Wireless Presentation

1
Wireless Presentation

• June 2009

2
Agenda

• RF marketing information
• EZRadio Introduction
• EZRadioLC Introduction
• EZRadioPro Introduction
• Support Source
• Development Kit
• Thank you

3
Silabs wireless product Portfolio

• EZRadioPRO
• High performance RF
• Designed for extended ranges (128 registers)
• 240-960 MHz continual coverage
• Si443x TRx, Si433x Rx, Si403x Tx
• EZRadio
• Moderate performance RF
• Simple to design with (only 12 registers)
• 315, 434, 868, 915 MHz banded coverage
• SI442x TRx, Si432x Rx, Si402x Tx
• EZRadioLC
• 315/433 MHz OOK/FSK
• STB RF remote control

4
Wireless Roadmap
EZRadioPRO
EZRadio
Si4430/31/32 Continual 240 - 960 MHz -118 dBm,
FSK128 / OOK40 kbps -8gt13 and 13gt20 dBm Tx
pwr
Si4421 434,868,915 MHz -112 dBm, FSK115 kbps 7
dBm Tx pwr
Si4420 315, 434, 868, 915 MHz -109 dBm, FSK256
kbps 3 dBm Tx pwr
Si4330 240 - 960 MHz -118 dBm, FSK128 / OOK40
kbps
Si4311 315/433 MHz -112 dBm, FSK / OOK
Si4320 315, 434, 868, 915 MHz -109 dBmFSK256 /
OOK1 kbps
Si4322 868, 915 MHz -108 dBmFSK256 kbps
Tx Rx TRx
Si4030/31/32 240 - 960 MHz FSK128 / OOK40
kbps -8gt13 and 13gt20 dBm Tx pwr
Si4020 315, 434, 868, 915 MHz 3 dBm, FSK256 /
OOK256 kbps
Si4021 434, 868, 915 MHz 8 dBmFSK115 / OOK512
kbps
Si4022 868, 915 MHz 8 dBm FSK115 kbps
2006
2007
Q408
Q109
Q308
2005
5
Market Acceptance and Trends

• Modern RF devices lower design barriers
• RF becoming easier to add to existing
  productswider RF adoption
• Fuller featured radios available (antenna
  tuning, AFC, etc)
• RF data-links costs are dropping
• Lightweight MCU encryption algorithms
• Open Standard AES128, TEA, XXTEA
• Proprietary Keeloq, Hitag, AVR411
• Lower barriers increasing wireless applications
• Game controller, sensors, data logging, etc.
• Large and established one-way link applications
  today
• RKE, remote control, sensors
• Increasing trend towards two-way links
• Confirm communication, reduced power consumption,
  increased noise immunity

6
Application Examples Wireless Everywhere

• Weather stations
• RKE security
• Entertainment (STB)
• Garage door
• Pagers
• Irrigation
• Lighting
• Shutters blinds
• Home automation
• Building automation
• Wireless doorbells
• Auto meter reading
• .
• ..

7
Wireless Application Examples

• Sub GHz wireless market a large and growing
  opportunity for Silicon Labs
• (total TRX/RX/TX chips in system)
• Automotive
• Remote keyless entry RKE (150 Mu/yr)
• Tire pressure monitoring systems TPMS(116 Mu/yr)
• After-market car alarms (38 Mu/yr)
• Consumer electronics
• Satellite set-top boxes (93 Mu/yr)
• Wireless weather stations (16 Mu/yr)
• Toys 400-900 MHz (10 Mu/yr)
• Baby monitors (15 Mu/yr)
• Remote controls, IR replacement/extension (5
  Mu/yr)
• Home
• Automated meter reading AMR (61 Mu/yr)
• Garage and gate door openers (31 Mu/yr)
• Security/home automation (72 Mu/yr)

