Mesh Parametrization and Its Applications

1
Mesh Parametrization and Its Applications

• ?????
• ????????
• ???
• ???????(???, ???)

2
Computer Graphics

• Definition
• all technologies related to producing pictures or
  images using a computer
• Computer animation, VR(virtual reality),
• Goal Reality and Real time
• Reality
• Mapping(texture) / Rendering(light)

v
3
Computer Graphics
v
4
Computer Graphics
v
5
Polygonal Objects(Mesh)
6
Parametrization

• Embedding 3D mesh to 2D parameter space
• Requirements
• distortion minimization
• one-to-one mapping

(s,t)
v
parametrization in 2D
triangular mesh in 3D
7
ParameterizationLevy
8
Previous Work

• Energy functional minimization
• Green-Lagrange tensor Maillot93
• orthogonality and homogeneous spacing Lévy98
• Dirichlet energy Hormann99
• Convex combination approach
• shape-preserving parametrization Floater97
• harmonic embedding Eck95

9
Convex Combination Approach (1)

• Convex combination and boundary condition
• determine shape of parameter space
• map boundary vertices onto a convex polygon
• determine coefficients for the inner vertices
• solve a linear system Ax b

1-ring neighborhood in parametric space
parameter space
3D mesh
10
Convex Combination Approach (2)

• Benefit
• simple and fast, one-to-one embedding
• Drawback
• high distortions near the boundary

parameterization with fixed boundary
3D mesh
11
Reducing Distortion near Boundary

• Floating boundary for the parameter space
• non-linear system Maillot93 Lévy98
  Hormann99
• linear system Lévy01
• heavy computation and/or non-one-to-one mapping

parameterization with floating boundary
3D mesh
12
Motivation

• Extension of convex combination approach
• distortion minimization near the boundary
• simple and fast
• one-to-one mapping

3D mesh
floating boundary
fixed boundary
13
Our Approach (1)

• Virtual boundary
• virtual vertices attached to the real boundary
• virtual boundary is fixed but real boundary can
  move to reduce the distortion in parameterization

virtual boundary
parametrization with virtual boundary
3D mesh
14
Our Approach (2)

• Parametrization process

Compute coefficients ?i,j (inner vertices
boundary vertices)
Determine shape of parameter space (convex
polygon)
making virtual boundary
Map virtual vertices to the polygon
Solve linear system
parametrization
15
Virtual Boundary

• Virtual vertices
• of virtual vertices 2 ? of real boundary
  vertices
• boundary vertex is adjacent to three virtual
  vertices
• no 3D positions are required for virtual vertices

virtual boundary
real boundary
connectivity of virtual vertices
16
Coefficient Computation (1)

• Shape-preserving parametrization Floater97
• conformal mapping of 1-ring neighborhood
• average of barycentric coordinates

conformal mapping onto 2D
1-ring neighborhood in 3D
averaging barycentric coord.
17
Coefficient Computation (2)

• Coefficients of real boundary vertices

map to 2D while preserving angles and lengths
place virtual vertices in 2D
1-ring neighborhood in 3D
1-ring neighborhood in 2D
1-ring neighborhood virtual vertices in 2D
18
2D Positions of Virtual Vertices

• Mapping virtual vertices onto convex polygon
• using edge lengths between real boundary vertices

virtual boundary
real boundary
relation of real and virtual boundary
mapping virtual boundary
19
Shape of Parameter Space

• Strong influence on the parameterization
• simple choices such as circle and rectangle?
• Convex hull of the projection of real boundary

circle
rectangle
convex polygon from projected boundary
20
Extended Virtual Boundary (1)

• More virtual vertices in multi-layered structure
• to reduce distortions near the real boundary

3D mesh
parametrization
region far from the boundary
21
Extended Virtual Boundary (2)

• Structure
• each layer has the same of virtual vertices
• Coefficients for virtual vertices

2nd virtual layer
1st virtual layer
real boundary
connectivity an coefficients of virtual vertices
22
Extended Virtual Boundary (3)

• Effect for concave real boundary

3D mesh
one layer
no virtual vertices
two layers
three layers
four layers
23
Results (1)
rectangle
circle
projected polygon

map the boundary
3D mesh
map virtual boundary
24
Results (2)

• Texture mapping

3D mesh
circle, virtual boundary
projected polygon, virtual boundary
rectangle
25
Applications(Texture)Levy
26
Applications(Texture) )Levy
27
Applications(Texture) )Levy
28
Conclusion and Future Work

• Extension of convex combination approach
• distortion minimization near the boundary
• Virtual boundary
• fixed instead of the real boundary
• multi-layered structure
• Future work
• connectivity and coefficients of virtual vertices
• speed up with multilevel approach
