Other Particle Searches at the Tevatron

1
Other Particle Searches at the Tevatron
Arnold Pompoš The University of Oklahoma For the
CDF DØ Collaborations
Štrbské Pleso
April 14-18
DIS 2004
Slovakia
2004
2
Outline
In this talk we report on

• Search for Large Extra Dimensions (LED)
• in Monojet MET channel
• in ee combined with ?? channel
• via dedicated search with ee
• in µµ channel
• Search for heavy gauge boson
• in ee channel
• in µµ channel
• Search for excited electrons

For search for Higgs, SUSY and LQ see S.
Beauceron, T. Kurca D. Ryans talks
3
-
Tevatron - pp collider
290 pb-1 on tape per experiment
data for physics
Feb 2002
April 2001

• High data taking efficiency
• in the range 80-90
• So far analyzed
• around 200 pb-1, which is already 2x the total
  Run I data.

Jul 2002
first data for analyses
detector commissioning
4
CDF DZero Experiments

• Extended spatial e, µ coverage
• New plug calorimeter improves also MET
  measurement
• Improved MET triggers
• Added triggers to identify leptons at early
  stage

• New silicon and fiber tracker
• Solenoid (2 Tesla)
• Upgrade of muon system
• Upgrade of Trigger/DAQ

5
New Phenomena Search Strategies
Both CDF DZero start searches with

• signature based strategy
• categorize data into bins of various event
  signatures
• compare bins to SM predictions and search for
  signs of deviations

and then the searches are tuned for best
sensitivity on

• specific models
• show us the signatures of your favorite model
• we tell you if data contains any event with such
  signature

6
New Phenomena Search Challenges

• Production cross sections very small
• s(new phenomena) 1 pb
• s(pp inelastic) 5x1010 pb
• Detectors are great, but not perfect
• particle detection efficiency lt 100
• Often hard to distinguish signal from background
• jet based strategies overwhelmed by SM processes

• we employ lepton based signatures, but the rates
  are often suppressed

-
7
Large Extra Dimensions
8
Motivations for Extra Dimensions

• Newtons 1/r2 law needs to be tested on
  submillimeter scales
• Hierarchy puzzle - Why is gravity so weak?
• EWK scale is MEWK1TeV
• Gravity scale is MPL1/vGN 1016 TeV
• Hierarchy solution Extra Dimensions.
• Gravity is localized (Randal Sundrum) on a
  different brane at d?0 from the brane we live
  on
• - Gravity propagation to extra D (us) is
  exponentially damped
• Gravity is not weak! (Arkani-Ahmed,
  Dimopoulos,Dvali) It is diluted into many
  dimensions, 4n, with n of them compactified to
  radius R
• M2PL(4 D) M2nPL(4n D)Rn
• - IF MPL(4n D) MEWK 1TeV then
• if n1 then R 1013 m (excluded by Newtons 1/r2
  law)
• if n2 then R 10-3 m (WORTH OF TESTING!)

9
Strong Gravity ( ADD )

• Compactified n dim. implies massive KK towers GKK
  of massless graviton G in each extra dim.
• SM lives in 31D, GKK live in 4n D ? strength of
  gravity diluted
• GKK couple to SM matter proportional 1/MPL (very
  weak coupling)
• Huge number of KK modes sum up and yield to
  measurable effects

V
g
q
g
g
q
g
Gkk
Gkk
Gkk
_
Gkk
Gkk
g
q
_
g
q
V
Possible real graviton emmission
Enable Graviton Mediated Processes
MonojetMET event signature
Dilepton and diphoton event signature
10
LED with Monojet MET
After all selection cuts Observe 63, Expect 100
with 60 uncertainty
Search for Real Graviton Emission
q
g
g
g
_
Gkk
Gkk
g
q
Analysis sensitive to jet energy scale (JES)
uncertainty.
Data versus SM
heavy G escapes to extra D large MET recoil
jet very energetic
Limit on Planck Scale Md
DØ ?Ldt 85 pb-1

• Data Selection
• MET gt 150 GeV,
• Jet1 gt 150 GeV
• Jet2 lt 50 (reduce ISR, FSR)
• ?FJ-MET gt 30o (reduce chance that MET comes
  from jet mismeasurement)
• Irreducible Background
• Z-gt ?? 1 or 2 jets (60 of total bckg.)

