1Lecture 8
- Chapters 37 38
- Cardiac Disorders
2Cardiac Disorders
- System heart, blood vessels (arteries veins),
Blood - Blood rich w/ O2 nutrients moves through
vessels called arteries to narrower arteriols to
capillaries where the rich blood is absorbed by
bodies cells waste products are absorbed (CO2,
urea, Cr, ammonia) deoxygenated blood
returned to circulation via venules to veins for
elimination through lungs kidneys
3Cardiac disorders
- Heart
- 4 chambers - R L atria, R L ventricles
- Blood from circulation to R atrium to R
ventricle to pulmonary artery to lungs for gas
exchange (CO2 O2) to L atrium to L ventricle to
aorta to systemic circulation - Heart muscle myocardium surrounds the atria
ventricles
4Cardiac Disorders
- Pericardium fibrous covering around the heart
that protects it from injury infection - Endocardium 3-layered membrane that lines the
inner part of the heart chambers - Valves 4 - two atrioventricular (tricuspid
mitral) 2 semilunar (pulmonic aortic) -
control blood. flow between atria ventricles
pulmonary artery the aorta
5Right Ventricle
6Cardiac disorders
- Conduction Generated conducted by the
myocardium - usually - Originates in sinoatrial (SA) node -
pacemaker - atrioventricular (AV) node bundle of
HIS - purkinje fibers ventricular muscle
tissue - contraction from apex upward forcing blood
to lungs circulatory system
7Cardiac disorders
- Blood flow Heart Rate (HR)
- Ave. HR 60 - 80 beats/min. (adult)
- Ave. BP 120/80 mm/Hg - resistance to blood
flow through systemic arterial circulation - Arterial BP determined by Cardiac Output (CO)
the volume of bld. expelled form the heart in 1
min. - calculated by mult. HR by stroke volume -
Ave. CO 4 - 8 l/min.
8Cardiac Disorders
- Stroke Volume (SV) amt. of bld ejected from the
L vent. w/ each heart beat - Ave. 70ml/beat - - SV determined by 3 factors
- -Preload - blood flow force that stretches the
ventricle - - Contractility - force of ventricular
contraction - - Afterload - Resistance to vent. ejection of
blood caused by opposing pressures in aorta
systemic circulation - Specific drugs can or preload afterload,
affecting both SV CO - most vasodilators dec.
preload afterload a dec. in arterial
pressure CO
9Cardiac DisordersCardiac Glycosides
- Digitalis - One of the oldest drugs (1200 AD)
- - Effective in treating congestive heart
failure (CHF) - - CHF when the heart muscle weakens
enlarges loss of ability to pump blood
through the heart into the systemic
circulation heart failure (or pump failure) - - peripheral lung tissues become congested
CHF
10Cardiac DisordersCardiac Glycosides
- CHF can be left sided or right sided
- Cardiac glycosides digitalis glycosides
- - inhibits the Na - K pump inc.
intracellular Ca - cardiac muscle fibers contract more
efficiently - - Digitalis 3 effects on the heart 1)
inotropic action (inc. myocard. contraction) 2) -
chronotropic action (dec. HR) ) - dromotropic
action (dec. conduction of the heart cells
11Cardiac DisordersCardiac Glycosides
- The inc. in myocardial contractility inc.
