ISPS

1
ISPS

• 4. Ship Security Assessment

2
Ship Security Assessment

1. Risk Assessment Methodology
2. Assessment Tools
3. On-scene security surveys
4. Practical steps to conduct a SSA
5. Security assessment documentation

3
I. Risk Assessment Methodology

• What is SSA It is a process that identifies
  weaknesses in physical structures, personnel
  protection systems, processes, or other areas
  that may lead to a security breach, and may
  suggest options to eliminate or mitigate those
  weaknesses.
• Objective Detect threats to critical assets of
  the company and define preventive measures
  against security incidents affecting the company
  and the ships in order to prioritise security
  measures.

4
I. Risk Assessment Methodology

• Must be carried out by Persons With Appropriate
  Skills To Evaluate The Security of A Ship (see
  next)
• Under supervision of / assigned by Company
  Security Officer
• And this In Accordance With Part A Of The Code,
  Taking Into Account Part B Of The Code.

5
I. Risk Assessment Methodology

• Persons With Appropriate Skills
• Remark by Classification Company
• We understand the CSO should decide who has the
  appropriate skills although the Code does not
  stipulate specifically who will evaluate the
  appropriate skills. We also understand persons to
  carry out SSA may draw upon expert assistance as
  in Code B/8.4 in addition to his own skills. The
  specific ways to draw upon expert assistance are
  considered to be security consultant, literature,
  internet web site, services delivered by e-mail
  and various information issued by each country.
  We advise to make a list of those assistance
  methods to use for carrying out SSA.

6
I. Risk Assessment Methodology

• 3 Key steps
• Identify the key ship board operations important
  to protect. RISK ASSESSMENT
• Identify the possible threats to the ship and
  their probability of occurrence against the
  requirements of the ISPS Code. THREAT ASSESSMENT

1. Risk Assessment
2. Threat Assessment

7
I. Risk Assessment Methodology

• What is RISK for What?

X

1. Risk Assessment
2. Threat Assessment

8
I. Risk Assessment Methodology

• Sequence of activities
• Define the system being studied
• Identify the hazards associated with that system
• Assess the likelihood of the hazards occurring
• Identify how each hazard might progress to
  various outcomes

1. Risk Assessment
2. Threat Assessment

9
I. Risk Assessment Methodology

• Sequence of activities (contd)
• Assess the likelihood of progression to each
  outcome
• Asses the consequences associated with each
  outcome
• Multiply likelihood and consequence to obtain the
  risk associated with each outcome
• Sum the risks associated with the outcomes to
  produce an overall risk

1. Risk Assessment
2. Threat Assessment

10
I. Risk Assessment Methodology

• The Threats according to the ISPS Code are
• Damage to, or destruction of, the port facility
  or of the ship (by explosive devices, arson,
  sabotage, vandalism)
• Hijacking or seizure of the ship or the persons
  on board
• Tampering with cargo, essential ship equipment or
  systems or ships stores
• Attacks whilst at sea or from seaward at berth or
  at anchor

1. Risk Assessment
2. Threat Assessment

11
I. Risk Assessment Methodology

• Threats according to the ISPS Code are (Cont.)
• Unauthorized access or use including the presence
  of stowaways
• Smuggling weapons or equipment
• Use of the ship to carry those intending to cause
  a security incident and their equipment
• Use of the ship itself as a weapon or as means to
  cause damage or destruction
• Blockage of port entrances, locks, approaches,
  etc.
• Nuclear, biological and chemical attack

1. Risk Assessment
2. Threat Assessment

12
I. Risk Assessment Methodology

• Security Objects according to the ISPS Code are
• The ports infrastructure, especially the ports
  accesses, entrances, approaches, etc
• The ports facilities
• The ports employees / the employees of the
  ports companies
• The cargo present at the port
• The ports environment (surrounding areas, air,
  water)
• The ships (and the passengers) in the port
• The IT systems

1. Risk Assessment
2. Threat Assessment

13
I. Risk Assessment Methodology

• Items to be protected include
• The ships personnel
• Passengers, visitors, vendors, repair
  technicians, port facility personnel etc.
• The capacity to maintain safe navigation and
  emergency response
• The cargo, particularly dangerous goods or
  hazardous supstances
• Ships stores

1. Risk Assessment
2. Threat Assessment

14
I. Risk Assessment Methodology

• Items to be protected include (Cont.)
• Any ship security communication equipment and
  systems
• Any ships security surveillance equipment and
  systems

1. Risk Assessment
2. Threat Assessment

15
I. Risk Assessment Methodology

• Items to be taken into account that could create
  vulnerabilities
• Conflicts between safety and security measures
• Conflicts between shipboars duties and security
  assignments
• Watchkeeping duties, number of ships personnell,
  and any implications to crew fatigue, alertness
  and performance
• Any identified security training dificiencies
• Any security equipment and systems , including
  communication systems

1. Risk Assessment
2. Threat Assessment

16
Ship Security Assessment

1. Risk Assessment Methodology
2. Assessment Tools
3. On-scene security surveys
4. Practical steps to conduct a SSA
5. Security assessment documentation

17
II. Assessment Tools

• The Ship Security Officer must use systematic and
  consistent approaches to evaluate the security
  conditions and vulnerabilities.
• The operational aspects will be the main focus.
• A checklist can/will be used and must include
  items like

18
II. Assessment Tools

• Minimum Checklist items
• General layout of the ship
• Location of areas that should have restricted
  access, such as the bridge, engine room, radio
  room etc.
• Location and function of each or potential access
  point to the ship
• Open deck arrangements including the height of
  the deck above water
• Emergency and stand-by equipment available to
  maintain essential services

19
II. Assessment Tools

• Minimum Checklist items (Cont.)
• Numerical strength, reliability, and security
  duties of the ships crew
• Existing security and safety equipment for
  protecting the passengers and crew
• Existing agreements with private companies for
  providing ship an waterside security services
• Existing protective measures and procedures in
  practice, uncluding inspection, control and
  monitoring equipment, personnel identification
  documents and communication, alarm, lighting,
  access control and other appropriate systems

20
Ship Security Assessment

1. Risk Assessment Methodology
2. Assessment Tools
3. On-scene security surveys
4. Practical steps to conduct a SSA
5. Security assessment documentation

21
III. On-scene security surveys

• The on-scene security survey is an integral part
  of any SSA.
• A SSA is not complete without an on-scene
  security survey.
• A company can use 1 assessment for different
  ships but the survey is unique for every vessel.

