What's new in UNIFACE 8

1
CBG Workshop
Michael Zille
2
Uniface 9 Whats new? Stichworte

• UDE
• Unicode
• Farbverwaltung
• Widgets
• Dynamische Formlayout-Änderungen
• XML Reader/Writer
• Integrierter Serverpage-Editor
• Proc Statements/Functions
• Migration

3
Application Platform Suite
4
UDE - Enhancements
5
(No Transcript)
6
UDE Look and Feel
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Multi Language Support (Unicode)
12

• Internationaler Standard für Zeichen bzw.
  Textelemente
• Codebereiche
• UCS-2, 16 Bit gt 65.536 Zeichen
• UCS-4, 32 Bit gt 1.114.112 Zeichen derzeit zu
  etwa 9 genutzt
• Formate
• UTF-8
• UTF-16
• ...
• Unicode Consortium (seit 1991)
• Zusammenarbeit mit ISO (Norm 10646)

13

• String literals
• Messages
• Menu text
• Panel text
• widgets

14
Restrictions

• No Unicode support for
• CHUI
• Profile Characters
• Uniface Names
• Enhanced Printing in non-Windows platform
• SQL (/workbench),database error messages,
  username and password
• C, Tuxedo and Corba Call-In and Call-Out
• UHTTP components
• UPOPMAIL components
• No Unicode sorting support
• Supported Databases ORACLE, SOLID
• external Interfaces e.g. Filenames (supported
  on Windows, not on UNIX)

15
SYS_CHARSET Specify the character set used for
communication with the operating system and for
communication between Uniface and non-Uniface
components, if they are not Unicode-based.
DEF_CHARSETdefault character set used for
storing data in String fields with C packing code
16
Support for Unicode and other Character Sets
17
(No Transcript)
18
Multi Language Support
Special strings does not exist anymore
19

• ASCII (ASC) (font0) uses Unicode Range 0-7F
• Extended ASCII (MUL) use Unicode Rage
  0-ff(formerly font 0 1)
• Full Character Set (FUL) DEFAULT is determind
  by FULL_SYNTAX (font 0 to 7)

20
(No Transcript)
21
Assignment Settings

• META_LANGUAGE Section
• EXTENDED_SYNTAXSpecify which characters are
  allowed as extended characters ( or _at_) in the
  field syntax definition.
• FULL_SYNTAXSpecify the allowed character set
  for the FUL shorthand code in the field syntax
  definition.
• META_IN_TRXSet the data storage format of
  String fields with the U packing code to XML or
  TRX.
• WIDE_CHAR_BEHAVIORSpecify the character set
  used for String fields with the W packing code.
• GAIJIAllow the use of Japanese Gaiji
  characters.

22
GUI - Enhancements
23
(No Transcript)
24
(No Transcript)
25
Color Handling

• Widgets
• Color List
• Color Box
• Functions Statements
• windowproperties(instancename)"backcolorCOLOR

• fieldproperties(fld_test)"backcolorCOLORforec
  olorCOLOR"
• colorbox/full
• Properties
• Windows Properties
• Background Color
• Widget Properties
• Background Color
• Foreground Color

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
Enhanced Grid Widget

• Supports Windows XP Vista look and feel
• Supports now the following widget types
• Editbox
• Checkbox
• Picture
• Command button
• Spin Button
• Drop-down List
• Color box

