Intracellular Networks

1
Intracellular Networks
(2) Intracellular Network Behaviour
Slides on http//www.ibi.vu.nl/teaching/masters/i
cn/icn_2008.php
2
Networks
"The thousands of components of a living cell are
dynamically interconnected, so that the cells
functional properties are ultimately encoded into
a complex intracellular web network of
molecular interactions." "This is perhaps most
evident with cellular metabolism, a fully
connected biochemical network in which hundreds
of metabolic substrates are densely integrated
through biochemical reactions." (Ravasz E, et
al.)
3
(No Transcript)
4
TF
Ribosomal proteins
5
(No Transcript)
6
(No Transcript)
7
Motifs
8
Small-world networks
A recent paper, Collective dynamics of
"small-world" networks, by Duncan J. Watts and
Steven H. Strogatz, which appeared in Nature
volume 393, pp. 440-442 (4 June 1998), has
attracted considerable attention. One can
consider two extremes of networks The first are
regular networks, where "nearby" nodes have large
numbers of interconnections, but "distant" nodes
have few. The second are random networks, where
the nodes are connected at random. Regular
networks are highly clustered, i.e., there is a
high density of connections between nearby nodes,
but have long path lengths, i.e., to go from one
distant node to another one must pass through
many intermediate nodes. Random networks are
highly un-clustered but have short path lengths.
This is because the randomness makes it less
likely that nearby nodes will have lots of
connections, but introduces more links that
connect one part of the network to another.
9
Regular and random networks
random
regular
regular complete
10
Regular, small-world and random
networksRewiring experiments (Watts and
Strogatz, 1998)
p is the probability that a randomly chosen
connection will be randomly redirected elsewhere
(i.e., p0 means nothing is changed, leaving the
network regular p1 means every connection is
changed and randomly reconnected, yielding
complete randomness). For example, for p  .01,
(so that only 1 of the edges in the graph have
been randomly changed), the "clustering
coefficient" is over 95 of what it would be for
a regular graph, but the "characteristic path
length" is less than 20 of what it would be for
a regular graph.
11
Small-world and networks
A small-world network can be generated from a
regular one by randomly disconnecting a few
points and randomly reconnecting them elsewhere.
Another way to think of a small world network
is that some so-called 'shortcut' links are added
to a regular network as shown here
The added links are shortcuts because they allow
travel from node (a) to node (b), to occur in
only 3 steps, instead of 5 without the shortcuts.
12
Small-world networks

• Network characterisation
• L characteristic path length
• C clustering coefficient
• A small-world network is much more highly
  clustered than an equally sparse random graph (C
  gtgt Crandom), and its characteristic path length L
  is close to the theoretical minimum shown by a
  random graph (L Lrandom).
• The reason a graph can have small L despite being
  highly clustered is that a few nodes connecting
  distant clusters are sufficient to lower L.
• Because C changes little as small-worldliness
  develops, it follows that small-worldliness is a
  global graph property that cannot be found by
  studying local graph properties.

13
Small-world networks

A network or order (0ltplt1 as in earlier slides)
can be characterized by the average shortest
length L(p) between any two points, and a
clustering coefficient C(p) that measures the
cliquishness of a typical neighbourhood (a local
property).

These can be calculated from mathematical
simulations and yield the following behavior
(Watts and Strogatz)


14
(No Transcript)
15
Small-world networks
Part of the reason for the interest in the
results of Watts and Strogatz is that small-world
networks seem to be good models for a wide
variety of physical situations. They showed that
the power grid for the western U.S. (nodes are
power stations, and there is an edge joining two
nodes if the power stations are joined by
high-voltage transmission lines), the neural
network of a nematode worm (nodes are neurons and
there is an edge joining two nodes if the neurons
are joined by a synapse or gap junction), and the
Internet Movie Database (nodes are actors and
there is an edge joining two nodes if the actors
have appeared in the same movie) all have the
characteristics (high clustering coefficient but
low characteristic path length) of small-world
networks. Intuitively, one can see why
small-world networks might provide a good model
for a number of situations. For example, people
tend to form tight clusters of friends and
colleagues (a regular network), but then one
person might move from New York to Los Angeles,
say, introducing a random edge. The results of
Watts and Strogatz then provide an explanation
for the empirically observed phenomenon that
there often seem to be surprisingly short
connections between unrelated people (e.g., you
meet a complete stranger on an airplane and soon
discover that your sister's best friend went to
college with his boss's wife).
16
Small world example metabolism.

