Jakob Schneider

1
Planar-Chiral Hydrogen-Bond Donor Catalysts
Synthesis, Application and Structural Analysis
Literature Seminar
Montréal, 11.04.2011

• Jakob Schneider

1
2
2
3
Planar-Chiral Hydrogen-Bond Donor Catalysts
Synthesis, Application and Structural Analysis
Outlook

• Hydrogen-Bond Catalysis
• 2.2Paracyclophane Chemistry
• Synthesis of planar-chiral H-bond donor
  catalysts
• Organocatalytic applications
• Experimental and computational structural
  analysis
• Synthesis and Application of amino acid-based
  organocatalysts

3
4
Organocatalysis Structural motivs
Takemoto, 2003
Rawal, 2002
L-proline-mediated enamine-catalysis 1970
Wang, 2005
Akiyama, 2004
Jacobsen, 2004
MacMillan, 2003
Fu, 2002
4
4
5
Hydrogen-Bond catalysis

• Properties of hydrogen bonds

Strong Moderate Weak
Type of bonding Mostly covalent Mostly electrostatic Electrostatic
Length of H-Bond (Å) 1.2-1.5 1.5-2.2 2.2-3.2
Bond angles () 175-180 130-180 90-150
Bond energy (kcal/mol) 14-40 4-15 lt4

• Hydrogen-bond vs. Brønsted acid catalysis

5
5
6
Broensted acid catalysis

• BINOL-derived phosphoric acid-catalyzed addition
  of silyl ketene acetales to
• aldimines.

6
6
7
Hydrogen Bond catalysis Chiral Diols

• TADDOL-catalyzed hetero-Diels Alder reaction

• H-Bond-promoted H-Bond

7
7
8
Hydrogen-Bond catalysis Development of
(thio)urea compounds

• Activation of epoxides and unsaturated ketones

• Schreiners electron-deficient N,N-diphenyl
  thiourea

8
8
9
Hydrogen-Bond catalysis

• Strecker reaction of N-alkyl imines, catalyzed
  by
• Jacobsens Schiff-base thiourea

• Takemotos thiourea catalyst
• asymmetric Michael reaction

• Bifunctional mode of action

9
9
10
Hydrogen-bond catalysis

• Wang, 2005 Asymmetric MBH reaction.

• Asymmetric Michael reaction

10
10
11
Hydrogen-bond catalysis

• Mono- and bidentate interaction of thiourea
  derivatives with
• anionic substrates

• Role of the thiourea
• - preorganizing the arrangement of substrates
• - activating substrates through polarization
• - stabilizing charges, transition states or
  intermediates

11
11
12
Proposed mechanisms

• Mechanistic controversies

• Ternary complexes in the thiourea-catalyzed
  Michael reaction a) Takemotos proposal and b)
  results calculated by Pápai et al

12
12
13
2.2Paracyclophane

• Ar-ring distance 3.083.09 Å

13
13
14
2.2Paracyclophane

Light-weight Parylene functions under rugged
vacuum conditions and extreme temperatures, and
has been proven in multiple spaceflight
applications Parylene meets MIL-I-46058C, Army
Regulation 70-71, NAV.INST. 3400.2, and
USAF-80-30 regs

• Applications of 2.2Paracyclophane-based
• polymers

14
14
15
2.2Paracyclophane

• Transannular substitution Pseudo-geminally
  directing effect of acetyl, carbomethoxy,
  carboxy, nitro and sulfone substitutents

• Selective ortho-functionalization of
  4-hydroxy2.2paracyclophane
• derivatives via Friedel-Crafts acylation or
  directed metalation

15
15
16
2.2Paracyclophanes - Applications

• Catalytic enantioselective cyclopropanation of
  styrenes

• Enantioselective diethylzinc addition to
  benzaldehyde

16
16
17
2.2Paracyclophanes - Applications

• a) 1,2-addition of diethylzinc to
  isobutyraldehyde
• b) 1,4-addition of
• diethylzinc to cinnamylaldehyde

17
17
18
2.2Paracyclophanes - Applications

• Application of the Phanephos ligand in the
  enantioselective
• hydrogenation of ß-ketoesters