31
Enhanced Tree Widget
Delete Items
Re-order
32
(No Transcript)
33
Dynamic Menus
34
Dynamic Menus
35
Dynamic Menus
36
(No Transcript)
37
Proc Functions Statements
38
paintedfieldproperties (myfield1, 2,
XposYpos) Xpos20Ypos15
paintedfieldproperties( Field ,
PaintedOccurrence , PropertyList )
PropertyValuesList PropertyValuesList
paintedfieldproperties( Field ,
PaintedOccurrence , Position Size )
39
paintedfieldproperties
paintedfieldproperties( Field ,
PaintedOccurrence , PropertyList )
PropertyValuesList PropertyValuesList
paintedfieldproperties( Field ,
PaintedOccurrence , Position Size )
paintedfieldproperties (NAME, 4)
"xsize3ysize25" paintedfieldproperties
(NAME.PROJECT.MYORG, "341") "xsize2"
paintedfieldproperties(FIELD1,"1")
"XPos50YPos50"
40
New Statements file/directory management
dircreate Creates the specified directory
dirdelete Deletes the specified directory
dirrename Renames the specified directory
filecopy Copies the specified file to the target
location filedelete Deletes the specified file
filemove Moves the specified file to the target
location filerename Renames the specified file
within the same directory
41
Use of Zip-files
These instructions can create, read, and write
zip files and directories.
(Local) File I/O
(Local) directory management
(Local) file management
filedump fileload
ldircreate ldirdelete ldirrename ldir
ldirlist
dircreate dirdelete dirrename
lfilecopy lfiledelete lfiledump lfileload
lfilemove lfilerename lfileexists
lfileproperties
filecopy filedelete filedump fileload
filemove filerename
lfiledump lfileload
ZIP unlock
flush lflush
42
Use of Zip-files
Zip Path Assignments Assignment file
redirections now accept zip archive definitions.
For example FILES All forms compiled into a
ZIP archive .frm myforms.zip.frm All xml
files are imported from the sources ZIP in the
installation directory umeta.xml
usys..\sources\sources.zipumeta.xml
usource.xml usys..\sources\sources.zipusour
ce.xml udefault.xml usys..\sources\sources.zi
pudefault.xml
43
(No Transcript)
44
UDE
Perform actions on Repository data, including
compiling, exporting, importing, and converting.
Syntax Export Repository data    ude ("export",
ObjectType , ObjectProfile ,ZipArchive
Filename , OptionList ) Import data into the
Repository    ude ("import", "misc",ZipArchive
Filename ,"", OptionList ) Copy or convert
data from one format to another    ude
("copy","misc", Source , Target , OptionList )
Compile development objects    ude ("compile",
ObjectType , ObjectProfile ,"", OptionList )
Note  ude only works on the development
Repository and requires a fully configured
Uniface Development Environment and Repository to
be available.
45
entitycopy
Copy data from one DBMS or file to another.
Syntax entitycopy Source , Target , OptionList
Description The entitycopy Proc statement copies
or converts one or more entity occurrences from a
source database or file to another. It enables
you to incorporate the functionality provided by
the /cpy command line switch into your Uniface
application.
46
Miscellaneous Functions

• procreturncontext
• itemcount
• string

47
procreturncontext
Return context information about the return value
of the previous Proc instruction.
Syntax procreturncontext
Description
The procreturncontext function provides
additional information for Proc instructions that
are typically involved in batch processing, such
as copying data. For example, it can be used
after entitycopy and UDE.
48
procreturncontext
Item Description
Context Context Context of the information. Can have the value EntityCopy, UDE Copy, UDE Import, or UDE Compile. If the Context is UDE Compile, only Release is available
Error Number Error number if process failed on error
InputRecords Number Number of records to be copied.
OutputRecords Number Number of records where an attempt was made to write them. The difference between InputRecords and OutputRecords is the number of void mappings.
WriteErrorsContinues Number Number of write errors encountered that did not stop the copy action.
InputDescriptors Number Number of descriptors to be copied. The same descriptor can occur more than once.
OutputDescriptors Number Number of signatures actually output. This can be less than the number of InputDescriptors if void mappings are encountered.
InputTrxFiles Number Number of TRX files to copy, if a wildcard was specified.
InputXmlFiles Number Number of XML files to copy, if a wildcard was specified.
Release ReleaseNumber Number of the Uniface release of the source data.
AdditionalInfo String Reserved for future
49
itemcount
Return the number of items in a list.
Syntax itemcount ( List )
Description The itemcount function enables you
to determine how many items are in a list before
processing each item.
variables string vListe endvariables putlistitems
/id vListe, order_id.order, total.order message/in
fo "Number of Items itemcount(vListe)"
50
string
Return a string containing the replacement of
each named XML entity in the input parameter
string by the character represented by the
entity. (XML entities are character mappings
they are not the same as Uniface entitites.)
Syntax string ( String )
In the following examples, FLD is a String field
whose packing code is W. vVar1string("XML has
five predeclared entities.") 0 xml entity
vVar2string("They are lt, gt, amp, \
apos, and quot.") 5 xml entities
FLDvVar1vVar2 After executing
this Proc, field FLD contains the following XML
has five predeclared entities. They are lt, gt,
, ', and ".
51
string
Variables string vVar1 string vVar2 string
vFLD endvariables GrossBuchstaben vVar165 vVar2
"" while(vVar1 lt 91) vVar2"vVar2vVar1
" vVar1vVar11 endwhile FLD_Wstring(vVar
2)
After executing this Proc, field FLD_W
contains ABCDEFGHIJKLMNOPQRSTUVWXYZ
52
XML Reader / - Writer
53
XML -Reader / -Writer

• It enables the procedural creation and parsing of
  XML strings
• It is comparable to SAX parser
• Use UXMLWRITER to generate a XML file or data
  stream
• Use UXMLREADER to parse an existing XML file or
  data stream