• Wagner and Fell (2001) modeled the known
  reactions of 287 substrates that represent the
  central routes of energy metabolism and
  small-molecule building block synthesis in E.
  coli. This included metabolic sub-pathways such
  as
• glycolysis
• pentose phosphate and Entner-Doudoro pathways
• glycogen metabolism
• acetate production
• glyoxalate and anaplerotic reactions
• tricarboxylic acid cycle
• oxidative phosphorylation
• amino acid and polyamine biosynthesis
• nucleotide and nucleoside biosynthesis
• folate synthesis and 1-carbon metabolism
• glycerol 3-phosphate and membrane lipids
• riboflavin
• coenzyme A
• NAD(P)
• porphyrins, haem and sirohaem
• lipopolysaccharides and murein
• pyrophosphate metabolism

• These sub-pathways form a network because some
  compounds are part of more than one pathway and
  because most of them include common components
  such as ATP and NADP.
• The graphs on the left show that considering
  either reactants or substrates, the clustering
  coefficient CgtgtCrandom, and the length
  coefficient L is near that of Lrandom,
  characteristics of a small world system.

random
Wagner A, Fell D (2001) The small world inside
large metabolic networks. Proc. R. Soc. London
Ser. B 268, 1803-1810.
17
Scale-free Networks
Using a Web crawler, physicist Albert-Laszlo
Barabasi and his colleagues at the University of
Notre Dame in Indiana in 1998 mapped the
connectedness of the Web. They were surprised to
find that the structure of the Web didn't conform
to the then-accepted model of random
connectivity. Instead, their experiment yielded a
connectivity map that they christened
"scale-free."

• Often small-world networks are also scale-free.
• In a scale-free network the characteristic
  clustering is maintained even as the networks
  themselves grow arbitrarily large.

18
Scale-free Networks

• In any real network some nodes are more highly
  connected than others.
• P(k) is the proportion of nodes that have
  k-links.
• For large, random graphs only a few nodes have a
  very small k and only a few have a very large k,
  leading to a bell-shaped Poisson distribution

