Cell Structure

1
Cell Structure
2
Cytoplasm

• All of the cellular contents between the plasma
  membrane and the nucleus

3
Cytosol

• Fluid portion of the cytoplasm
• 55 of the cells volume
• 75-90 water
• Contains dissolved/suspended solutes
• Ions, glucose, ATP, lipids, proteins, amino
  acids, waste
• Site of most of the chemical reactions in the cell

4
Organelles

• Specialized structures inside cells that have
  characteristic shapes and specific functions

5
Cytoskeleton

• Network of protein filaments
• Microfilaments, intermediate filaments,
  microtubules

6
Microfilaments

• Thinnest
• On the periphery of the cell
• Contribute to shape and strength
• Help generate movement
• Support microvilli

7
Intermediate Filaments

• Thicker than microfilaments, thinner than
  microtubules
• Found in cells subject to tension
• Help to hold organelles in place

8
Microtubules

• Largest
• Help determine shape
• Function in movement of organelles
• Function in movement of cilia and flagella

9
Centrosome

• Near the nucleus
• Pair of centrioles
• Cylindrical structures composed of clusters of
  microtubules arranged in a circular pattern
• Pericentriolar Material
• Tubulins organizing center for the growth of
  mitotic spindles

10
(No Transcript)
11
Cilia and Flagella

• Motile projections on the cell surface
• Cilia numerous short hair-like projections on
  the cell surface.
• Propel fluids across the surface of the cell
• Flagella longer than cilia, propel the entire
  cell.
• Only example in the human is sperm cell

12
(No Transcript)
13
Ribosomes

• Site of protein synthesis
• High content of RNA
• 2 sub-units
• Large and small
• Made in the nucleolus and assembled in the
  cytosol
• Attached to ER or free in cytosol

14
(No Transcript)
15
Endoplasmic Reticulum

• Network of folded membranes that extends through
  the cytoplasm
• Rough ER extends from nuclear envelope has
  ribosomes attached processes and sorts proteins
  that will be incorporated into the membranes
• Smooth ER extends from rough ER no ribosomes
  attached fatty acids and steroids are
  synthesized.

16
(No Transcript)
17
Golgi Complex (Body Apparatus)

• Packages and transports materials
• Cisterns flattened membranous sacs with bulging
  edges that make up the Golgi Body

18
Transport of Proteins by the Golgi Body

• Protein is surrounded by ER membrane and buds of
  to form a transport vesicle
• Transport vesicle moves toward Golgi Body
• Vesicle fuses with Golgi Body and proteins enter
• Proteins move from one cistern to another by
  transfer vesicles
• In last cistern proteins are sorted and packaged
• Proteins leave Golgi Body in secretory vesicles,
  other membrane vesicles or transport vesicles

19
Lysosomes

• Membrane enclosed vesicles that contain digestive
  enzymes
• Help to recycle cellular components
• Autophagy worn out organelles are digested
• Autolysis enzymes destroy its own cell

20
Tay-Sachs Disease

• An inherited condition in which one lysosomal
  enzyme is absent.
• Normally breaks down a membrane glycolipid found
  in nerve cells. It is not broken down, it
  accumulates which makes the nerve cell function
  less efficiently
• Seizure, muscle rigidity, blindness, dementia,
  uncooridated. Usually die before age 5

21
Peroxisomes

• Similar to lysosomes but smaller
• Contain oxides
• Enzymes that can oxidize various organic
  substances
• Abundant in liver where there are a lot of toxic
  substances
• Contain catalase

22
Proteasomes

• Contain enzyme called protease
• Continuously destroys unneeded, damaged or faulty
  proteins
• Recycles amino acids

23
Mitochondria

• Site of cellular respiration (makes ATP)
• Active cells have a larger number
• Double Membrane
• Outer smooth
• Inner folded
• Cristae folds
• Enzymes that catalyze a series of reactions are
  found in the matrix

24
(No Transcript)
25
(No Transcript)
26
Check Point Questions

• What is the difference between cytoplasm and
  cytosol?
• What is an organelle?
• Describe the structure of a ribosome, the Golgi
  Body and a mitochondrion.
