CS252 Graduate Computer Architecture Lecture 17 ECC (continued), CRC

1
CS252Graduate Computer ArchitectureLecture
17ECC (continued), CRC

• John Kubiatowicz
• Electrical Engineering and Computer Sciences
• University of California, Berkeley
• http//www.eecs.berkeley.edu/kubitron/cs252

2
Review Code Vector Space
Code Space
C0f(v0)
Code Distance (Hamming Distance)
v0

• Not every vector in the code space is valid
• Hamming Distance (d)
• Minimum number of bit flips to turn one code word
  into another
• Number of errors that we can detect (d-1)
• Number of errors that we can fix ½(d-1)

3
Review How to Generate code words?

• Consider a linear code. Need a Generator Matrix.

• Let vi be the data value (k bits), Ci be
  resulting code (n bits)
• Are there 2k unique code values?
• Only if the k columns of G are linearly
  independent!
• Of course, need some way of decoding as well.
• Is this linear??? Why or why not?
• A code is systematic if the data is directly
  encoded within the code words.
• Means Generator has form
• Can always turn non-systematiccode into a
  systematic one (row ops)

4
Implicitly Defining Codes by Check Matrix

• But what is the distance of the code? Not
  obvious
• Instead, consider a parity-check matrix H
  (n?n-k)
• Compute the following syndrome Si given code
  element Ci
• Define valid code words Ci as those that give
  Si0 (null space of H)
• Size of null space? (n-rank H)k if (n-k)
  linearly independent columns in H
• Suppose you transmit code word C, and there is an
  error. Model this as vector E which flips
  selected bits of C to get R (received)
• Consider what happens when we multiply by H
• What is distance of code?
• Code has distance d if no sum of d-1 or less
  columns yields 0
• I.e. No error vectors, E, of weight lt d have zero
  syndromes
• Code design Design H matrix with these
  properties

5
How to relate G and H (Binary Codes)

• Defining H makes it easy to understand distance
  of code, but hard to generate code (H defines
  code implicitly!)
• However, let H be of following form
• Then, G can be of following form (maximal code
  size)
• Notice G generates values in null-space of H

6
Simple example (Parity, D2)

• Parity code (8-bits)
• Note Complexity of logic depends on number of 1s
  in row!

7
Simple example Repetition (voting, D3)

• Repetition code (1-bit)
• Positives simple
• Negatives
• Expensive only 33 of code word is data
• Not packed in Hamming-bound sense (only D3).
  Could get much more efficient coding by encoding
  multiple bits at a time

8
Simple Example Hamming Code (d3)

• Example (7,4) code
• Protect 4 data bits with 3 parity bits
• 1 2 3 4 5 6 7
• p1 p2 d1 p3 d2 d3 d4
• Bit position number
• 001 110
• 011 310
• 101 510
• 111 710
• 010 210
• 011 310
• 110 610
• 111 710
• 100 410
• 101 510
• 110 610
• 111 710

9
How to correct errors?

• But what is the distance of the code? Not
  obvious
• Instead, consider a parity-check matrix H
  (n?n-k)
• Compute the following syndrome Si given code
  element Ci
• Suppose that two correctable error vectors E1 and
  E2 produce same syndrome
• But, since both E1 and E2 have ? (d-1)/2 bits,
  E1 E2 ? d-1 bits set this cannot be true!
• So, syndrome is unique indicator of correctable
  error vectors

10
Example, d4 code (SEC-DED)

• Design H with
• All columns non-zero, odd-weight, distinct
• Note that odd-weight refers to Hamming Weight,
  i.e. number of zeros
• Why does this generate d4?
• Any single bit error will generate a distinct,
  non-zero value
• Any double error will generate a distinct,
  non-zero value
• Why? Add together two distinct columns, get
  distinct result
• Any triple error will generate a non-zero value
• Why? Add together three odd-weight values, get an
  odd-weight value
• So need four errors before indistinguishable
  from code word
• Because d4
• Can correct 1 error (Single Error Correction,
  i.e. SEC)
• Can detect 2 errors (Double Error Detection, i.e.
  DED)
• Example
• Note log size of nullspace will be (columns
  rank) 4, so
• Rank 4, since rows independent, 4 cols indpt
• Clearly, 8 bits in code word
• Thus (8,4) code