Scale-free networks fall off more slowly and are
more highly skewed than random ones due to the
combination of small-world local highly connected
neighborhoods and more 'shortcuts' than would be
expected by chance.
Scale-free networks are governed by a power law
of the form P(k) k-?
19
Scale-free Networks
Because of the P(k) k-? power law relationship,
a log-log plot of P(k) versus k gives a straight
line of slope -?
Some networks, especially small-world networks of
modest size do not follow a power law, but are
exponential. This point can be significant when
trying to understand the rules that underlie the
network.
20
Hierarchical networks
C(k) k 1 a straight line of slope l on a
loglog plot (see figure, part Cc). A
hierarchical architecture implies that sparsely
connected nodes are part of highly clustered
areas, with communication between the different
highly clustered neighbourhoods being maintained
by a few hubs
21
Hierarchical networks
Iterative construction leading to a hierarchical
network. Starting from a fully connected cluster
of five nodes shown in (a) (note that the
diagonal nodes are also connectedlinks not
visible), we create four identical replicas,
connecting the peripheral nodes of each cluster
to the central node of the original cluster,
obtaining a network of N25 nodes (b). In the
next step, we create four replicas of the
obtained cluster, and connect the peripheral
nodes again, as shown in (c), to the central node
of the original module, obtaining a N125-node
network. This process can be continued
indefinitely.
22
Comparing Random and Scale-Free DistributionIn
the random network (right), the five nodes with
the most links (in red) are connected to only 27
of all nodes (green). In the scale-free network
(left), the five most connected nodes (red),
often called hubs, are connected to 60 of all
nodes (green).
23
Scale-free Networks
Before discovering scale-free networks, Barabasi
and his team had been doing work that modeled
surfaces in terms of fractals, which are also
scale-free. Their discoveries about networks
have been found to have implications well beyond
the Internet the notion of scale-free networks
has turned the study of a number of fields upside
down. Scale-free networks have been used to
explain behaviors as diverse as those of power
grids, the stock market and cancerous cells, as
well as the dispersal of sexually transmitted
diseases.
24
Scale-free Networks
Put simply, the nodes of a scale-free network
aren't randomly or evenly connected. Scale-free
networks include many "very connected" nodes,
hubs of connectivity that shape the way the
network operates. The ratio of very connected
nodes to the number of nodes in the rest of the
network remains constant as the network changes
in size. In contrast, random connectivity
distributionsthe kinds of models used to study
networks like the Internet before Barabasi and
his team made their observationpredicted that
there would be no well-connected nodes, or that
there would be so few that they would be
statistically insignificant. Although not all
nodes in that kind of network would be connected
to the same degree, most would have a number of
connections hovering around a small, average
value. Also, as a randomly distributed network
grows, the relative number of very connected
nodes decreases.
25
Scale-free Networks
The ramifications of this difference between the
two types of networks are significant, but it's
worth pointing out that both scale-free and
randomly distributed networks can be what are
called "small world" networks. That means it
doesn't take many hops to get from one node to
anotherthe science behind the notion that there
are only six degrees of separation between any
two people in the world. So, in both scale-free
and randomly distributed networks, with or
without very connected nodes, it may not take
many hops for a node to make a connection with
another node. There's a good chance, though, that
in a scale-free network, many transactions would
be funneled through one of the well-connected hub
nodes - one like Googles Web portal. Because
of these differences, the two types of networks
behave differently as they break down. The
connectedness of a randomly distributed network
decays steadily as nodes fail, slowly breaking
into smaller, separate domains that are unable to
communicate.
26
Scale-free Networks
Resists Random Failure Scale-free networks, on
the other hand, may show almost no degradation as
random nodes fail. With their very connected
nodes, which are statistically unlikely to fail
under random conditions, connectivity in the
network is maintained. It takes quite a lot of
random failure before the hubs are wiped out, and
only then does the network stop working. (Of
course, there's always the possibility that the
very connected nodes would be the first to go.)
In a targeted attack, in which failures aren't
random but are the result of mischief, or worse,
directed at hubs, the scale-free network fails
catastrophically. Take out the very connected
nodes, and the whole network stops functioning.
In these days of concern about cyber attacks on
the critical infrastructure, whether the nodes on
the network in question are randomly distributed
or are scale-free makes a big difference.
27
Scale-free Networks
Epidemiologists are also pondering the
significance of scale-free connectivity. Until
now, it has been accepted that stopping sexually
transmitted diseases requires reaching or
immunizing a large proportion of the population
most contacts will be safe, and the disease will
no longer spread. But if societies of people
include the very connected individuals of
scale-free networksindividuals who have sex
lives that are quantitatively different from
those of their peersthen health offensives will
fail unless they target these individuals. These
individuals will propagate the disease no matter
how many of their more subdued neighbors are
immunized. Now consider the following
Geographic connectivity of Internet nodes is
scale-free, the number of links on Web pages is
scale-free, Web users belong to interest groups
that are connected in a scale-free way, and
e-mails propagate in a scale-free way. Barabasi's
model of the Internet tells us that stopping a
computer virus from spreading requires that we
focus on protecting the hubs.
28
Scale Free Network Hubs, highly connected
nodes, bring together different parts of the
network Rubustness Removing random nodes has
little effect Low attack resistance Removing a
hub is lethal (PPI centrality-lethality rule,
see later). Random Network No hubs Low
robustness Low attack resistance
29
(No Transcript)
30
(No Transcript)
31
14-3-3 subtypes (paralogs)
Schematic representation of co-immunoprecipitation
studies performed with anti- MARK (microtubule
affinity-regulating kinase) antibodies. The
strength of the interactions is indicated by
the thickness of the arrows (after (2) .
32
connect preferentially to a hub
33
Preferential attachment

• Hub protein characteristics
• Multiple binding sites
• Promiscuous binding
• Non-specific binding

connect preferentially to a hub
34
Hub proteins in yeast
Genome-wide studies show that deletion of a hub
protein is more likely to be lethal than deletion
of a non-hub protein, a phenomenon known as the
centrality-lethality rule.

