Neuromuscular Fundamentals

1
Neuromuscular Fundamentals

• Anatomy and Physiology of Human Movement
• 420050

2
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

3
Introduction

• Responsible for movement of body and all of its
  joints
• Muscles also provide
• Protection
• Posture and support
• Produce a major portion of total body heat
• Over 600 skeletal muscles comprise approximately
  40 to 50 of body weight
• 215 pairs of skeletal muscles usually work in
  cooperation with each other to perform opposite
  actions at the joints which they cross
• Aggregate muscle action - muscles work in groups
  rather than independently to achieve a given
  joint motion

4
Muscle Tissue Properties

• Irritability or Excitability - property of muscle
  being sensitive or responsive to chemical,
  electrical, or mechanical stimuli
• Contractility - ability of muscle to contract
  develop tension or internal force against
  resistance when stimulated
• Extensibility - ability of muscle to be passively
  stretched beyond it normal resting length
• Elasticity - ability of muscle to return to its
  original length following stretching

5
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

6
Structure and Function

• Nervous system structure
• Muscular system structure
• Neuromuscular function

7
Figure 14.1, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
8
Nervous System Structure

• Integration of information from millions of
  sensory neurons ? action via motor neurons

Figure 12.1, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
9
Nervous System Structure

• Organization
• Brain
• Spinal cord
• Nerves
• Fascicles
• Neurons

Figure 12.2, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
Figure 12.7, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
10
Nervous System Structure

• Both sensory and motor neurons in nerves

Figure 12.11, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
11
Nervous System Structure

• The neuron Functional unit of nervous tissue
  (brain, spinal cord, nerves)
• Dendrites Receptor sites
• Cell body Integration
• Axon Transmission
• Myelin sheath Protection and speed
• Nodes of Ranvier Saltatory conduction
• Terminal branches Increased innervation
• Axon terminals Connection with muscular system
• Synaptic vescicles Delivery mechanism of
  message
• Neurotransmitter The message

12
Dendrites
Cell body
Axon
Myelin sheath
Node of Ranvier
Terminal ending
Terminal branch
Figure 12.4, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
13
Figure 12.8, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
Terminal ending
Synaptic vescicle
Neurotransmitter Acetylcholine (ACh)
14
Figure 12.19, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
15
Structure and Function

• Nervous system structure
• Muscular system structure
• Neuromuscular function

16
Classification of Muscle Tissue

• Three types
• 1. Smooth muscle
• 2. Cardiac muscle
• 3. Skeletal muscle

17
Skeletal Muscle Properties

• Extensibility The ability to lengthen
• Contractility The ability to shorten
• Elasticity The ability to return to original
  length
• Irritability The ability to receive and respond
  to stimulus

18
Muscular System Structure

• Organization
• Muscle (epimyseum)
• Fascicle (perimyseum)
• Muscle fiber (endomyseum)
• Myofibril
• Myofilament
• Actin and myosin
• Other Significant Structures
• Sarcolemma
• Transverse tubule
• Sarcoplasmic reticulum
• Tropomyosin
• Troponin

19
Figure 10.1, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
20
Figure 10.4, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
21
http//staff.fcps.net/cverdecc/Adv20AP/Notes/Mus
cle20Unit/sliding20filament20theory/slidin16.jp
g
22
Figure 10.8, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
23
Structure and Function

• Nervous system structure
• Muscular system structure
• Neuromuscular function

24
Neuromuscular Function

• Basic Progression
• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding filaments

25
Nerve Impulse

• What is a nerve impulse?
• -Transmitted electrical charge
• -Excites or inhibits an action
• -An impulse that travels along an axon is an
  ACTION POTENTIAL

26
Nerve Impulse

• How does a neuron send an impulse?
• -Adequate stimulus from dendrite
• -Depolarization of the resting membrane
  potential
• -Repolarization of the resting membrane
  potential
• -Propagation

27
Nerve Impulse

• What is the resting membrane potential?
• -Difference in charge between inside/outside of
  the neuron

-70 mV
Figure 12.9, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
28
Nerve Impulse

• What is depolarization?
• -Reversal of the RMP from 70 mV to 30mV

Propagation of the action potential
Figure 12.9, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
29
Nerve Impulse

• What is repolarization?
• -Return of the RMP to 70 mV

Figure 12.9, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
30
30 mV
-70 mV
31
Neuromuscular Function

• Basic Progression
• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding filaments

32
Release of the Neurotransmitter

• Action potential ? axon terminals
• 1. Calcium uptake
• 2. Release of synaptic vescicles (ACh)
• 3. Vescicles release ACh
• 4. ACh binds sarcolemma

33
Figure 12.8, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
Ca2
ACh
34
Figure 14.5, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
35
Neuromuscular Function

• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding filaments

36
Ach
37
AP Along the Sarcolemma

• Action potential ? Transverse tubules
• 1. T-tubules carry AP inside
• 2. AP activates sarcoplasmic reticulum

38
Figure 14.5, Marieb Mallett (2003). Human
Anatomy. Benjamin Cummings.
39
Neuromuscular Function

• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding Filaments

40
Calcium Release

• AP ? T-tubules ? Sarcoplasmic reticulum
• 1. Activation of SR
• 2. Calcium released into sarcoplasm

41
CALCIUM RELEASE
Sarcolemma
42
Neuromuscular Function

• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding filaments

43
Coupling of Actin and Myosin

• Tropomyosin
• Troponin

44
Blocked
Coupling of actin and myosin
45
Neuromuscular Function

• 1. Nerve impulse
• 2. Neurotransmitter release
• 3. Action potential along sarcolemma
• 4. Calcium release
• 5. Coupling of actin and myosin
• 6. Sliding filaments

46
Sliding Filament Theory

• Basic Progression of Events
• 1. Cross-bridge
• 2. Power stroke
• 3. Dissociation
• 4. Reactivation of myosin

47
Cross-Bridge

• Activation of myosin via ATP
• -ATP ? ADP Pi Energy
• -Activation ? cocked position

48
Power Stroke

• ADP Pi are released
• Configurational change
• Actin and myosin slide

49
Dissociation

• New ATP binds to myosin
• Dissociation occurs

50
Reactivation of Myosin Head

• ATP ? ADP Pi Energy
• Reactivates the myosin head
• Process starts over
• Process continues until
• -Nerve impulse stops
• -AP stops
• -Calcium pumped back into SR
• -Tropomyosin/troponin back to original position

51
(No Transcript)
52
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

53
Shape of Muscles Fiber Arrangement

• Muscles have different shapes fiber
  arrangements
• Shape fiber arrangement affects
• Muscles ability to exert force
• Range through which it can effectively exert
  force onto the bones

54
Shape of Muscles Fiber Arrangement

• Two major types of fiber arrangements
• Parallel pennate
• Each is further subdivided according to shape

55
Fiber Arrangement - Parallel

• Parallel muscles
• fibers arranged parallel to length of muscle
• produce a greater range of movement than similar
  sized muscles with pennate arrangement
• Categorized into following shapes
• Flat
• Fusiform
• Strap
• Radiate
• Sphincter or circular

56
Fiber Arrangement - Parallel

• Flat muscles
• Usually thin broad, originating from broad,
  fibrous, sheet-like aponeuroses
• Allows them to spread their forces over a broad
  area
• Ex Rectus abdominus external oblique

Modified from Van De Graaff KM Human anatomy, ed
6, Dubuque, IA, 2002, McGraw-Hill.
57
Fiber Arrangement - Parallel

• Fusiform muscles
• Spindle-shaped with a central belly that tapers
  to tendons on each end
• Allows them to focus their power onto small, bony
  targets
• Ex Brachialis, biceps brachii

Figure 3.3. Hamilton, Weimar Luttgens (2005).
Kinesiology Scientific basis for human motion.
McGraw-Hill.
58
Fiber Arrangement - Parallel

• Strap muscles
• More uniform in diameter with essentially all
  fibers arranged in a long parallel manner
• Enables a focusing of power onto small, bony
  targets
• Ex Sartorius, sternocleidomastoid

Figure 8.7. Hamilton, Weimar Luttgens (2005).
Kinesiology Scientific basis for human motion.
McGraw-Hill.
59
Fiber Arrangement - Parallel

• Radiate muscles
• Also described sometimes as being triangular,
  fan-shaped or convergent
• Have combined arrangement of flat fusiform
• Originate on broad aponeuroses converge onto a
  tendon
• Ex Pectoralis major, trapezius

Modified from Van De Graaff KM Human anatomy, ed
6, Dubuque, IA, 2002, McGraw-Hill.
60
Fiber Arrangement - Parallel

• Sphincter or circular muscles
• Technically endless strap muscles
• Surround openings function to close them upon
  contraction
• Ex Orbicularis oris surrounding the mouth

Modified from Van De Graaff KM Human anatomy, ed
6, Dubuque, IA, 2002, McGraw-Hill.
61
Fiber Arrangement - Pennate

• Pennate muscles
• Have shorter fibers
• Arranged obliquely to their tendons in a manner
  similar to a feather
• Reduces mechanical efficiency of each fiber
• Increases overall number of fibers packed into
  muscle
• Overall effect more crossbridges more force!

