Interface Gold Standard Calibration System

1
Interface Gold Standard Calibration System
2

INTERFACE

• Developed in 1989, Interface, Inc. began to
  market the Gold Standard System in 1991. It is
  now used in more than 250 labs throughout the
  world.

3
Gold StandardTM Load Cell Calibration System
INTERFACE

• One 9840 2 Channel Indicator for Load Cell
  Exitation/ Signal Conditioning
• One ICS-202 Force Calibration Software
• One SIS-103 One-Day Training at Interface
• One CT-139-10 SCB1 to GS Load Cell Cable
• One CT-142-10 SCB1 to Standard Load Cell Cable
• One CX-0440 mV/V Transfer Standard
• One SIS-104 System Setup

4
Interface Gold StandardTM Calibration Systems
INTERFACE

• Controlled calibration process reduces
  calibration times by 50 to 90 and produces
  consistent calibration results
• Easy-to-use software reduces operator training
  time
• Fully integrated reporting functions
• Automatic archiving of calibration results
• Supports ASTM E74, ASTM E4 and ISO 7500/1,
  EH10002
• Industry Accepted terms and calculations
• 0.1µV display resolution
• Used in over 250 calibration labs world-wide

5
Gold StandardTM Calibration System Options
INTERFACE

• GS-USB Provides USB interface for HRBSC, SCB1,
  DA-101 and HL4IO instrument boards includes
  internal power supply, cooling fan and USB cable.
• SCB1 20 bit instrument board provides signal
  conditioning for the Gold StandardTM System.
  Available in single or dual channel versions.
• HRBSC High-resolution 22 bit instrument board
  increases accuracy over the SCB1.
• DA-101 Digital to analog board for generating
  command signal for system control. Provides
  setpoint signal for servo controlled hydraulic
  force testing.
• HL4IO High level 4-channel input board allows
  calibration of 5 and 10 VDC output transducers
  and includes all features of the DA-101.
• Load Cell Simulator mV/V transfer standards are
  used to calibrate the Gold StandardTM system, and
  for setting up and testing load cell readout
  devices. CX-0404 - specifically designed for
  instrument substitution testing as per ASTM E74.
• Desktop, laptop or portable PC Contact factory
  for currently available configurations.
• Gold StandardTM or Platinum StandardTM load cells
  as required.

6
1600 Gold StandardTM Calibration Load Cell
INTERFACE

• Tension and compression in one unit
• .005 nonrepeatability
• .01 creep
• High output - to 4mV/V
• High precision base installed
• 3 run NIST traceable calibration
• Factory installed calibration adapter
• Eccentric load compensated
• .0008/F temp. effect on output
• 4 lower load limit per ASTM E74

7
1600 Gold StandardTM Calibration Compression Only
Load Cell
INTERFACE

• .005 nonrepeatability
• .01 creep
• High output - to 4mV/V
• High precision base installed
• 3 run NIST traceable calibration
• Eccentric load compensated
• .0008/F temp. effect on output
• 4 lower load limit

8
Model 1800 Platinum SeriesLow Profile Load Cells
INTERFACE

• .005 non-repeatability
• .01 Creep
• Designed to be used at 2 lower load limit
• .008 /F temp effect on output
• Eccentric load compensated

9
Model 9840 Intelligent Indicator
INTERFACE

• 24 bit internal resolution
• /-999,999 Count Bipolar Display
• Nonlinearity lt ? 0.005
• Stores calibration for up to 25 load cells
• Fast, direct analog output
• ? VDC scalable analog output
• Full duplex RS232C
• Peak/Valley hold
• Front panel and remote tare

10
Precision mV/V Load Cell Simulator
INTERFACE

• Most accurate load cell simulator.
• Special low thermal
• emf construction.
• Each unit individually calibrated,
• aged and recalibrated.
• Strong, rugged design.
• Instrument substitution testing.
• MDL CX-0404 is specifically designed for
  instrument substitution testing as per ASTM E74.