• .. network analysis suggests that the
  centrality-lethality rule is unrelated to the
  network architecture, but is explained by the
  simple fact that hubs have large numbers of PPIs,
  therefore high probabilities of engaging in
  essential PPIs
• He X, Zhang J (2006) Why do hubs tend to be
  essential in protein networks? PLoS Genet
  2(6)e88

35
Network motifs
36
Network motifs Types of feed-forward loops
Transcription regulation networks control the
expression of genes. The transcription networks
of well-studied microorganisms appear to be made
up of a small set of recurring regulation
patterns, called network motifs. The same network
motifs have recently been found in diverse
organisms from bacteria to humans, suggesting
that they serve as basic building blocks of
transcription networks.
Uri Alon, Nature 8, 450-461 2007
37
Network motifs

• Different Motifs in different processes
• More interconnected motifs are more conserved

38
(No Transcript)
39
(No Transcript)
40
Network Dynamics

• Party hubs always the same partners (same time
  and space)
• Date hubs different partners in different
  conditions (different time and/or space)
• Difference is important for inter-process
  communication

41
Network Dynamics

• Party hubs always the same partners (same time
  and space)
• Multiple small binding surfaces
• Date hubs different partners in different
  conditions (different time and/or space)
• A single (or perhaps a few) large (and less
  specific) binding surfaces

Date hubs large binding surfaces / Party hubs
small binding surfaces
42
s

• Need to create new binding interfaces

43
A network example from Meta-genomics Ecogenomics
soil ecosystems
A virtual network where species are nodes and
(groups of) chemical compounds are exchanged
between the nodes
44
(No Transcript)
45
(No Transcript)
46
Preferential attachment in biodegradation networks
New degradable compounds are observed to attach
preferentially to hubs close to (or in) the
Central Metabolism
Valencia and co-workers
47
The Matchmaker 14-3-3 family

• Massively interacting protein family (the PPI
  champions) by means of various binding modes
• Involved in many essential cell processes
• Occurs throughout kingdom of life
• Various numbers of isoforms in different
  organisms (7 in human)

48
14-3-3 dimer structure
49
14-3-3 network (hub?) promotion by binding and
bringing together two different proteins
50
Janus-faced character of 14-3-3s Identified
(co)-targets fall in opposing classes.
Clear color actin growth, pro-apoptotic,
stimulation of transcription, nuclear import,
neuron development. Hatched opposing functions.
100 56 proteins (De Boer Jimenez, unpubl.
data.).
51
Targets of 14-3-3 proteins implicated in tumor
development. Arrows indicate positive effects
while sticks represent inhibitory effects.
Targets involved in primary apoptosis and cell
cycle control are not shown due to space
limitations.
52
Role of 14-3-3 proteins in apoptosis 14-3-3
proteins inhibit apoptosis through multiple
mechanisms sequestration and control of
subcellular localization of phosphorylated and
nonphosphorylated pro- and anti-apoptotic
proteins.
What is the role of the subtypes? Modularity?
53
14-3-3 subtypes (paralogs)
Different subtypes display different binding
modes, reflecting pronounced divergent evolution
after duplication
14-3-3- subtypes ?,?,? and ?
Schematic representation of co-immunoprecipitation
studies performed with anti- MARK (microtubule
affinity-regulating kinase) antibodies. The
strength of the interactions is indicated by
the thickness of the arrows.
54
Phylogenetic profile analysis

• Function prediction of genes based on
  guilt-by-association a non-homologous
  approach
• The phylogenetic profile of a protein is a string
  that encodes the presence or absence of the
  protein in every sequenced genome
• Because proteins that participate in a common
  structural complex or metabolic pathway are
  likely to co-evolve, the phylogenetic profiles of
  such proteins are often similar''

55
Phylogenetic profile analysis

• Evolution suppresses unnecessary proteins
• Once a member of an interaction is lost, the
  partner is likely to be lost as well

