Lesson Overview

1
Lesson Overview

• 27.2 Respiration

2
THINK ABOUT IT

• Humans can drown because our lungs cant extract
  the oxygen we need from water. Most fishes have
  the opposite problem out of water, their gills
  dont work.
• How are these different respiratory systems
  adapted to their different functions?

3
Gas Diffusion and Membranes

• Animals have evolved respiratory structures
  that help movement of these gases by passive
  diffusion.
• Substances diffuse from an area of higher
  concentration to an area of lower concentration.
• Gases diffuse most efficiently across a thin,
  moist membrane that is permeable to those gases.
• The larger the surface area of that membrane,
  the more diffusion can take place.

4
Requirements for Respiration

• Respiratory structures provide a large surface
  area of moist, selectively permeable membrane.
• Respiratory structures maintain a difference in
  concentrations of oxygen carbon dioxide
  promoting diffusion.
• Because respiratory surfaces are moist, an
  animals breath condenses into fog when the air
  outside is very dry.

5
Gas Exchange

• What characteristics do the respiratory
  structures of all animals share?

6
Gas Exchange

• What characteristics do the respiratory
  structures of all animals share?
• Respiratory structures provide a large surface
  area of moist, selectively permeable membrane.
• Respiratory structures maintain a difference in
  the relative concentrations of oxygen and carbon
  dioxide on either side of the respiratory
  membrane, promoting diffusion.

7
Respiratory Surfaces of Aquatic Animals

• Many aquatic invertebrates most aquatic
  chordates exchange gases through gills.
• Gills are feathery structures that expose a
  large surface area of thin, selectively permeable
  membrane to water.
• Gill membranes is a network of tiny,
  thin-walled blood vessels called capillaries.

8
Respiratory Surfaces of Aquatic Animals

• Many animals actively pump water over their
  gills as blood flows through inside.
• As water passes over the gills, gas exchange is
  completed within the gill capillaries.

9
Respiratory Surfaces of Aquatic Animals

• Aquatic reptiles aquatic mammals, such as
  whales, breathe with lungs and must hold their
  breath underwater.
• Lungs are organs that exchange oxygen and carbon
  dioxide between blood and air.

10
Respiratory Surfaces of Aquatic Animals

• Some aquatic invertebrates, such as cnidarians
  flatworms have thin-walled bodies rely on air
  diffusion through their outer body covering.
  (skin breathers)
• A few aquatic chordates, including lancelets,
  some amphibians, and even some sea snakes, rely
  on skin to breath ex.) lungless frog

11
Respiratory Surfaces of Aquatic Animals

• How do aquatic animals breathe?

12
Respiratory Surfaces of Aquatic Animals

• How do aquatic animals breathe?
• Many aquatic invertebrates and most aquatic
  chordates other than reptiles and mammals
  exchange gases through gills.
• Aquatic reptiles and aquatic mammals, such as
  whales, breathe with lungs and must hold their
  breath underwater.

13
Respiratory Surfaces in Land Invertebrates

• Terrestrial invertebrates have a wide variety of
  respiratory structures.
• Some land invertebrates, such as earthwormsskin
  breather/ land snailsmantle cavity, which is
  lined with moist tissue and blood vessels.

14
Respiratory Surfaces in Land Invertebrates

• Spiders respire using organs called book lungs,
  which are made of parallel, sheetlike layers of
  thin tissues containing blood vessels.

15
Respiratory Surfaces in Land Invertebrates

• Most insects respire using a system of tracheal
  tubes that extends throughout the body.
• Air enters and leaves the system through
  openings in the body surface called spiracles.

16
Lung Structure in Vertebrates

• Inhaling O2 air into the lungs.
• Inside the lungs, O2 diffuses into the blood
  through lung capillaries.
• Co2 diffuses out of capillaries into the lungs.
• Oxygen-poor air is then exhaled.

17
Amphibian, Reptilian, and Mammalian Lungs

• The internal surface area of lungs increases
  from amphibians to reptiles to mammals.

18
Amphibian, Reptilian, and Mammalian Lungs

• A typical amphibian lung is little more than a
  sac with ridges.

19
Amphibian, Reptilian, and Mammalian Lungs

• Reptilian lungs are divided into chambers that
  increase the surface area for gas exchange.

20
Amphibian, Reptilian, and Mammalian Lungs

• Mammalian lungs branch extensively and are
  filled with bubblelike structures called alveoli.

21
Amphibian, Reptilian, and Mammalian Lungs

• Alveoli provide an enormous surface area for gas
  exchange, and enable mammals to take in the large
  amounts of oxygen required by their high
  metabolic rates.

22
Bird Lungs

• In birds, the lungs are structured so that air
  flows mostly in only one direction, so no stale
  air gets trapped in the system.
• Gas exchange surfaces are continuously in
  contact with fresh air.
• This highly efficient gas exchange helps birds
  obtain the oxygen they need to power their flight
  muscles at high altitudes for long periods of
  time.

23
Respiratory Surfaces of Terrestrial Animals

• What respiratory structures enable land animals
  to breathe?

24
Respiratory Surfaces of Terrestrial Animals

• What respiratory structures enable land animals
  to breathe?
• Respiratory structures in terrestrial
  invertebrates include skin, mantle cavities, book
  lungs, and tracheal tubes.
• What respiratory structures enable land animals
  to breathe?
• But all terrestrial vertebratesreptiles, birds,
  mammals, and the land stages of most
  amphibiansbreathe with lungs.