62
Fiber Arrangement - Pennate

• Categorized based upon the exact arrangement
  between fibers tendon
• Unipennate
• Bipennate
• Multipennate

Modified from Van De Graaff KM Human anatomy, ed
6, Dubuque, IA, 2002, McGraw-Hill.
63
Fiber Arrangement - Pennate

• Unipennate muscles
• Fibers run obliquely from a tendon on one side
  only
• Ex Biceps femoris, extensor digitorum longus,
  tibialis posterior

64
Fiber Arrangement - Pennate

• Bipennate muscle
• Fibers run obliquely on both sides from a central
  tendon
• Ex Rectus femoris, flexor hallucis longus

65
Fiber Arrangement - Pennate

• Multipennate muscles
• Have several tendons with fibers running
  diagonally between them
• Ex Deltoid
• Bipennate unipennate produce more force than
  multipennate

66
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

67
Muscle Actions Terminology

• Origin (Proximal Attachment)
• Structurally, the proximal attachment of a muscle
  or the part that attaches closest to the midline
  or center of the body
• Functionally historically, the least movable
  part or attachment of the muscle
• Note The least movable may not necessarily be
  the proximal attachment

68
Muscle Actions Terminology

• Insertion (Distal Attachment)
• Structurally, the distal attachment or the part
  that attaches farthest from the midline or center
  of the body
• Functionally historically, the most movable
  part is generally considered the insertion

69
Muscle Actions Terminology

• When a particular muscle is activated
• It tends to pull both ends toward the center
• Actual movement is towards more stable attachment
• Examples
• Bicep curl vs. chin-up
• Hip extension vs. RDL

70
Muscle Actions

• Action - when tension is developed in a muscle as
  a result of a stimulus
• Muscle contraction term is exclusive in nature
• As a result, it has become increasingly common to
  refer to the various types of muscle contractions
  as muscle actions instead

71
Muscle Actions

• Muscle actions can be used to cause, control, or
  prevent joint movement or
• To initiate or accelerate movement of a body
  segment
• To slow down or decelerate movement of a body
  segment
• To prevent movement of a body segment by external
  forces

72
Types of Muscle Actions

• Muscle action (under tension)
• Isometric
• Isotonic
• Concentric
• Eccentric

73
Types of Muscle Actions

• Isometric action
• Tension is developed within muscle but joint
  angles remain constant
• AKA Static movement
• May be used to prevent a body segment from being
  moved by external forces
• Internal torque external torque

74
Types of Muscle Actions

• Isotonic (same tension) contractions involve
  muscle developing tension to either cause or
  control joint movement
• AKA Dynamic movement
• Isotonic contractions are either concentric
  (shortening) or eccentric (lengthening)

75
Types of Muscle Actions

• Concentric contractions involve muscle developing
  tension as it shortens
• Internal torque gt external torque
• Causes movement against gravity or other
  resistance
• Described as being a positive action
• Eccentric contractions involve the muscle
  lengthening under tension
• External torque gt internal torque
• Controls movement caused by gravity or other
  resistance
• Described as being a negative action

76
What is the role of the elbow extensors in each
phase?
Modified from Shier D, Butler J, Lewis R Holes
human anatomy physiology, ed 9, Dubuque, IA,
2002, McGraw-Hill
77
Types of Muscle Actions

• Movement may occur at any given joint without any
  muscle contraction whatsoever
• referred to as passive
• solely due to external forces such as those
  applied by another person, object, or resistance
  or the force of gravity in the presence of muscle
  relaxation

78
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

79
Role of Muscles

• Agonist muscles
• The activated muscle group during concentric or
  eccentric phases of movement
• Known as primary or prime movers, or muscles most
  involved

80
Role of Muscles

• Antagonist muscles
• Located on opposite side of joint from agonist
• Have the opposite concentric action
• Also known as contralateral muscles
• Work in cooperation with agonist muscles by
  relaxing allowing movement
• Reciprocal Inhibition

81
(No Transcript)
82
Role of Muscles

• Stabilizers
• Surround joint or body part
• Contract to fixate or stabilize the area to
  enable another limb or body segment to exert
  force move
• Also known as fixators

83
Role of Muscles

• Synergist
• Assist in action of agonists
• Not necessarily prime movers for the action
• Also known as guiding muscles
• Assist in refined movement rule out undesired
  motions

84
Role of Muscles

• Neutralizers
• Counteract or neutralize the action of another
  muscle to prevent undesirable movements such as
  inappropriate muscle substitutions
• Activation to resist specific actions of other
  muscles

85
Outline

• Introduction
• Structure and Function
• Fiber Arrangement
• Muscle Actions
• Role of Muscles
• Neural Control
• Factors that Affect Muscle Tension

