Science, Systems, Matter, and Energy

1
Chapter 2

• Science, Systems, Matter, and Energy

2
Core Case Study Environmental Lesson from
Easter Island

• Thriving society
• 15,000 people by 1400.
• Used resources faster than could be renewed
• By 1600 only a few trees remained.
• Civilization collapsed
• By 1722 only several hundred people left.

Figure 2-1
3

• What is needed in order to avoid this same fate?

4
TYPES AND STRUCTURE OF MATTER

• Elements and Compounds
• Matter exists in chemical forms as elements and
  compounds.
• Elements (represented on the periodic table) are
  the distinctive building blocks of matter.
• Compounds two or more different elements held
  together in fixed proportions by chemical bonds.

5
Atoms
Figure 2-4
6
Animation Atomic Number, Mass Number
PLAY ANIMATION
7
Ions

• An ion is an atom or group of atoms with one or
  more net positive or negative electrical charges.
• The number of positive or negative charges on an
  ion is shown as a superscript after the symbol
  for an atom or group of atoms
• Hydrogen ions (H), Hydroxide ions (OH-)
• Sodium ions (Na), Chloride ions (Cl-)

8
Animation Ionic Bonds
PLAY ANIMATION
9

• The pH (potential of Hydrogen) is the
  concentration of hydrogen ions in one liter of
  solution.

Figure 2-5
10
Compounds and Chemical Formulas

• Chemical formulas are shorthand ways to show the
  atoms and ions in a chemical compound.
• Combining Hydrogen ions (H) and Hydroxide ions
  (OH-) makes the compound H2O (dihydrogen oxide,
  a.k.a. water).
• Combining Sodium ions (Na) and Chloride ions
  (Cl-) makes the compound NaCl (sodium chloride
  a.k.a. salt).

11
Organic Compounds Carbon Rules

• Organic compounds contain carbon atoms combined
  with one another and with various other atoms
  such as H, N, or Cl-.
• Contain at least two carbon atoms combined with
  each other and with atoms.
• Methane (CH4) is the only exception.
• All other compounds are inorganic.

12
Animation Carbon Bonds
PLAY ANIMATION
13
Organic Compounds Carbon Rules

• Hydrocarbons compounds of carbon and hydrogen
  atoms (e.g. methane (CH4)).
• Chlorinated hydrocarbons compounds of carbon,
  hydrogen, and chlorine atoms (e.g. DDT
  (C14H9Cl5)).
• Simple carbohydrates certain types of compounds
  of carbon, hydrogen, and oxygen (e.g. glucose
  (C6H12O6)).

14
Cells The Fundamental Units of Life

• Cells are the basic structural and functional
  units of all forms of life.
• Prokaryotic cells (bacteria) lack a distinct
  nucleus.
• Eukaryotic cells (plants and animals) have a
  distinct nucleus.

Figure 2-6
15
Macromolecules, DNA, Genes and Chromosomes

• Large, complex organic molecules (macromolecules)
  make up the basic molecular units found in living
  organisms.
• Complex carbohydrates
• Proteins
• Nucleic acids
• Lipids

Figure 2-7
16
States of Matter

• The atoms, ions, and molecules that make up
  matter are found in three physical states
• solid, liquid, gaseous.
• A fourth state, plasma, is a high energy mixture
  of positively charged ions and negatively charged
  electrons.
• The sun and stars consist mostly of plasma.
• Scientists have made artificial plasma (used in
  TV screens, gas discharge lasers, florescent
  light).

17
Matter Quality

• Matter can be classified as having high or low
  quality depending on how useful it is to us as a
  resource.
• High quality matter is concentrated and easily
  extracted.
• low quality matter is more widely dispersed and
  more difficult to extract.

Figure 2-8
18
CHANGES IN MATTER

• Matter can change from one physical form to
  another or change its chemical composition.
• When a physical or chemical change occurs, no
  atoms are created or destroyed.
• Law of conservation of matter.
• Physical change maintains original chemical
  composition.
• Chemical change involves a chemical reaction
  which changes the arrangement of the elements or
  compounds involved.
• Chemical equations are used to represent the
  reaction.

19
Chemical Change

• Energy is given off during the reaction as a
  product.

