Title: Transposons


1
Transposons
  • Dr Derakhshandeh

2
Mobile Genetic Elements
  • Transposons or Transposable elements (TEs)
  • move around the genome

3
Transposable elements in prokaryotes
  • Insertion sequence (IS) elements
  • Transposons (Tn)
  • Bacteriophage Mu

4
Insertion sequence (IS) elements
  • Simplest type of transposable element found in
    bacterial chromosomes and plasmids
  • Encode only genes for mobilization and insertion
  • Range in size from 768 bp to 5 kb
  • IS1 first identified in E. colis glactose operon
    is 768 bp long and is present with 4-19 copies in
    the E. coli chromosome
  • Ends of all known IS elements show inverted
    terminal repeats (ITRs)

5
(No Transcript)
6
Integration of IS element in chromosomal DNA
7
Three different mechanisms for transposition
  • Conservative transposition
  • Replicative transposition
  • Retrotransposition

8
Three different mechanisms for transposition
  • Conservative transposition The element itself
    moves from the donor site into the target site
  • Replicative transposition The element moves a
    copy of itself to a new site via a DNA
    intermediate
  • Retrotransposition The element makes an RNA copy
    of itself which is reversed-transcribed into a
    DNA copy which is then inserted (cDNA)

9
Conservative transposition
10
Replicative transposition
11
Retrotransposition
12
common feature of mobile elements
  • Generation of short direct repeats flanking the
    newly inserted element
  • This results for a staggered cut being made in
    the DNA strands at the site of insertion

13
(No Transcript)
14
Transposons (Tn)
  • Similar to IS elements but are more complex
    structurally and carry additional genes
  • 2 types of transposons
  • Composite transposons
  • Noncomposite transposons

15
  • Composite transposons

16
IS10R is an autonomous element, while IS10L is
non-autonomous
17
Composite Transposons
  • Tetracycline resistance is carried by a
    transposable element
  • The transposon is a composite transposon,
    composed of IS-elements flanking an included
    sequence, in this case containing an antibiotic
    resistance gene
  • IS10R is an autonomous element
  • while IS10L is non-autonomous
  • Composite transposons probably evolved from IS
    elements by the chance location of a pair in
    close proximity to one another. Inactivation of
    one element by mutation would not harm ability to
    transpose and would assure continued
    transposition of the entire transposon

18
  • Noncomposite transposons

19
Noncomposite transposons (Tn)
  • Carry genes (e.g., a gene for antibiotic
    resistance)
  • Ends are non-IS element repeated sequences
  • Tn3 is 5 kb with 38-bp ITRs and includes 3 genes
    bla (?-lactamase), tnpA (transposase), and tnpB
    (resolvase, which functions in recombination)

20
Examples of DNA-intermediate mobile elements
  • Insertion Sequences (IS) elements in bacteria
  • P elements in Drosophila
  • AC/DS (dissociation) elements in maize
  • AC is a full-length autonomous copy
  • DS is a truncated copy of AC that is
    non-autonomous, requiring AC in order to
    transpose
  • At least seven major classes of DNA transposons
    in the human genome (3 of total genome)

21
Methods for Generation of Mutant Populations
  • The most reliable method to ascertain gene
    function is to disrupt the gene and determine the
    phenotype change in the resulting mutant
    individual
  • Two most popular methods to generate mutants
  • 1. Insertional mutagenesis
  • 2. Deletion mutagenesis

22
Two main methods
  • 1. Transposon insertion
  • 2. T-DNA insertion

23
Transposon mutagenesis
  • Transposable elements or transposons
  • sections of DNA (sequence elements)
  • move, or transpose, from one site in the genome
    to another

24
All transposable elements fall into one ofthe
following two classes
  • 1. DNA elements
  • 2. Retroelements

25
DNA elements
  • These elements transpose via DNA intermediates
    such as
  • Ac/Ds and Spm in plants, P elements in animals,
    Tn in bacteria
  • A common feature of DNA elements is the flanking
    of the element by short inverted repeat sequences
  • The enzyme transposase recognizes these
    sequences, creates a stem/loop structure
  • excises the loop from the region of the genome
  • The excised loop can then be inserted into
  • another region of the genome

26
DNA-Immediate Mobile Genetic Elements
  • The Short inverted repeats at the ends of the
    element
  • These inverted repeats act as the substrates for
    recombination reactions mediated by the
    transposase

27
Structure and transposition of a transposable
element
28
Retroelements
  • transpose via RNA intermediates
  • The RNA is copied by reverse transcriptase into
    DNA
  • the DNA integrates into the genome
  • Retroelements are found in all eukaryotes
  • such as Tos in rice, copia in animals and Ty1 in
    yeast

29
Retrotransposon transposition
30
Retorviruses
  • The basic structure is an LTR long terminal
    repeat which flanks three genes,
  • A complete retroviruses also contains three
    genes
  • gag structural gene for capsid
  • Pol reverse transcriptase
  • env envelope gene for the virus