86
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

87
Number Coding Rate Coding

• Difference between lifting a minimal vs. maximal
  resistance is the number of muscle fibers
  recruited (crossbridges)
• The number of muscle fibers recruited may be
  increased by
• Activating those motor units containing a greater
  number of muscle fibers (Number Coding)
• Activating more motor units (Number Coding)
• Increasing the frequency of motor unit activation
  (Rate Coding)

88
Number Coding Rate Coding

• Number of muscle fibers per motor unit varies
  significantly
• From less than 10 in muscles requiring precise
  and detailed such as muscles of the eye
• To as many as a few thousand in large muscles
  that perform less complex activities such as the
  quadriceps and gastrocnemius

89
Number Coding Rate Coding

• Greater contraction forces may also be achieved
  by increasing the frequency or motor unit
  activation (Rate Coding)

90
All or None Principle

• Motor unit
• Single motor neuron all muscle fibers it
  innervates
• Typical muscle contraction
• The number of motor units responding (and number
  of muscle fibers contracting) within the muscle
  may vary significantly from relatively few to
  virtually all
• All of the fibers within the motor unit will fire
  when stimulated by the CNS
• All or None Principle - regardless of number,
  individual muscle fibers within a given motor
  unit will either fire contract maximally or not
  at all

91
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

92
Length - Tension Relationship

• Maximal ability of a muscle to develop tension
  exert force varies depending upon the length of
  the muscle during contraction

Passive Tension
Active Tension
93
Figure 20.2, Plowman and Smith (2002). Exercise
Physiology, Benjamin Cummings.
94
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

95
Force Velocity Relationship

• When muscle is contracting (concentrically or
  eccentrically) the rate of length change is
  significantly related to the amount of force
  potential

96
Force Velocity Relationship

• Maximum concentric velocity minimum resistance
• As load increases, concentric velocity decreases
• Eventually velocity 0 (isometric action)

97
Force Velocity Relationship

• As load increases beyond muscles ability to
  maintain an isometric contraction, the muscle
  begins eccentric action
• As load increases, eccentric velocity increases
• Eventually velocity maximum when muscle tension
  fails

98
Muscle Force Velocity Relationship

• Indirect relationship between force (load) and
  concentric velocity
• Direct relationship between force (load) and
  eccentric velocity

99
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

100
Uni Vs. Biarticular Muscles

• Uniarticular muscles
• Cross act directly only on the single joint
  that they cross
• Ex Brachialis
• Can only pull humerus ulna closer together
• Ex Gluteus Maximus
• Can only pull posterior femur and pelvis closer
  together

101
Uni Vs. Biarticular Muscles

• Biarticular muscles
• Cross act on two different joints
• May contract cause motion at either one or both
  of its joints
• Advantages over uniarticular muscles

102
Advantage 1

• Can cause and/or control motion at more than one
  joint
• Rectus femoris Knee extension, hip flexion
• Hamstrings Knee flexion, hip extension

103
Advantage 2

• Can maintain a relatively constant length due to
  "shortening" at one joint and "lengthening" at
  another joint (Quasi-isometric)
• - Recall the Length-Tension Relationship

104
Advantage 3

• Prevention of Reciprocal Inhibition
• This effect is negated with biarticular muscles
  when they move concurrently
• Concurrent movement
• Concurrent lengthening and shortening of
  muscle
• Countercurrent movement
• Both ends lengthen or shorten

105
What if the muscles of the hip/knee were
uniarticular?
Hip
Knee
Ankle
Muscles stretched/shortened to extreme lengths!
Implication?
106
Figure 20.2, Plowman and Smith (2002). Exercise
Physiology, Benjamin Cummings.
107
Quasi-isometric action? Implication?
Hip
Knee
Ankle
108
Active Passive Insufficiency

• Countercurrent muscle actions can reduce the
  effectiveness of the muscle
• As muscle shortens its ability to exert force
  diminishes
• Active insufficiency Diminished crossbridges
• As muscle lengthens its ability to move through
  ROM or generate tension diminishes
• Passively insufficiency Diminished crossbridges
  and excessive passive tension

109
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

110
Cross-Sectional Area

• Hypertrophy vs. hyperplasia
• Increased of myofilaments
• Increased size and of myofibrils
• Increased size of muscle fibers

http//estb.msn.com/i/6B/917B20A6BE353420124115B1A
111
Factors That Affect Muscle Tension

• Number Coding and Rate Coding
• Length-Tension Relationship
• Force-Velocity Relationship
• Uniarticular vs. Biarticular Muscles
• Cross-sectional Diameter
• Muscle Fiber Type

112
Muscle Fiber Characteristics

• Three basic types
• 1. Type I
• -Slow twitch, oxidative, red
• 2. Type IIb
• -Fast twitch, glycolytic, white
• 3. Type IIa
• -FOG