56
Phylogenetic profile analysis

• Phylogenetic profile (against N genomes)
• For each gene X in a target genome (e.g., E
  coli), build a phylogenetic profile as follows
• If gene X has a homolog in genome i, the ith bit
  of Xs phylogenetic profile is 1, otherwise it
  is 0

57
Phylogenetic profile analysis

• Example phylogenetic profiles based on 60
  genomes

genome
gene
orf1034111011011001011111010001010000000011110001
1111110110111010101 orf10361011110001000001010000
010010000000010111101110011011010000101 orf103711
01100110000001110010000111111001101111101011101111
000010100 orf103811101001100100101100100111000001
01110101101111111111110000101 orf1039111111111111
1111111111111111111111111111101111111111111111101
orf104 10001010000000000000001010000000001100000
00000000100101000100 orf1040111011111111110111110
1111100000111111100111111110110111111101 orf10411
11111111111111111011111111111110111111110111111111
1111111101 orf10421110100101010010010110000100001
001111110111110101101100010101 orf104311101001100
10000010100111100100001111110101111011101000010101
orf104411111001111100100101110101111110011111111
11111101101100010101 orf1045111111011011001111111
1111111111101111111101111111111110010101 orf10460
10110000001000101100000011111000001010000000101001
0100000000 orf10470000000000000001000010000001000
100000000000000010000000000000 orf105
01101101101000101111011010101110011011001011111000
10000010001 orf1054010010011000000110000100010000
0000100100100001000100100000000
By correlating the rows (open reading frames
(ORF) or genes) you find out about joint presence
or absence of genes this is a signal for a
functional connection
Genes with similar phylogenetic profiles have
related functions or functionally linked D
Eisenberg and colleagues (1999)
58
Phylogenetic profile analysis

• Phylogenetic profiles contain great amount of
  functional information
• Phlylogenetic profile analysis can be used to
  distinguish orthologous genes from paralogous
  genes
• Subcellular localization 361 yeast
  nucleus-encoded mitochondrial proteins are
  identified at 50 accuracy with 58 coverage
  through phylogenetic profile analysis
• Functional complementarity By examining inverse
  phylogenetic profiles, one can find functionally
  complementary genes that have evolved through one
  of several mechanisms of convergent evolution.

59
Prediction of protein-protein interactionsRosetta
stone

• Gene fusion is the an effective method for
  prediction of protein-protein interactions
• If proteins A and B are homologous to two domains
  of a protein C, A and B are predicted to have
  interaction

A
B
Two-domain protein
C
Though gene-fusion has low prediction coverage,
it false-positive rate is low (high specificity)
60
Gene (domain) fusion example

• Vertebrates have a multi-enzyme protein
  (GARs-AIRs-GARt) comprising the enzymes GAR
  synthetase (GARs), AIR synthetase (AIRs), and GAR
  transformylase (GARt).
• In insects, the polypeptide appears as
  GARs-(AIRs)2-GARt.
• In yeast, GARs-AIRs is encoded separately from
  GARt
• In bacteria each domain is encoded separately
  (Henikoff et al., 1997).
• GAR glycinamide ribonucleotide
• AIR aminoimidazole ribonucleotide

61
Protein interaction prediction through
co-evolution

• FALSE NEGATIVES
• need many organisms
• relies on known orthologous relationships
• FALSE POSITIVES
• Phylogenetic signals at the organismal level
• Functional interaction may not mean physical
  interaction

62
Protein interaction database

• There are numerous databases of protein-protein
  interactions
• DIP is a popular protein-protein interaction
  database

The DIP database catalogs experimentally
determined interactions between proteins. It
combines information from a variety of sources to
create a single, consistent set of
protein-protein interactions.
63
Protein interaction databases

• BIND - Biomolecular Interaction Network Database
• DIP - Database of Interacting Proteins
• PIM Hybrigenics
• PathCalling Yeast Interaction Database
• MINT - a Molecular Interactions Database
• GRID - The General Repository for Interaction
  Datasets
• InterPreTS - protein interaction prediction
  through tertiary structure
• STRING - predicted functional associations among
  genes/proteins
• Mammalian protein-protein interaction database
  (PPI)
• InterDom - database of putative interacting
  protein domains
• FusionDB - database of bacterial and archaeal
  gene fusion events
• IntAct Project
• The Human Protein Interaction Database (HPID)
• ADVICE - Automated Detection and Validation of
  Interaction by Co-evolution
• InterWeaver - protein interaction reports with
  online evidence
• PathBLAST - alignment of protein interaction
  networks
• ClusPro - a fully automated algorithm for
  protein-protein docking
• HPRD - Human Protein Reference Database