11
Tweeks

• No reason cannot make code shorter than required
• Suppose n-k8 bits of parity. What is max code
  size (n) for d4?
• Maximum number of unique, odd-weight columns 27
  128
• So, n 128. But, then k n (n k) 120.
  Weird!
• Just throw out columns of high weight and make
  72, 64 code!
• But shortened codes like this might have d gt 4
  in some special directions
• Example Kaneda paper, catches failures of groups
  of 4 bits
• Good for catching chip failures when DRAM has
  groups of 4 bits
• What about EVENODD code?
• Can be used to handle two erasures
• What about two dead DRAMs? Yes, if you can
  really know they are dead

12
(No Transcript)
13
Galois Field

• Definition Field a complete group of elements
  with
• Addition, subtraction, multiplication, division
• Completely closed under these operations
• Every element has an additive inverse
• Every element except zero has a multiplicative
  inverse
• Examples
• Real numbers
• Binary, called GF(2) ? Galois Field with base 2
• Values 0, 1. Addition/subtraction use xor.
  Multiplicative inverse of 1 is 1
• Prime field, GF(p) ? Galois Field with base p
• Values 0 p-1
• Addition/subtraction/multiplication modulo p
• Multiplicative Inverse every value except 0 has
  inverse
• Example GF(5) 1?1 ? 1 mod 5, 2?3 ? 1mod 5, 4?4
  ? 1 mod 5
• General Galois Field GF(pm) ? base p (prime!),
  dimension m
• Values are vectors of elements of GF(p) of
  dimension m
• Add/subtract vector addition/subtraction
• Multiply/divide more complex
• Just like read numbers but finite!

14
Specific Example Galois Fields GF(2n)

• Consider polynomials whose coefficients come from
  GF(2).
• Each term of the form xn is either present or
  absent.
• Examples 0, 1, x, x2, and x7 x6 1
• 1x7 1 x6 0 x5 0 x4 0 x3 0
  x2 0 x1 1 x0
• With addition and multiplication these form a
  field
• Add XOR each element individually with no
  carry
• x4 x3 x 1
• x4 x2 x
• x3 x2 1
• Multiply multiplying by x is like shifting to
  the left.
• x2 x 1
• ? x 1
• x2 x 1
• x3 x2 x
• x3 1

15
So what about division (mod)
x4 x2
x3 x with remainder 0
x
x4 x2 1
x3 x2 with remainder 1
X 1
x3
x2
0x
0
x4 0x3 x2 0x 1
X 1
x3 x2
x3 x2
0x2 0x
0x 1
Remainder 1
16
Producing Galois Fields

• These polynomials form a Galois (finite) field if
  we take the results of this multiplication modulo
  a prime polynomial p(x).
• A prime polynomial is one that cannot be written
  as the product of two non-trivial polynomials
  q(x)r(x)
• Perform modulo operation by subtracting a
  (polynomial) multiple of p(x) from the result.
  If the multiple is 1, this corresponds to XOR-ing
  the result with p(x).
• For any degree, there exists at least one prime
  polynomial.
• With it we can form GF(2n)

• Additionally,
• Every Galois field has a primitive element, ?,
  such that all non-zero elements of the field can
  be expressed as a power of ?. By raising ? to
  powers (modulo p(x)), all non-zero field elements
  can be formed.
• Certain choices of p(x) make the simple
  polynomial x the primitive element. These
  polynomials are called primitive, and one exists
  for every degree.
• For example, x4 x 1 is primitive. So ? x
  is a primitive element and successive powers of ?
  will generate all non-zero elements of GF(16).
  Example on next slide.