54
Simple API for XML (SAX)

• Die Simple API for XML (SAX) ist ein
  Pseudo-Standard,
• der ein Application Programming Interface (API)
  zum Parsen von XML-Daten beschreibt.
• Die aktuelle Hauptversion SAX 2.0 wurde 2000 von
  David Meggionson veröffentlicht und
• ist Public Domain.
• Ein SAX-Parser liest XML-Daten als sequentiellen
  Datenstrom und ruft für im Standard definierte
  Ereignisse vorgegebene Rückruffunktionen
  (callback function) auf.
• Eine Anwendung, die SAX nutzt, kann eigene
  Unterprogramme als Rückruffunktionen registrieren
  und auf diese Weise die XML-Daten auswerten.

55
Simple API for XML (SAX)
lt?xml version"1.0"?gtltdocgt ltparagt Hello,
world!lt/paragt lt/docgt
lt?xml version"1.0"?gt ltdocgt ltparagt Hello,
world! lt/paragt lt/docgt
start document start element doc start
element para characters Hello, world!
end element para end element doc end
document
56
XML-Reader

• STARTDOCUMENTactivated when the parser starts
  reading the document.
• STARTELEMENTactivated when the parser encounters
  a start tag, for example lttag docgt
• CHARACTERactivated when character data is
  encountered between a tag and its end tag.
• ENDELEMENTactivated when the parser encounters
  an end-tag such as lt/tag docgt.
• ENDDOCUMENTactivated when the end of the
  document is reached.

57
XML-Reader
operation warning error fatalerror params str
ing list in endparams your code end
operation startdocument your code end ---------
----------------?gt operation enddocument your
code End
operation startelement params string name
in string attr in endparams your
code end ----------------------------?gt operation
endelement params string name
in endparams your code end
operation characters params string chars
in endparams your code end
58
To create a SAX handler

• Create a component that implements at least one
  SAX callback operation.These operations are
  activated by the PARSE and PARSEFILE operations
  of the UXMLREADER component.
• Optionally, implement error handling operations
  to handle invalid data and other errors. Data
  read by the parser is expected to be legaleither
  there is no DTD defined for the data, or if there
  is a DTD, the tags, attributes and character data
  conform to the DTD. If this is not the case, the
  appropriate operation is activated, if present.
• For warnings, the WARNING operation is activated.

• If the error is deemed recoverable by the SAX
  parser, the ERROR operation is activated
  otherwise, the FATALERROR operation is activated.

• If there is no ERROR operation, recoverable
  errors are silently recovered from and ignored.
• After a fatal error occurs, no further processing
  of the XML file is done and the PARSE or
  PARSEFILE operation returns a negative value.

59
To read and parse an XML document

• Create an instance of the UXMLREADER component.
• Create an instance of the handler component, or
  retrieve the instance name of an already active
  handler component.
• Activate the handler by calling the SETHANDLER
  operation.
• Start parsing XML documents using PARSE to parse
  a field or variable of type string or xmlstream,
  or PARSEFILE to start parsing a file.
• As the XML document is parsed, the
  operations in the handler instance are activated
  based on what the parser encounters in the XML
  document. When PARSE or PARSEFILE returns, either
  the entire XML document has been successfully
  parsed, or a fatal error has occurred, in which
  case a negative return value is returned.

60
XML-Writer

• internal Uniface component that enables you to
  generate XML documents
• The UXMLWRITER component operations enable you to
  construct an XML document.
• The operations must be called in a specific
  sequence.
• STARTDOCUMENT
• ENDDOCUMENT
• STARTELEMENT
• ENDELEMENT
• ADDATTRIBUTE
• CHARACTERS
• DOCCOMMENT
• GETDOCUMENT

61
To generate an XML document

1. For each XML document you want to generate,
   create an instance of the UXMLWRITER component.
2. Call the STARTDOCUMENT operation for each
   instance.
3. Add XML elements, attributes and comments using
   the operations available on the UXMLWRITER
   component.
4. Retrieve the resulting XML documents with the
   GETDOCUMENT operation.
5. Manipulate the data as required.
6. Delete the instances of UXMLWRITER when they are
   no longer required.

62
Integrated Web Development
63
Integrated Web Development

• No generation of HTML Skeletons
• USP layout information is incorporated into the
  server page itself
• Complete definition is stored in the repository
  and compiled into the .usp files
• The integrated graphical HTML layout editor is
  the main tool for defining server pages
• Component editor for
• view data structure
• load fields
• define properties
• write proc code

64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
Migration
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
CBG Workshop

• Zeit für Fragen