64
Protein interaction database
65
Network of protein interactions and predicted
functional links involving silencing information
regulator (SIR) proteins. Filled circles
represent proteins of known function open
circles represent proteins of unknown function,
represented only by their Saccharomyces genome
sequence numbers ( http//genome-www.stanford.edu/
Saccharomyces). Solid lines show experimentally
determined interactions, as summarized in the
Database of Interacting Proteins19
(http//dip.doe-mbi.ucla.edu). Dashed lines show
functional links predicted by the Rosetta Stone
method12. Dotted lines show functional links
predicted by phylogenetic profiles16. Some
predicted links are omitted for clarity.
66
Network of predicted functional linkages
involving the yeast prion protein20 Sup35. The
dashed line shows the only experimentally
determined interaction. The other functional
links were calculated from genome and expression
data11 by a combination of methods, including
phylogenetic profiles, Rosetta stone linkages and
mRNA expression. Linkages predicted by more than
one method, and hence particularly reliable, are
shown by heavy lines. Adapted from ref. 11.
67
STRING - predicted functional associations among
genes/proteins

• STRING is a database of predicted functional
  associations among genes/proteins.
• Genes of similar function tend to be maintained
  in close neighborhood, tend to be present or
  absent together, i.e. to have the same
  phylogenetic occurrence, and can sometimes be
  found fused into a single gene encoding a
  combined polypeptide.
• STRING integrates this information from as many
  genomes as possible to predict functional links
  between proteins.

Berend Snel en Martijn Huynen (RUN) and the group
of Peer Bork (EMBL, Heidelberg)
68
STRING - predicted functional associations among
genes/proteins

• STRING is a database of known and predicted
  protein-protein interactions.The interactions
  include direct (physical) and indirect
  (functional) associations they are derived from
  four sources
• Genomic Context (Synteny)
• High-throughput Experiments
• (Conserved) Co-expression
• Previous Knowledge
• STRING quantitatively integrates interaction
  data from these sources for a large number of
  organisms, and transfers information between
  these organisms where applicable. The database
  currently contains 736429 proteins in 179 species

69
STRING - predicted functional associations among
genes/proteins
Conserved Neighborhood This view shows
runs of genes that occur repeatedly in close
neighborhood in (prokaryotic) genomes. Genes
located together in a run are linked with a black
line (maximum allowed intergenic distance is 300
bp). Note that if there are multiple runs for a
given species, these are separated by white
space. If there are other genes in the run that
are below the current score threshold, they are
drawn as small white triangles. Gene fusion
occurences are also drawn, but only if they are
present in a run.
70
STRING - predicted functional associations among
genes/proteins

• Gene clusters in a genomic region are likely to
  interact
• co-ordinated expression
• co-ordinated gene gains/losses

71
Functional inference at systems level

• Function prediction of individual genes could be
  made in the context of biological
  pathways/networks
• Example phoB is predicted to be a transcription
  regulator and it regulates all the genes in the
  pho-regulon (a group of co-regulated operons)
  and within this regulon, gene A is interacting
  with gene B, etc.

phoB
72
Functional inference at systems level

• KEGG is database of biological pathways and
  networks

73
Functional inference at systems level
74
Functional inference at systems level
75
Consequence of evolution

• Notion of comparative analysis (Darwin)
• What you know about one species might be
  transferable to another, for example from mouse
  to human
• Provides a framework to do multi-level
  large-scale analysis of the genomics data
  plethora

76
Functional inference at systems level

• By doing homologous search, one can map a known
  biological pathway in one organism to another
  one hence predict gene functions in the context
  of biological pathways/networks
• Mapping networks of multiple organisms and
  looking at the evolutionary conservation allows
  the delineation of modules and essential parts of
  the networks

