Acceleration Structures

1
Acceleration Structures

• CS 148 Introduction to Computer Graphics and
  Imaging

Image "BL Object 5" by Douglas Eichenberg (2003)
2
Ray-Scene Intersection
Traversing all primitives in the scene for each
ray is inefficient! Need auxiliary structures to
accelerate this process.
3
Acceleration Structures for Vertex Normals (for
rendering)

• for each Vertex v in V
• for each Triangle t in T
• if Triangle t contains Vertex v
• inner_loop(v,t)
• O(T V) running time
• for each Triangle t in T
• for each v in t.v1, t.v2, t.v3
• v.relevant_triangles.append(t)
• for each Vertex v in V
• for each t in v.relevant_triangles
• inner_loop(v,t)
• O(TV) running time

insert
Data Structure
retrieve
4
Acceleration Structures for Ray Tracing

• Two basic ideas
• Partition the objects
• Flat bounding volumes
• Hierarchical bounding volume hierarchies (BVH)
• Partition the space
• Flat Uniform Grid
• Hierarchical Octree, Kd-Tree

Uniform Grid
BVH
Bounding Volumes
Kd-Tree
5
How to evaluate an acceleration structure?

• How fast is it to construct the structure?
• Building a hierarchy for n primitives takes
  O(nlogn) time
• Inserting n primitives into a uniform grid takes
  O(n) time
• How much memory will it use?
• A tree for n primitives takes O(n) space
• A uniform grid subdividing the space takes
  O(nxnynz) space
• How fast is it for a ray to traverse in the
  structure?
• Root to Leaf traversal is O(log n)
• Need (efficient) methods for finding neighbors in
  both hierarchies and flat data structures

6
Bounding Volume

• Enclosing each object with a simpler piece of
  geometry
• Sphere, box (axis-aligned, object-aligned)
• If the ray does not hit the bounding volume, it
  cannot hit the enclosed object
• Avoid expensive intersection test with the object

7
Bounding Sphere

• A sphere enclosing all of the vertices of the
  object.
• Fastest bounding volume for intersection test
  with a ray.
• Minimize the radius of the bounding sphere
• For a triangle or a tetrahedron, the minimal
  radius is simply the radius of its circumsphere.
• How about more complicated geometry?

8
Constructing Bounding Sphere

• An intuitive way
• Compute the centroid PC of all vertices
• Loop through all vertices and compute the maximal
  Pi-PC2 to find the farthest vertex Pfarthest
  from PC
• Return Pfarthest-PC as the minimal radius
• A counter example a crowd of points with one
  discrete
• point far away, the radius calculated in this
  way is about
• twice as big as the minimal one.
• A hierarchical way
• Build the bounding sphere for each triangle
• Recursively merge the neighboring spheres
• into a larger one until all the spheres are
  merged
• into one sphere
• Return the radius of that sphere as the minimal
  radius
• Optimal methods
• Randomized Linear programming, running in
  expected O(n) time.

9
Pros and Cons of Bounding Sphere

• Advantages
• Constructing a bounding sphere is fast.
• Ray-sphere intersection test is easy.
• No need to change when object rotates
• Disadvantages
• Cannot tightly enclose the object in some cases,
  e.g., long and thin objects,
• which leads to false positives

10
Axis-Aligned Bounding Box (AABB)

• An axis-aligned box containing the object.
• Constructing an AABB is trivial
• Loop through all of the vertices and find the min
  and max values in each dimension separately.
• Use the min/max values as the bottom-left/top-righ
  t corners of the bounding box.

11
Ray-Box (Axis Aligned) Intersection

• A box is the intersection of 3 pairs of slabs in
  3 dimensions
• Each slab contains two parallel planes and the
  space between them
• We can detect the intersection between the ray
  and the box by detecting the intersections
  between the ray and the three pairs of slabs.
• For each pair of slabs there are two intersection
  points Pnear and Pfar, and there are 6
  intersection points in total for 3 pairs.
• If the maximal Pnear is ahead of the minimal Pfar
  on the ray, the ray misses the box. Otherwise it
  hits the box.