card., peripheral, kidney function by inc. CO,
dec. preload, improving bld flow to periphery
kidneys, dec. edema, inc. fluid excretion
fluid retention in lung extremities is
decreased - Digitals also used to correct atrial fibrillation
atrial flutter (cardiac dysrhythmias)
12Cardiac Disorders Cardiac Glycosides
- Digoxin (Lanoxin) - Protein binding - low, t1/2
36 hrs - drug accumulation can occur - - monitor SE serum levels closely
- - metabolized by liver excreted by kidneys -
kidney dysfunction can affect excretion of dig. - - Do not confuse digoxin digitoxin
- - digitoxin highly protein bound w/ a long
t1/2 - seldom prescribed
13Cardiac DisordersDigoxin (Lanoxin)
- Action inc. myocardial contraction (
inotrophy), - and slows HR (- chronotropy), therefore
regulating the rate rhythm of the heart - - Therapeutic serum levels 0.5 - 2.0 ng/ml
- Use moderate/severe systolic CHF, arrythmias
- SE Dig. toxicity - bradycardia (pulse lt 60),
anorexia, diarrhea, NV, blurred vision, lethargy
- older adults more prone to toxicity - DI - Other heart meds
14Cardiac DisordersHeart Failure
- Other drugs
- Vasodilators - dec. venous blood return to the
heart dec. cardiac filling, ventricular
stretching O2 demand - Angiotensin-converting enzyme (ACE) inhibitors
- dilate venules arterioles improves renal
bld flow dec. bld fluid volume - Diruetics - first-line reduces fluid volume
15Cardiac DisordersAntianginal Drugs
- Used to treat angina pectoris ( acute cardiac
pain caused by inadequate bld flow resulting from
plaque occlusion in the coronary arteries of the
myocardium or from spasms of the coronary
arteries) - described as tightness, pressure in
center of chest, pain radiating down L arm -
attacks may lead to an MI - 3 Types of angina pectoris
- 1. Classic (stable) - stress or exercise
- 2. Unstable (preinfarction) - frequently over
day, severity - 3. Variant (Prinzmetal, vasospastic) - during
rest -
16Cardiac DisordersAntianginal Drugs
- Action - Inc. blood flow by inc. O2 supply, or by
dec. O2 demand by the myocardium - Nitrates, beta-blockers, calcium channel blockers
- Nitrates calcium channel blockers effective in
treating variant or vasospastic angina (not beta
blockers) - beta blockers effective in treating stable angina
- Non-pharm Rx avoid heavy meals, smoking,
extremes in weather changes, strenuous exercise,
stress - Proper nutrition, moderate exercise,
adequate rest relaxation techniques
17Cardiac DisordersAntianginals
- Nitrates - First agents used - Nitroglycerine
(NTG) - - Action - acts directly on the smooth muscle of
blood vessels relaxation dilation. - - Dec. cardiac preload afterload reduces
O2 demand - - dilation of veins less blood return to
the heart - - dilation of arteries less
vasoconstriction resistance - - Onset of Action
- - sublingual (under the tongue) IV 1 - 3
min. - - transderm nitro patch 30 - 60 min
18Cardiac DisordersAntianginals
- SE Headaches - less frequent w/ continued use,
hypotension, dizziness, weakness, faintness - Beta Blockers - Block the beta receptor site
- Atenolol (Tenormin), Metoprolol tartrate
(Lopressor), Nadolol (Corgard), Propranolol HCL
(Inderal) - - Action - Dec. the effects of the sympathetic
nervous system by blocking release of epi.
norepi dec. HR BP reduce the need for
O2 the pain of angina - - Nonselective (beta-1 beta-2) - Inderal,
Corgard, Visken - - Selective (beta -1) - Tenormin, Lopressor
19Cardiac DisordersAntianginals
- SE - Dec. in HR BP
- - Closely monitor vital signs
- Calcium Channel Blockers (Calcium Blockers) -
Newest - Amlodipine (Norvasc), Diltiazem HCL
(Cardizem), Nifedipine (Procardia, Adalat),
Verapamil (Calan, Isoptin) - - Action - Ca activates myocard. contraction
inc. workload of heart. Calcium blockers dec.
cardiac contractility (- inotropic) the
workload of the heart dec. O2 need
20Cardiac DisordersCalcium Blockers
- Use - long - term Rx of angina
- SE - Headache, Hypotension, dizziness, flushing
of the skin - - Bradycardia w/ verapamil (Calan)
- - Hypotension esp. w/ Nifedipine (most potent)
- promotes vasodilation of coronary peripheral
arteries - Calcium blockers can cause changes in liver
kidney function - Check liver enzymes
periodically - Can be given w/ nitrates to prevent angina
21Cardiac DisordersAntidysrhythmics
- Cardiac dysrhythmia (arrhythmia) any deviation
from the normal rate or pattern of the heartbeat.