20
Types of Pollutants

• Factors that determine the severity of a
  pollutants effects chemical nature,
  concentration, and persistence.
• Pollutants are classified based on their
  persistence
• Degradable pollutants
• Biodegradable pollutants
• Slowly degradable pollutants
• Nondegradable pollutants

21
Nuclear Changes Radioactive Decay

• Natural radioactive decay unstable isotopes
  spontaneously emit fast moving chunks of matter
  (alpha or beta particles), high-energy radiation
  (gamma rays), or both at a fixed rate.
• Radiation is commonly used in energy production
  and medical applications.
• The rate of decay is expressed as a half-life
  (the time needed for one-half of the nuclei to
  decay to form a different isotope).

22
Animation Half-Life
PLAY ANIMATION
23
Nuclear Changes Fission

• Nuclear fission nuclei of certain isotopes with
  large mass numbers are split apart into lighter
  nuclei when struck by neutrons.

Figure 2-9
24
Nuclear Changes Fusion

• Nuclear fusion two isotopes of light elements
  are forced together at extremely high
  temperatures until they fuse to form a heavier
  nucleus.

Figure 2-10
25
Video Nuclear Energy
PLAY VIDEO

• From ABC News, Environmental Science in the
  Headlines, 2005 DVD.

26
ENERGY

• Energy is the ability to do work and transfer
  heat.
• Kinetic energy energy in motion
• heat, electromagnetic radiation
• Potential energy stored for possible use
• batteries, glucose molecules

27
Electromagnetic Spectrum

• Many different forms of electromagnetic radiation
  exist, each having a different wavelength and
  energy content.

Figure 2-11
28
Electromagnetic Spectrum

• Organisms vary in their ability to sense
  different parts of the spectrum.

Figure 2-12
29
Relative Energy Quality (usefulness)
Source of Energy
Energy Tasks
Electricity Very high temperature heat (greater
than 2,500C) Nuclear fission (uranium) Nuclear
fusion (deuterium) Concentrated
sunlight High-velocity wind
Very high-temperature heat (greater than 2,500C)
for industrial processes and producing
electricity to run electrical devices (lights,
motors)
High-temperature heat (1,0002,500C) Hydroge
n gas Natural gas Gasoline Coal Food
Mechanical motion to move vehicles and other
things) High-temperature heat (1,0002,500C)
for industrial processes and producing
electricity
Normal sunlight Moderate-velocity
wind High-velocity water flow Concentrated
geothermal energy Moderate-temperature
heat (1001,000C) Wood and crop wastes
Moderate-temperature heat (1001,000C) for
industrial processes, cooking, producing steam,
electricity, and hot water
Dispersed geothermal energy Low-temperature heat
(100C or lower)
Low-temperature heat (100C or less) for
space heating
Fig. 2-13, p. 44
30
ENERGY LAWS TWO RULES WE CANNOT BREAK

• The first law of thermodynamics we cannot create
  or destroy energy.
• We can change energy from one form to another.
• The second law of thermodynamics energy quality
  always decreases.
• When energy changes from one form to another, it
  is always degraded to a more dispersed form.
• Energy efficiency is a measure of how much useful
  work is accomplished before it changes to its
  next form.

31
Mechanicalenergy(moving,thinking,living)
Chemical energy (photosynthesis)
Chemical energy (food)
Solar energy
Waste Heat
Waste Heat
Waste Heat
Waste Heat
Fig. 2-14, p. 45
32
Animation Energy Flow
PLAY ANIMATION
33
SUSTAINABILITY AND MATTER AND ENERGY LAWS

• Unsustainable High-Throughput Economies Working
  in Straight Lines
• Converts resources to goods in a manner that
  promotes waste and pollution.

Figure 2-15
34
Sustainable Low-Throughput Economies Learning
from Nature

• Matter-Recycling-and-Reuse Economies Working in
  Circles
• Mimics nature by recycling and reusing, thus
  reducing pollutants and waste.
• It is not sustainable for growing populations.

35
Inputs (from environment)
System Throughputs
Outputs (into environment)
Energy conservation
Low-quality Energy (heat)
Energy
Sustainable low-waste economy
Waste and pollution
Waste and pollution
Pollution control
Matter
Recycle and reuse
Matter Feedback
Energy Feedback
Fig. 2-16, p. 47
36
Animation Economic Types
PLAY ANIMATION