17
Galois Fields Primitives

• ?0 1
• ?1 x
• ?2 x2
• ?3 x3
• ?4 x 1
• ?5 x2 x
• ?6 x3 x2
• ?7 x3 x 1
• ?8 x2 1
• ?9 x3 x
• ?10 x2 x 1
• ?11 x3 x2 x
• ?12 x3 x2 x 1
• ?13 x3 x2 1
• ?14 x3 1
• ?15 1

• Note this pattern of coefficients matches the
  bits from our 4-bit LFSR example.
• In general finding primitive polynomials is
  difficult. Most people just look them up in a
  table, such as

?4 x4 mod x4 x 1 x4 xor x4 x 1
x 1
18
Primitive Polynomials

• x2 x 1
• x3 x 1
• x4 x 1
• x5 x2 1
• x6 x 1
• x7 x3 1
• x8 x4 x3 x2 1
• x9 x4 1
• x10 x3 1
• x11 x2 1

x12 x6 x4 x 1 x13 x4 x3 x 1 x14
x10 x6 x 1 x15 x 1 x16 x12 x3 x
1 x17 x3 1 x18 x7 1 x19 x5 x2 x
1 x20 x3 1 x21 x2 1
x22 x 1 x23 x5 1 x24 x7 x2 x 1 x25
x3 1 x26 x6 x2 x 1 x27 x5 x2 x
1 x28 x3 1 x29 x 1 x30 x6 x4 x
1 x31 x3 1 x32 x7 x6 x2 1
Galois Field Hardware Multiplicat
ion by x ? shift left Taking the result
mod p(x) ? XOR-ing with the coefficients of
p(x) when the most significant coefficient
is 1. Obtaining all 2n-1 non-zero ? Shifting and
XOR-ing 2n-1 times. elements by evaluating xk for
k 1, , 2n-1
19
Building an LFSR from a Primitive Poly(Cycle
through all non-zero values)

• For k-bit LFSR number the flip-flops with FF1 on
  the right.
• The feedback path comes from the Q output of the
  leftmost FF.
• Find the primitive polynomial of the form xk
  1.
• The x0 1 term corresponds to connecting the
  feedback directly to the D input of FF 1.
• Each term of the form xn corresponds to
  connecting an xor between FF n and n1.
• 4-bit example, uses x4 x 1
• x4 ? FF4s Q output
• x ? xor between FF1 and FF2
• 1 ? FF1s D input
• To build an 8-bit LFSR, use the primitive
  polynomial x8 x4 x3 x2 1 and connect xors
  between FF2 and FF3, FF3 and FF4, and FF4 and FF5.

20
Reed-Solomon Codes

• Galois field codes code words consist of symbols
• Rather than bits
• Reed-Solomon codes
• Based on polynomials in GF(2k) (I.e. k-bit
  symbols)
• Data as coefficients, code space as values of
  polynomial
• P(x)a0a1x1 ak-1xk-1
• Coded P(0),P(1),P(2).,P(n-1)
• Can recover polynomial as long as get any k of n
• Properties can choose number of check symbols
• Reed-Solomon codes are maximum distance
  separable (MDS)
• Can add d symbols for distance d1 code
• Often used in erasure code mode as long as no
  more than n-k coded symbols erased, can recover
  data
• Side note Multiplication by constant in GF(2k)
  can be represented by k?k matrix a?x
• Decompose unknown vector into k bits
  xx02x12k-1xk-1
• Each column is result of multiplying a by 2i

21
Reed-Solomon Codes (cont)

• Reed-solomon codes (Non-systematic)
• Data as coefficients, code space as values of
  polynomial
• P(x)a0a1x1 a6x6
• Coded P(0),P(1),P(2).,P(6)
• Called Vandermonde Matrix maximum rank
• Different representation(This H and G not
  related)
• Clear that all combinations oftwo or less
  columns independent ? d3
• Very easy to pick whatever d you happen to want
  add more rows
• Fast, Systematic version of Reed-Solomon
• Cauchy Reed-Solomon, others

22
Another Example Redundant Check

• Send a message M and a check word C
• Simple function on ltM,Cgt to determine if both
  received correctly (with high probability)
• Example XOR all the bytes in M and append the
  checksum byte, C, at the end
• Receiver XORs ltM,Cgt
• What should result be?
• What errors are caught?