Remote keyless entry
Garage door openers
Wireless weather stations
Remote controls
8
EZRadio Current Portfolio
EZRadio Introduction
Product Frequency bands Comments
Transmitter SI4020 315/433/868/915 MHz Automatic Antenna tuning, EEPROM mode, OOK
Transmitter SI4021 433/868/915 MHz Improved phase noise, bit synchronization
Transmitter SI4022 433/868/915 MHz Wider frequency bands, improved Xtal startup and current consumption, 64bit TX FIFO, auto sleep, 32kHz clock output
Receiver SI4320 315/433/868/915 MHz Standalone mode, AFC, RX FIFO
Receiver SI4322 433/868/915 MHz Wide frequency bands, improved selectivity Xtal startup and current consumption, auto sleep, 32kHz clock output
Transceivers SI4420 315/433/868/915 MHz EZMac, TX latch
Transceivers SI4421 433/868/915 MHz Improved phase noise, EZMac
9
EZRadio
Transmitter Parameter(SI4020/SI4021/SI4022)

• Fully integrated Transmitter (Low BOM, easy
  design-in)
• FSK and OOK support
• Standalone and MCU mode support
• Programmable power output level, automatic
  antenna tuning circuit
• Low battery detection and wakeup timer
• 2.2-5.4V operation supply voltage(SI40222.2-3.8V)

• Compact 16 pin TSSOP
• Band support315/433/868/915MHz(SI4022 none
  315MHz band)

10
Transmitter with MCU or EEPROM Mode Application
EZRadio
SI4021
SI4021
MCU Mode Application
EEPROM Mode Application
11
EZRadio
Customer Application (Use SI4021 Remote
Controller)
Standard 10MHz Crystal
MCU
Button
SI4021
Loop Antenna (None Match Circuit)
12
EZRadio
Receiver Parameters(SI4320/SI4322)

• Full integrated ISM receiver (Low BOM, easy
  design-in)
• Use band315 /433/868/915MHz(SI4322 none 315MHz
  band)
• FSK and OOK support
• Standalone and MCU mode support
• High bit rate up to 115.2kbps in digital
• Programmable baseband bandwith(67-400kHz)
• 16bit RX data FIFO(64bit FIFO SI4322)
• RSSI (Digital and Analog), AFC and DQD
• Low battery detection and wakeup timer
• 2.2-5.4V operation supply Votlage(SI43222.2-3.8V)

• Low standby current (0.3uA)
• Compact 16 pin TSSOP

13
Receiver with Standalone or MCU Mode Application
EZRadio
SI4320
SI4320
Standalone Mode Application
MCU Mode Application
14
Standalone mode demo(SI4320)
EZRadio
CR2032 Battery
Loop Antenna (none match Circuit )
Standard 10 MHz Crystal
Indication LED
SI4320
15
Transceiver Parameters(SI4420/SI4421)
EZRadio
A Transceiver (Transmitter Receiver)

• No external antenna switch needed
• Transmitter FIFO
• Automatic antenna tuning
• No external RF parts (excl. 10 MHz quartz
  crystal) WDS 2.0 can help engineers where none
  standard 10MHz XTals are used.

16
EZRadioLC Si4010 SoC RKE Transmitter

• Hardware Features
• Low-cost wireless transmitter at 315, 434, 868,
  915 MHz
• Integrated 8051 MCU with flexible packet format
• No external SAW or crystal oscillator required
• Low power (18 mA Tx _at_ 10 dBm power, 0.1 uA
  standby)
• Supply voltage 1.8 to 3.6 V
• FSK, ASK modulation options
• 10 dBm maximum output power with 16 dBm
  programmable range
• Automatic antenna tuning for optimum PA
  efficiency and higher radiated power
• PA wave shaping reduces spurious content in ASK
  mode
• 250 ppm frequency accuracy with no external
  reference
• External 1-pin xtal option for tighter frequency
  accuracy
• 5 general purpose input/outputs (power-on push
  button capable)
• -40 to 85C temperature range
• Software Features
• Transmit packet encryption
• AES standard, customer specific encryption
• Standalone operation
• Button push to encrypted payload output

