Questions

1
(No Transcript)
2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
Questions

• Can we believe what we see?
• Are there errors in the data?
• Have we added errors when we created the
  visualization?
• What uncertainty is there in the picture?

6
Uncertainty Visualization
NCRM Research Methods Festival 2008
Ken Brodlie University of Leeds in
collaboration with Rodolfo Allendes - University
of Leeds Keith Haines University of
Reading Adriano Lopes Universidade Nova de
Lisboa
7
Outline

• Motivation scope for error in data
  visualization
• Simple graphs
• Structural versus data uncertainty
• Two dimensional data
• Contouring, surface views and image plots
• Visualizing uncertainty
• Special look at uncertainty contouring
• Case study oceanographic data from Reading
  e-Science Centre
• Three dimensional data
• Isosurfacing and volume rendering
• Visualizing uncertainty
• Conclusions

8
Motivation

• Sources of error abound in visualization
• Consider the typical pipeline of processes

Yet we rarely think about this when we visualize
data!!
9
One-dimensional graphs

• The line chart remains the most commonly used
  visualization technique
• but there is often uncertainty

Wikipedia line chart
10
A Simple Example
This table shows the observed oxygen levels
in the flue gas, when coal undergoes
combustion in a furnace
TIME (mins)
0
2
4
10
28
30
32
20.8
8.8
4.2
0.5
3.9
6.2
9.6
OXYGEN ()
11
Visualizing the Data no uncertaintybut is this
what we want to see?
12
Estimating behaviour between the data - but are
we certain?
13
Perhaps this is the behaviour but something is
wrong
14
At least this is credible..but still we are far
from certain
This is structural uncertainty, or model
uncertainty
15
Error bars

• We can also have data uncertainty
• .. error information can be incorporated into a
  graph using error bars

All you ever want to know about error bars
see Cumming, Fidler Vaux (2007) Error bars in
experimental biology Journal of Cell Biology,
177, p7-11
NC State University, LabWrite
16
Summary Statistics for Multiple Values Box plots

• Statistics about multiple data values at a point
  can be summarised using box plots

• or variants such as violin plots

17
Two Dimensional Data

• We have three classic visualization techniques
• Contour map
• Surface view
• Image plot

18
Image Plots Using Saturation

• Image plots colour each pixel with predicted
  value
• Some interpolation methods (here kriging) also
  deliver measure of prediction error
• Hengl (2003) has suggested using saturation to
  encode uncertainty
• Colour mapping goes from 1D (thickness) to 2D
  (thickness and uncertainty)
• Note other studies have argued that saturation is
  not a good way of encoding uncertainty!!

Top-soil thickness (cm)
19
Image Plots - Using Annotation Effects

• Cedilnik and Rheingans (2000)
• Proposed use of annotation to display uncertainty

Latitude/longitude lines sharpened to indicate
high certainty
IEEE Visualization 2000
focus on perceptual effect qualitative rather
than quantitative
20
Image Plots - Augmented Views

• Uncertainty can be added as a surface layer
• Ground cover observations at sparse set of points
  used to generate 250 datasets
• Mean is image view
• Standard deviation is surface height
• Interquartile range is colour
• Bar glyphs give mean/median difference

Love, Pang, Kao (2005) Visualizing Spatial
Multivalue Data IEEE CGA
21
Surface Views Using Animation

• Surface views show 2D data as an elevation view
• Animation can be used to show a set of possible
  outcomes from a simulation
• Here Ehlschlaeger et al (1997) show the impact
  of potential sea level rise on shoreline of
  Boston harbour

Ehlschlaeger, Shortridge and Goodchild, Visualizin
g Spatial Data Uncertainty using
Animation Computers and Geosciences, 1997
Important to take spatial autocorrelation into
account
22
Contouring of 2D Data

• We have recently been looking at contouring 2D
  data and on visualizing the uncertainty
  associated with that data
• Rather than a single value at each datapoint
  (x,y) f
• we have a random variable, F, with an
  associated probability density function, f(z)

Measurement errors normal distribution Rounding
errors uniform distribution Ensemble
computing distribution derived from data
We can contour f how do we contour F?
23
How do we interpolate uncertainty?

• Central to much of visualization is interpolation
  often we are interested not so much in the data
  but the bits inbetween

• Similarly for the uncertain case

x
1
0
Linear combination of two normal distributions is
another normal distribution
and obvious extensions to 2D bilinear and 3D
trilinear
24
Uncertainty Contour Lines

• In the traditional case, the definition of a
  contour line is
• Set of all points p

• In the uncertainty case, the definition could be

25
E-Science Application Ocean Dynamic Topography

• Mean dynamic ocean topography difference
  between average sea surface and its rest-state
  (the geoid)
• Measures the steady-state circulation of ocean
  currents that help regulate the Earths climate

• But different models predict different
  topography!
• Bingham and Haines (2006) produced a composite
  MDT from an ensemble of 8 models
• RMS error for composite MDT is 3.2 cm, on a grid
  of 829x325

26
Is it easy to understand the error information?

• Error field overlayed as an image plot

but can we show the uncertainty using just the
contouring paradigm?
27
Fuzzy Contours
Here we map probability to intensity zero fuzzy
contour is
28
Adding the Mean as a Traditional Contour Line
29
Looking at each model
30
Comparison
31
Contour Bands
32
Fuzzy Contours or Contour Bands
33
Contour shading

• Often we shade the bands between contour lines

• and we can do the same with uncertainty
  contouring

34
Uncertain Contour Shading Colour Blending
Colour blending, using transparency to indicate
level of certainty
35
Uncertain Contour Shading Probabilistic Model
Colour chosen according to random variable with
corresponding distribution
36
As a Movie
37
Looking at each model
Each model rendered with one eighth transparency
38
Powerwall for Uncertainty
39
Ocean Currents 1943 map
40
Three dimensional data

• There are two main methods
• Isosurfacing
• This is the analogy of contouring where a surface
  of equal threshold value is extracted
• Marching cubes algorithm works across each grid
  cell, determining surface separating points above
  and below threshold
• Volume rendering
• This is the analogy of image plots where
  transparency is used to see through outer
  layers
• Imagine data as a gel-like material, with colour
  and transparency determined by the data

http//www.csit.fsu.edu/futch/iso/
41
Mapping Uncertainty onto Isosurface

• Rhodes, Bergeron et al (2003)
• Multiresolution isosurfacing error information
  available at different mesh resolutions
• Given error at grid points, interpolate to get
  error at intersection points
• Colour map the isosurface mesh according to the
  error values

but no indication of spatial distribution of
isosurface no incorporation of type of error
distribution
42
Using Volume Rendering

• Johnson and Sanderson (2003)
• Combined isosurface and volume rendering
• Isosurface average and volume render error

spatial extent shown, but no indication that
they have incorporated any probability
distribution information
43
Uncertainty in Volume Rendering

• Djurcilov et al, UCSC (2002)
• Use the opacity component of volume rendering to
  encode uncertainty

Middle Atlantic Shelf Break Mean salinity
Low opacity high uncertainty
44
Uncertainty in Volume Rendering
45
Conclusions

• Important to convey uncertainty information
  within a visualization
• We have looked at
• Graphs
• Contours, surface views, image plots
• Isosurfaces, volume rendering
• Uncertainty remains a challenging topic for the
  visualization community