11
Why use a simulator or mV/V Standard ?

• Calibrate Indicator or Signal Conditioner
  periodically
• Daily sanity check on measurements
• Establish true
• zero
• Check cables

11
12
Model CX Standard

• 6 digit calibration
• 10 ppm uncertainty

12
13
Shunt Calibration

• Technique of unbalancing bridge with external
  shunt resistor
• Less Expensive
• OK for medium-accuracy work
• Affected by preload, temperature, bridge
  resistance drift, cable length

13
14
Transducer Calibration Procedures
14
15
Machine Calibration Procedures
15
16
Measurement Uncertainty Model, Calibrating Load
Cell by Comparison
16
17
Uncertainty Components

• CNS Cal of Standard Transducer by NIST
• DS Drift in Standard since last cal
• PS Creep in Standard Transducer
• TS Temperature effect on output of Standard
• RHF Nonreproducibility of frame, load string
• CH Calibration of HRBSC Instrument
• DH Drift in HRBSC since last cal
• TH Temperature effect on HRBSC Instrument
• LH Nonlinearity of HRBSC Instrument
• NH Noise of HRBSC Instrument

17
18
CH Uncertainty in calibration of HRBSC

•   (rectangular
  distribution)
•  Source of Uncertainty Type
  Uncertainty (RDG)






• CCX Calibration of CX-0610 B
  0.0008
• DCX Drift in transfer function of
• CX-0610 between calibrations B
  0.0010
• TCX Temperature effect on
• CX-0610
  B 0.0054
• NCX Noise of the HRBSC
• instrument during calibration
• with the CX-0610 B
  0.0003
•
  ------------
• Combined (Root Sum of Squares)
  0.0056

18
19
Uncertainty Budget Example
19
20
Dominant Uncertainty Components

• Nonreproducibility of load frame, threads,
  adaptors, alignment
• Calibration of Standard at low end of range
• Drift in Standard since last cal

20
21
Load Cell Calibration System Software - Opening
Screen
INTERFACE
22
INTERFACE
DUT Description
23
Setpoint Entry
INTERFACE
24
Setpoint File Selection
INTERFACE
25
Exercise Load Cells
INTERFACE
26
Begin Calibration
INTERFACE
27
Calibration
INTERFACE
28
Completed Calibration
INTERFACE
29
Error Plot
INTERFACE
30
Curve Fit
INTERFACE
31
Load Cell History
INTERFACE
32
INTERFACE
INTERFACE
33
Report Designer
INTERFACE
34
Custom Report
INTERFACE
35
Gold StandardTM E4 Machine Calibration System
INTERFACE

• 9840-100-1 Intelligent Indicator
• One ICS-205 E4 Machine Calibration Software
• One CT-177-10 Gold Standardtm Interconnect Cable
  Assemby
• Serial Cable, Laptop to 9840
• One CX-0440 4mV/V Transfer Standard
• One SIS-104 System Setup
• Training at Interface

36
Features of the Portable E4 Machine
Calibration Software
INTERFACE

• Capable of providing the user with printed
  copies of
• E4-02 Test Machine Verification Report.
• ISO 7500/1 Test Machine Verification Report.

37
Portable E4 System Software Opening Screen
INTERFACE
38
Setpoint Entry
INTERFACE
39
Setpoint File Selection
INTERFACE
40
Meter Configuration
INTERFACE
41
Machine Details
INTERFACE
42
Load Point Entry
INTERFACE
43
Load Point Entry
INTERFACE
44
Begin Verification
INTERFACE
45
Data Collection
INTERFACE
46
Completed Verification
INTERFACE
47
E4 Report
INTERFACE
48
Verification History
INTERFACE
49
ISO 7500-1 Report
INTERFACE
50
ISO 7500-1
INTERFACE
51
Report Designer
INTERFACE
52
Custom E4 Report
INTERFACE
53
Custom ISO Report
INTERFACE