HRs too slow (bradycardia), fast (tachycardia),
or irregular - Electrocardiogram (ECG) identifies the type of
dysrhythmia - - P wave atrial activation
- - QRS complex ventricular depolarization
- - T wave ventricular repolarization
- - PR interval atrioventricular conduction
time - - QT interval ventricular action potential
duration
22Cardiac DisordersAntidysrhythmics
- Atrial dysrhythmias prevent proper filling of
the ventricles dec. CO by 1/3 - Ventricular dysrhythmias life threatening d/t
ineffective filling of the ventricle dec. or
absent CO - Dysrhythmias can occur - after an MI, from
hypoxia (lack of O2 to body tissue), hypercapnia
(inc. CO2 in the bld.), excess catecholamines
(epi, norepi), or electrolyte imbalance
23Cardiac DisordersAntidysrhythmic Drugs
- 2 major classifications of dysrhythmias
- Above bundle of HIS supraventricular -
A-flutter, a-fib., PACs - Below bundle of HIS Ventricular - PVCs,
Vent. tachycardia, V-fib. - Desired action restoration of normal cardiac
rhythm - 4 Classes
- 1. Fast (sodium) Channel Blockers - dec. the
fast Na influx to the cardiac cells, so - dec.
conduction time of cardiac tissue, dec.
likelihood of ectopic foci, inc. repolarization - - 3 subgroups of fast channel blockers
24Cardiac DisordersAntidysrhythmics
- Class 1A - Procainamide (Pronestyl, Procan),
Quinidine Sulfate (Quinidex) - slows conduction
prolongs repolarization - - Use Control PVCs, vent. tachycardia
- - SE Anorexia, headache, dizziness, weakness
- Class 1B - Lidocaine (Xylocaine), Mexiletine
(Mexitil) - - Slows conduction shortens repolarization
- - Use Ventricular arrythmias associated w/
acute MIs - - IM IV - IV bolus then a drip started (1 -
4 mg/min.)
25Cardiac DisordersAntidysrhythmics
- Class 1C - Flecainide (Tambocor) - Prolongs
conduction w/ little to no effect on
repolarization - - Use - Life-threatening vent. dysrhythmias,
supraventricular tachycardia, a-fib or flutter - Beta Blockers - dec. conduction velocity
- Prolong Repolarization - Amiodarone (Cordarone) -
emergency Rx of ventricular dysrhythmias. Inc.
refractory perios prolong action potential
duration - Calcium Channel Blockers - inc. refractory period
of the AV node, dec. vent. response
26Diuretics
- Used for 2 main purposed decrease hypertension
(lower BP), decrease edema (peripheral
pulmonary) in CHF and renal or liver disorders - Other uses Dec. cerebral edema (Mannitol),
dec. intraocular eye pressure (glaucoma), dec.
ascities (liver disease) - Used either singly or in combo to dec. BP dec.