17
Si4010 Block Diagram

• Integrated 8051 MCU
• On-chip memory
• 2 kB OTP (1.8 kB available for custom
  programming)
• 2 kB RAM (1.8 kB available for custom
  programming)
• 256 bytes of data RAM
• 8 kB ROM
• 20 bit EEPROM for rolling code counter

18
Si4010 Keyfob Application Schematic

• No external MCU, EEPROM, SAW, or crystal
  oscillators needed
• Smallest BOM, board area, and lowest total cost

19
EZRadioLC Si4311 OOK/FSK Receiver

• Optimized for low-cost wireless remote control
  receivers
• Easy to use, no external MCU required
• No RF SAW or IF ceramic filters needed
• Features
• Low power 19 mA RX current
• Supply voltage from 2.7 to 3.6 V
• High sensitivity
• -113 dBm _at_ 4 kbps FSK, BW 48 kHz, BER 10-3
• -112 dBm _at_ 2.4 kbps OOK, BW 24 kHz, BER 10-3
• 315 or 433.92 MHz operation
• Selectable channel bandwidths
• Integrated LDO regulator for direct connection to
  battery
• Integrated noise squelch circuit
• 3 x 3 x 0.85 mm 20-pin QFN package
• Small board area of 20 mm2

20
FSK Application Schematic _at_ 433.92 MHz

• Easy to use
• RF input ? digital output
• Channel BW chosen by state of BW31 pins
• Integrated LDO regulator allows direct connection
  to battery

21
EZRadioPRO Products
EZRadioPRO

• Transceivers
• SI4430 - Freq Range900-960MHz Output Power
  13dBm
• SI4431 - Freq Range240-930MHz Output Power
  13dBm
• SI4432 - Freq Range240-930MHz Output Power
  20dBm

• Receivers
• SI4330 - Freq Range240-960MHz Sensitivity
  -118dBm

• Transmitters
• SI4030 - Freq Range900-960MHz Output Power
  13dBm
• SI4031 - Freq Range240-930MHz Output Power
  13dBm
• SI4032 - Freq Range240-930MHz Output Power
  20dBm

22
EZRadioPRO

• Main Performance Specs
• Frequency Range 240-960MHz
• Sensitivity -118dBm
• Data Rate 1-128kbps
• 20dBm Max Output Power Version
• Configurable 11 to 20dBm
• 13dBm Max Output Power Version
• Configurable -8 to 13dBm
• Low Power Consumption
• 17mA Receive
• 60mA Transmit _at_20dBm
• Power Supply 1.8-3.6V

IA4432

• General Features
• 20 Pin QFN Package
• -40C - 85C Temperature Range
• Green Lead Free Package
• Low BOM

23
EZRadioPRO
Range measurements done at Hungary office with
development platform
Data rate Range
2.4kbps 2.05km
4.8kbps 2.03km
9.6kbps 1.5km
50kbps 1.37km
100kbps 1.1km
125kbps 0.96km
24
Distance Test site
EZRadioPRO
51M
25
What is Antenna Diversity?
EZRadioPRO

• Two antennas in system
• EZRadioPRO will choose the best antenna for
  optimal performance
• Gain 8-10dB in Link Budget Gain
• Common feature used in cell/cordless phones to
  avoid multipath/fading

26
What is the Packet Handler??
EZRadioPRO

• Typical Packet Structure Shown Above
• Preamble, Sync Word TX Header, Packet Length, and
  CRC fields set through SPI registers
• ALL that needs to be loaded into FIFO is Data
• EZRadioPRO will automatically construct/deconstruc
  t the packet

27
EZRadioPRO Schematics
SI4431/32
28
EZRadioPRO System Benefits
Competitive System Solutions
EZRadioPRO System Solutions