12
Pseudocode

• float RayBoxIntersection (Ray ray, Box box,
  Interval tmin, tmax)
• calculate tnear,x , tfar,x , tnear,y , tfar,y ,
  tnear,z , tfar,z on 3 axes
• tnearmax(tnear,x , tnear,y , tnear,z)
• tfarmin(tfar,x , tfar,y , tfar,z)
• if(tnearlttfar tneargttmin tnearlttmax)
• return tnear ////report intersection at tnear
• else
• return -1 ////no intersection

13
Pros and Cons of AABB

• Advantages
• Constructing an AABB is simple.
• Simply scan over all vertices and find min and
  max values in each dimension in O(n) time
• Ray-box intersection test is fast.
• Disadvantages
• Need to recalculate the bounding box any time an
  object rotates (unless the ray is transformed
  into object space)
• Cannot tightly enclose the object (similar to
  spheres)

14
Oriented Bounding Box (OBB)

• The orientation of the box depends on the
  orientation of the object
• Dont need to recompute the box when an object
  rotates
• Can pre-compute OBB in object space and transform
  OBB to world space with the object (same is true
  for spheres)

15
Constructing OBB

• How to compute the orientation of the object?
• Singular Value Decomposition
• Compute the covariance matrix and the eigenvalues
  and the corresponding eigenvectors of the 3x3
  matrix
• Using these eigenvectors as the basis of the
  local coordinate system of the bounding box

16
Constructing an OBB for a Triangle Mesh

• Compute the mean centroid of all triangles
• where pi, qi, and ri are the vertices of ith
  triangle, and n is the number of triangles.
• Construct the 3x3 covariance matrix C, the
  element Cjk is computed as
• where and
• Calculate the eigenvectors e1, e2, e3 of C and
  take them as the basis vectors for the local
  coordinate system of the OBB.
• All of the eigenvectors are mutually orthogonal
  since C is symmetric.
• Find the extremal vertices along each basis
  vector and resize the bounding box to bound those
  vertices (similar to the AABB)

Gottschalk et.al. 96
17
Ray-Box (Object Oriented) Intersection

• Similar to Ray-AABB intersection
• Calculate the maximum tnear and the minimum tfar
• The planes of the slabs are not axis aligned any
  more
• Recall how to compute intersection between a ray
  and an arbitrary plane in 3D space

Ray-AABB intersection
Ray-OBB intersection
18
Or we can transform the ray

• Transform the ray into the OBB coordinate system
  and perform ray-AABB intersection test.

World Coordinate
OBB Coordinate
19
Pros and Cons of OBB

• Advantages
• Fit the object tighter than AABB
• Disadvantages
• Extra cost for ray-box intersection
• Finding an OBB is computationally expensive (but
  is done as a precomputation)
• Finding the minimal OBB is hard (but an
  approximation such as the one we just proposed
  - is usually good enough)

20
Bounding Volume Hierarchies (BVH)

• A bounding volume hierarchy is a tree
• Each leaf encloses a primitive object
• Each interior node encloses all the bounding
  volumes of its children

21
Constructing the BVH

• Bottom up
• Begin with the bounding volume for each primitive

• Recursively merge them into larger volumes
  according to some criteria
• E.g., merge nearest neighbors, minimizing the sum
  of surface area
• Stop in case of a single bounding volume at the
  root
• Top down
• Begin with the group of all primitives and its
  bounding volume
• Recursively split primitives and the
  corresponding bounding volume according to some
  criteria
• E.g., split primitives w.r.t coordinate axis,
  minimizing the sum of surface area
• Stop when all leaf nodes are indivisible.

22
Example Splitting Strategies in Constructing
OBB Tree to Bound a Object

• Split using center points along the longest axis
  of object bounded with OBB

Gottschalk et.al. 96
Kamat and Martinez, 2007
23
Where/When to create the BVHs?

• Create the BVH individually for each object
• The BVH is in object space
• Can be translated with the object and does not
  need to be updated
• Create BVH for unioning together all BVs of all
  objects in a scene
• This global BVH is in the world space
• Must be updated whenever something moves in the
  scene
• Do both!

24
Ray Traversal in BVH

• Use hierarchy to accelerate ray intersections
• Intersect node contents only if the ray
  intersects the bounding volume

25
How to backtrack the ray in BVH?

• Depth-first search
• Find the nearest intersection inside a node by
  recursively finding the intersections of all its
  subnodes and return the minimum t.
• How to improve the efficiency?

To report ray-primitive in node C, we need to
recursively traverse all its subnodes (D, G, H,
I) to find all the ray-primitive intersections
(triangles in G and I) and report the minimum one
(triangle in G).
26
Early Termination in Ray Traversal

• Sort hits detect early termination
• Sort the intersections of the ray and the child
  node bounding volumes and terminate when the
  first ray-primitive intersection is found.