77
Network Evolution
Human
Yeast
This pathway diagram shows a comparison of
pathways in (left) Homo sapiens (human) and
(right) Saccharomyces cerevisiae (bakers yeast).
Changes in controlling enzymes (square boxes in
red) and the pathway itself have occurred (yeast
has one altered (overtaking) path in the graph)
78
The citric-acid cycle
http//en.wikipedia.org/wiki/Krebs_cycle
79
The citric-acid cycle
Fig. 1. (a) A graphical representation of the
reactions of the citric-acid cycle (CAC),
including the connections with pyruvate and
phosphoenolpyruvate, and the glyoxylate shunt.
When there are two enzymes that are not
homologous to each other but that catalyse the
same reaction (non-homologous gene displacement),
one is marked with a solid line and the other
with a dashed line. The oxidative direction is
clockwise. The enzymes with their EC numbers are
as follows 1, citrate synthase (4.1.3.7) 2,
aconitase (4.2.1.3) 3, isocitrate dehydrogenase
(1.1.1.42) 4, 2-ketoglutarate dehydrogenase
(solid line 1.2.4.2 and 2.3.1.61) and
2-ketoglutarate ferredoxin oxidoreductase (dashed
line 1.2.7.3) 5, succinyl- CoA synthetase
(solid line 6.2.1.5) or succinyl-CoAacetoacetate
-CoA transferase (dashed line 2.8.3.5) 6,
succinate dehydrogenase or fumarate reductase
(1.3.99.1) 7, fumarase (4.2.1.2) class I (dashed
line) and class II (solid line) 8,
bacterial-type malate dehydrogenase (solid line)
or archaeal-type malate dehydrogenase (dashed
line) (1.1.1.37) 9, isocitrate lyase (4.1.3.1)
10, malate synthase (4.1.3.2) 11,
phosphoenolpyruvate carboxykinase (4.1.1.49) or
phosphoenolpyruvate carboxylase (4.1.1.32) 12,
malic enzyme (1.1.1.40 or 1.1.1.38) 13, pyruvate
carboxylase or oxaloacetate decarboxylase
(6.4.1.1) 14, pyruvate dehydrogenase (solid
line 1.2.4.1 and 2.3.1.12) and pyruvate
ferredoxin oxidoreductase (dashed line 1.2.7.1).
M. A. Huynen, T. Dandekar and P. Bork Variation
and evolution of the citric acid cycle a genomic
approach'' Trends Microbiol, 7, 281-29 (1999)
80
The citric-acid cycle
b) Individual species might not have a complete
CAC. This diagram shows the genes for the CAC for
each unicellular species for which a genome
sequence has been published, together with the
phylogeny of the species. The distance-based
phylogeny was constructed using the fraction of
genes shared between genomes as a similarity
criterion. The major kingdoms of life are
indicated in red (Archaea), blue (Bacteria) and
yellow (Eukarya). Question marks represent
reactions for which there is biochemical evidence
in the species itself or in a related species but
for which no genes could be found. Genes that lie
in a single operon are shown in the same color.
Genes were assumed to be located in a single
operon when they were transcribed in the same
direction and the stretches of non-coding DNA
separating them were less than 50 nucleotides in
length.
M. A. Huynen, T. Dandekar and P. Bork Variation
and evolution of the citric acid cycle a genomic
approach'' Trends Microbiol, 7, 281-29 (1999)
81
Wrapping up

• Prims algorithm for MST and derived clustering
  protocol
• Regular, random, small-world and scale-free
  networks
• Evolution of topology and dynamics of biological
  networks, e.g. duplication, preferential
  attachment, party/date hub proteins,..
• We have seen a number of ways to infer a putative
  function for a protein sequence (e.g. guilt by
  association) PPI prediction is a special case
  and you should know the related methods
• Phylogenetic signal to predict PPI (co-evolution)
• To gain confidence, it is important to combine as
  many different prediction protocols as possible
  (the STRING server is an example of this)
• Comparing and overlaying various networks (e.g.
  regulation, signalling, metabolic, PPI) and
  studying conservation at these network levels is
  one of the current grand challenges, and will be
  crucially important for a systemsbased approach
  to (intra)cellular behaviour.
