Title: Architectural Design Principles


1
Architectural Design Principles
2
Outline
  • Architectural level of design
  • The design of the system in terms of components
    and connectors and their arrangements
  • Architecting with design operators
  • These are explicit transformations of a design
    decomposition, replication, compression,
    abstraction, and resource sharing.
  • Functional design strategies
  • Architectural designs can be transformed by
    applying higher-level macro operations such as
    design patterns and other design strategies.

3
Architectural Level of Design
  • Applying design principles
  • Understanding quality attributes helps you to
    reason about specific characteristics
  • Design principles guide the decisions that need
    to be made during the application of design
    methods.
  • Systematic variation is a technique that helps
    the architect discover or create a solution field
    to a given problem.

4
Architectural Level of Design (Contd)
  • Applying design principles (contd)
  • The architect can go down multiple paths forming
    a solution tree.
  • At any time the architect may apply design
    evaluation techniques to test the quality
    attributes of the design.
  • The architect can also apply architecture styles
    and patterns as operations.
  • Operations are not necessarily transitive the
    result may depend on the order applied.

5
Architectural Level of Design (Contd)
  • Using Systems Thinking
  • Considering the entire vies of the problem, not
    just the subproblems.
  • Systems thinking requires a balance between
    looking at the big picture and looking at
    subpictures.
  • Take a two pass approach
  • On the first pass capture what comes to you and
    dont filter it or try to formalize it
  • On the second and subsequent passes, remove,
    revise and refine as necessary.

6
Architecting with Design Operators
  • The application of design operators starts with a
    representation of the system as a single
    component that has externally visible
    characteristics and functions.
  • The system is initially divided into two
    components, each with a well-defined purpose and
    the two components interact by the way of
    connectors.
  • The system now appears as two modules that share
    a set of global design rules, which define the
    connectors.

7
Common Software Design Operators
  • Decomposition
  • Replication
  • Compression
  • Abstraction
  • Resource sharing

8
Decomposition
  • This is the operation of separating distinct
    functionality into distince components that have
    well-defined interfaces.
  • It is the most important and most used principle
    in any engineering design field.
  • It is used to achieve a variety of quality
    attributes including modifiability, portability,
    performance, and buildability.

9
Decomposition (Contd)
  • Two types of decomposition
  • Part/whole
  • Generalization/specialization
  • Each application of the decomposition operator
    divides a component into two subcomponents.
  • The choice of where to draw the line between
    components is driven by what quality attributes
    you are trying to emphasize.

10
Identifying Functional Components
  • Components are identified in several ways
  • Interfaces The interfaces between the system
    and external entities should be associated with
    components, one per interface (or set of
    interfaces) but interfaces should not be
    fragmented across multiple components.
  • Domains There are two types of domains
    application domains and solution domains. Each
    application domain (e.g., Content Authoring,
    Publishing, Marketing) may be modeled by a
    separate domain. Similarly you may identify
    components like Content Repository, Content
    Delivery, Project Management, and Royalty
    Management may be components in the solution
    domain.

11
Identifying Functional Components (Contd)
  • Components are identified in several ways
    (contd)
  • Functional abstraction layers These decompose
    the system into a functional hierarchy. From
    this hierarchy it is possible to identify common
    functions that can be represented by shared
    components.
  • Domain entities Just as a domain may be
    represented as a component, it may be useful to
    represent specific domain entities directly as
    components. In the publishing domain there is an
    entity called a Content Reviewer. It may be
    appropriate to model this entity as a component,
    or alternatively to model it in some process and
    not explicitly in the structure of the system.

12
Composition/Aggregation
  • This involves assembling components to form new
    components.
  • The new components have behaviors that are not
    inherent in the subcomponents individually.
  • This is not exactly the opposite of
    decomposition.
  • The true opposite of decomposition is compression.

13
Component Communication
  • When a component is divided into two components
    there is an implied communications channel
    between them.
  • It may be asynchronous or synchronous.
  • Asynchronous communication decouples the
    processing of the two components which may
    improve performance and reliability, but it may
    add complexity.

14
Compression
  • This is the opposite of decomposition.
  • It is the merging of components into a single
    component or removing layers or interfaces
    between components.
  • Compression is used to improve performance by
    eliminating a level of indirection.
  • For example, a presentation component may
    interact directly with a database instead of
    using middle-tier objects.

15
Abstraction
  • Abstraction hides information by introducing a
    semantically rich layer of services while hiding
    implementation details.
  • Hiding the underlying implementation makes other
    components portable with respect to the
    abstracted component.
  • Abstraction is also referred to as creating a
    virtual machine.
  • It can be used to improve adaptability.

16
Resource Sharing
  • This is the encapsulating of data or services to
    share them among multiple independent client
    components.
  • The result is enhanced integrability,
    portability, and modularity.
  • Persistent data (such as that stored in
    databases) is a common shared resource.
  • Resource sharing can simplify some aspects of
    systems configuration and management.

17
Replication
  • This is the operation of duplicating a component
    in order to enhance reliability and performance.
  • There are two flavors of runtime replication
  • Redundancy where several identical copies of a
    component execute simultaneously.
  • N-version programming where there are several
    different implementations of the same
    functionality.
  • A good design approach to redundancy and backups
    is to make component switching transparent to the
    other components that are using it.

18
Functional Design Strategies
  • Two strategies for achieving reliability
  • Self-Monitoring -- This is a system that is able
    to detect certain types of failures and handle
    them appropriately. There are two approaches
  • Process monitoring a layer above the
    application that watches over the system
  • Component monitoring a monitor is established
    for monitoring each component
  • Recovery This is a system that is able to
    restore itself after a failure.
  • Instrumenting Similar to self-monitoring. A
    component can be instrumented to measure aspects
    of the execution.

19
Summary
  • General design methods combined with quality
    attributes and design principles yields an
    architectural design method that is heuristic and
    participative.