31
(No Transcript)
32
How do we use a transposonfor mutagenesis?
  • The insertion and excision of transposable
    elements
  • result in changes to the DNA at the transposition
    site
  • The transposition can be identified when a known
    DNA sequence or selection markers are inserted
    within the elements

33
Transposomics
  • EZTN Transposomes provide an efficient and
    reliable method for generating a library of
    random gene knockouts in vivo
  • Gene inactivation and examination of the
    resulting phenotype will identify the function of
    the interrupted genes

34
Transposon-Mediated Homologous RecombinationGene
Knockout in FungiHamer et al. 2001. Proc Natl
Acad Sci U S A. 2001 2498(9)5110-5
35
T-DNA insertion mutagenesis
  • T-DNA is a segment of the tumor-inducing (Ti)
    plasmid of Agrobacterium
  • delimited by short imperfect repeat border
    sequences

36
T-DNA transfer from Agrobacterium to plant cell
37
Temperate bacteriophage Mu (Mu mutator)
  • 37 kb linear DNA with central phage DNA and
    unequal lengths of host DNA at each end
  • Mu integrates by transposition
  • replicates when E. coli replicates
  • During the lysogenic cycle, Mu remains integrated
    in E. coli chromosome

38
bacteriophage Mu
39
The advantages / disadvantage of Mu
  • The advantages of the use of Mu are
  • it is not normally found in the bacterial genome
  • therefore there are few problems with homology to
    existing sequences in the chromosome in contrast
    to most other transposons
  • Mu does not need a separate vector system
  • since it is itself a vector
  • A wide variety of useful mutants of Mu have been
    generated
  • The disadvantage of Mu
  • it is a bacteriophage and therefore can kill the
    host cell

40
(No Transcript)
41
  • Drosophila transposons
  • 15 of Drosophila genome thought to be mobile
  • 2 different classes
  • Copia retrotransposons
  • Conserved, 5-100 scattered copies/genome
  • Structurally similar to yeast Ty elements
  • Use RNA and reverse transcriptase
  • Eye Color in Drosophila (white apricot wa)

42
ITR(17bp)
ITR(17bp)
DTR
DTR
43
P elements
  • Hybrid dysgenesis, defects arise from crossing of
    specific Drosophila strains
  • Occurs when haploid genome of male (P strain)
    possesses 40 P elements/genome
  • P elements vary in length from 500-2,900 bp
  • P elements code a repressor, which makes them
    stable in the P strain in male (but unstable when
    crossed to the wild type female/ female lacks
    repressor in cytoplasm)

44
(No Transcript)
45
(No Transcript)
46
Ac (activator)/Ds (dissociation) System
discovered by B. McClintock (Noble Prize Winner
in 1983)
47
Ac/Ds System
48
Ac/Ds System
49
Schematic Diagram of the Ds Donor Site
andPossible Transposition Events
50
  • Open arrowheads indicate the 5' and 3' ends of th
    transposon
  • The Ds element carries the NPTII gene, which
    confers resistance to kanamycin (KanR)
  • and a modified GUS reporter gene (Sundaresan
  • et al. 1995 )
  • Possible transposition events include the
    following
  • (1) unlinked or loosely linked transposition to
    the same chromosome
  • (2) transposition to a different chromosome
  • (3) closely linked transposition and
  • (4) closely linked transposition disrupting
    theIAAH gene

51
Ac/Ds Transposon tagging system
  • Advantages Efficient and cost-effective method
    to generate a large mutant population
  • Disadvantages Secondary transposition
    complicates gene identification
  • And transposon system is not available in many
    species

52
  • Transposition elements in Human

53
Mobile Genetic Elements and Other Families of
Repetitive DNA
  • The genome is littered with large families of
    repetitive sequences
  • have no apparent function in the cell
  • Mobile Genetic Elements
  • Tandemly repeated simple sequence DNAs
  • Satellite DNAs
  • Short simple repeats (microsatellites)

54
LINEs (Long interspersed elements)
  • LINEs are one of the most ancient and successful
    inventions in eukaryotic genomes
  • In humans, are about 6 kb long
  • encode two open reading frames (ORFs)
  • Most LINE-derived repeats are short, with an
    average size of 900 bp - 1,070 bp
  • The LINE machinery is believed to be responsible
    for most reverse transcription in the genome

55
SINEs (Short interspersed elements)
  • short (about 100-400 bp)
  • A single monophyletic family of SINEs (ALU)
  • This family is the only active SINE in the human
    genome
  • The human genome contains three distinct
    monophyletic families of SINEs the active Alu,
    and the inactive MIR and Ther2/MIR3

56
Identification of a human specific Alu insertion
in the factor XIIIB gene
  • Alu repeats are interspersed repetitive DNA
    elements specific to primates that are present in
    500,000 to 1 million copies
  • An Alu Insert as the Cause of a Severe Form of
    Hemophilia A (factor VIII)
  • Acta Haematol 2001106126129

57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