• Larger MCU memory requirement
• MCU awake to poll radio more current
• ADC required for temp / battery sensor
• Additional SW developer burden
• Reduced performance and battery life, increased
  cost, complicated design

• Reduced MCU memory requirement
• MCU asleep while radio qualifies data
• Integrated ADC, temp sensor, battery detect
• Packet qualification simplifies SW
• EZRadioPRO improves performance, reduces current
  and cost, eases design

29
Wireless MCU

• In wireless applications customers need a MCU
• Implements overall product functionality
• Protocol communication tasks
• Acknowledgements between nodes
• Packet construction and deconstruction (built
  into EZRP)
• Security Encryption
• Keeloq, AES128, AVR411
• Radio control
• Radio configuration (frequency, modulation, etc)
• Antenna Diversity (built into EZRP)
• Antenna Switching (built into EZRP)
• I/O requirements (built into EZRP)

30
How to win the MCU/RF bundle

• RF performance/features critical for product
  selection
• Link range
• Battery life
• Winning the radio socket creates opportunity to
  win MCU
• Some customers need unique MCU features
• 0.9V battery operation
• Capacitive touch-sense
• For other generic MCU applications make it
  easy!
• Reference designs with radio and MCU
• EZLink modules are ideal reference platform
• Example radio application code
• Networking software EZMac
• Domain specific software
• AES-128 encryption
• Frequency hoping

31
Supporting Reference Source Code

• MCU and RF teams porting RF code to C8051 MCU
• Point-to-point simple links
• Transceiver ping-pong
• EZMac
• EZMac Litesmallest footprint
• EZMac Standardadds multicast and error detection
  support
• EZMac Plusadds packet forwards
• EZMacPROlower footprint, uses hardware blocks in
  EZRadioPRO devices(currently in development)
• Frequency hopping spread spectrum
• All of the above is available in the development
  kits

32
Supporting Software

• EZMac
• Hardware maybe complex for some Software Complex
  for others
• Reference source code
• Designed to handle the radio communication,
  application sits on top

33
Supporting Software

• EZHopper provides the FHSS hopping engine to
  enable high output powers (e.g. 20dBm) while
  also meeting FCC regulations
• EZHopper available as licensable LIBRARIES only.
• Soon to be embedded into EZMac PRO

• EZHopper

34
Available Wireless/MCU Development Kits

• Software Development Board (SDB)
• Designed for the following
• Customer demonstration
• BASIC RF testing
• Code development (on a known platform)

Part No. SDBC-DK3

• EZLink Fast Prototyping Module
• Designed for the following
• Know good RF module for customer prototyping
• EZRadio and EZRadioPRO variants (All set for HB
  only)
• Supersets only available

Part Nos.EZLC-DK1-4x2x xxx EZLC-DK1-4x3x xxx
35
Available Wireless/MCU Development Kits

• Lab-based RF Evaluation Board
• Designed for the following
• Advanced RF testing
• Designed to be controlled by the WDS chip
  configurator
• Often referred to as a LoadBoard
• Note plan to migrate to a SDB platform plug-in

Part No. ISM-DK3

• RF Test cards
• Designed for the following specifications
• Chip specific (e.g. Si4431, Si4320)
• Frequency specific (e.g. 868, 915 MHz)
• Antenna specific (e.g. BIFA, 50O, Loop)
• Plugs into both the SDB and the LoadBoard
  platforms
• Known RF characteristics

Part Nos.See price book
36
Supporting Tools

• Wireless Development Suite
• PC-based GUI software tools
• Terminal emulator (Vista does not have
  hyperterminal anymore)
• Chip configurator
• Automated Datasheet Enter your RF
  characteristics and the registers are
  automatically set
• C Header Generator Create a file with the
  register settings and import into your compiler
• Reference Designs
• Development and demonstration kits
• Schematics
• Layouts
• C8051 MCU versions coming soon!

Available today on CDs in development kits
37
www.silabs.com/WirelessThank you!!!