• Fürstners 2.2Pyridinophane-
• -based NHC ligand

• Epoxide ring-opening and Diels-Alder reaction
• (essentially racemic), catalyzed by RP-PHANOL

18
18
19
Development of planar-chiral catalysts

• Bifunctional thiourea-catalyst
• H-bond donor
• Planar chirality
• Defined distance between the functionalities
• Flexible catalyst design

19
19
20

Synthesis

20
20
21

Synthesis

21
21
22
2.2Paracyclophanes Synthetic Approaches
22
22
23
2.2Paracyclophanes Synthetic Approaches
23
23
24
Synthesis
24
24
25

Synthesis

• Versatile precursor synthesis

25
25
26

Synthesis
26
26
27

Synthesis
27
27
28

Synthesis

• Variation of the steric environment

• Variation of the H-bond donor functionality

28
28
29
Organocatalytic applications

• Asymmetric transfer hydrogenation of
• nitro olefins

• possible catalyst-substrate
• complex

29
29
30
Organocatalytic applications

• Asymmetric transfer hydrogenation of
• nitro olefins

• possible catalyst-substrate
• complex

• 30 24 ee

• 29 21 ee

• 42 lt5 ee

30
30
31
Structural analysis

• X-Ray structure of the racemic
  2.2Paracyclophane-thiourea
• H-bond-mediated association of the dimer

31
31
32
Structural analysis - Conformational Analysis
A quick introduction
1. Simple Force Field Approach Rough
classification
gt 130 kJ
2. Best of Energy Optimization simple
method (e.g. B3LYP, B98)
3. Single Point Energy calculation (various
methods and basis sets)
mPW1K, MP2, MP2(FC), QCISD,
Comparison of relative energies
32
33
Structural analysis - Comparison of relative
energies
- Ranking dependent on applied method
33
34
Computational analysis of conformers

• 1. Force-field conformational analysis
• 2. Energy optimization with DFT (B98/6-31G(d))
• 3. Single-point energy calculation with HF
  (MP2(FC)/6-31G(2d,p))
• 4. Comparison of all obtained structures

• 0.0

• 26.76 kJ/mol

• 26.01 kJ/mol

• 38.41 kJ/mol

34
34
35
Structural analysis NMR-titration
0
1
2
3

• Determination of the
• catalyst/substrate stoichiometry

Addition (equiv) of the substrate

• Observing the complexation of substrates

35
35
36
Structural analysis anion-complexation

• co-crystal structure of a
• thioureaNMe4Cl complex
• double hydrogen bonding

36
36
37
Structural analysis anion-complexation

• Complexation of DMSO

?d 0.144 ppm
37
37
38
Structural analysis

• Binding mode of the thiourea catalyst

• weak H-bond-
• interactions

• strong H-bond-
• interactions

38
38
39
Synthesis of amino acid-based catalysts

• easily accessible library of catalysts

• commercially available
• amino acid esters as
• starting materials

• tertiary alcohols

• secondary alcohols

• primary alcohols

39
39
40
Application of amino acid-based catalysts

• Asymmetric transfer hydrogenation
• of nitro olefins and nitro acrylates

• optimized conditions

• catalyst-screening

• tertiary alcohols
• 26 81, lt5 16 ee

• secondary alcohols
• 70 90, 20 62 ee

• primary alcohols
• 78 99, 50 70 ee

• 99, 70 ee

40
40
41
Application of amino acid-based catalysts

• Asymmetric transfer hydrogenation of
• nitro olefins and nitro acrylates

• scope

99, 70 ee
99, 50 ee
97, 67 ee
95, 63 ee
88, 56 ee
95, 68 ee
76, 87 ee
84, 40 ee
95, 60 ee
99, 58 ee
93, 54 ee
41
41
42
Application of amino acid-based catalysts

• mechanistic considerations

42
42
43
Conclusion

• Development of planar-chiral organocatalysts

• Organocatalytic applications transfer
• hydrogenation

• Conformational / substrate-binding
• analysis

• Synthesis and application of amino acid-
• based catalysts

43
43
44
Acknowledgements
Montréal, 11.04.2011

• Dr. Jan Paradies
• Prof. Stefan Bräse

44
