Chapter 4 Stochastic Modeling and Stochastic Timing

1
Chapter 4Stochastic Modeling and Stochastic
Timing

• UCLA EE201C
• Professor Lei He

2
Outline

• Process Variation
• Trends
• Modeling
• Statistic Static Timing Analysis (SSTA)
• Monte Carlo simulation
• Path-based and block-based SSTA

3
As Good as Models Tell

• STA (static timing analysis) assumed
• Delays are deterministic values
• Everything works at the extreme case (corner
  case)
• Useful timing information is obtained
• However, anything is as good as models tell
• Is delay really deterministic?
• Do all gates work at their extreme case at the
  same time?
• Is the predicated info correlated to the
  measurement?

4
Factors Affecting Device Delay

• Manufacturing factors
• Channel length (gate length)
• Channel width
• Thickness of dioxide (tox)
• Threshold (Vth)
• Operation factors
• Power supply fluctuation
• Temperature
• Coupling
• Material physics device fatigue
• Electron migration
• hot electron effects

5
Lithography Manufacturing Process

• As technology scales, all kinds of sources of
  variations
• Critical dimension (CD) control for minimum
  feature size
• Doping density
• Masking

6
Process Variation Trend

• Keep increasing as technology scales down Nassif
  01
• Absolute process variations do not scale well
• Relative process variations keep increasing

7
Variation Impact on Delay Visweswariah 04
Sources of Variation Impact on Delay
Interconnect wiring (width/thickness/Inter layer dielectric thickness) -10 25
Environmental ?15
Device fatigue ?10
Device characteristics (Vt, Tox) ? 5

• Extreme case guard band -40, 55
• In reality, even higher as more sources of
  variation
• Can be both pessimistic and optimistic

8
Variation-aware Delay Modeling

• Delay can be modeled as a random variable (R.V.)
• R.V. follows certain probability distribution
• Some typical distributions
• Normal distribution
• Uniform distribution

9
Review of Probability

• R.V. X can take value from its domain randomly
• Domain can be continuous/discrete,
  finite/infinite
• PDF vs. CDF

10
Review of Probability

• Mean and Variance
• Normal Distribution

11
Multivariate Distribution

• Similar definition can be extended for
  multivariate cases
• Joint PDF (JPDF), Covariance
• Becomes much more complicated
• Correlation MATTERS!!

12
Types of Process Variation

• Inter-die vs. intra-die variations
• Die to die / wafer to wafer / lot to lot
• Within a single die
• Random vs. systematic
• CMP and OPC related
• Doping density, lens aberration
• Many more confusing terms
• OCV/ACLV
• CMP
• Partly due to the fact that this area is fairly
  new and ever changing

13
Variation-aware Delay Modeling

• How to characterize delay variations?
• SPICE simulation
• Measurement
• Example for a 2-stage buffer
• Assume only channel length is R.V. for 65nm
  technology
• Uniform distribution with domain 10 of its
  nominal value
• Random sample channel length from 0.91.1, and
  measure the delays through SPICE
• Plot delay PDF

14
Variation-aware Timing Analysis

• How this would affect our STA?
• Min-Max approach would be too risky
• Corner-based STA is too expensive
• 2n corners
• To be accurate, analyze timing statistically
• But how?
• Every label (delays) in the DAG is modeled as a
  R.V. with certain distribution
• Should use multivariate R.V. analysis
• Correlation is KEY!

15
Correlation Types

• Correlation interpretation
• Gates, wires, and paths become slower or faster
  simultaneously
• Due to the common sources of underlying
  variations
• Global variation
• Inter-chip variations
• Structural correlation
• Path re-convergence
• Spatial correlation
• Devices close-by have higher correlation than
  that far-apart

16
Statistical Static Timing Analysis SSTA

• Fairly new (hot) topic
• Many debates
• Many new ideas
• Not quite consistency across different ref.
• Unfortunately/Fortunately, live with it
• In this lecture, cover some typical ones
• Monte Carlo simulation (Golden case)
• One path-based approach
• One block-based approach
• More for your own entertainment

17
Monte Carlo Simulation

• Definition
• A technique involving the use of random numbers
  solving physical or mathematical problems
• Characteristics
• Physical process is simulated without explicitly
  knowing equations that describe the system output
• Only requirement is that the physical system be
  described by PDF

18
Monte Carlo for SSTA

• Randomly sample each R.V. in accordance with its
  respective PDF
• Instantiate a specific DAG
• Solving STA using the technique we discussed
  before
• This is called one Monte Carlo run
• Run it many times until certain data statistics
  converge
• Stopping condition can be fairly sophisticated
• Finally, extract statistics from Monte Carlo runs
• PDF of RAT/AT/Slack
• Yield curve