27
Early Termination in Ray Traversal
To report ray-primitive in node C, we can avoid
testing triangles in H and I by recursively
sorting the intersections of the ray and the
subnodes of C (D and I of C, and subnodes G and H
of D). Searching terminates when it finds the
first triangle (in G) in the sorted nodes.
28
Some cases that BVH doesnt work well

• Objects with similar sizes are approximately
  uniformly distributed in space
• BVH has an extra log n constant that is not
  warranted in this case i.e. not enough
  successful pruning occurs

"Warm Up" by Norbert Kern (2001)
Shorebirds by Jim Charter (2000)
http//hof.povray.org/warm_up.html
http//hof.povray.org/shorebir.html
29
Partition the space instead

• Instead of using the objects to divide space just
  divide all of space and register objects with the
  cells they (or their bounding volumes) overlap

30
Uniform Grids

• Divide 3D space into nxnynz axis-aligned grid
  cells
• Perform Ray-object intersection test only when
  the ray hits the grid cell containing the object
• The size of the grid cell is crucial to the
  performance
• No speedup if the cell size is too big, no
  pruning, everything in one cell
• A lot of empty cells if the cell size is too
  small
• A practical way to choose cell size is to average
  the edge lengths of the bounding boxes of all
  primitives

31
Constructing a Uniform Grid

• Find the bounding box of the scene
• Initialize the grid with that bounding box and a
  proper cell size
• Each cell maintains a list (or an array) to store
  the overlapped primitives
• Insert primitives into cells
• One primitive may be inserted into multiple cells

32
Ray Traversal in a Uniform Grid

• Traverse all the cells pierced by the ray before
  the ray intersects with a primitive or reaches
  the boundary of the bounding box

33
Incremental Traversal

• An incremental algorithm similar to line
  rasterization
• From the current intersection point P on the face
  of cell (i, j, k), perform ray-plane intersection
  tests with the next 3 grid planes along the ray
  direction to get the 3 candidate intersection
  points for the next intersection.
• The next intersection point is the nearest one
  among the 3 candidates.
• Update the cell index according to the new
  intersection point. Perform ray-primitive
  intersection tests in the new cell.
• Repeat the above process until the ray intersects
  with a primitive or reaches the boundary of the
  bounding box.

34
Improving the Algorithm

• Efficiently finding the next intersection point
  on the grid
• The intersections with the grid planes have the
  same spacing in each independent dimension
• Using the precomputed dtx, dty, and dtz, we dont
  need to perform ray-plane intersection tests
  every time.
• dtx Cx/Dx, dty Cy/Dy, dtz Cz/Dz, in which (Cx,
  Cy, Cz) is the cell size and (Dx, Dy, Dz) is the
  ray direction.

35
Pseudocode

• ////tnext denotes the t for the 3 candidate
  intersections on planes in 3 dimensions,
• ////it is initialized based on the first cell
  pierced by the ray in the grid
• Initialize tnext
• ////s is a 3d (integer) vector denoting the
  direction for incrementing cell index along the
  ray,
• ////for each direction, if(ray.dirdgt0) sd1 else
  sd-1
• Initialize s
• void IncrementalRayTraverse(Ray ray, Vec3 cell,
  Vec3 tnext)
• float tintersect min(tnext,x tnext,y tnext,z)
• int d the axis of tintersect ////the face of
  intersection
• celldsd
• ray.tminray.tmax
• ray.tmax tintersect
• tnext,d dtd
• process ray-primitive intersections in the new
  cell
• between ray.tmin and ray.tmax

36
Avoid Redundant Intersection Test

• A primitive may be stored in multiple cells
• For each cell, an intersection test on that
  primitive may be performed
• Solution associate each primitive with a bool
• If the primitive has already been determined to
  not intersect the ray, or is not the closest
  intersecting primitive, store false in the bool
• Before the actual ray-primitive intersection
  test, check the bool first

37
Pros and Cons of the Uniform Grids

• Advantages
• Construction is fast.
• Regular Layout, Cache coherent
• Ray traversal is easy.
• Disadvantages
• Empty cells in a sparse scene will waste memory
• Hard to choose the cell size
• No adaptivity

38
Ray Traversal in Viewing Frustum

• Sending rays in the camera space
• Create a uniform grid in the frustum
• Avoid the traversal steps and intersection tests
• Cache coherent, all the cells are aligned along
  the ray!
• Can traverse a bunch of rays in one time

39
Optimizing the Uniform Grid

• Optimizing the storage
• Spatial Hashing use a hash table instead of a 3D
  array.
• Avoid the extra storage for a large number of
  empty cells.
• Optimizing the performance
• Adaptive grids rectilinear grid, embedded grid,
  octree

Rectilinear Grid
Embedded Grid
Octree (Quadtree)
40
Octree

• Each node potentially has exactly 8 children
• Each node can equally subdivide its space (an
  AABB) into eight subboxes by 3 midplanes.
• Children of a node are contained within the box
  of the node itself.