edema - Diuretics produce inc. urine flow (diuresis) by
inhibiting Na H2O reabsorption from the kidney
tubules. Act on the kidneys in diff. locations to
enhance excretion of Na (pg. 678)
27Diuretics
- Every 11/2 hr. the total vol. of the bodys
extracellular fluid (ECF) goes through the
kidneys (glomeruli) for cleansing 1st process
for urine formation - sm. particles
(electrolytes, drugs, glucose waste) filtered
in the glomeruli - Normally 99 of filtered Na passing through
glomeruli reabsorbed. 50 - 55 Na reabsorbtion in
proximal tubules, 35 - 40 in loop of Henle, 5 -
10 in distal tubules, lt3 in collecting tubules - Diuretics that act on tubules closest to
glomerule have greatest effect in causing
natriuresis (Na loss in urine) - Mannitol
28Diuretics
- Diuretics have an antihypertensive effect by
promoting Na H2O loss by blocking Na/Cl
reabsorption a dec. in fluid vol. a dec. of
BP - With fluid loss - edema should decrease. When Na
is retained, H2O also retained BP increases - Many diuretics cause loss of other electrolytes
(K, Mg, Cl, bicarb) - 5 categories of diuretics
29Action of Diuretics on Different Segments of
Renal Tubules
30DiureticsThiazides/Thiazide-like Diuretics
- Hydrochlorothiazide (Hydrodiuril, HCTZ),
Metolazone (Zaroxolyn) - Action - Distal tubules of the kidney to
promote Na, Cl, H2O excretion acts directly on
arterioles, causing vasodilation BP
preload CO dec. vascular fluid dec. in BP - Use - Rx of hypertension peripheral edema
- SE - Electrolyte imbalance (hypokalemia),
hyperglycemia (inc. bld sugar), hyperlipidemia
(inc. bld lipid level), dizziness, headaches, NV
31DiureticsThiazides
- CI - renal failure
- DI - Digoxin - if hypokalemia occurs, the
action of digoxin is enhanced dig. toxicity can
occur - Considered potassium - wasting - K
supplements are frequently prescribed serum K
levels are monitored - Loop Diuretics - Act on the ascending loop of
Henle by inhibiting Cl transport of Na into the
circulation (inhibits passive reabsorbtion of Na) - - Potent cause marked depletion of H2O
electrolytes - - Effect dose related - dose response
32DiureticsLoop diuretics
- More potent than thiazides as diuretics, but less
effective as antihypertensive agents - Can renal bld flow up to 40
- Have a great saluretic (Na-loosing) effect can
cause rapid diuresis vascular fluid vol.
dec. in CO BP - Bumetanide (Bumex), Furosemide (Lasix) -
derivatives of sulfonamides - Furosemide (Lasix) -
- Use - Rx fluid retention/overload due to
CHF, renal dysfunction, cirrhosis hypertension
pulmonary edema -
33Diruetics Loop Diuretics
- Lasix (cont) - used when other conservative
measures fail (Na restriction less potent
diuretics) - May be given IV or PO
- SE - Electrolyte imbalance ( esp.
hypokalemia K lt 3.5) dehydration, orthostatic
hypotension - DI - digitalis preparations - dig. toxicity
can result - Nursing - Strict I O, daily weights, vital
signs, hydration status of client - Clients should be on K supplements, monitor
serum K levels closely -
34DiureticsPotassium-Sparing Diuretics
- Weaker than thiazides loop diuretics
- Action - act primarily in the collecting distal
duct renal tubules to promote Na H2O excretion
K retention - Use - mild diuretics or in combo w/
antihypertensive drugs - K supplements not used - serum potassium excess
(hyperkalemia) results if K supplement taken w/
potassium - sparing diuretics
35DiureticsPotassium - Sparing
- Spironolactone (Aldactone), Triamterene
(Dyrenium) - Aldactone (an aldosterone antagonist) -
Aldosterone a mineralocorticoid hormone that
promotes Na retention K excretion Aldosterone
antagonsits inhibit the Na-K pump (K retained
Na excreted) - Amiloride (Midamor) - antihypertensive agent
- Triamterene - Rx of edema caused by CHF or
cirrhosis - K - sparing diuretics used alone less effective
than when combined with reducing body fluid Na - - Usually combine w/ a potassium wasting
diuretic
36Diuretics Combination
- Combine a potassium sparing potassium wasting
diuretic intensifies the diuretic effect
prevents K loss - spironolactone hydrochlorothiazide
(Aldactazide) - amiloride hydrochlorothiazide (Moduretic)
- triamterene hydrochlorothiazide (Dyazide,
Maxide) - When diuretic combinations are used, either
combined in one tablet or as separate tablets,
the dose of each is usually less than the dose of
any single drug - SE hyperkalemia - caution w/ clients having
poor renal function do NOT use K supplements
(unless K low)
