClassAds to represent
  collected data
• Schema-free data representation
• Provides matching mechanism
• Represent whatever data you gather in a way that
  works best for you

18
Hawkeye ClassAds

• Example ClassAd snippet
• RAM_MemFree 841932800
• RAM_MemShared 0
• RAM_MemTotal 1055367168
• RAM_SwapCached 0
• RAM_SwapFree 2147483647
• RAM_SwapTotal 2147483647

19
Hawkeye Modules

• Current library of modules monitor
• Processes, CPU usage, etc.
• RAM, I/O, VM Statistics, etc.
• Disk space
• CVS repository
• GASS Cache statistics
• etc.

20
Hawkeye and Condor

• Hawkeye has Condor specific tools
• Developed to help us run our pool

21
Condor Node Module

• Run on each node of the pool
• Watches the Condor daemons
• Monitors multiple virtual machines
• Can identify run-away or orphaned jobs / processes

22
Condor Pool Module

• Run on just one host
• Reports overall pool health
• Watches for absent nodes
• Lots of data on
• Job Submitters
• Running Jobs
• CPUs in the pool

23
Other Condor Modules

• Checkpoint server module
• Watch of checkpoints, disk space, etc.
• Job history module
• Number and types of jobs, etc.

24
Custom Hawkeye Modules

• Hawkeye allows you to run your own custom
  modules to gather data
• Simple text to stdout
• Can be a shell One liner
• Can be a 100 line perl program
• All current modules are in perl
• Can be 10k-line C program

25
Hawkeye Alerts

• Hawkeye allows you in set your own custom
  alerts
• On attributes generated by standard and/or custom
  modules
• Flexible, uses ClassAd Match-making
• Used to generate dynamic web pages

26
Hawkeye Matchmaking

• Hawkeye alerts are done using ClassAd
  match-making.

27
Sample Alert Trigger

• AlertTrigger ( MyType "Pool"
  Absent.count gt 5 )
• AlertSeverity ( Absent.count gt 5 ) ? 1
  0
• Name "Absent Nodes"
• AlertText StrCat(Absent.count,
• " machines
  are missing in ",
• Name)

28
Advanced Trigger Tool

• ClassAd based trigger system with state
• Example Take some action if a machine has been
  heavily loaded for a certain amount of time
• Much more flexible
• You specify the action to take
• Maintains state information

29
More on Advanced Trigger

• Both current and previous state can be used in
  generating a trigger
• Example Send me an email when the system has
  been heavily loaded for a specified time, but
  don't flood my inbox with them...

30
Hawkeye Extras

• Currently available
• Tool to set up a Condor to easily install run
  Hawkeye modules
• In development
• Grid Exerciser module
• Data plotting tool

31
Hawkeye at UW

• Currently at UW CS, we're using Hawkeye
  extensively
• To monitor our 1400-CPU Condor cluster
• To aid in detecting and correcting cluster
  problems
• Hawkeye is one of our main tools for pool
  administration

32

33
(No Transcript)
34
(No Transcript)
35
What is the status of Hawkeye?

• Version 1.0 Release Candidate 5 RC5
• Version 1.0 real soon
• Available from http//cs.wisc.edu/condor/hawkeye
• Get help
• Condor condor-admin_at_cs.wisc.edu