41
Constructing an Octree

• In a top-down way
• Find the global bounding box that contains all
  the primitives and correspond it to the root of
  the tree
• Recursively partition a node into 8 octants by 3
  midplanes.
• If a primitive belongs to multiple octants, put
  it in each octant.
• Recursion stops when the termination criteria are
  satisfied.
• e.g., maximum depth, minimum number of primitives
  in a node.

42
Ray Traversal in an Octree

• Traverse all leaf nodes in the octree passed
  through by the ray and perform intersection tests
  for the primitives inside those leaves.

43
Recursive Traversal

• Basic idea
• For a leaf node, perform intersection test for
  its primitives and terminate if an intersection
  is detected.
• For an interior node, recursively process all the
  subnodes inside it.
• Two important questions
• How to find the first subbox at which the ray
  enters the current box?
• How to find the next subbox (or
• report exit) when the ray exits a
• subbox?

44
Observation

• For a given ray and a box, the number of its
  subboxes intersected with the ray and the
  intersection sequence of these subboxes is only
  determined by the two intersection points and the
  corresponding box faces.

45
Find the First Entry Subnode

• First find the entry face by computing
  min(tnear,x,tnear,y,tnear,z)
• Recall what we did for ray-AABB intersection test
• On each face there are 4 corresponding subboxes,
  decide which subbox the ray enters using
  midplanes.
• Find the midplane is crossed before or after the
  entry.

Crossed before the entry
Crossed after the entry
46
Find the Next Subnode

• Build an automaton whose states correspond to the
  boxes and whose transitions are associated to the
  movements between neighboring sub-nodes visited
  sequentially by the ray.

47
Recursive Traversal Example
48
Pros and Cons of the Octree

• Advantages
• Adaptivity
• Memory efficiency
• Disadvantages
• Ray traversal is complicated
• Partition strategy is not flexible
• Not cache coherent

49
Hybrid Structure

• Start with a uniform grid and subdivide each node
  using hierarchies
• Each node of a uniform grid can contain a whole
  octree
• Improve the performance of the octree no need to
  traverse the tree from a single root every time

Losasso et.al. 2006
50
K-d Tree

• Using a hyperplane translated in one dimension

51
K-d Tree

• A binary tree for space searching
• Every non-leaf node can be thought of as
  implicitly generating a splitting hyperplane that
  divides the space into two parts
• Points to the left of this hyperplane are
  represented by the left subtree of that node and
  points right of the hyperplane are represented by
  the right subtree.

52
Constructing a K-d Tree

• In a top-down way
• Begin with the global bounding box containing all
  primitives.
• Choose an axis and a splitting plane
  perpendicular to that plane, subdivide the
  primitives on both sides of the plane into two
  groups.
• Stop when the number of primitives in each single
  group is below a threshold.

53
Ray Traversal in a K-d Tree

• Traverse all leaf nodes in the k-d tree passed
  through by the ray

54
Recursive Traversal

• Similar to recursive traversal in an octree
• Each interior node has two children, there are
  only 3 cases for subnode intersections
• intersecting with the left child only, the right
  child only, and both.
• The number of intersected subboxes and its
  sequence can be determined by the intersection
  points and faces of the ray and the node and the
  splitting plane of the node.
• Notice the difference with an octree the
  splitting plane does not have to be in the middle
  of the box

55
Non-Recursive Traversal

• Recursion is expensive on GPU for real-time ray
  tracing.
• Kd-Restart
• Restart the traversal to the root every time it
  reaches a leaf
• Kd-Backtrack
• return to parent nodes that enables traversing
  other unvisited nodes
• Neighbor-link
• Each leaf stores ropes that directly link it to
  the adjacent node via its 6 faces

Popov et.al. 07
56
Pros and Cons of the K-d Tree

• Advantages
• Adaptivity
• Fast ray traversal
• Disadvantages
• Construction is complicated

57
Partitioning Objects or Space?

• Any of the acceleration structures can be applied
  in both object space and world space in the same
  manner
• When a structure is in the world space, it has to
  be updated whenever some object or primitive in
  the structure is transformed
• When a structure is in the object space, it can
  be transformed with the object and does not need
  to be updated
• E.g., a uniform grid in world space for a bunch
  of birds with a BVH in object space for each bird