bit i is XOR of ith bit of each byte
23
Example TCP Checksum
TCP Packet Format
Application (HTTP,FTP, DNS)
7
Transport (TCP, UDP)
4
Network (IP)
3
Data Link (Ethernet, 802.11b)
2

• TCP Checksum a 16-bit checksum, consisting of
  the one's complement of the one's complement sum
  of the contents of the TCP segment header and
  data, is computed by a sender, and included in a
  segment transmission. (note end-around carry)
• Summing all the words, including the checksum
  word, should yield zero

Physical
1
24
Example Ethernet CRC-32
Application (HTTP,FTP, DNS)
7
Transport (TCP, UDP)
4
Network (IP)
3
Data Link (Ethernet, 802.11b)
2
Physical
1
25
CRC concept

• I have a msg polynomial M(x) of degree m
• We both have a generator poly G(x) of degree n
• Let r(x) remainder of M(x) xn / G(x)
• M(x) xn G(x)p(x) r(x)
• r(x) is of degree n
• What is (M(x) xn r(x)) / G(x) ?
• So I send you M(x) xn r(x)
• mn degree polynomial
• You divide by G(x) to check
• M(x) is just the m most signficant coefficients,
  r(x) the lower n
• x-bit Message is viewed as coefficients of
  x-degree polynomial over binary numbers

26
Polynomial division
0 0 0 0
1
0
1
1 0 0 1 1
1 0 1 1 0 0 1 0 0 0 0
1 0 0 1 1

• When MSB is zero, just shift left, bringing in
  next bit
• When MSB is 1, XOR with divisor and shift eft

0 0 1 0 1
0 1 0 1 0
1 0 1 0 1
1 0 0 1 1
0 0 1 0 0
27
CRC encoding
1 0 1 1 0 0 1 0 0 0 0
0 0 0 0
0 0 0 1
0 1 1 0 0 1 0 0 0 0
0 0 1 0 1 1 0 0 1
0 0 0 0
0 1 0 1 1 0 0 1 0
0 0 0
1 0 1 1 0 0 1 0
0 0 0
0 1 0 1 0 1 0 0 0
0
1 0 1 0 1 0 0
0 0
0 1 1
0 0 0 0 0
1 1 0
0 0 0 0
1 0 1
1 0 0
0 1 0
1 0
1 0 1
0
Message sent
1 0 1 1 0 0 1 1 0 1 0
28
CRC decoding
1 0 1 1 0 0 1 1 0 1 0
0 0 0 0
0 0 0 1
0 1 1 0 0 1 1 0 1 0
0 0 1 0 1 1 0 0 1
1 0 1 0
0 1 0 1 1 0 0 1 1
0 1 0
1 0 1 1 0 0 1 1
0 1 0
0 1 0 1 0 1 1 0
1 0
1 0 1 0 1 1 0
1 0
0 1 1
0 1 0 1 0
1 1 0
1 0 1 0
1 0 0
1 1 0
0 0 0
0 0
0 0 0
0
29
Generating Polynomials

• CRC-16 G(x) x16 x15 x2 1
• detects single and double bit errors
• All errors with an odd number of bits
• Burst errors of length 16 or less
• Most errors for longer bursts
• CRC-32 G(x) x32 x26 x23 x22 x16 x12
  x11 x10 x8 x7 x5 x4 x2 x 1
• Used in ethernet
• Also 32 bits of 1 added on front of the message
• Initialize the LFSR to all 1s

30
Conclusion

• ECC add redundancy to correct for errors
• (n,k,d) ? n code bits, k data bits, distance d
• Linear codes code vectors computed by linear
  transformation
• Erasure code after identifying erasures, can
  correct
• Reed-Solomon codes
• Based on GF(pn), often GF(2n)
• Easy to get distance d1 code with d extra
  symbols
• Often used in erasure mode
• Redundancy useful to gain reliability
• Redundant diskscontrollersetc (RAID)
• Geographical scale systems (OceanStore)
• Disk technology
• Two innovations GMR, Vertical recording
• Disk Latency Queuing Time Seek Time
  Rotation Time Xfer Time Ctrl Time