LEP
11
LED with ee ?? - Theory
Search for enhanced dilepton production
Gravity effect parametrized by hG
ee, ?? invariant mass
scatter. angle
Functions of M cosq determined by theory

• DØ Search Strategy
• Combine dielectron and diphoton to diEM signature
• Fit distribution of M vs cosq of Data SM
• Extract ?G from the fit
• Translate ?G into Ms limit

• ?G F/MS4
• F is a model dependent dimensionless parameter
  1
• GRW F 1
• HLZ F log(Ms2/M2), n 2
• F 2/(n-2), n gt 2
• Hewett F 2 ?/p, ? 1
• Ms is the UV cutoff MPL(4n dim)

12
LED with ee ?? - Event Selection

• LED search focuses on very high mass Drell-Yan
  region (graviton is heavy)
• We are not searching for dilepton mass peaks
  (will do so in Z searches)
• Region of interest is way above the Z mass ? very
  energetic e ?
• Triggers
• high pT single or dielectron triggers
• diphoton triggers

Unprescaled, gt99 efficient due to high pT of EM
objects

• Event Selection
• Two fiducial, central-central or central-forward,
  isolated EM objects
• ET gt 25 GeV for both EM objects
• No track selection. Treat dielectron and diphoton
  samples together

13
LED with ee ?? - Data vs Background

• Background estimation
• Drell-Yan and direct diphoton production
  estimated from MC
• Instrumental backgrounds estimated from data that
  fail electron quality cuts
• Normalize backgrounds by fitting to the low di-em
  mass spectrum, where no LED signal is expected

Data
Data vs MC
Signal prediction
QCD
SM prediction
DØ ?Ldt 200 pb-1
14
LED with ee ?? - DØ Limits

• Data agrees with SM prediction
• Extract ?g parameter from fit

• Translate hG95 limits to 95 CL lower limits on
  Planck scale MS, in TeV, using different
  formalisms for F

NLO k1.3 scale applied to signal MC
GRW HLZ for n Hewett
2 3 4 5 6 7 ? 1/-1
1.36 1.56 1.61 1.36 1.23 1.14 1.08 1.22/1.10
1.43 1.67 1.70 1.43 1.29 1.20 1.14 1.28/NA
DØ RunII
DØ RunI Run II
15
LED with ee - CDF Limits

• Data agrees with SM prediction
• Extract parameter from M(ee) fit
• Use cosq as a cross check

hG95 1.17 TeV-4
hG95 1.05 TeV-4
? -1
? 1

• Translate hG95 limits to 95 CL lower limits on
  Planck scale MS, in TeV, using different
  formalisms for F

GRW HLZ for n Hewett
2 3 4 5 6 7 ? 1/-1
1.11 1.11 1.17 0.99 0.89 0.83 0.79 0.99/0.96
No NLO k factor applied to signal MC
16
LED with µµ - DØ

• Event selection
• pT gt 15 GeV for both muon objects
• Isolated tracks
• M(mumu) gt 50 GeV
• Cosmics removed

DØ ?Ldt 100 pb-1
Observed events 3,000 events
No deviation from SM in data
Soon see results from 200pb-1
GRW HLZ for n Hewett
2 3 4 5 6 7 ? 1
0.88 0.75 1.05 0.88 0.80 0.74 0.70 0.79
17
LED with µµ - CDF

• Data agrees very well with SM predictions
• New LED results are around the corner _at_ CDF from
  µµ channel

18
LED with KK modes of Z Photon

• Model
• compactified n extra dimensions
• chiral matter lives on 3D
• gauge bosons live in all dimensions -gt existence
  Z ? KK modes
• Task
• measure the effect of KK modes of Z and ? on ee
  production

is bilinearly in
? same tools as LED
?C p2/3M2PL(4n dim)
and depends on dilepton mass and scattering angle

• Note
• at high masses the dilepton production is
  enhanced
• at intermediate masses M(Z) ? MC the negative
  interference causes event deficit.