19
Monte Carlo Simulation

• Pros
• Conceptually easy
• Implementation not that difficult
• Make use of previous STA algorithm
• Accurate, used as golden case (benchmarking)
• Cons
• Computationally expensive
• No many diagnostic information if something is
  wrong
• No incremental computation possible
• Efficient solution
• Analytical Statistical static timing analysis
  (SSTA)

20
SSTA Algorithms

• Objective
• Find probability distribution of circuit delay
• Path Based SSTA
• Statistically calculate path delay distributions
• Find statistical maximum of these path delays
• Identify potential critical paths
• Block Based SSTA
• Traverse DAG to calculate the delay distribution
  for each node
• Widely used due to the incremental computation
  capability

21
Path-based SSTA Orshansky DAC-02

• Key operations
• Summation
• Path delay sum(node delay)
• Maximum
• Critical path delay max(path delay)
• Delay model
• First order approximation
• Obtained from SPICE simulation

22
Path-based SSTA Key Operations

• Gate delay variance and covariance
• Path delay variance and covariance

23
Path-based SSTA Approximation

• Maximum operation is approximated
• Closed form is not known yet
• Lower and upper bound for path delay mean
• Let DD1...Dn be an arbitrary path delay
  distribution with correlation
• Let XX1...Xn identical to D but WITHOUT
  correlation
• Can prove an upper bound for mean(D)
• Mean(D) lt Mean(X)
• Similarly an lower bound can be established

24
Path-based SSTA Approximation

• Lower and upper bound for path delay variance
• Result from theory of Gaussian process Borell
  Inequality
• Variance of maxD1Dn around its mean is smaller
  than variance of a single Di with largest variance

25
Path-based SSTA Experiment Results

• Timing approximation is tighter
• Variation is smaller
• Mean clock frequency is smaller

26
Block-based SSTA Devgan ICCAD03

• AT and gate delays are modeled as R.V.
• AT as CDFs
• Gate Delays as PDFs
• For easy computation
• Delay distributions can take any form
• Model CDFs as Piece-Wise Linear functions
• Model PDFs as constant step functions

27
Block-based SSTA Key Operations

• Addition

AT2 AT1D1
28
Block-based SSTA Key Operations

• Closed form for addition

29
Block-based SSTA Key Operations

• Maximum C max (A, B)
• CDF of C CDF of A x CDF of B
• Assume independence for now
• Closed form computation via PWL

30
Block-based SSTA Correlation

• Correlation due to path reconvergence
• AT5 and AT6 are correlated due to shared AT4
• Exact handling this correlation would cause
  exponential complexity
• Utilize the structure of the circuits

31
Block-based SSTA Correlation
A4 max(A2D24, A3D34)
A2 and A3 are related
A2 A1 D12 and A3 A1 D13
A4max(A1D12D24, A1 D13D34) A1max(D12D24,
D13D34)

• This formula works well for this simple case
• How does this work for general cases?

32
Block-based SSTA General Cases

• General situation
• An input of a gate can depend on many preceding
  timing points
• There may be shared paths in the input cone

33
Block-based SSTA Heuristic Algorithm

• Create a dependency list
• Keep track of the reconvergence fanout nodes a
  particular node depends on
• Basically a list of pointers
• Compute the dominant common node
• For each pair wise max
• Determine that by statistical dominance and logic
  level
• Take out the common part contributed by the
  dominant node
• Perform max of the two CDFs
• An example follows

34
Block-based SSTA Example
Dependency list for G4
Create the dependency list
35
Block-based SSTA Example
Dominant common node
36
Block-based SSTA Example
Compute the pair wise max
ATD max(A1D1z, A2 D2z, A3D3z, A4 D4z)
ATx AB max(A1-AB D1z, A2-AB D2z)
ATy Ac max(A3-Ac D3z, A4-Ac D4z)
ATD max (ATx, ATy)
37
Block-based SSTA Experiments

• Runtime comparison
• SSTA w/ correlation and w/o correlation

Circuit w/ correlation w/o correlation
C432 1.5 1.0
C499 1.26 1.0
C880 1.22 1.0
C1908 1.33 1.0
C2670 1.23 1.0
C3540 1.26 1.0
C6288 1.20 1.0
C7552 1.30 1.0
38
Block-based SSTA Experiments

• Timing distribution
• SSTA w/ correlation and w/o correlation and Monte
  Carlo Simulation

39
Conclusion Summary
40
Summary

• Timing analysis is a key part of the design
  process
• Static timing analysis (STA)
• Sign off tools for tape out
• Statistical static timing analysis (SSTA)
• Arises due to process variation when technology
  continues to scale
• More to be done for SSTA
• Correlations matter
• Interconnect variability
• Slew propagation
• Gate delay models
• How to guide for optimal design?