22
III. On-scene security surveys

• The survey should fulfill the following
  functions
• Identification of existing security measures,
  procedures and operations
• Identification and evaluation of key shipboard
  operations that it is important to protect
• Identification of possible threats to the key
  shipboard operations and the likelihood of their
  occurrence, in order to establish and prioritize
  security measures
• Identification of weaknesses, including human
  factors in the infrastructure, policies and
  procedures

23
III. On-scene security surveys

• Min. items to be examined by On-scene security
  survey
• Ensuring the performance of all ship security
  duties
• Monitoring restricted areas to endure that only
  authorized persons have access
• Controlling access to the ship, including any
  identification systems
• Monitoring of deck areas and areas surrounding
  the ship

24
III. On-scene security surveys

• Min. items to be examined by On-scene security
  survey (Cont.)
• Controlling the embarkation of persons and their
  effects (accompanied and unaccompanied baggage
  and ships personnel personal effects)
• Supervising the handling of cargo and the
  delivery of ships stores
• Ensuring that ship security communication,
  information, and equipment are readily available

25
III. On-scene security surveys

• Threats...
• May imply risks for...
• Security Objects.

Preventive Measures Detective Measures Correctiv
e Measures
26
Ship Security Assessment

1. Risk Assessment Methodology
2. Assessment Tools
3. On-scene security surveys
4. Practical steps to conduct a SSA
5. Security assessment documentation

27
Overall steps to produce a SSA
IV. Practical steps to conduct a SSA
28
IV. Practical steps to conduct a SSA

• Step 1 Obtain and record the following
  information required to conduct an assessment
• Ship and company documentation as detailed in
  section 1 (should contribute to the threat
  evaluation phase)
• Record and document the following in detail
• Authorised access points as detailed in section 4
• Restricted areas as detailed within section 5
• Escape and evacuation routes as detailed in
  section 6
• Existing security equipment/systems as detailed
  in section 7

29
IV. Practical steps to conduct a SSA

• A copy of the ships general arrangement plan
  annotated with
• Authorised access points as detailed in section 4
• Restricted areas as detailed within section 5
• Escape and evacuation routes as detailed in
  section 6
• Existing security equipment/systems as detailed
  in section 7
• This gathered information will be used in the
  following steps.

30
IV. Practical steps to conduct a SSA

• Step 2 Conduct and document a detailed threat
  evaluation and risk assessment for the ship as
  detailed in section 8. Assess for any weaknesses,
  note them and address them in the on-scene
  security survey. Keep a copy of this
  documentation and add them to the final SSA.

31
IV. Practical steps to conduct a SSA

• Step 3 Conduct the on-scene security survey
  during which all previous information gathered
  must be confirmed and any weaknesses identified
  as detailed in section 9. Keep a copy of this
  survey in the final SSA

32
IV. Practical steps to conduct a SSA

• Step 4 If any ammendments are to be made to one
  of the previous documents, due to the making of
  the security survey, it must be done at this
  point. All additions and ammendments must be
  documented and copied in the ship security plan.
  They must also be retained in the SSA.

33
IV. Practical steps to conduct a SSA

• Step 5 Present the SSA to the company for review
  and acceptance. The SSP will be finalised with
  the SSA.
• Step 6 The SSP, accompanied with the assessment,
  is put forward for approval by the Administration
  or Recognised Security Organisation (RSO)

34
IV. Practical steps to conduct a SSA

• Practical steps for the mitigation of different
  threats/ scenarios
• Step 1 Scenario Selection
• Step 2 Evaluate/score the scenario in terms of
  potential consequences
• Step 3 Evaluate/score the scenario in terms of
  ships vulnerability
• Step 4 Determine if the scenario requires a
  mitigation strategy
• Step 5 Implement mitigation strategy

35
Potential Threat Scenarios
IV. Practical steps to conduct a SSA
36
Step 1 Scenario Selection
IV. Practical steps to conduct a SSA
37
Step 2 Evaluate, score the scenario in terms of
potential consequences
IV. Practical steps to conduct a SSA
38
Step 3 Evaluate, score the scenario in terms of
ships vulnerability
IV. Practical steps to conduct a SSA
39
Step 4 Determine if the scenario requires a
mitigation strategy
IV. Practical steps to conduct a SSA
40
Step 5 Implement mitigation strategy
IV. Practical steps to conduct a SSA
41
IV. Practical steps to conduct a SSA

• Exercise Restricted Areas
• Sum up the restricted areas o/b
• Read Comment

42
Ship Security Assessment

1. Risk Assessment Methodology
2. Assessment Tools
3. On-scene security surveys
4. Practical steps to conduct a SSA
5. Security assessment documentation

43
V. Security assessment documentation

• After completion of the SSA a report must be
  prepared, consisting of a summary of how the
  assessment was cinducted, a description of each
  vernerability found during the assessment, and a
  description of counter measures thet could be
  used to address each vulnerability.
• This report must be protected from unautherized
  access or disclosure.