• Search strategy same as in LED
• extract ?C from fit and translate into a limit on
  Mc

19
LED with KK modes of Z Photon- Limit

• Event Selection
• same as in diEM search, but
• gt1 e must have track
• no electron isolation required

Data
SM prediction
QCD
Signal prediction
Observed 14200 events
DØ ?Ldt 200 pb-1
Data vs MC
No deviation from SM in data
MCgt1.12 TeV
20
Localized Gravity ( RS ) with ee

• Gravity Propagates in Compactified 5th dim. -gt
  Towers of Kaluza-Klein modes of the graviton
• Coupling of GKK to Standard Model is of the order
  of TeV (determined by parameter k/MPL)
• Graviton mediated ee production searched
• CDF searched its high pT ee µµ sample

First direct constraints on RS
21
Localized Gravity ( RS ) with µµ
22
Heavy Extra Gauge Boson
23
Z Search Motivation

• Extra U(1) gauge boson is predicted by BSM
  theories (SO(10),E6)
• SSM Z couplings to fermions considered
  identical to the SM Z
• E6 inspired models E6 ? SU(3) x SU(2) x U(1)y x
  U(1)? x U(1)?, Z Z? sin? Z? cos?

Z? if ? 0 Z? if ? tan-1v(3/5) Z? if ?
p/2 ZI if ? tan-1(-v(3/5))
Z

• We search for leptonic Z decays. (Br 4 but
  very small bckg.)
• Same high pT ee µµ datasets searched as in LED
  analysis
• Looking for a mass peak in M(dilepton)
  distribution, located beyond the Z peak
  (different from LED searches, where we fit the
  high mass continuum).

24
Z in ee channel
DØ ?Ldt 200 pb-1

• Same event selection as for the search for LED in
  ee channel (KK modes of gauge bosons) .
• Different data interpretation

Data
SM prediction
Signal prediction
QCD
Limits (in GeV)

• SM Couplings
• CDF 750
• DØ 780
• E6 ZI Z? Z? Z?
• CDF 570 610 625 650
• DØ 575 640 650 680

SM coupling
ZI Z? Z? Z?
95 CL limit
25
Z in µµ channel Limits
DØ ?Ldt 100 pb-1
DØ result with 200 pb-1 is coming soon.
26
Excited Electron
27
Electron compositeness?
Contact Interaction

• CDF has searched for excited electrons (e),
  whose existence would indicate compositeness of
  electrons
• At Tevatron, e can be produced via contact
  interactions or gauge mediated interactions
• We select events with eeg in the final state
• Look for resonances in M(eg)
• Region of interest lies beyond the Z mass
• ET(e1)gt25 GeV, ET(e2)gt25 GeV, ET(g)gt25 GeV
• 81 GeV lt M(ee) lt 101 GeV (veto SM Z)
• SM background Zg events

M(e)/?, ? is the compositness scale
Gauge Mediated Interaction
f/?, f is the coupling to Z
In CDF ?Ldt 200 pb-1 we observed 3 events and
expected 3 events
28
Excited Electron Limits
Contact Interaction Limit
Gauge Mediated Interaction Limit
29
Spectacular eeee Event

• We are not only excluding, we are also measuring ?

• ZZ candidate in eeee channel
• sxBr 9x10-4

Calorimeter eta-phi lego plot
Et(e1)44 GeV
Et(e2)42 GeV
Et(p1)46 GeV
Et(p2)26 GeV
MET13 GeV
Central tracker
30
Conclusion
31
Conclusion

• Tevatron keeps breaking peak luminosity records
  and is steadily delivering collisions
• CDF and DØ detectors are recording high quality
  data
• We searched CDFs and DØs high energy electron,
  muon and photon samples for signs of new
  phenomena
• We set world leading limits on parameters of
  theories which consider the existence of extra
  dimensions, extra gauge boson or composite
  electron
• We are still in only a fraction of the expected
  total luminosity of 8fb-1 (2009)? MORE GREAT
  PHYSICS RESULTS are coming soon and even more in
  few years ?.
